Devine SM-100 User manual

Devine SM-100
Instrument Condenser Microphone
User manual
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 27-01-2014 DK Revision date + author initials: 27-01-2014 DK

Introduction
Thank you for purchasing this Devine SM-100 Instrument Condenser Microphone. Before you unpack a the
received items, carefu y read this manua to become fami iar with the functions of the microphone. A so
check the contents of the box to make sure a necessary parts are inc uded. If any parts are missing, or if the
microphone fai s to operate proper y, or if you have any prob ems whi e using it, disconnect it from phantom
power supp y and contact your oca dea er for more information and he p.
Box contents:
- 1 Devine SM-100 microphone
- 1 Microphone c ip
- 1 Windshie d
- 1 Leather- ook bag
Unit and accessory inspection
- If the unit is not going to be used for a onger period of time, disconnect it from its source and store it in a
dust-free environment.
- A ways check the unit for possib e damage before use. If you suspect that something is wrong with the unit,
do not connect it. When you suspect that your unit is broken or damaged, contact your oca dea er or a
certified technician to inspect the unit.
Note: Illustrations shown in this manual may vary from the actual product.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 27-01-2014 DK Revision date + author initials: 27-01-2014 DK

Description
The Devine SM-100 is an instrument condenser microphone for recording app ications. The SM-100 adopts
a 16 mm high qua ity capsu e and a high qua ity e ectric circuit. It has a high sensitivity and ow se f noise, a
(cardioid) Uni-directiona po ar pattern and a 3-pin XLR output connector for perfect signa transmission. The
SM-100 can be wide y used for recording acoustic instruments, overheads, piano, orchestra sound, etc.
IMP RTANT: Phantom power
This instrument condenser microphone requires +48V phantom power from a PA-mixer, studio-mixer, audio-
interface or phantom power supp y. Consu t the manua of your equipment or contact your oca dea er when
in doubt if your equipment is capab e of providing a +48V vo tage.
This microphone wi not work proper y when there is no proper +48V vo tage activated. A ways check this if
you suspect that your microphone might be damaged or broken.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 27-01-2014 DK Revision date + author initials: 27-01-2014 DK

Usage
1. Turn on your amp ifier or mixing board and set the vo ume contro to minimum position to connect the
phantom power to the microphone.
2. Whi e turning on the phantom switch, accommodate the vo ume contro from ow to high unti your
preferred eve is reached.
3. If the head of the microphone is covered by hand or brought c ose to the speaker, a how ing sound may be
generated. To prevent this, first decrease the vo ume and then p ace the microphone in such a manner that it
is not pointed towards the speaker. A so, p ease make sure there is a sufficient distance between the
microphone and speaker.
4. P ease note that the components of this microphone have a very fine sensitivity. Do not drop, hit or app y a
strong shock to it.
5. To maintain the sensitivity and qua ity of sound reproducing, avoid exposing the microphone to moisture
and extreme temperatures.
Troubleshooting
Problem Possible Cause Solution
No sound, or very ow sound
signa
No phantom power Connect or activate phantom
power supp y
Vo ume set too ow Increase incoming vo ume and
gain on your mixer, interface or
other sound processing device
Microphone positioned too far
away
P ace the microphone c oser to the
sound source
Ratt ing and cracking sounds Moist inside the microphone Let the microphone dry on room
temperature and avoid use of the
microphone in humid or moist
environments. Do not et the
microphone come in contact with
water or iquids.
Loud high frequencies coming
from the speakers
Microphone positioned too c ose to
the speakers, which causes
feedback
Move the microphone further away
from the speakers, or change the
position to prevent the microphone
to be aimed direct y at the
speakers.
Interruptance of the microphone
signa
Loose cab e or broken cab e Check if the cab e is p ugged into
the microphone correct y. If that
does not so ve the prob em, try to
change the cab e.
Distortion and/or noise in the
captured sound
Too much airf ow caused by voca
airf ows
Use a pop fi ter (so d separate y)
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 27-01-2014 DK Revision date + author initials: 27-01-2014 DK

Technical specifications
Sma condenser microphone
Perfect for recording acoustic instruments, overheads, piano, etc.
E ement: 16 mm condenser capsu e
Po ar Pattern: Uni-directiona
Freqeuncy Response: 30 Hz-18 kHz
Sensitivity: -38±3dB (0dB=1V/Pa at 1KHz)
Output Impedance: 100Ω±30% (at 1 kHz)
Se f Noise: 24dB A
Max. input SPL: 135dB (at 1 kHz ≤1% T.H.D)
S/N Ratio: 70dB
Power requirement : 9V-52V Phantom Power
Includes:
1 Microphone c ip
1 Windshie d
1 Leather ook-bag, for safe transport and storage
