Diaz Framefix User manual
FramexTM
www.diaz.be 1
V. 21-01
Use our measuring tool to mesure a window for a FramexTM. Make sure the
magnetic tape covers the window frame completely. If this isn’t the case,
the window isn’t appropriate for the FramexTM.
Measurement
1
2Put the measuring tool in all four corners and mark the outsides.
Measure the window from line to line.
* Always take the smallest size.
Manual
FramexTM
breedte
hoogte
W1*
W2*
H1* H2*
width
height
FramexTM
www.diaz.be 2
V. 21-01
Assembling the corners
Attach the magnetic strips to one another
<1 mm
Do NOT remove the green coloured protection foil of the upper magnetic strip!
Attach the 2nd magnetic strip to the already attached strip, with the protection foil
directed to you.
1
FramexTM
www.diaz.be 3
V. 21-01
Fix product in the frame
Horizontal blind with side guidance
A
Attach the blind in the supports.
Pull the cable through the predrilled whole and x the xation ring
onto the cable.
Push the xation ring through the prole and put tension on the cable.
1
2
3
FramexTM
www.diaz.be 4
V. 21-01
Horizontal blind Top-Down-Bottom-Up
B
‘CLICK’
‘CLICK’
Pull down the cords
simultaneously
using both hands.
FramexTM
www.diaz.be 5
V. 21-01
Plissé (type VS)
C
2
1
1
2
FramexTM
www.diaz.be 6
V. 21-01
Installation FramefixTM
1*
1*
1*
2
2
1
1
1*
1*
1*
2
2
1
1
1*
1*
1*
2
2
1
1
Remove the green coloured protection foil
of the magnetic strip and put the frame
onto the window frame. Start at the bottom,
and work your way up. Fix the frame by pushing
the entire frame evenly.
1
Prepare the window
It is important to degrease the surface
on which you will mount with the towels
that were sent.
Let the surface dry during 5 minutes
after degreasing it.
Put primer on the surface. The primer contains
a capsule which you should break by pressing
the black circle. Then, the primer coating
can be applied.
Let the surface dry another 5 minutes.
1 2
Primer
ATTENTION! Fix your FrameFix
only onto a dry & dust-free
surface.
Please do not use the blind within the rst 6 hours after mounting.
The glue in the magnetic tape gets stronger during the rst 12 hours after mounting.
