Dialogic Eiconcard Family User manual

www.dialogic.com
Eiconcard™ Family
Installation Guide
for PCI and PCI Express Compatible Bus
64-0308-09.fm Page 1 Monday, March 15, 2010 3:32 PM

page 2
Copyright © 2001-2010 Dialogic Corporation. All Rights Reserved. You may not reproduce this
document in whole or in part without permission in writing from Dialogic Corporation at the
address provided below.
All contents of this document are furnished for informational use only and are subject to change
without notice and do not represent a commitment on the part of Dialogic Corporation or its
subsidiaries ("Dialogic"). Reasonable effort is made to ensure the accuracy of the information
contained in the document. However, Dialogic does not warrant the accuracy of this information
and cannot accept responsibility for errors, inaccuracies or omissions that may be contained in
this document.
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH DIALOGIC®
PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY
INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN
A SIGNED AGREEMENT BETWEEN YOU AND DIALOGIC, DIALOGIC ASSUMES NO LIABILITY
WHATSOEVER, AND DIALOGIC DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING
TO SALE AND/OR USE OF DIALOGIC PRODUCTS INCLUDING LIABILITY OR WARRANTIES
RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT
OF ANY INTELLECTUAL PROPERTY RIGHT OF A THIRD PARTY.
Dialogic products are not intended for use in medical, life saving, life sustaining, critical control
or safety systems, or in nuclear facility applications.
Due to differing national regulations and approval requirements, certain Dialogic products may
be suitable for use only in specific countries, and thus may not function properly in other
countries. You are responsible for ensuring that your use of such products occurs only in the
countries where such use is suitable. For information on specific products, contact Dialogic
Corporation at the address indicated below or on the web at www.dialogic.com.
It is possible that the use or implementation of any one of the concepts, applications, or ideas
described in this document, in marketing collateral produced by or on web pages maintained by
Dialogic may infringe one or more patents or other intellectual property rights owned by third
parties. Dialogic does not provide any intellectual property licenses with the sale of Dialogic
products other than a license to use such product in accordance with intellectual property owned
or validly licensed by Dialogic and no such licenses are provided except pursuant to a signed
agreement with Dialogic. More detailed information about such intellectual property is available
from Dialogic's legal department at 9800 Cavendish Blvd., 5th Floor, Montreal, Quebec, Canada
H4M 2V9. Dialogic encourages all users of its products to procure all necessary intellectual
property licenses required to implement any concepts or applications and does not condone or
encourage any intellectual property infringement and disclaims any responsibility related
thereto. These intellectual property licenses may differ from country to country and it is the
responsibility of those who develop the concepts or applications to be aware of and comply with
different national license requirements.
Dialogic, Dialogic Pro, Brooktrout, Diva, Cantata, SnowShore, Eicon, Eicon Networks, NMS
Communications, NMS (stylized), Eiconcard, SIPcontrol, Diva ISDN, TruFax, Exnet, EXS,
SwitchKit, N20, Making Innovation Thrive, Connecting to Growth, Video is the New Voice,
Fusion, Vision, PacketMedia, NaturalAccess, NaturalCallControl, NaturalConference, NaturalFax
and Shiva, among others as well as related logos, are either registered trademarks or
trademarks of Dialogic Corporation or its subsidiaries. Dialogic's trademarks may be used
publicly only with permission from Dialogic. Such permission may only be granted by Dialogic's
legal department at 9800 Cavendish Blvd., 5th Floor, Montreal, Quebec, Canada H4M 2V9. Any
authorized use of Dialogic's trademarks will be subjectto full respect of the trademark guidelines
published by Dialogic from time to time and any use of Dialogic's trademarks requires proper
acknowledgement.
Windows is a registered trademark of Microsoft Corporation in the United States and/or other
countries. Other names of actual companies and products mentioned herein are the trademarks
of their respective owners.
Dialogic Corporation License Agreement for use of Software
This is an Agreement between you, the Company, and your Affiliates (referred to in some
instances as "You" and in other instances as "Company") and all Your Authorized Users and
Dialogic Corporation ("Dialogic").
YOU SHOULD CAREFULLY READ THIS SOFTWARE LICENSE AGREEMENT ("AGREEMENT"),
WHETHER IT IS BEING MADE AVAILABLE TO YOU AS PART OF SEALED PACKAGING AND/OR VIA
DOWNLOADING, BEFORE OPENING THE APPLICABLE PACKAGING AND/OR COMMENCING THE
APPLICABLE DOWNLOADING. BY OPENING THE APPLICABLE PACKAGING AND/OR
COMMENCING THE APPLICABLE DOWNLOADING, YOU AGREE TO AND ACCEPT THE TERMS AND
CONDITIONS OF THIS AGREEMENT. IF YOU DO NOT AGREE WITH OR ARE UNWILLING TO
ACCEPT THESE TERMS AND CONDITIONS, YOU MAY RETURN THE APPLICABLE PACKAGING IN
64-0308-09.fm Page 2 Monday, March 15, 2010 3:32 PM

page 3
UNOPENED "AS NEW" CONDITION (INCLUDING ALL DOCUMENTATION AND BINDERS OR OTHER
CONTAINERS) FOR A FULL REFUND AND/OR YOU SHOULD NOT COMMENCE THE APPLICABLE
DOWNLOADING. BY DOWNLOADING, INSTALLING, COPYING OR OTHERWISE USING THE
ENCLOSED SOFTWARE ("PROGRAM"), WHETHER SUCH PROGRAM WAS MADE AVAILABLE TO
YOU AS PART OF SEALED PACKAGING AND/OR VIA DOWNLOADING, YOU FURTHER AGREE AND
ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT AND UNDERSTAND IT, AND THAT BY
TAKING ANY ONE OR MORE OF SUCH STEPS/ACTIONS YOU AGREE TO BE BOUND BY SUCH
TERMS AND CONDITIONS. DIALOGIC IS UNWILLING TO LICENSE THE PROGRAM TO YOU IF
YOU DO NOT ACCEPT AND AGREE TO BE BOUND BY THE TERMS AND CONDITIONS OF THIS
AGREEMENT.
Intellectual Property
The enclosed Program and all accompanying documentation are individually and collectively
owned by Dialogic Corporation ("Dialogic"), its subsidiaries and/or its suppliers and are
protected by all applicable intellectual property laws and international treaty provisions.
Therefore, You and Your Authorized Users must treat the Program and documentation like any
other material so protected, except as expressly permitted in this Agreement. In particular, but
without limitation, You acknowledge that the Program and its accompanying documentation
constitute valuable intellectual property rights, including without limitation trade secrets and
copyrights, and confidential information of Dialogic. The Program and all programs developed
thereunder and all copies thereof (including without limitation translations, compilations, partial
copies with modifications and updated works) are proprietary to Dialogic and title to all
applicable copyrights, trade secrets, patents and other intellectual property rights therein
remains in Dialogic, its subsidiaries, and/or its suppliers. Except as expressly permitted in this
Agreement, You shall not sell, transfer, publish, disclose, display or otherwise make available
the Program or copies thereof to others. You agree to secure and protect the Program, its
accompanying documentation and copies thereof in a manner consistent with the maintenance
of Dialogic's rights therein and to take appropriate action by instruction or agreement with Your
employees and/or consultants who are permitted access to the Program to satisfy Your
obligations hereunder. Violation of any provision of this paragraph shall be the basis for
immediate termination of this Agreement. Because unauthorized use or transfer of the Program
or documentation may diminish substantially the value of such materials and irrevocably harm
Dialogic, if You breach the provisions of this Section of this Agreement, Dialogic shall be entitled
to injunctive and/or other equitable relief, in addition to other remedies afforded by law, to
prevent a breach of this Section of this Agreement.
Grant of License
Subject to the terms and conditions of this Agreement Dialogic grants to You a non-exclusive,
personal, non-transferable license to use the Program in object code form only and solely in
accordance with the following terms and conditions:
You may make, install and use only one (1) copy of the Program on a single-user computer, file
server, or on a workstation of a local area network, and only in conjunction with a legally
acquired Dialogic® hardware or software product You may also make one copy solely for backup
or archive purposes;
The primary Authorized User on the computer on which the Program is installed may make a
second copy for his/her exclusive use on either a home or portable computer;
• You may copy the Program into any machine readable or printed form for backup or
modification purposes in support of Your use of one copy of the Program;
• You may distribute the Program in object code only and only as part of, or integrated by You
into, a computer system that (i) contains a Dialogic hardware product, (ii) includes a
substantial amount of other software and/or hardware manufactured or marketed by You and
(iii) is marketed and sublicensed to an end user for the end user's own internal use in the
regular course of business (a "Licensed System");
• Each end user to whom a Licensed System is distributed must agree to license terms with
respect to the Program that are at least as protective of Dialogic's rights in the Program as
those set forth in this Agreement;
• You shall receive one (1) Program master disk, and shall be solely responsible for copying the
Program into the Licensed Systems and for warranting the physical media on which it is copied
• You may make one (1) copy of the documentation accompanying the Program, provided that
all copyright notices contained within the documentation are retained;
• You may modify the Program and/or merge it into another Program for Your use in one
computer; (any portion of this Program will continue to be subject to the terms and conditions
of this Agreement);
64-0308-09.fm Page 3 Monday, March 15, 2010 3:32 PM

page 4
• You may transfer the Program, documentation and the license to another eligible party within
Your Company if the other party agrees to accept the terms and conditions of this Agreement.
If You transfer the Program and documentation, You must at the same time either transfer all
copies whether in printed or machine readable form to the same party or destroy any copies
not transferred; this includes all modifications and portions of the Program contained in or
merged into other Programs;
• You shall not remove, and each copy of the Program shall contain, the same copyright,
proprietary, patent and/or other applicable intellectual property or other ownership notices,
plus any restricted rights legends that appear in the Program and/or this Agreement and, if
You copy the Program onto media to which a label may be attached, You shall attach a label
to the media that includes all such notices and legends that appear on the Program master
disk and envelope;
• You may not rent or lease the Program. You may not reverse engineer, decompile or
disassemble the Program. Except as is strictly necessary for You to integrate the Program with
other software and/or hardware to produce the Licensed Systems, You shall not copy, modify
or reproduce the Program or documentation in any way. You shall use Your best efforts to
ensure that any user of the Program does not reverse engineer, decompile or disassemble the
Program to derive a source code equivalent of the Program;
• If You transfer possession of any copy, modification or merged portion of the Program or
documentation to another party in any way other than as expressly permitted in this
Agreement, this license is immediately and automatically terminated;
• The Program may be used only in conjunction with Dialogic hardware;
• The Program shall not be exported or re-exported in violation of any export provisions of the
United States or any other applicable jurisdiction.
Upgrades
If the Program is provided as an upgrade and the upgrade is an upgrade from another product
licensed to You and Your Authorized Users by Dialogic, the upgrade is governed by the license
agreement earlier provided with that software product package and the present Agreement does
not grant You additional license(s).
Term
The Agreement is effective until terminated. You may terminate it at any time by notifying
Dialogic and/or by destroying the Program and all accompanying documentation together with
all copies, modifications and merged portions in any form. The Agreement will also terminate
automatically upon the occurrence or lack of occurrence of certain terms and/or conditions set
forth in this Agreement, or if You fail to comply with any term or condition of this Agreement.
You agree that upon any such termination You shall destroy or return to Dialogic the Program
and all accompanying documentation supplied by Dialogic, together with any and all copies,
modifications and merged portions in any form. All provisions of this Agreement relating to
disclaimers of warranties, limitation of liability, remedies, or damages, and licensor's proprietary
rights shall survive termination.
Limited Warranty
Dialogic solely warrants the media on which the Program is furnished to You to be free from
defects in materials and workmanship under normal use for a period of ninety (90) days from
the date of purchase by You as evidenced by a copy of Your receipt. If such a defect appears
within the warranty period, You may return the defective media to Dialogic for replacement
without charge provided Dialogic, in good faith, determines that it was defective in materials or
workmanship. Replacement is Your sole remedy with respect to such a defect. Dialogic offers
no warranty for Your reproduction of the Program. This Limited Warranty is void if failure of the
Program has resulted from accident, misuse, abuse or misapplication.
Disclaimers, Limitations of Liability and Customer Remedies
Except as set forth in the "Limited Warranty" Section of this Agreement, the Program and
accompanying documentation are provided to You "as is." Neither Dialogic, its subsidiaries, its
suppliers, nor its licensor(s) (if any) warrants that the Program will meet Your requirements or
that its use will be uninterrupted or error-free. Except as set forth in the "Limited Warranty"
Section, EACH OF DIALOGIC, ITS SUBSIDIARIES, ITS SUPPLIERS AND ITS LICENSOR(S) (IF
ANY) DISCLAIMS ANY AND ALL REPRESENTATIONS AND WARRANTIES, EXPRESS OR IMPLIED,
WITH RESPECT TO THE PROGRAM AND ACCOMPANYING DOCUMENTATION, INCLUDING BUT
NOT LIMITED TO THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, OR AGAINST LATENT DEFECTS. Except as set forth in
the "Limited Warranty" Section, neither Dialogic, its subsidiaries, its suppliers, nor its licensor(s)
(if any) shall have any liability to You or any third party for any claim, loss or damage of any
kind, including but not limited to lost business profits, business interruption, loss of information,
64-0308-09.fm Page 4 Monday, March 15, 2010 3:32 PM

page 5
or other pecuniary loss and indirect, punitive, incidental, economic, consequential or special
damages, arising out of or in connection with this Agreement and/or the use, inability to use
the Program and/or the Program's performance or inability to perform nor from or in connection
with the Program's accompanying documentation, or any data or equipment related thereto or
used in connection therewith. In no event shall Dialogic's, its subsidiaries', its suppliers' or its
licensor(s)'s liability for damages, whether arising out of contract, negligence, warranty, or
patent or copyright infringement, exceed the fees You paid for the Program. No representation
or warranty regarding the Program may be made without Dialogic's, its subsidiaries', its
suppliers', or its licensor(s)'s (if any) prior written consent, and any warranty or representation
made by You or Your customers regarding the Program shall not constitute an obligation of
Dialogic, its subsidiaries, its suppliers, or other licensor(s) (if any). This limited warranty gives
You specific legal rights. You may have other rights, which may vary from jurisdiction to
jurisdiction. Also, as some jurisdictions do not allow the exclusion or limitation for certain
damages, some of the above limitations may not apply to You.
Right to Audit
If this Program is licensed for use in a Company, Your Company and You individually and
collectively agree to keep all usual and proper records and books of accounts and all usual proper
entries relating to each installation of the Program during the term of this Agreement and for a
period of three (3) years thereafter. During this period, Dialogic may cause an audit to be made
of the applicable records in order to verify Your compliance with this Agreement and prompt
adjustment shall be made to compensate for any errors or omissions disclosed by such audit.
Any such audit shall be conducted by an independent certified public accountant selected by
Dialogic and shall be conducted during the regular business hours at Your offices and in such a
manner as not to interfere with Your normal business activities. Any such audit shall be paid for
by Dialogic unless material discrepancies are disclosed. For such purposes, "material
discrepancies" shall mean three percent (3%) or more of the Authorized Users within the
Company. If material discrepancies are disclosed, Your Company agrees to pay Dialogic for the
costs associated with the audit as well as the license fees for the additional licensed channels
or additional authorized users. In no event shall audits be made more frequently than semi-
annually unless the immediately preceding audit disclosed a material discrepancy.
Supplementary Software
Any Supplementary Software provided with the Program and/or referred to in this Agreement
is provided "as is" with no warranty of any kind.
Miscellaneous
You acknowledge that You have read this Agreement, that You understand it, and that You agree
to be bound by its terms and conditions, and You further agree that this is the complete and
exclusive statement of the Agreement between the Dialogic and You ("the Parties"), which
supersedes and merges all prior proposals, understandings and all other agreements, oral and
written, between the Parties relating to the Program. You agree to indemnify and hold harmless
Dialogic and its subsidiaries, affiliates, suppliers, officers, directors and employees from and
against any claim, injury, loss or expense, including reasonable attorneys' fees, arising out of
(i) Your failure to comply with the provisions of this Agreement, or (ii) any other wrongful
conduct by or on behalf of You. This Agreement applies to all updates, future releases,
modifications and portions of the Program contained in or merged into other programs. This
Agreement may not be modified or altered except by written instrument duly executed by
Dialogic. No action, regardless of form, arising out of this Agreement or the use of the Program
may be brought by You more than two (2) years after the cause of action has first arisen. Except
as provided herein, neither this Agreement nor any rights granted are assignable or
transferable, and any assignment or transfer will be null and void. If You authorize any other
person to copy the Program, You shall obligate that person in writing to comply with all
conditions of this Agreement. Dialogic shall have the right to collect from You its reasonable
expenses incurred in enforcing this agreement, including attorney's fees. The waiver or failure
of Dialogic to exercise in any respect any right provided for herein shall not be deemed a waiver
of any further right hereunder. All rights and remedies, whether conferred hereunder or by any
other instrument or law, will be cumulative and may be exercised singularly or concurrently.
Failure by either Dialogic or You to enforce any term or condition of the Agreement will not be
deemed a waiver of future enforcement of that or any other term or conditions. The terms and
conditions stated herein are declared to be severable. Should any term(s) or condition(s) of this
Agreement be held to be invalid or unenforceable the validity, construction and enforceability of
the remaining terms and conditions of this Agreement shall not be affected. It is expressly
agreed that Dialogic and You are acting as independent contractors under this Agreement. These
terms and conditions will prevail notwithstanding any different, conflicting or additional terms
and conditions that may appear on any other agreement between Dialogic and You. Deviations
from these terms and conditions are not valid unless agreed to in writing in advance by an
authorized representative of Dialogic. Any notices sent to Dialogic under this Agreement must
64-0308-09.fm Page 5 Monday, March 15, 2010 3:32 PM

page 6
be sent by registered mail or courier to the attention of Dialogic's legal department at the
address below or such other address as may be listed on www.dialogic.com from time to time
as being Dialogic's Montreal headquarters.
U.S. Government Restricted Rights
The Program and all accompanying documentation are provided with RESTRICTED RIGHTS.Use,
duplication or disclosure by the U.S. Government is subject to restrictions as set forth in
subparagraph (c)(1)(iii) of The Rights in Technical Data and Computer Software clause at DFARS
252.227-7013 or subparagraph (c) (1) and (2) of the Commercial Computer Software-Restricted
Rights at 48 CFR52.227-19, both as applicable.
Governing Law
Any and all claims arising under this Agreement shall be construed and controlled by the laws
in force in the Province of Quebec, Canada, excluding its principles of conflict of laws and the
United Nations Convention on Contracts for the Sale of Goods. Dialogic is not obligated under
any other agreements unless they are in writing and signed by an authorized representative of
Dialogic.
Contractor/ manufacturer is:
Dialogic CORPORATION.
9800 Cavendish Blvd., Montreal, Quebec, Canada H4M 2V9
This Agreement has been drafted in English at the express wish of the parties. Ce contrat a été
rédigé en anglais à la demande expresse des parties.
64-0308-09.fm Page 6 Monday, March 15, 2010 3:32 PM

page 7
Contents
Introduction .................................................................... 9
Eiconcard C series...................................................................... 9
Eiconcard S series...................................................................... 9
Installing the Eiconcard................................................. 11
Making an ISDN connection ........................................... 14
In Europe and most countries worldwide ..................................... 14
In North America and other countries ......................................... 14
Termination............................................................................. 15
Making a VHSI connection ............................................. 16
VHSI cables............................................................................. 16
Making a V.24 Connection.............................................. 17
V.24 cables ............................................................................. 17
Status lights
Eiconcard C90, C91 S/T, C91 V2, and C91 PCIe LP......... 18
Status Lights
Eiconcard S91 S/T and S91 V2....................................... 19
Status Lights
Eiconcard S90, S92, S94, S94/66 MHz, S94 V2,
and S94 PCIe ................................................................. 20
VHSI port specifications ................................................ 21
Cable construction information................................................... 22
V.24 DCE interface .................................................................. 23
V.24 DTE interface ................................................................... 25
V.35 interface ......................................................................... 27
EIA-530 interface .................................................................... 29
V.36/RS-449 interface .............................................................. 31
X.21 interface ......................................................................... 33
Back-to-back connections.......................................................... 35
V.24 port specifications ................................................. 36
Technical specifications
Eiconcard C series.......................................................... 37
Technical data ........................................................................ 37
Hardware Installation ............................................................... 37
External Interface .................................................................... 37
V.24 port ................................................................................ 37
Performance............................................................................ 37
Power Requirements................................................................. 38
Power Consumption.................................................................. 38
Environmental Requirements ..................................................... 38
64-0308-09.fm Page 7 Monday, March 15, 2010 3:32 PM

page 8
Technical specifications
Eiconcard S series ......................................................... 39
Technical data ......................................................................... 39
Hardware installation................................................................ 39
Performance............................................................................ 39
Environmental requirements...................................................... 39
External interface .................................................................... 40
VHSI ports.............................................................................. 40
Power requirements ................................................................. 40
Power consumption.................................................................. 40
International regulatory information ............................ 41
Regulatory information for the USA ............................................ 41
Regulatory information for Canada ............................................. 43
Regulatory information for Europe.............................................. 44
Regulatory information for Australia ........................................... 46
Declarations of conformity............................................ 47
64-0308-09.fm Page 8 Monday, March 15, 2010 3:32 PM

Eiconcard™ Family Installation Guide
page 9
Introduction
This booklet describes the Dialogic®Eiconcard™ C and S series
interface cards.
All Eiconcards have been tested and found to comply with
the Electromagnetic compatibility, Safety and Network
connection regulations within the European Union, North
America, and other major territories. Read the regulatory
information on page 41 before installing and using your
product.
Eiconcard C series
The Eiconcard C series are intelligent multi-protocol wide-area
network (WAN) interface cards for PCI/PCIe-based workstations,
offering connectivity through V.24 and/or ISDN ports.
The Eiconcard C series allows you to connect using WAN protocols
such as X.25, Frame Relay, PPP, SDLC and HDLC, over leased lines,
dial-up lines or ISDN lines.
V.24 port
The V.24 port supports line speeds of 64 kbps.
ISDN BRI port
The ISDN BRI port supports transfer rates up to 64 kbps on each
“B” channel and 16 kbps on the “D” channel. It features an
integrated S/T interface.
Eiconcard S series
The Eiconcard S series are intelligent multi-protocol wide-area
network (WAN) interface cards for PCI/PCIe-based servers. These
interface cards feature a Very High Speed Interface (VHSI) port
Model CPU/Memory/Flash V.24 Ports ISDN BRI Ports
Eiconcard C90 16 MHz Motorola 68302
512 KB RAM
512 KB Flash
10
Eiconcard C91 S/T 16 MHz Motorola 68302
512 KB RAM
512 KB Flash
11
Eiconcard C91 V2 50 MHz Motorola 850
8 MB SDRAM 11
Eiconcard C91 PCIe LP 50 MHz Motorola 852T
8 MB SDRAM 11
64-0308-09.fm Page 9 Monday, March 15, 2010 3:32 PM

Introduction
page 10
and an ISDN BRI port, supporting line speeds up to 2 Mbps (T1/E1)
and 128 kbps respectively.
The Eiconcard S Series allows you to connect using WAN protocols
such as X.25, Frame Relay, PPP, SDLC and HDLC, over leased lines,
dial-up lines or ISDN lines.
VHSI port
The VHSI port features automatic interface selection. The
intelligent controller on the Eiconcard detects the type of cable
connected to the port and automatically selects the matching
interface.
VHSI ports support full duplex communications over a V.24, V.35,
EIA-530, V.36/RS-449, or X.21 interface at speeds up to 2 Mbps
per port (depending on the interface).
ISDN BRI port
The ISDN BRI port supports transfer rates up to 64 kbps on each
“B” channel and 16 kbps on the “D” channel. It features an
integrated S/T interface.
Model CPU/Memory/Flash VHSI
Ports ISDN BRI Ports
Eiconcard S90 25 MHz Motorola 68302
1 MB RAM
1 MB Flash
10
Eiconcard S91 S/T 25 MHz Motorola 68302
1 MB RAM
1 MB Flash
11
Eiconcard S91 V2 50 MHz Motorola 855T
8MB SDRAM 11
Eiconcard S92 33 MHz Motorola 68360
2 MB RAM
1 MB FLASH
20
Eiconcard S94
Eiconcard S94/66 MHz 33 MHz Motorola 68360 8 MB RAM
1 MB FLASH
20
Eiconcard S94 V2
Eiconcard S94 PCIe 100 MHz Motorola 852T 16 MB SDRAM 20
64-0308-09.fm Page 10 Monday, March 15, 2010 3:32 PM

Eiconcard™ Family Installation Guide
page 11
Installing the Eiconcard
If you want the Eiconcard to be available to multiple users on a
LAN, install it in the computer that will function as a gateway for
the LAN.
1Preparethecomputer
Turn off the computer and disconnect its power cable. Wait at
least 30 seconds to ensure that all power has drained from the
system. Remove the cover of the computer according to the
instructions that came with it.
2 Install the Eiconcard
a) Drain static electricity from your body by touching the metal
chassis (the unpainted metal at the back of your computer).
b) Locate a slot in your computer that has the same bus type
as the Eiconcard. All Eiconcards (except for the Eiconcard
S94 PCIe and the Eiconcard C91 PCIe LP) can be installed
into either a 32-bit or 64-bit PCI slot. However, only the
Eiconcard S94/66 MHz and Eiconcard S94 V2 can take full
advantage of a 64-bit slot. See “Technical data” on page 37
for more information on the PCI capability of your card.
The Eiconcard S94 PCIe and Eiconcard C91 PCIe LP must be
installed in a PCI express (PCIe) slot. Both cards are
compatible with all PCIe compliant slots.
The C91 PCIe LP is a low-profile card. To install it in a full-
height slot, you must replace the low-profile bracket that is
attached by default with the full-height bracket included in
the package. To do this, remove the retaining screw holding
the bracket to the PC board, and the two jackposts holding
the bracket to the micro-D 25 plug connector. Swap the
brackets, and then fasten with the screw and jackposts.
64-0308-09.fm Page 11 Monday, March 15, 2010 3:32 PM

Installing the Eiconcard
page 12
c) Insert the Eiconcard into the slot and fasten it with a screw.
3 Test the Eiconcard
The application software available for the Eiconcard contains a
test program to verify the Eiconcard’s integrity. Consult the
documentation supplied with this software for details.
Bracket
jackposts
Bracket retaining screw
64-0308-09.fm Page 12 Monday, March 15, 2010 3:32 PM

Eiconcard™ Family Installation Guide
page 13
4ConfiguretheEiconcard
Before you can use the Eiconcard, you must configure it to work
with your communications software. Consult the
documentation supplied with this software for complete
instructions on how to configure the Eiconcard.
5 Connect to your external line
You are now ready to connect the Eiconcard to your external
line.
• To set up an ISDN connection, refer to “Making an ISDN
connection” on page 14.
• To set up a VHSI connection using a S series Eiconcard,
refer to “Making a VHSI connection” on page 16.
• To set up a V.24 connection using a C series Eiconcard, refer
to “Making a V.24 Connection” on page 17.
64-0308-09.fm Page 13 Monday, March 15, 2010 3:32 PM

Making an ISDN connection
page 14
Making an ISDN connection
Before you connect the Eiconcard, check with your ISDN provider
to determine if you need an NT1 to terminate your ISDN line. In
some countries, the NT1 is installed by your ISDN provider and
resides in the central switching office. In other countries, the NT1
must be installed at your premises, either by you or your ISDN
provider. You can order an NT1 from Dialogic or from another
supplier.
In Europe and most countries worldwide
In Europe and most countries outside of North America and Japan,
the NT1 is installed at the central switching office by the ISDN
provider. In these areas, the Eiconcard can be connected directly
to the ISDN line using the included cable. Plug one end of the cable
into the Eiconcard and plug the other end into the ISDN wall jack.
In North America and other countries
In North America and some other countries, the NT1 is installed at
your premises with its “U” jack connected to the ISDN wall jack.
The Eiconcard can be connected directly to the “S/T” jack on the
NT1 using the included cable.
Eiconcard ISDN jack
Supplied Cable
S/T jack U jack
NT1
ISDN jack
Eiconcard
Supplied Cable
64-0308-09.fm Page 14 Monday, March 15, 2010 3:32 PM

Eiconcard™ Family Installation Guide
page 15
Termination
This section provides instructions to help set up termination
scenarios for installations in Australia and North America.
Termination requirements vary according to the number of ISDN
devices connected to the NT1 and the distance between the ISDN
devices and the NT1.
Terminating resistor
If you purchased the Eiconcard in North America, a 100 ohm
terminating resistor is included. The terminating resistor is
installed by inserting the RJ-45 end of the ISDN cable into the
terminating resistor, and then inserting the terminating resistor
into an ISDN jack.
Terminating a single ISDN device
If the NT1 is connected to a single Eiconcard, then:
•If the connection spans 75 meters (250 feet) or more,
set the NT1 to provide 100 ohms of resistance and connect the
terminating resistor. Consult the manual provided with the NT1
for more detailed instructions.
Note: Some NT1s do not support connections over 75 meters.
•If the connection spans less than 75 meters (250 feet),
set the NT1 to 50 ohms of resistance and do not connect the
terminating resistor. Consult the manual provided with the NT1
for more detailed instructions.
Terminating multiple ISDN devices
If the NT1 is connected to more than one Eiconcard or other ISDN
device, then follow the instructions below.
•If the connection spans 75 meters (250 feet) or more,
then the ISDN device at each end of the connection must be
set to 100 ohm termination. If the Eiconcard is at one end of
the connection, connect the 100 ohm terminating resistor to
the end of the ISDN cable. Consult the manuals provided with
the other ISDN devices and NT1 for detailed instructions.
Note: Some NT1s do not support connections over 75 meters.
•If the connection spans less than 75 meters (250 feet),
set the NT1 to 50 ohms of resistance, and do not connect the
terminating resistor. Set the other ISDN devices to no
termination. Consult the manuals provided with the NT1 and
other ISDN devices for more detailed instructions.
64-0308-09.fm Page 15 Monday, March 15, 2010 3:32 PM

Making a VHSI connection
page 16
Making a VHSI connection
(S series Eiconcards only)
The VHSI port can be used to connect the Eiconcard as a DTE to
devices such as Data Service Units (DSUs) that support one of the
following interfaces: V.24, V.35, EIA-530, V.36/RS-449, or X.21.
It can also be used to connect the Eiconcard directly to a host
computer, or back-to-back with a VHSI port on another Eiconcard.
If multiple VHSI ports are present on an Eiconcard, each port is
configured independently.
To use a particular interface, simply install the appropriate cable.
The Eiconcard recognizes the cable and automatically prepares the
port for that interface.
Consult the documentation which came with your networking
software for more information about port configuration.
VHSI cables
The following table lists the most common connections supported
by the VHSI port, and specifies the part number of the required
Dialogic cable. For information on making your own cables, see
“VHSI port specifications” on page 21.
Interface Connection Part #
V.24 to V.24 DCE 300-077
to V.24 DTE 300-078
V.35 to V.35 DCE 300-076
to V.35 DCE (France) 300-083
EIA-530 to EIA-530 DCE 300-080
V.36/RS-449 to V.36/RS-449 DCE 300-079
X.21 to X.21 DCE 300-081
Direct to VHSI port on another Eiconcard 300-075
64-0308-09.fm Page 16 Monday, March 15, 2010 3:32 PM

Eiconcard™ Family Installation Guide
page 17
Making a V.24 Connection
(C series Eiconcards only)
The V.24 port can be used to connect the Eiconcard as a DTE to
devices that support a V.24 interface, directly to a host computer,
or back-to-back with a V.24 port on another Eiconcard.
Consult the documentation which came with your networking
software for more information about port configuration.
V.24 cables
The following table lists the most common connections supported
by the V.24 port, and specifies the part number of the required
Dialogic cable. For information on making your own cables, see
“V.24 port specifications” on page 36.
Connection Cables Required Part #
Eiconcard C90, C91 S/T
and C91 V2 to V.24 DCE V.24 DCE Cable 300-007
Eiconcard C90, C91 S/T
and C91 V2 to V.24 DTE V.24 Null Modem Cable 300-022
C91 PCIe LP to V.24 DCE V.24 DCE Cable 300-402
C91 PCIe LP to V.24 DTE V.24 Null Modem Cable 300-401
64-0308-09.fm Page 17 Monday, March 15, 2010 3:32 PM

Status lights Eiconcard C90, C91 S/T, C91 V2, and C91
PCIe LP
page 18
Status lights
Eiconcard C90, C91 S/T, C91 V2, and
C91 PCIe LP
ISDN D-channel Status
(Eiconcard C91 S/T, C91 V2, and C91
PCIe LP only)
The D-channel controls the link to your
ISDN service provider.
Off...........The line is not active. The cable may not
be connected.
Blinking....The line is active, but a link cannot be
established. This may be a symptom of
incorrect configuration.
Steady.....The ISDN line is active and operating
normally.
ISDN B-channel Status
(Eiconcard C91 S/T, C91 V2, and C91
PCIe LP only)
The B-channels are used for the link to
the remote ISDN device.
Off .......... There is no connection.
Blinking ... Attempting to connect to the remote
device.
Steady..... The connection is active and able to
transmit data.
Configuration Status
This status light illuminates when the
Eiconcard is being configured.
Consult the documentation provided
with the configuration software for
information about this status light.
ISDN
port
V.24
port
64-0308-09.fm Page 18 Monday, March 15, 2010 3:32 PM

Eiconcard™ Family Installation Guide
page 19
Status Lights
Eiconcard S91 S/T and S91 V2
ISDN D-channel status
The D-channel controls the link to your
ISDN service provider.
Off.........The line is not active. The cable
may not be connected.
Blinking..The line is active, but a link cannot
be established. This may be a
symptom of incorrect
configuration.
Steady ...The ISDN line is active and
operating normally.
ISDN B-channel status
The B-channels are used for the link to
the remote ISDN device.
Off ........ There is no connection.
Blinking.. Attempting to connect to the
remote device.
Steady... The connection is active and able
to transmit data.
Configuration status
This status light illuminates when the
Eiconcard is being configured.
Consult the documentation provided
with the configuration software for
information about this status light.
ISDN
port
VHSI
port
64-0308-09.fm Page 19 Monday, March 15, 2010 3:32 PM

Status Lights Eiconcard S90, S92, S94, S94/66 MHz,
S94 V2, and S94 PCIe
page 20
Status Lights
EiconcardS90, S92,S94,S94/66MHz,
S94 V2, and S94 PCIe
Configuration status
This status light illuminates when the
Eiconcard and/or port is being
configured.
Consult the documentation provided
with the configuration software for
information about this status light.
VHSI
port
VHSI
port
Note The Eiconcard S90 has only one
VHSI port
64-0308-09.fm Page 20 Monday, March 15, 2010 3:32 PM
