Diamond FT6M-18 User manual

Mod: FT6M-18
Production code: T POLIS PW 6 ST/MC18
08/2012

TEOREMA POLIS PW
STANDARD
Pastry bread and pizza oven
Installation, use and maintenance manual

INDEX
3
INDEX
1. PRESENTATION....................................................................5
2. HOW TO USE THIS MANUAL...............................................6
3. SPECIFICATIONS..................................................................8
3.1 Identifying the product.......................................................................8
3.2 Conformity to European Directives....................................................8
3.3 Use intended for the product.............................................................8
3.4 Technical specifications.....................................................................9
4. INSTALLATION....................................................................11
4.1 Checking on delivery.......................................................................11
4.2 Choosing a place for installation......................................................11
4.3 Moving the unit................................................................................13
4.4 Positioning and mounting the unit ...................................................14
4.5 Electrical connection........................................................................14
4.6 Emissions from cooking appliances ................................................15
4.7 Checking before starting work.........................................................16
5. CONTROL PANEL...............................................................17
5.1 Description of controls....................................................................17
6. FUNCTIONS.........................................................................18
6.1 System functional states..................................................................18
6.1.1 Standby on/off button ....................................................18
6.2 Settings............................................................................................18
6.2.1 Set temperature setting ............................................18
6.2.2 Upper and lower element setting ..................................18
6.2.3 Economy button............................................................19
6.2.4 Start/Stop button...........................................................19
6.2.5 Oven light button ...........................................................19
6.2.6 Switch for suction hood - Light switch for steam
generator.............................................................................................20
6.3 Programming...................................................................................20
6.3.1 Clock and day setting ...........................................................20
6.3.2 Baking cycle programming ...................................................21
6.3.3 Auto switch-on programming................................................22
6.3.4 Timer setting.........................................................................23
6.4 Alarms .............................................................................................23
6.4.1 Overtemperature alarm.........................................................23
7. THE USE OF THE OVEN.....................................................25
7.1 Preparations for use........................................................................25
7.2 Switching on the control panel.........................................................25
7.3 Settings............................................................................................25

INDEX
4
7.4 Starting baking.................................................................................25
7.5 Loading the oven.............................................................................26
7.6 General indications for good baking................................................26
7.7 Switching off....................................................................................27
7.8 Cleaning ..........................................................................................27
8. CLEANING ...........................................................................28
8.1 Cleaning the exposed parts.............................................................28
8.2 Cleaning the parts made from ceramic refractory material..............28
8.3 Cleaning the oven’s cooking chamber.............................................29
8.4 Cleaning external surfaces..............................................................29
9. MAINTAINANCE ..................................................................30
9.1 Changing the halogen lamp.............................................................30
9.2 Wiring diagram ................................................................................31
9.3 Adapting to different voltages of power supply................................31
9.3.1 Rewiring the connections to the elements............................31
9.3.2 Applying the new label..........................................................31
9.4 Exploded diagrams and list of replacement parts............................39
10. DECOMISSIONING AND DEMOLITION...........................46
11. DECLARATION OF CONFORMITY..................................47

1. PRESENTATION
5
1. PRESENTATION
The modular range of “TEOREMA POLIS PW” ovens represent a new
way of thinking about traditional pastry ovens
They are designed and constructed to a high mechanical and electrical
standard and made to last.
Specifically, the STANDARD version is an oven with a redesigned
housing that keeps the internal components of its predecessor , the
TEOREMA POLIS, an oven that has evolved to a high level of proven
reliability.
This version has been designed to offer our clients a highly reliable,
simple oven but with a new styling. This has given us the opportunity to
rethink its structural parts making it even more robust and reliable whilst
including all the suggestions for improvements received from our clients
over the years.
“TEOREMA POLIS PW” a complete range to satisfy everyone’s
needs.
The manufacturer would like to thank you for the preference expressed in
your purchasing this product. We can confidently assure you that it is a
good choice. Our company has been committed to the manufacture of
quality products for many years. We do not believe in making
compromises and use the best possible materials.

2. HOW TO USE THIS MANUAL
6
2. HOW TO USE THIS MANUAL
The paragraphs marked with this symbol contain indications
essential to safety. They must all be read both by installers, the end
user and any employees that use the oven. The manufacturer does
not assume any responsibility for damage or injury incurred as a
result of ignoring the safety criteria outlined in these paragraphs.
This symbol applied to various points on the oven serves to
warn the user of danger: “ATTENTION HOT SURFACES!”.
This symbol, applied to various points on the oven, serves
to warn the user of the presence of a non-insulated “high voltage
hazard” inside the oven’s casing, there being enough power to
constitute a fire risk or to electrocute a person.
The paragraphs marked with this symbol contain important
information to avoid causing damage to the oven. It is in the users
own interest to read these paragraphs carefully.
It is recommended that this installation, instruction and service
manual be kept in close proximity to the equipment so that it can be easily
and quickly consulted. The manual must accompany the equipment if it is
resold as it cannot be considered complete and safe without it.
Take note of the code and the manual version number shown on the
back cover. In the event that this copy is lost or destroyed, you can order
another copy using the details mentioned later in the manual.
This manual is made up of a number of chapters. They should be
read in their entirety by both installers and service personnel as well as by
the end user to make sure that the equipment is used safely and to get
the best results from the product.
However, indications are given on the following pages to help consult
the various chapters more rapidly.

2. HOW TO USE THIS MANUAL
7
Chapter 3 Shows what the equipment can be used for and gives the
specifications of the oven and all the values that are necessary for
choosing the right environment for its installation and use.
This manual should be used as a point of reference to check that the
equipment is being used in the way intended and ensure that information
concerning the precise value of a given measurement or tolerance of the
equipment is available whenever necessary.
Chapter 4 contains all the information needed to install the oven. These
are mainly aimed at specialized personnel but should be read by the end
user beforehand so as to predispose the environment where the oven will
be operated for installation.
Chapter 5 is for reference when the end user needs to find out more
about a specific aspect of the control panel. It is not recommended to
use the contents of this chapter alone to learn to use the equipment
from scratch.
Chapter 6 and 7 are intended for the end user who needs to learn
how to use the oven. These sections guide the user through the
operations necessary for turning on, using and turning off the equipment
under conditions of safety. To take advantage of all the possibilities
offered by the equipment, the user should make reference to chapter 6.
Chapter 8 supplies all the information necessary for the cleaning of the
equipment: all those operations that must be carried out by the user to
guarantee that the equipment continues to function under safe conditions
to ensure suitable conditions for hygiene and health and continue to get
the best results.
Chapter 9 gives information for the periodic operations of maintenance
and extraordinary interventions such as repairs or changing parts of the
equipment.
This chapter also shows an exploded diagram of the appliance and a
list of spare parts to help in ordering and substituting them if they are
damaged.
These maintenance operations must be carried out by
specialized personnel.
Chapter 10 offers information useful in the event that the oven is not
used for a prolonged period.
Chapter 11 facsimile declaration of conformity.

3. TECHNICAL SPECIFICATIONS
8
3. SPECIFICATIONS
3.1 Identifying the product
This manual refers to the TEOREMA POLIS PW range of coking units,
models: 2/MC18, 2/MC30, 2S/MC18, 3/MC18, 3/MC30, 4/MC18, 4/MC30,
6/MC18, 6/MC30, 6/MC18 SUPER, 6/MC30 SUPER, 8/MC18 and 8/MC30
STANDARD version.
3.2 Conformity to European Directives
The TEOREMA POLIS PW STANDARD version cooking units bear the
following obligatory marking:
Guaranteeing their conformity to the following European directives
2004/108/CE electromagnetic compatibility;
2006/95/CE low voltage.
3.3 Use intended for the product
The TEOREMA POLIS PW STANDARD version range of cooking units
have been designed for the catering industry baking pastry products and
are intended exclusively for professional use by trained personnel in the
catering industry.
The operations intended to be carried out with the units during normal use
are: the loading and unloading of products from the hob and baking
chamber, turning on, regulating and turning off the oven and cleaning of the
equipment.

3. TECHNICAL SPECIFICATIONS
9
3.4 Technical specifications
The following tables shows the cooking unit’s technical specifications.
2/MC18
(2/MC30) 2S/MC18 3/MC18 (3/MC30) 4/MC18 (4/MC30) 6/MC18 (6/MC30)
Unit of
measu
rement
Weight 136
(155) 136 179 (207) 200 (230) 275 (310) Kg
External dimensions 1250x1010x360
(1250x1010x480) 1020x1210x360 1660x1010x360 (1660x1010x480) 1250x1610x360 (1250x1610x480) 1660x1610x360 (1660x1610x480) mm
Chamber dimensions 830x660x180
(830x660x300) 650x860x180 1240x660x180 (1240x660x300) 830x1260x180 (830x1260x300) 1240x1260x180 (1240x1260x300) mm
Number of baking
pans (cm 60x40) 2 2 3 4 6
n°
Electrical power
supply triphase or triphase + neutral
Voltage 230 o 400 Vac
Frequency 50 o 60 Hz
Current at 400V 50Hz 8.7 10.5 11.3 17.4 22.6
A
Current at 230V 50Hz 15.1 18 19.6 30.1 39.3
A
Total electrical power 6 6.4 7.8 10 13
kW
Level of protection IP23
Electrical connection cable with 4 or 5 conductors without plug
Length of cable 2 m
Area of conductor
cross section 4 (400V-3N)
4 (230V-3) 4 (400V-3N) 6 (230V-3) 6 (400V-3N) 10 (230V-3) mm2
Chamber illumination lamp
Type Halogen
Power 50 W
Baking control
Temperature Control Electronic temperature control
Maximum temperature
setting 400 °C
Safety thermostat
temperature 500 °C
Power control Separate for oven top and bottom
Environmental conditions
Temperature 0 - 40 °C
Maximum humidity 95% without condensation
Table 3-1

3. TECHNICAL SPECIFICATIONS
10
Table 3-1
6/MC18 SUPER
(6/MC30 SUPER) 8/MC18 (8/MC30)
Unit of
measu
rement
Weight 275
(310) 365 (390) Kg
External dimensions 1660x1610x360
(1660x1610x480) 1660x1880x360
(1660x1880x480) mm
Chamber dimensions 1240x1260x180
(1240x1260x300) 1240x1670x180
(1240x1670x300) mm
Number of baking pans
(cm 60x40) 6 8
n°
Electrical power supply triphase or triphase + neutral
Voltage 230 o 400 Vac
Frequency 50 o 60 Hz
Current at 400V 50Hz 24.6 26.3
A
Current at 230V 50Hz 30 32.7
A
Total electrical power 17 18.2
kW
Level of protection IP23
Electrical connection cable with 4 or 5 conductors without plug
Length of cable 2 m
Area of conductor cross
section 6 (400V-3N)
10 (230V-3) 10 (400V-3N) 10 (230V-3) mm2
Chamber illumination lamp
Type Halogen
Power 50 W
Baking control
Temperature Control Electronic temperature control
Maximum temperature
setting 400 °C
Safety thermostat
temperature 500 °C
Power control Separate for oven top and bottom
Environmental conditions
Temperature 0 - 40 °C
Maximum humidity 95% without condensation

4. INSTALLATION
11
4. INSTALLATION
ATTENTION: these installation instructions are for the exclusive
use of personnel qualified for the installation and maintenance of
electrical and gas equipment conceived for professional use in the
foodservice industry and community catering operations. An
installation carried out by unqualified persons could cause damage
to the oven, to people, animals or property.
ATTENTION: Proceed with the installation according to those
norms in force in the country where it is being carried out.
In addition, where it is necessary to carry out modifications or adaptations
to the electrical or gas systems of the building in which the oven will be
installed, whoever carries out such modifications must certify that the work
has been undertaken according to current “best practices”.
4.1 Checking on delivery
Unless otherwise agreed, the products are carefully packaged in a
robust structure in wood and with a sheet of nylon bubble wrap giving
protection against knocks and humidity during transport. These are
consigned to the freight operator in the best of condition.
We recommend, however, that you to check the packaging on arrival for
any signs of damage. If damage has occurred, have it noted on the receipt
which must be signed by the driver.
Once the equipment has been unpacked, check that it has not suffered
damage. Also check that all the dissembled parts are present.
In the event of damage to the equipment and/or missing parts, bear in
mind that the freight operator can only accept claims within 15 days of
delivery and that the manufacturer cannot be held responsible for damage
incurred to its products during their delivery. We are however, available to
assist you in presenting your claim.
In the event of damage do not try to use the equipment and
consult with professionally qualified personnel.
4.2 Choosing a place for installation
An effective, safe and long lasting functioning of the appliance also
depends on the position in which it is installed. For this reason, it is
advisable to carefully consider where to install the equipment before it is
delivered.

4. INSTALLATION
12
Fig. 4.1
Install the appliance in a dry and easily
accessible place both to facilitate its use
and to carry out cleaning and
maintenance. The area around the
equipment must be kept clear. It is
particularly important to avoid obstructing
the cooling outlets located at the sides of
the equipment.
When choosing a place to install the
cooking units “TEOREMA POLIS PW”,
bear in mind that they must be completed
with other units in the series: hood, chamber, base.
The appliance must be installed at least 20cm from the walls of
the room or from other equipment so that the ventilation outlets
located on the sides of the oven are not obstructed.
Whilst in operation, cooking equipment produces vapor and cooking
smells that compromise the integrity of a healthy working environment
In the case of electric ovens, even if it is not obligatory, the
installation of an extraction fan and hood is recommended to improve
conditions in the working environment and to avoid damage to the ceiling
of the area where it is housed caused by hot, oily fumes.
A check must be made to ensure that the temperature and relative
humidity never exceed the maximum and minimum values indicted in the
specifications (see paragraph 3.4) even when the oven itself or other
ovens in the room are functioning.
Exceeding these values especially the temperature or the maximum
relative humidity can easily and unexpectedly damage electrical
equipment creating hazardous situations.
The manufacturer cannot answer for damage caused by ignoring
these abovementioned norms as well as the information in this
manual.

4. INSTALLATION
13
4.3 Moving the unit
To unload and transport the unit while it
is packed, a pallet truck or a transpallet
lifter with a load capacity at least equal
to that of the unit should be used,
inserting the forks in the spaces
provided at the base of the packing.
To transport the module without
packing, use ropes or straps (certified
as suitable for lifting heavy loads)
threaded through the rings on the top of
the oven and lift with a fork lift truck
(Fig.1).
DO NOT raise the module by inserting forks or bars inside the
cooking chamber because this could cause damage the refractory
material at the top of the oven.
In all situations, to avoid unpredictable movement, be aware of
the equipment’s centre of mass.
Take care that children do not play with the packaging materials
( e.g., plastic sheeting and Styrofoam): suffocation danger!
1

4. INSTALLATION
14
4.4 Positioning and mounting the unit
1 - Position the module on the base
/cell/other unit, maneuvering it as
described at paragraph 4.3 (Fig.2)
2 - Allow the four fixing
Flanges on the corners of the oven
to drop into position (Fig.2)
3 - Secure with the screws provided
(Fig.2)
NO MORE THAN 3 UNITS
SHOULD BE STACKED ONE ON
TOP OF THE OTHER
When one or more units is
mounted on top of another, seal
the gasket around the vapor
exhaust tubes at the back, at the
point where they join. Use high
temperature resistant silicon for this.
4.5 Electrical connection
Before making any connection, check that the specifications of the
electrical supply to which the equipment must be connected, correspond
to the specifications of the power supply required by the apparatus itself
(see Tab. 3-1).
The appliances are supplied with an electric connection with
ground/earth cable for connecting the appliance to the power grid
according to the supply required (see cap. 3.4 Tab. 3-1).
In compliance with the safety norms in force. It is obligatory to connect
the ground/earth cable (yellow-green) to an earthing system with the
same dispersion capacity as the appliance itself. The efficiency of
this system must be correctly verified according to the norms in
force.
2

4. INSTALLATION
15
The power cable must terminate with a plug to connect to the electrical
switchgear having a corresponding differential magneto thermal switch.
The equipment is not supplied with a power plug.
The coupling between plug and socket must be such that the earth
conductor is connected first and disconnected last and must have the right
dimensions for the rated current (see Table 3-1). Plugs and sockets for
industrial use of the type CEE17 are suitable or those which satisfy
European norm EN 60309.
The thermal circuit breaker must be calibrated to the total rated current
and the magnetic circuit breaker calibrated to the rated current (In the
case of ovens this is only slightly higher than rated current), while the
differential mechanism must be calibrated to the 30 mA current (see Table
3-1).
The electrical socket must be easily accessible and must not require
further location after the installation of the equipment. The distance
between the equipment and the socket must be sufficient to avoid
stretching the power cable
The power cable must never be trapped under the feet or
wheels of the equipment
If the Power cable is damaged it must be substituted by
customer support or by a qualified service engineer so as to avoid
any risk.
The manufacturer does not accept responsibility for damage
caused by failure to observe the abovementioned norms.
For the position of the electrical power connections, see Fig. 4-2.
4.6 Emissions from cooking appliances
ATTENTION! Proceed with the installation of the oven
according to the norms defined by current legislation in the country
concerning the installation of this typology of oven so as to
guarantee the sustainability of a healthy working environment. For
more information it is recommended that specific norms be
consulted.
The manufacturer cannot answer for damage caused by ignoring
these abovementioned norms as well as the information in this
manual.

4. INSTALLATION
16
C (mm)
2/MC18 - 2/MC30 560
2S/MC18 445
3/MC18 - 3/MC30 764
4/MC18 - 4/MC30 560
6/MC18 - 6/MC30 764
6/MC18 - 6/MC30 SUPER 764
8/MC18 - 8/MC30 764
A= ELECTRICAL POWER INPUT
B= WATER VAPOUR EXHAUST Ø 200mm
Fig. 4-2 Electrical power connection and water vapour exhaust
4.7 Checking before starting work
After completing installation of the unit a series of checks must be carried
out, listed as follows:
- check that the various disassembled parts have been assembled
- check the power cable
- check that the control panel is working
- If present, check that the ventilation hood is working

5. CONTROL PANEL
17
5. CONTROL PANEL
5.1 Description of controls
Fig. 5.1 shows the control panel with all controls:
General system on/off button
Oven temperature and time
display Set temperature display
Program setting increase button
“Timer” - “Oven temperature” –
Clock setting” display button -
Program setting decrease
button
Upper element power setting
indicator
Upper element control display
Upper element power sequential
increase button
Lower element power setting
indicator
Lower element control display
Lower element power sequential
decrease button
Timer programming button
Baking cycle display
Baking cycle increase button
Oven light on/off
Baking start/stop button
Economy button
Light switch for suction hood
Light switch for steam
generator
Fig. 5.1 Control panel

6. FUNCTIONS
18
6. FUNCTIONS
6.1 System functional states
6.1.1 Standby on/off button
When on standby the panel is powered but no system function is enabled.
The general remote switch is disabled and the message OFF is displayed
on the set display on the control panel along with the current time
on the display with flashing seconds dot (between the second
and third figure, ½ second on, ½ second off).
All buttons on the panel are disabled except for the button (system on)
and the key, pressure on which will bring the system to clock setting
mode (see “programming” section).
Pressing the button, the system comes on, the last SET temperature
programmed is displayed on the set display , and the cycle used
prior to switching the oven off is displayed on the display.
6.2 Settings
6.2.1 Set temperature setting
To set the SET temperature use the and buttons until the desired
baking temperature appears on the display.
6.2.2 Upper and lower element setting
Pressing the buttons varies the time the oven heating elements remain
on. Each time the button is pressed increases this value by 1 unit, up to a
maximum of 9 units. Further pressure returns the value to 0.
NB. Each unit on the two displays corresponds to 5 seconds element on
time. For the remaining units the elements remain off. The total duration of
the cycle is 45 seconds.
The on time of the two elements can be varied at any time, even during the
baking cycle. The upper elements during the first part of the cycle while the
lower ones come on during the second.

6. FUNCTIONS
19
For example, setting the upper elements to 6 and the lower ones to 5 gives
the following result:
5 10 15 20 25 30 35 40 45
Upper ON OFF
Lower OFF ON
Note that with this setting, for the first 20 seconds only the upper elements
are on, so the oven uses half the total power. Over the next 10 seconds
both the upper and power elements are on, with the oven using full power.
In the remaining 15 seconds, on the lower elements are on, so the oven
once again uses half its available power.
6.2.3 Economy button
Pressing the economy button sets power values to pre-set levels
(upper 5 and lower 3) with the following result:
5 10 15 20 25 30 35 40 45
Upper ON OFF
Lower OFF ON
Note that with this setting, in the first 25 seconds only the upper elements
are on, with the oven using half power. Both elements are off for the
following 5 seconds. In the remaining 15 seconds only the lower elements
are on and so the oven once again uses only half power. This means that
throughout the cycle the oven never uses more than half power and for 5
seconds power consumption is zero.
A similar result can be obtained through manual power settings, if the sum
of upper and lower times is less than or at most equal to 9.
6.2.4 Start/Stop button
Pressing the start/stop button starts the baking cycle according to the
previous setting.
6.2.5 Oven light button
Pressing the oven light button switches on the light in the oven. Press
again to switch it off.

6. FUNCTIONS
20
6.2.6 Switch for suction hood - Light switch for
steam generator
The switch for suction hood control is
placed on the side part of the suction
hood, on the upper side (Pos.1 of Fig.
6.1).
Push this switch on position “I” to start one
of the two motors of the suction hood.
Push this switch on position "II" to start
both motors of the suction hood. Push this
switch on position “0” to stop it.
On the side part of the control panel, you
find the light switch that starts and stops
the steam generator, if the oven is
equipped with this accessory (see Pos.2 -
Fig. 6.1).
6.3 Programming
6.3.1 Clock and day setting
The time and day can only be set with the system on standby, that is to say
when the display “OFF”.
Pressing the key and holding it for 3 seconds displays the time on the
display with the two figures corresponding to the hour flashing.
The correct hour can be set using the and keys. To memorise the
new hour setting and pass on to setting minutes, press the key again.
The minutes start flashing and can be set in the same way as the hours.
Before pressing again, set the day of the week using the upper
element power sequence button . This displays the number
corresponding to the day on the upper element control display .
For example:
1=MONDAY
2=TUESDAY
3=WEDNESDAY
4=THURSDAY
5=FRIDAY
6=SATURDAY
7=SUNDAY
Pos.1
Pos.2
Fig 6.1
