3G SOHO 14/07/2008
Wireless 3G Gateway HSDPA & HSUPA Station
3G SOHO - Code 8D5634
3G SOHO PLUS - Code 8D5635
l3.5G/HSUPA/HSDPA Wireless Gateway
lFast Internet with 7.2 Mbps UMTS Technology
lSimultaneous Internet and Voice call
l2 Mbps Upload transmission
l65.000 colors display
lSend and Receive SMS with your 54M Wireless PC
lRemotecongurationandManagement
l1analogphone FxS port
l1 FxO port for
Mobile eXtension applications
l Built-in ADSL 2/2+ Router function (optional)
lBattery Backup (optional)
DESCRIPTION
3GSOHObelongstoDigicom’sGatewaysnewgeneration,projectedand
carriedoutusingthelatestwirelesstechnologies.
INTERNET
3G SOHO is the ideal solution for High-speed Internet connectionsusing
HSDPA technology (1) at 7.2Mbps. Furthermore thanks to the HSUPA
standard support,thegatewaycantransferthee-mailattachedleswith
an upload speed up to 2Mbps (1).
PHONE
Easy call with 3G SOHO: just connect a traditional phone to the TEL
connector to make a call via GSM,asitwereamobilephone.Thebilling
systemwillbethenGSMtoGSMwithconsiderablesavingsifcomparedto
thePSTN-mobilerates.
Note 1: The support of HSDPA and HSUPA technologies and their
Download/Upload speeds depend on the mobile operator.

For further information visit our
website http://www.digicom.it
Itisidealforalltheapplicationsofsmallremoteofce,
teleworking, for the management of agents network,
etc.
MANAGEMENT AND CONFIGURATION
Conguration and management of 3G SOHO are
carried out via WEB interface, independently by the
operatingsystem.
Asfortheapplicationswithmobiletelecomoperators,it
issupportedthemanagementofTR069protocol.
VoIP and Fax T.38 Ready
Digicom’s gateway is ready for the latest generation
applications that forsee the use of Full-IP technology
even for the transmission of Voice and Fax.
Thanks to Digicom’s long experience in carrying out
VoIP CPE - Customer Premise Equipment, 3G SOHO
is ready to integrate the IP Telephony and the T.38
Fax mode.
SMS
ThroughtheWEBinterfaceyoucansend and receive
SMS.TheinformationofSMSreceivedisdisplayed.
DISPLAY
All the main information about the gateway status are
supplied on a 65.000 colors display, for example
the coverage level, the caller ID connection, the SMS
received,thelostcalls,thedateandtimewillbeavailable
onthedisplaytoguaranteethemaximumefcency.
LAN and Wi-Fi
3G SOHO uses the 54M Wireless LAN technology for
the connection to your laptop. A LAN Ethernet port is
available for the wired connection.
MOBILE EXTENSION (Optional)
3G SOHO has a full series of options that add high
value functions like an FxO analog port or the built-in
ADSL Router.
The Mobile eXtension function, performed with the
FxOanalogport,canremotemanageallthecallsofyour
PSTNline(orPABXextension)onthemobilephone.
SoyouwillbeabletoansweracallcomingtothePSTN
line with your mobile phone. You will also call from your
mobilephoneusingthePSTNline.
This function is very useful in applications of mobile
companyLANwhereyoucanremotemanagethePABX
line on your mobile phone.
You will be able to operate and work as if you were in
ofceevenwhenyouareaway.
UMTS
Network
3G Soho
FxS
Port
ring...ring...
ring...ring...
Hello!
335 12345678
FxO
Port
Dial
0331-702(611)
PABX
PSTN

For further information visit our
website http://www.digicom.it
3G SOHO 14/07/2008
ADSL (Optional)
3G SOHO can be equipped with a built-in ADSL2/2+ Router.
Inthisway,incaseofBACKUP of the ADSL line orformobile-to-mobilecalls(inLeastCostRoutingapplication),
the UMTS module can be used.
BACKUP
Withthebuilt-inADSLrouteroptionandthepossibilitytousetheUMTSnetwork,youcanbealwaysonlineeven
whentheADSLlineisdown.Youre-mailwillbealwaysavailableandyoucanbereachedviaphonethroughthe
mobile network.
Youcanalsoaddabackuprechargeablebatteryinordertohaveyourgatewayalwaysoperativeevenwhenthe
electric power is down.
LEAST COST ROUTING
Thismodeallowsasaving on the telephone bill (2),usingthemobilenetwork,insteadofthePSTNone,forthe
mobile-to-mobile calls.
Dependingontheprexesinsertedduringtheconguration,3GSOHOwillcallusingthemobilenetworkinsteadof
thePSTNnetworkwithaconsiderablesavingonthetelephonebill.
InordertoperformthisapplicationitisneecessarytheFxOoptionontheproduct.
Note 2 : The telephone saving depends on the rates plan defined by your operator for the prefixes inserted
during the configuration.
3G Soho
UMTS
INTERNET
ADSL
Firewall
Computer
Wireless
Camera

For further information visit our
website http://www.digicom.it
TECHNICAL FEATURES
Wireless WAN
l3G Gateway for Small Office/Home Office or Consumer
applications
lUMTS Technology with HSDPA Category 8 (7.2
Donwnlink)
lHSUPA Category 5 (2.0 Uplink update to 5.76 Mbps)
lEDGE/GPSR Class 12
lBands: UMTS 2100/1900/850 MHz
lBands: EDGE/GPRS/GSM 850/900/1800/1900MHz
Hardware
l1.8” 65.000 colors display
lWEB based local and remote configuration
l1 FxS analog phone port
l1 FxO (optional) analog port for Mobile eXtension
applications
lLAN: 1 10/100 Ethernet port
lSize and Weight: 295 x 140 x 75 mm; 450gr.
lReset to Factory Default Button
l1 SIM holder
l12VDC/1.2A external power supply
lOperating temperature 0-40 ºC
l20-95% non condensing humidity
lBackup Battery (optional) Li-ion 7.4 V /850 mA
lCE Mark
Network Functionalities
lFull Routing IP (static and dynamic, NAT, Dynamic DNS
(DDNS)
lFirewall function (SPI) and protection from DoS attacks
lPacket Filtering, URL content
lDMZ, VPN Pass-through
lDHCP Server/Client support
Wireless LAN
lWireless up to 54Mbps (IEEE802.11g, b)
l64/128 bit WEP, WPA-PSK/WPA2-PSK encryption
Management
lWEB based local and remote configuration and
management
lFirmware upgrade through WEB interface
lManagement via TR069 protocol
dware
ADLS (optional)
lBuilt-in ADSL 2/2+ Router
lStandard ADSL2+, G.dmt bisplus (ITU G.992.5); ADSL
2 G.dmt.bis (ITU G.992.3), Full.rate ANS T1.413 Issue
2, G.dmt (ITU G.992.1), G.Lite (ITU G.992.2) G.hs (ITU
G.994.1), ATM Adaptation Layer Type 5 (AAL5)
lMultiple Protocol over AAL5 (RFC 2684 Formely RFC
1483); Bridge or Routed Ethernet encapsulation, VC and
LLC based mux
lPPP over Ethernet (PPPoE) and PPP over ATM (PPPoA)
esso
3G SoHo is available in 2 versionstosatisfyallthecustomer’sneeds.
ThePLUSversionhas1FxOphoneinterfacetousetheadditionalfunctionsofMobileeXtensionandtheconnection
toPABXextensionside,thenitcanbeusedasagatewayfortheincomingcalls.
ItisequippedalsowiththeADSL2/2+routerfortheBack-uporInstantOfceapplications(whilewaitingfortheADSL
connection,youusethe3Gone).
8D5634 - 3G SOHO-GatewayHSDPA/HSUPA7.2MDownload-2MUpload,1interfacciaLAN10/100,1FxSVoiceport
8D5635 - 3G SOHO PLUS -GatewayHSDPA/HSUPA7.2MDownload-2MUpload,110/100LANinterface,1FxSVoice
port,1FxOVoiceport,built-inADSL2/2+router
