VENETA 65101-21717-B Instruction sheet

Inside Video Outside Video
How to install your
#65101-21717-B
Aluminium Venetian Blind
Required Tools
Included Hardware
measuring
tape
drill with
2mm bit
phillips bit or
screwdriver
pencil knife
The hardware can be found in
the end of every box.
Installation
Bracket
Hold Down
Bracket
Child Safety
Cleat
Medium & Long
Screws for
Wood
1Installation Brackets
With the bottom of the blind angled slightly towards you,
position the top front of the blind onto the top front lip of the
brackets.
Tilt the blind up at the back noticing it click into place.
2Install Blind
When wand length is longer than blind width, a connector
will be used.
Slide wand hook through eyelet on headrail.
3Attach Wand (if ordered)
Need HELP?
Customer Service
1300 836 382
“the best compliment
you can give
is a referral”
Installing inside the window frame…
At top of window frame, measure 70mm in from each side and
39mm back from front of window frame and mark with a pencil; this
is the centre back of the outer brackets.
Place brackets in position and mark where the 2 screws will go.
We recommend drilling pilot holes for the screws using a 2mm bit.
Fix the brackets into position using 2 long screws for each bracket.
If more brackets are supplied, space them evenly between the first
two brackets.
Installing outside the window frame…
Measure 70mm in from top left and top right of where the blind will sit
and mark with a pencil; this is the centre of where the brackets will go.
Place brackets in position (normally flush with top of architrave) and
mark where the screws will go.
We recommend using a spirit level to align brackets if not installing
on the architrave.
We recommend drilling pilot holes for the screws using a 2mm bit.
Fix the brackets into position using 2 long screws for each bracket.
If more brackets are supplied, space them evenly between the first
two brackets.
Space evenly
70mm 70mm
39mm
Wall Plugs for Brick
or Cement using
a 6mm bit
(if requested)

Installation
continued…
How to install, operate and maintain your
Aluminium Venetian Blind
4Hold Down Brackets
Installing inside the window frame...
Position hold down bracket vertically inside window frame where the
bottom rail hangs naturally, mark where the 2 screws will go.
We recommend drilling pilot holes for the screws using a 2mm bit.
Fix bracket into position using 2 medium screws.
Insert bracket knob into bottom rail.
Repeat for bracket at other end of bottom rail.
Installing outside the window frame...
Position hold down bracket horizontally outside window frame where
the bottom rail hangs naturally, mark where the 2 screws will go.
We recommend drilling pilot holes for the screws using a 2mm bit.
Fix bracket into position using 2 medium screws.
Insert bracket knob into the bottom rail.
Repeat for bracket at other end of the bottom rail.
5Child Safety Cleat
Great Job… Enjoy your new Veneta Blinds!
Attach the Child Safety Cleats to the wall at least 1.6 metres off the ground
using 2 medium screws for each cleat. Ensure the cleat is fixed firmly.
Tie all the loose lift cord around the Child Safety Cleat at all times.
To avoid creating a possible
strangulation hazard for children,
the corded or chained internal
window covering must be installed
in such a way that a loose cord or
chain cannot form a loop 220 mm
or longer at a height of less than
1600 mm above floor level.
A cord/chain guide may be
installed lower than 1600mm
above floor level if the
cord/chain is sufficiently
secured or tensioned to
prevent a loop 220 mm or
longer from being formed.
If a cord/chain guide is
installed lower than 1600 mm
above floor level, it must be
designed to prevent a child
from being able to remove the
cord/chain.
If a cleat is used to secure the
cord, it must be at least 1600 mm
above floor level because a
child is capable of unwinding a
cord from a cleat.
www.venetablinds.com.au/child-safety
WARNING
ALL WINDOW COVERINGS
WITH CORD OR CHAIN
Operating your
Blind
Tilt the slats by using the twin cords or the wand.
Raise or lower your blind with the lift cord.
Pull the cord down and to the centre of blind to
unlock, then move to desired position.
Move cord to the outside of blind to lock into position
and release.
Maintaining your
Blind
Dust can be removed using a feather duster or
vacuum with brush attachment on low suction.
Clean your Aluminium Venetians using a warm damp
cloth. Do not use solvents or chemicals.
If the Safety Tassel happens to break apart, simply gather
the cords without twisting and place into the slot as per
diagram. Close the cord release door and pull the cords to
make sure the Tassel is closed tightly.
Please write a review on our
website at…
www.venetablinds.com.au
Feedback?
We would love to know how you
went with your installation…
