Devine USB-100 User manual

USB 100
USB dynamic studio microphone
User manual
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 10-12-2015 RV Revision date + author initials: -

Introduction
Thank you for purchasing the Devine USB 100 studio microphone. This studio microphone can be connected
directly to a computer thanks to the built-in USB audio interface and the supplied USB cable.
The Devine USB 100 is a versatile USB studio microphone ith a stylish, vintage look. It is the ideal
Rockabilly-recording microphone thanks to its vintage-style combined ith modern technology.
For optimal performance, connect the USB 100 to a computer. After the correct drivers are automatically
installed, the USB 100 ill be ready for use. It can be used as a microphone for Skype, for example, as ell
as for podcasting, broadcasting and vocal recording.
If you ish to use the USB 100 for recording applications, you'll need to install soft are to do so. Devine
recommends the free soft are Audacity.
The USB 100 performs best hen placed on a microphone stand. This ay, you can use the microphone in a
seated or standing position. The base of the microphone is equipped ith a 5/8” thread, but a thread adapter
to 3/8” is included if your microphone stand requires it.
The super-cardioid polar pattern of the USB 100 is so that it picks up most of the sound directly in front of the
microphone and a little from the rear. For optimal sound quality, position the vocalist or musician as close to
the microphone as possible, approx. 2-3 centimetres, and make sure they sing/speak/play directly into the
front of the microphone.
Please note that the USB 100 microphone is a sensitive microphone and should be handled ith care hen
transported or installed. Impacts and/or severe vibrations may have a negative impact on the lifespan and
performance of the microphone. This microphone is not designed for on-the-road use.
Before you unpack all the received items, carefully read this manual to familiarise yourself ith the functions
of the microphone. Also, check the contents of the box to make sure all necessary parts are included (see
the section Box contents in this user manual). If the microphone fails to operate properly, or if you
encounter any problems hile using it, disconnect it immediately and contact your local dealer for more
information and help.
WEEE: Dispose of this product properly. This product is part of the WEEE directive – the
Waste Electrical and Electronic Equipment directive. The requirements stated in this directive
apply to all manufacturers and producers of electronic equipment in the EU.
Do not dispose of this product together ith regular household rubbish. Contact your local
government representative for more information about proper disposal and recycling of
electronic products in your region. By recycling this product properly after use, e can ork
together to enjoy these products and protect our environment from pollution.
CE: The CE mark indicates that the product complies ith applicable European directives and
regulations.
Indoor use only: This device is designed to be used indoors only. The maximum ambient
temperature should not exceed 40 degrees Celsius (104 degrees Fahrenheit)
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 10-12-2015 RV Revision date + author initials: -

Box contents
Box contents:
1x Devine USB 100 studio microphone
1x thread adapter from 5/8” outer thread to 3/8” inner thread
1x USB A – USB B cable, +/- 1.7 m length
Unit and accessory inspection:
- If you do not plan to use the unit for an extended period of time, disconnect it and store it in a dust-free
environment.
- Al ays check the unit for possible damage before use. If you suspect that something is rong ith the unit,
do not connect it! If you suspect that your unit is broken or damaged, contact your local dealer or a certified
technician to inspect the unit.
Contact:
Devine pro audio and studio products
Verrijn Stuart eg 18
4462 GE Goes
The NetherlandsPlease do not send any products directly to this address. If you wish to return a product for
a refund or repair, please contact your local dealer for an RMA (Return Material Authorisation)
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 10-12-2015 RV Revision date + author initials: -

Using the microphone
The Devine USB 100 studio microphone is suitable for various studio recording applications. It is designed
for vocal recording, but can be used for instrument recording as ell. It has a super-cardioid polar pattern,
hich means it captures most sound directly from the front of the microphone and a little from the rear.
Setting up the microphone
Make sure that the USB 100 is placed on a suitable stand. This
can be a small desktop stand, as ell as a large vertical or boom
arm microphone stand. A thread adapter is included to ensure that
the Devine USB 100 can be connected to nearly any microphone
stand (3+4).
Make sure that the microphone is positioned as closely to the
sound source as possible. To ensure optimal sound quality,
the vocalist or musician needs to speak/sing/play directly into the
front of the microphone. This ensures that the recording or live
streaming takes place at an optimal volume, ithout the addition
of extra boost or gain ( hich can cause un anted noise).
Connecting to the computer
The USB 100 can be connected to any Windo s or Apple
computer, desktop model or laptop. A soft are CD is not required
to install the soft are on your computer.
Al ays use the included cable to connect the microphone to your
computer. The square connector on one end fits perfectly in the
base of the microphone (1+2), and the other end fits into a free
USB port on your computer.
If your computer is turned on and has finished its start-up
procedure, connect the USB 100. When connected, a bright blue
LED ill turn on, indicating that there is USB po er.
The computer should no recognize the USB 100 as a USB
microphone and can use it for various applications. If your
computer does not recognize the microphone or the required
drivers are not installed:
- ensure that your computer is connected to the internet to
automatically do nload the required drivers
- (for Windo s) try a different driver, for example ASIO4ALL .asio4all.com (free do nload).
- (for Mac) Mac computers are usually equipped ith Core Audio API handling for audio hich ill take care
of the installation process
Using the microphone for live roadcasting or recording
As stated earlier in this user manual, the sound source needs to be placed as closely to the microphone as
possible to ensure optimal audio quality. Placing the microphone further a ay from the source ill result in
lo -volume recording or amplification, hich ould need to be artificially boosted. This ill also boost the lo
self-noise of the microphone itself ho ever ( hich is present on all microphones). If you ensure that the
source volume is good, un anted noise as a result of artificial boost ill be kept to a minimum.
Most live broadcasting and/or podcasting soft are can only influence volume. Ensure that peaks in sound
are not present to prevent distortion. When using recording soft are, start recording a track and test it to
make sure the signal isn't too lo or too high. Reduce the microphone volume and/or gain if needed.
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 10-12-2015 RV Revision date + author initials: -

Protecting the microphone:
This Devine microphone is equipped ith very sensitive electronics hich provide optimal audio
performance. Make sure the microphone is not exposed to situations that may cause permanent damage as
a result of severe impacts, collisions, or falls from high altitudes. Improper use of the microphone is not
covered by arranty. Al ays transport the microphone in the original packaging, or in a flight case ith
proper fitted foam inlay. This microphone is not intended for on-the-road use.
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 10-12-2015 RV Revision date + author initials: -

Trou leshooting
Pro lem Possi le Cause Solution
No sound, or very lo sound
signal
USB cable not connected
(properly)
Connect the USB cable to your
computer / make sure the cable is
connected properly
Volume set too lo Increase input volume and gain on
your mixer, interface or other
sound processing device
Microphone positioned too far
a ay
Place the microphone closer to the
sound source
Rattling and cracking sounds Moisture inside the microphone Allo the microphone to dry in
room temperature. Avoid use of
the microphone in humid or moist
environments. Do not let the
microphone come in contact ith
ater or liquids.
Loud, high frequencies coming
from the speakers
Microphone is positioned too close
to the speakers, hich is causing
feedback
Move the microphone further a ay
from the speakers, or change the
position to prevent the microphone
from being aimed directly at the
speakers.
Microphone signal is interrupted Loose or broken USB cable Check if the USB cable is plugged
into the microphone correctly. If
that does not solve the problem,
try replacing the cable.
Distortion and/or noise in the
captured sound
Too much airflo caused by vocals Use a pop filter or indshield (sold
separately)
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 10-12-2015 RV Revision date + author initials: -

Technical specifications
- orks ith all types of recording soft are or DAW (e.g. Audacity)
- compatible ith Windo s2000/XP/Vista or later and Mac OS X
- studio USB microphone
- ideal for recording individual instruments, vocals and speech
- orks on Windo s and Mac computers
- installs drivers automatically
- utilises a high-quality condenser capsule
- dynamic microphone capsule
- polar pattern: super-cardioid (super-directional)
- connection: USB Plug-and-Play (USB A - USB B)
- sampling and bit-rate: 16 bits / 48 kHz
- frequency response: 50 Hz - 16 kHz
- sensitivity: -54 dB (+/- 3 dB) (0 dB = 1 V/Pa @ 1 kHz)
- output impedance: 250 ohms +/- 30% (@ 1 kHz)
- dimensions: 68 x 56 x 190 mm
- eight: 470 g
Included accessories:
1x thread adapter from 5/8” outer to 3/8” inner thread
1x USB A – USB B cable, +/- 1.7 metres long
Frequency response and polar pattern graph:
