DeWalt DXPAEV016 User manual
DXPAEV016
16 Amp Portable Vehicle Charger
[ES-Product Name]
[FR-Product Name]
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
INSTRUCTION MANUAL
WARNING:
WARNING:
Read all instructions before operating
product. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
This product or its power cord contains lead, a
chemical known to the State of California to cause cancer and birth
defect or other reproductive harm. Wash hands after handling. For
more information go to www.P65Warnings.ca.gov
WARNING:
WARNING:
Read all instructions before operating
product. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
This product or its power cord contains lead, a
chemical known to the State of California to cause cancer and birth
defect or other reproductive harm. Wash hands after handling. For
more information go to www.P65Warnings.ca.gov
WARNING:
WARNING:
Read all instructions before operating
product. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
This product or its power cord contains lead, a
chemical known to the State of California to cause cancer and birth
defect or other reproductive harm. Wash hands after handling. For
more information go to www.P65Warnings.ca.gov
a properly grounded outlet.
WARNING - Grounding Instructions for
Cord-connected Product
This product must be grounded. If it should malfunction or break
down, grounding provides a path of least resistance for electric
current to reduce the risk of electric shock. This product is equipped
with a cord having an equipment grounding conductor and a
grounding plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
WARNING: Improper connection of the equipment-grounding
conductor is able to result in a risk of electric shock. Check with a
qualified electrician or serviceman if you are in doubt as to whether
the product is properly grounded. Do not modify the plug provided
with the product - if it will not fit the outlet, have a proper
NEMA 6-20 outlet installed by a qualified electrician.
h. Do not put inflammable, explosive or combustible materials,
chemicals, combustible steam or other dangerous goods near
the product.
i. The electric vehicles can only be charged with the engine off
and stationary. Do not start the engine when the charging
handle is still connected.
j. Do not touch the terminals or other current-carrying parts when
your hands are wet.
k. Do not trample or drive over the product’s cables.
l. Do not put any foreign objects into the enclosure.
m. Do not use power generators as a power source for charging
electric vehicles.
n. Do not use the product when either you, the vehicle or the
product is exposed to severe rain, snow, electrical storm or
other inclement weather.
o. Do not use or store the product in a recessed area or below the
floor level.
above the floor level.
WARNING - Specific Safety
Instructions for Cord-Connected Product
WARNING: If this product is installed outdoors, the outlet
must be rated for outdoor installation. The outlet must be installed
properly to maintain the proper NEMA rating of the enclosure.
WARNING:To reduce the risk of electric shock, connect only to
WARNING:To reduce the risk of fire, connect only to a circuit
provided with 20 amperes maximum branch circuit overcurrent
protection in accordance with the National Electrical Code, ANSI/
NFPA 70 and the Canadian Electrical Code, Part I, C22.1.
• Do not plug the product into a damaged, loose or worn outlet.
Ensure that the prongs on the plug fit snugly into the outlet.
• Do not disconnect the product from the outlet when the vehicle
is charging.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS
DEWALT EV CHARGER, CALL US TOLL FREE AT: 1-855-815-1171.
16AMP PORTABLE VEHICLE CHARGER
• The product is intended to charge electric vehicles compatible
with SAE J1772 AC Level 2 charging standard.
• The product is intended to be used in indoor and protected
outdoor areas.
• The product is intended for household use only. Not for use in
commercial garages. A COMMERCIAL GARAGE is dened as
a facility or portion of a facility, also used to house or repair
internal combustion engine vehicles, in which vapors from
ammable liquids (gasoline) are present.
IMPORTANT SAFETY
INSTRUCTIONS
INSTRUCTIONS PERTAINING TO RISK OF
FIRE OR ELECTRIC SHOCK!
Read these instructions carefully and retain them for future
use. If this product is passed to a third party, then these
instructions must be included.
WARNING: When using electric products, basic precautions
should always be followed, including the following. This manual
contains important instructions for models DXPAEV016 that
shall be followed during, operation and maintenance of the unit.
WARNING: Risk of electric shock! Do not disconnect under
load.
WARNING: This product is intended only for charging vehicles
not requiring ventilation during charging.
WARNING: Use of the product may affect or impair the
operation of any medical or implantable electronic devices, such as
an implantable cardiac pacemaker or an implantable cardioverter
defibrillator. Check with your electronic device manufacturer
concerning the effects that charging may have on such electronic
devices before using the product.
WARNING: Do not expose to liquid, vapor or rain.
WARNING: Do not use this product if there is any damage to
the unit.
WARNING: Risk of electric shock. Do not remove cover or
attempt to open the enclosure. No user serviceable parts inside.
Refer servicing to qualified service personnel.
a. Read all the instructions before using this product.
b. Use supervision when operating this product around children
c. Do not put fingers into the electric vehicle connector.
d. Do not use this product if the flexible power cord or EV cable
is frayed, has broken insulation or any other signs of damage.
e. Do not use this product if the enclosure or the EV connector
is broken, cracked, opened or shows any other indication of
damage.
3
English
f. To avoid a risk of fire or electric shock, do not use this device
with an extension cord.
g. Do not operate the product in temperatures outside its
.
Main Unit Components
A. Main Unit
B. LED Indicator
C. Charging Handle
D. Release Lever
E. Protective Cover
A
B
C
D
E
Plug-in Installation
CAUTION: Ensure that the proper dedicated outlet
Alternatively, a licensed electrician may install a NEMA 6-20 outlet.
CAUTION:
(500-660 mm) from the ground adjacent to the stud where the
The NEMA 6-20 outlet should be located 20-26 in
product is to be mounted.
1. Connect the power plug to the NEMA 6-20 outlet.
2. Lights up after power on (AC input voltage within the range of
120V-240). Green indicator - 12A. Blue indicator - 16A.
3. Ensure that the charging handle is fully inserted into your vehicle's
charging port so it clicks rmly into place. The charging process starts.
4. When your vehicle is fully charged, you can verify the charging
status by checking your vehicle’s dashboard.
NEMA 6-20 is available for use with this product.
Operating Instructions
LED Indicator
Blue
Green
Green
Red and Blue
12A
Green 16A
POWER
Lights up after power on (AC input
voltage within the range of 120V-240),
Blue indicator - 12A
Green indicator - 16A
The indicator lights up when charging
handle inserted into the vehicle's
charging port and lights off when the
charging handle is removed.
The indicator will lights up when have
fault. Please see below table of Error
Codes.
The indicator lights up when charging
process starts and lights off when the
charging is complete.
READY
CHARGE
FAULT
4
English
SAVE THESE
INSTRUCTIONS
Before First Use
DANGER: Risk of suffocation! Keep any packaging materials
away from children and pets - these materials are a potential
source of danger, e.g. suffocation.
• Remove all packaging materials
• Remove and review all components before use.
• Check the product for transport damages.
Installation Instructions
CAUTION: Protect the product from harsh weather conditions
such as rain, snow and extreme temperatures. Consider installing the
product under a carport or in a garage.
CAUTION: Install the product in a safe location away from
flammable materials and out of reach of children and pets.
NOTICE: It is recommended to install the product at a sufficient
height from grade such that the height of the storage means for the
coupling device is located between 24" (600 mm) and 48" (1.
from grade.
• Install the product within convenient proximity to where there is
an existing NEMA 6-20 outlet. Additionally, ensure that the cord
or wiring leading into the product has some slack.
• For optimal charging efficiency, place the product as close as
possible to the electrical panel to avoid lengthy cable runs.
• Install the product to an easily accessible location for the driver
to plug in and out the vehicle. Make sure the installation location
allows enough slack for the charging cable to reach the vehicle's
charging port.
• The wall used for installation must have the capacity to support
the weight of the product and its accessories and must remain
level once the installation is completed.
• Avoid installing the product in areas with excessive vibration or
elevated temperatures.
FCC Statement
FCC Supplier's Declaration of
Conformity
Unique identifier: DXPAEV016
Responsible party: Paragon Group USA LLC, 100 West
Forest Avenue, Unit A, Englewood,
NJ07631, USA
U.S. contact
information:
Paragon Group USA LLC, 100 West
Forest Avenue, Unit A, Englewood,
NJ07631, USA
Email: [email protected]
Error Codes
Problem
Over voltage/
under voltage
RED BLUE
OFFON
Over current FLASH onceON 2S
Ground fault FLASH twiceON 2S
Current leakage FLASH 3 timesON 2S
Over
temperature FLASH 4 timesON 2S
Relay failure FLASH 5 timesON 2S
Failed
self-check FLASH 6 timesON 2S
Communication
fault FLASH 7 timesON 2S
Troubleshooting
Problem Possible solution
The vehicle is not
responding or
charging.
• Verify that the product has power:
Ensure that the prongs on the plug
t snugly into the 6-20 outlet.
• Verify that the connector of the
charging handle ts securely to
the vehicle's charging port.
• Verify that the vehicle has been
turned off.
• Inspect the product for damage.
If damaged, stop using the product
and switch the circuit breaker off.
Contact customer service.
User Maintenance Instructions
WARNING: The product contains no user serviceable parts.
Do not attempt to repair or service any other part of the product
yourself.
WARNING: The maintenance, and servicing of the product
must only be performed by qualified personnel in accordance with
applicable local regulations
WARNING: Disconnect the charging handle from the vehicle's
charging port and switch the circuit breaker off before cleaning.
• Do not use cleaning solvents to clean any part of the product.
Automatic Charging
• With the product powered, it starts charging few seconds after
connecting the charging handle to the vehicle’s charging port.
• The product automatically detects outlet voltage and maximum
allowable input current of your vehicle.
1. Press the release lever, plug the SAE-J1772 connector
of the charging handle to the vehicle's charging port.
The charging process starts.
2. The product switches off automatically once the vehicle's
battery is fully charged.
NOTICE: When the charging is complete, press the release lever
and unplug the SAE-J1772 connector, covering the handle with
item E after use.
5
English
NOTICE: If power reset can not solve the problem, stop using the
product. Switch the circuit breaker off and contact customer
service for support.
Accessories
WARNING: Since accessories, other than those offered by
DEWALT, have not been tested with this product, use of such
accessories with this product could be hazardous. To reduce
the risk of injury, only DEWALT recommended accessories should
be used with this product.
If you need assistance regarding accessories, please contact the
• Cover the charging handle with the protective cover before
cleaning.
• Regularly clean the product using a soft, dry cloth to remove
accumulated dust and dirt.
• Regularly inspect the charging cable and plug for any visible
damage or wear.
Moving and Storage Instructions
WARNING: When transporting the product, handle with care.
Do not subject it to strong force or impact or pull, twist, tangle,
drag or step on the product, to prevent damage to it or any
components.
•Cover the charging handle with the protective cover before storing.
• Protect the product from any external impact.
• Store the product in a dry indoor area and within the storage
. Keep
away from children and pets.
Free Warning Label Replacement
If warning labels become illegible or are missing, please call
1-855-815-1171 for a free replacement.
Red and blue light indicator ash exclusively
and sequentially in the order of red then blue,
number of red/blue sequence occurrences
represent different error codes.
Service Information
Whether you need technical advice, repair or genuine factory
replacement parts, contact the manufacturer at 1-855-815-1171
FCC Interference Statement
NOTICE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to ratio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
NOTICE: Per FCC Part 15, changes or modifications to this
equipment not expressly approved by DEWALT could void your
authority to operate this equipment.
Specifications
Model: DXPAEV016
120V / 240V
Rated input/output
voltage:
Rated frequency: 60Hz
Rated current: 12A / 16A
Rated charging power: 1.44kW / 3.84kW
Rated standby power: Max. 3W
Charging connector: SAE J1772 standard compliant
Power plug type:
NEMA 6-20
Cable length: 25 ft (7.6m)
Enclosure rating: Type 4
Ground fault circuit
interrupter:
Integrated, no additional required
(CCID20)
Agency approvals: CSAus
Altitude:
Operating temperature:
Storage temperature:
Relative humidity: ≤95% RH, no water droplet
condensation
NEMA rating: Type 4
Net weight: 6.17 lbs (2.8kg)
Dimensions W x D x H
(main unit):
4.33 x 9.27 x 2.17 "
(11 x 23.55 x 5.51cm)
6
English
This warranty gives you, the original retail purchaser, specific legal
rights and you may have other rights which vary in certain states or
provinces. This product is not intended for commercial use.
90 DAYS Refund Policy
If you are not completely satisfied with the performance of this
product for any reason, you can return it within ninety (90) days from
the date of purchase with a receipt for a full refund.
Please visit our website www.DEWALT.com/register to register
your new DEWALT product and to be kept up to date on
new products and special offers.
Three Years Limited Warranty
The manufacturer warrants this product against defects in material
and workmanship for a period of three (3) years from the date of retail
purchase by the original end-user purchaser (“Warranty Period”).
If there is a defect and a valid claim is received within the Warranty
Period, the defective product can be repaired, replaced or refunded,
without charge, in the following ways: (1) Return the product to the
manufacturer for repair, replacement or refund at manufacturer’s
option. Proof of purchase may be required by manufacturer. (2)
Return the product to the retailer where product was purchased
for an exchange (provided that the store is a participating retailer).
Returns to retailer should be made within the time period of the
retailer’s return policy for exchanges only (usually 30 to 90 days after
the sale). Proof of purchase may be required. Please check with
the retailer for their specific return policy regarding returns that are
beyond the time set for exchanges.
This warranty does not apply to: accessories, bulbs, fuses and
batteries; defects resulting from normal wear and tear, accidents;
damages sustained during shipping; alterations; unauthorized use or
repair; neglect, misuse, abuse; and failure to follow instructions for
care and maintenance for the product.
Canada IC Notice
This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference
that may cause undesired operation of the device.
This equipment complies with Industry Canada radiation exposure
limits set forth for an uncontrolled environment.
This Class B digital apparatus complies with Canadian CAN
ICES-003(B) / NMB-003(B) standard.
Fabriqué et importé par
Paragon Group USA LLC, 100 West
Forest Avenue, unité A, Englewood,
NJ 07631, États-Unis
www.DEWALT.com
1-855-815-1171
Made in RPC
Copyright © 2023 Paragon Group USA, LLC.
DEWALT® et le logo DEWALT sont des marques de commerce
de le DEWALT Industrial Tool Co., ou un aflié de celui-ci
et sont utilisés sous licence.
Le jeu de couleurs jaune / noir est une marque
pour les outils et accessoires de DEWALT.
Fabricado e importado por
Paragon Group USA LLC, 100 West
Forest Avenue, Unidad A, Englewood,
NJ 07631, EE. UU.
www.DEWALT.com
1-855-815-1171
Hecho en PRC
Copyright © 2023 Paragon Group USA, LLC.
DEWALT® y el logotipo de DEWALT son marcas registradas de
el DEWALT Industrial Tool Co., o un aliado de la misma
y se usan bajo licencia.
El esquema de color amarillo/negro es una marca registrada
Para herramientas y accesorios de DEWALT Power.
Manufactured and Imported by
Paragon Group USA LLC, 100 West
Forest Avenue, Unit A, Englewood,
NJ 07631, USA
www.DEWALT.com
1-855-815-1171
Made in PRC
Copyright © 2023 Paragon Group USA, LLC.
DEWALT® and the DEWALT Logo are trademarks of
the DEWALT Industrial Tool Co., or an afliate thereof
and are used under license.
The yellow/black color scheme is a trademark
for DEWALT power tools & accessories.
1-855-815-1171
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS DEWALT TOOL, CALL US TOLL FREE AT
SI TIENE ALGUNA PREGUNTA O COMENTARIO SOBRE ESTA HERRAMIENTA DEWALT, LLÁMENOS GRATUITAMENTE AL
SI VOUS AVEZ DES QUESTIONS OU DES COMMENTAIRES SUR CET OUTIL DEWALT, APPELEZ-NOUS SANS FRAIS AU
Table of contents
Other DeWalt Automobile Batteries Charger manuals
