Silencing an Alarm
While the  re alarm horns, strobes, or sirens are sounding,
use one of the following methods to silence the alarm
depending on which type of keypad is installed.
630F Function Keys
While the alarm bell or siren is sounding, turn the keyswitch
to the ENABLE position and press the SILENCE key. The
keypad displays
ALARM SILENCED
.
630F LCD Display Keypad
While the alarm bell or siren is sounding, enter the
programmed user code followed by the
COMMAND
key. The
keypad displays
ALARM SILENCED
.
692F LED Keypad
Press the
SILENCE
key and enter the programmed user code
followed by the
COMMAND
key to silence a system alarm and
the keypad sounder.
Resetting an Alarm
The panel must be silenced before it can be reset. Follow
procedure to the left to silence the alarm.
630F Function Keys
Turn the keyswitch to the ENABLE position and press the
RESET key. The sensor turns off then turns on. The keypad
and system are reset.
630F LCD Display Keypad
Press the
COMMAND
key until
MENU? NO YES
displays.
Press the key under
YES
. Enter the programmed user code
followed by the
COMMAND
key. The display reads
SENSOR
RESET?
Press any top row key. The sensor turns off then
turns on. The keypad and system are reset.
692F LED Keypad
Press the
RESET
key and enter the programmed user code
followed by the
COMMAND
key to reset the panel. It takes
 ve seconds for the panel to reset.

XR5 User’s Guide
i
User’s Guide
for XR5 Fire Command™ Panels
Table of Contents
Section
Page
Section
Page
Emergency Evacuation Plans
...................................
iv
Draw a Floor Plan of Your Home or Business
.....................
iv
Develop Escape Routes
...................................................
iv
Decide Where to meet
....................................................
iv
Practice Your Escape Plans
..............................................
iv
Early Detection
...............................................................
iv
About this User Guide
...............................................
5
About the 630F LCD Keypad
.....................................
6
The 630F LCD Keypad
.....................................................
6
Function Keys
...............................................................
..
6
End User Options
............................................................
8
Fire System Terms
....................................................
8
Fire Command Messages
..........................................
9
Fire Command Tones
..............................................
10
Silencing the Bells During an Alarm
................................
10
Silencing the Keypad Trouble Sounder
............................
10
Keypad User Menu
..................................................
10
Sensor Reset
..........................................................
11
System Test
............................................................
12
Fire Drill
...............................................................
...
12
User Codes
..............................................................
12
Display Events
........................................................
13
Zone Event Displays
......................................................
13
Zone Bypass Event Displays
...........................................
13
Supervisory Event Displays
............................................
14
Auto Recall Event Displays
.............................................
14
About the 692F LED Keypad
...................................
15
Function Keys
...............................................................
15
Data Entry keys
............................................................
15
Command key
..............................................................
15
System LEDs
...............................................................
.
15
Zone Alarm and Trouble LEDs
........................................
16
Alert Tones
...............................................................
...
16
Keyboard Backlighting
...................................................
16
Keypad Function Keys
............................................
16
Resetting Sensors
..................................................
17
Testing the System
.................................................
17
User Codes
..............................................................
17
2-Button Fire Keys
..................................................
17

ii
XR5 User’s Guide
Emergency Evacuation Plans
Practice Your Escape Plans
Devising an escape plan is only the beginning. For the plan to
be effective everyone should practice escape routes from each
room.
Second Floor
Building Front Building Back
First Floor
Fire Escape
Window Ladder
Sample Escape Route Map
Early Detection
The best way to survive a  re or other emergency is to get out
early. A  re alarm system installation, with smoke and carbon
monoxide detectors in each room, can greatly decrease your
risk of loss or injury.
The National Fire Protection Association recommends that you
establish an emergency evacuation plan to safeguard lives in
the event of a  re or other emergency.
Draw a Floor Plan of Your Home or Business
On a clean sheet of paper, draw the walls, windows, doors,
and stairs. Also draw any obstacles that a person may
encounter while exiting the building such as large furniture or
appliances.
Develop Escape Routes
Determine at least two routes the occupants in each room can
take to safely escape. One route can be the most obvious such
as the door. Another can be through an easily opened window.
If the window is high off the ground, an escape ladder should
be provided.
Draw arrows on the  oor plan to show escape routes from each
room.
Decide Where to meet
Prearrange a meeting place outside and away from where
emergency personnel are likely to be working. A neighbor’s
house or across the street in front of the house are good
locations. Always perform a head count to make sure all
occupants safely exited. NEVER ENTER A BURNING BUILDING.
If the head count shows one or more persons missing, give this
information immediately to the authorities. Never enter a
building to look for someone.

Introduction
XR5 User’s Guide
1
Description
630F LCD Fire Command Center
692F Fire Command LED Keypad
The XR5 Fire Command™ system has been designed with your
safety in mind using the latest in computer technology.
You can perform system functions such as silencing bells by
pressing a few keys. You can also change the personal user
code at any time.
About this User Guide
This User Guide discusses features of the XR5 Fire Command™
system using the 630F LCD keypad and the 692F LED keypad.
The guide is divided into two sections that discuss using the XR5
system with either the LCD keypad or the LED keypad. Turn to
the appropriate section for information about controlling your
Fire Command™ system with your particular keypad model.
If you are not sure which model you have, please compare your
keypad with the following images.

2
XR5 User’s Guide
LCD Keypad User’s Guide
LCD Keypad User’s Guide
RESET Key
Pressing the RESET key performs a sensor reset and silences the
alarm bells.
TEST Key
Pressing the TEST key performs a system test.
DRILL Key
Pressing the DRILL key displays a prompt “SURE? YES NO”. Press
YES to begin the  re drill. Press NO to return to the status
list.





   
   
 
   
   












630F Fire Command Center
About the 630F LCD Keypad
The 630F LCD keypad has many features to allow you to properly
operate the system and review previous event history. The
keypad provides a passcode protected User Menu where you
can access the functions needed to operate the system. See
Keypad User Menu
. In addition to the User Menu, items on the
following pages list speci c and common operational features.
The
630F LCD Keypad
All of the 630F Fire Command Center keys, except the four
function keys, can be used at any time without turning the
keyswitch. You can only use the four function keys when the
keyswitch is turned to the enable position. It is not necessary
to use the keyswitch when using a user code to perform
operations.
The following descriptions and illustration highlight the speci c
630F Fire Command Center features.
Four
Function Keys
The 630F Fire Command Center is designed with four keys on
the left side of the keypad. After turning the keyswitch, you
can quickly perform vital functions using these four keys.
SILENCE Key
Pressing the SILENCE key silences the alarm bells.

LCD Keypad User’s Guide
XR5 User’s Guide
3
630F Status LEDs
The 630F keyboard provides three LEDs to indicate the system
status.
POWER LED
remains ON steady when both AC and battery input
are good. The LED turns OFF when AC input is low. The LED
 ashes for 1/2 second intervals when battery input is low.
TROUBLE LED
turns ON when any trouble is displayed in the
status list, such as AC, battery, phone line, transmit, NAC, or
any zone trouble. This light is OFF when no trouble displays in
the status list.
ALARM LED
is ON when any alarm currently displays in the
status list. This LED is OFF when no alarm is currently displayed
in the status list.
Select keys
These keys allow you to choose an option by pressing the Select
key under the choices shown in the display.
LCD display
The keypad uses a backlit LCD display and plain English text to
show events occurring on your system.
Data Entry keys
These keys allow you to enter the code number when using the
system.
Back Arrow key
The Back Arrow key allows you to back up through the list of
functions in the User Menu, or make corrections when enter ing
in formation.
COMMAND key
The COMMAND key allows you to advance through the options
on the keypad display, and enter information into the system.
Power LED
This remains on steady as long as your  re system is connected
to its AC power supply. Should there be an interruption, the
green LED turns off. The system backup battery maintains
normal operation for a time, allowing you to contact our
service department. Should the battery power become low,
the Power LED  ashes.

4
XR5 User’s Guide
LCD Keypad User’s Guide
Keypad Address
The LCD displays the keypad’s current address. The information
cannot be changed by the user. Press the Back Arrow key to exit
the
User Options
function.
Model Number
The keypad model number,  rmware version, and date display,
but cannot be changed.
Fire System Terms
Zone
A zone refers to one or more  re system devices. For example,
smoke detectors on the east side of the premises can be
grouped together under the zone name
EAST SMOKES
.
Central Station Monitoring
Your system can also be programmed to send alarm and trouble
reports to a central station where operators can dispatch the
appropriate authorities.
Status List
Status is a feature that automatically displays the status of your
system on the keypads. The Status List displays alarm or trouble
conditions on zones and trouble conditions that occur with AC
or battery power or the phone lines. If more than one alarm or
trouble condition occurs at the same time, the keypad displays
this information in order of occurrence.
End User Options
The User Options allow you to make adjustments to your keypad
to best  t your environment and needs.
To access the User Options portion of the keypad, press and
hold the Back Arrow and COMMAND keys for two seconds. The
keypad display changes to SET BRIGHTNESS.
Press the COMMAND key to display the next option or the Back
Arrow key to exit.
Backlighting Brightness
Sets the keypad LCD and AC LED brightness level. At the
SET BRIGHTNESS display, use the left Select key to lower the
keypad brightness. Use the right Select key to increase the
brightness.
Note:
If the brightness level is lowered, it temporarily reverts
back to maximum intensity whenever a key is pressed.
Internal Speaker Tone
Sets the keypad internal speaker tone. At the SET TONE display,
use the top left Select key to make the tone lower. Use the
right Select key to make the tone higher.
Volume level
Sets the keypad internal speaker volume level for key presses
and prewarn conditions. During alarm, trouble, and prewarn
conditions, the volume is always at maximum level. At SET
VOLUME LEVEL, use the left Select key to lower the keypad
volume. Use the right Select key to raise the volume.

LCD Keypad User’s Guide
XR5 User’s Guide
5
Fire Command Messages
SYSTEM NORMAL
This display indicates that  re protection devices, phone lines
to the panel, and the panel itself, are in good condition.
ALARM
A  re, supervisory, or auxiliary zone has been tripped. Your
system may sound the  re bells, strobes, and any other response
programmed into the system.
SILENCED
A user has silenced the  re bells by entering the code or by
using the Alarm Silence function in the User Menu. Even though
the bells are silenced, the system is still in a state of alarm. A
red LED on your keypad is on until a Sensor Reset is performed
(see the inside front cover).
SUPVSRY
A supervisory alarm has occurred and is in the Status List for
review.
BYPASS
A zone has been disabled by the system due to repeated trips.
If the zone remains normal for one hour it can be restored into
the system.
ENTER CODE
The system requires you to enter the user code. As you enter
the code, the display shows an asterisk (*) in place of each digit
pressed.
TRY AGAIN
The user code you have entered is not recognized by the
system. Check the code and try again.
INVALID CODE
You receive this message if you enter an incorrect user code a
second time, after receiving the Try Again message.
PH LINE 1 TRBL
There is a problem with the phone line connected to your
system. Call for service as soon as possible.
TROUBLE
There is a problem with a protection device or system
component. This display is accompanied by a description of the
problem.
SERVICE REQUIRED or SYSTEM TROUBLE
There is a problem on the system. Call for service.

6
XR5 User’s Guide
LCD Keypad User’s Guide
Fire Command Tones
Your keypad also contains a small speaker that alerts you about
events as they occur on your system.
Fire Alarm tone
: An intermittent sweeping siren that sounds
until the  re alarm is silenced.
Key press tone
: A short beep each time you press a key on the
keypad and it is acknowledged by the system.
Trouble tone
: A steady tone indicating a trouble condition on
your system. Press a Select key to silence.
Silencing the Bells During an Alarm
630F Keyswitch
While the alarm bell or siren is sounding, turn the keyswitch to
the ENABLE position and press the SILENCE key. The SILENCE
key does not stop an alarm report from being sent to the central
station and does not reset any alarmed devices.
630F Code Entry
While the alarm bell or siren is sounding, enter the user code.
The keypad displays
ALARM SILENCED
.
Silencing the Keypad Trouble Sounder
630F Keyswitch
To silence the trouble sounder in the keypad, turn the keyswitch
to the ENABLE position and press the SILENCE key.
630F Code Entry
To silence the trouble sounder in the keypad, press any Select
key and enter the user code.
Keypad
User Menu
Many of the features of your system are accessible in the User
Menu you can access from the keypad. The menu requires you
to enter the user code before you can access any functions.
To access the User Menu:
1. Press the COMMAND key until
MENU? NO YES
displays.
2. Select
YES
. The keypad displays
ENTER CODE: –
. Enter
the user code and press the COMMAND key. You can now
scroll down through the list of menu options.
User Menu Options
The list shows the User Menu options in the order they appear
in the display. A detailed description of each option follows in
this guide.

LCD Keypad User’s Guide
XR5 User’s Guide
7
Menu Option
Description
SENSOR RESET
Resets smoke detectors that have
latched due to an alarm condition.
SYSTEM TEST
Tests the system siren, communication
to the central station and backup
battery.
FIRE DRILL
Allows you to practice  re drill
evacuations.
USER CODES
Allows you to change the user code.
DISPLAY EVENTS
Allows you to view or print the last 16
events that occurred on your system.
The following pages detail each user menu item and provide
instructions on when and how to use them properly.
Sensor Reset
Function:
Sensor Reset momentarily removes power to smoke
detectors allowing them to reset after they have tripped. The
detectors must be reset before they can detect any additional
alarm conditions.
Make sure all smoke is cleared from around the smoke detectors
before performing a Sensor Reset to prevent the alarm from
occurring again.
1.
Access the User Menu.
2.
When
SENSOR RESET?
displays, press any Select key.
The keypad displays
SENSORS OFF
for  ve seconds
followed by
SENSORS ON
.
3.
The keypad returns to the status display.

8
XR5 User’s Guide
LCD Keypad User’s Guide
System Test
Function
: Tests the battery, alarm bell or siren, and
communi cation to a central station. The System Test function
begins automatically as soon as you select it.
1.
Access the User Menu. Press the COMMAND key until
SYSTEM TEST?
displays.
2.
Press any Select key. The system test begins
automatically and the keypad displays:
1)
BELL SOUNDING
during a two second bell test,
then:
2)
BATTERY - OKAY
or
BATTERY - TRBL
or BATTERY - TRBLor
to indicate
the condition of the battery, then:
3)
*
TRANSMIT TEST
and
ATTEMPT NO : 1
during the
transmit test, then:
4) *
TRANSMIT OKAY
or
TRANSMIT FAILED
to show the
results of the transmit test, then:
5)
TEST END
to indicate the System Test is complete.
6)
You can cancel the transmit test by pressing the
Back Arrow key.
* The transmit tests are not applicable for local
systems.
Fire Drill
Function:
Allows you to practice  re drill evacuations.
1.
Access the User Menu. Press COMMAND until
FIRE DRILL
displays.
2.
Press any Select key. The keypad displays
SURE? NO
YES
. Press the Select key under
YES
. The system rings
the bells until you enter the user code or until the
programmed bell time expires.
User Codes
Function
: Allows you to change the user code number you
enter at the keypad.
NOTE:
The user code must always have 4 digits.
1.
Access the User Menu.
2.
Press
COMMAND
until
USER CODES
displays. Press any
top row key.
3.
The keypad displays
CODE NO: * * * *
. Press any top
row key to clear the existing user code.
4.
The keypad displays
CODE NO: —
. Enter a new 4-digit
user code.
If the code you entered is a special service code used internally
by the system, the keypad displays
ALREADY IN USE
. You must
enter a different user code.

LCD Keypad User’s Guide
XR5 User’s Guide
9
Display Events
Function:
Allows you to review up to 16 past events that
occurred on your system in the order of their occurrence.
The system records two event types:
Zone Events
- Records zone alarms, troubles, restorals, and
service.
Supervisory
- Records problems with the system’s hardware
components.
The system’s memory can hold up to 16 events. After 16 events
are in memory, any new event causes the oldest event to be
cleared.
1.
Access the User Menu.
2.
Press COMMAND until
DISPLAY EVENTS?
appears.
3.
Press any Select key. The keypad displays the  rst
recorded event. Use COMMAND to scroll down through
the event displays.
Use the Back Arrow key to scroll back up through the event
displays. If you press the Back Arrow key when you  rst enter
Display Events, the keypad returns to the Status List.
Zone
Event Displays
# FIRE ALARM
The display actually contains three separate sections.
#
- Records the zone number. Press the Select key under the
zone number to display the custom zone name programmed into
the system.
FIRE
- This is the type of zone on which the activity occurred.
There are three possible zone types you may see on your
keypad.
FIRE - Fire
SUPV - Supervisory
AUX1 - Auxiliary 1
ALARM
- This is the event that occurred. There are 3 event
types:
ALARM
TROUBLE RESTORE
Zone Bypass Event Displays
# BYPAS
BYPAS -
This zone has been bypassed by the system.
RESET
- This zone has been reset by the system.
Press the Select key under the zone number to display the
custom zone name programmed into the system.

10
XR5 User’s Guide
LCD Keypad User’s Guide
Supervisory Event Displays
POWER TROUBLE
The display contains two separate sections.
POWER
- The type of condition that occurred on your system.
POWER - The type of condition that occurred on your system.POWER
POWER - Problem with the AC power supply.
PH LINE # - Problem with phone line 1 or 2.
BATTERY - Problem with a low battery. This could be due to
the battery exceeding its life expectancy. Call the service
department whenever you see a low battery display.
The status regarding that condition.
TROUBLE
RESTORE
Auto Recall Event Displays
Your system sends periodic recall (test) reports to the central
station to test the communications link. Each successful test
transmission is logged into the Display Events and shown as
AUTO RECALL
.

LED Keypad User’s Guide
XR5 User’s Guide
11
About the
692F LED Keypad
This device has been placed at locations throughout the
premises to allow you to properly operate the system.
AABBCCDDEEFFGGHHIIJJKKLL
VVWWXXMMNNOOPPQQRRSSTTUU
YYZZ
9 0
2 3 4
5 6 7 8
COMMAND
1
SILENCED
TROUBLE
POWER
ALARM
TROUBLE
1 2 3 4 5
SILENCE RESET TEST CODE
SPECIAL
System LEDs
Zone
Alarm
LEDs
Backlit Data
Entry Keys
Function
Keys
COMMAND Key
SPECIAL Key
Zone
Trouble
LEDs
692F LED Keypad Operational Functions
Function Keys
There are four keys under the display called the Function keys.
These keys allow you to perform system operations by pressing
one key, followed by the entry of a user code.
SILENCE Key
Press the SILENCE key to silence the alarm bells.
LED Keypad User’s Guide
RESET Key
Press the RESET key to perform a sensor reset and silence the
alarm bells.
TEST Key
Press the TEST key to perform a system test.
CODE Key
Press the CODE key to change the user code.
Data Entry keys
These keys allow you to enter your user code and other
information into the system.
COMMAND
key
The COMMAND key allows you to complete a data entry
function.
System LEDs
The Fire Command Center incorporates three LEDs to indicate
the status of the system. The three indicator lights are described
below.
Yellow Silenced LED
On
when the bells are silenced manually from the keypad or
after the Bell Cutoff time.
Off
when a Sensor Reset is performed or if the alarm sounds
Off when a Sensor Reset is performed or if the alarm sounds Off
again.

12
XR5 User’s Guide
LED Keypad User’s Guide
Yellow Trouble LED
On
when the system is unable to send a report to your central
station or when the phone line is in a bad condition.
Off
when the system is operating correctly.
Off when the system is operating correctly.Off
Pulse
(1 second on, 1 second off) when there is a problem with
the system. Call for service.
Green Power LED
On
when AC and battery power are okay.
Off
during AC trouble.
Flash
(1/2 second on, 1/2 second off) when the system’s
battery is low or missing.
Zone Alarm and Trouble LEDs
Red Zone Alarm LEDs
On
steady during an alarm condition.
Off
when the zone has restored to normal and a Sensor Reset
has been performed.
Yellow Zone Trouble LEDs
On
during a trouble condition.
Off
when the zone restores to normal.
Pulses
if the zone alarm or trouble is a Supervisory type zone.
Alert Tones
Steady Tone
indicates a trouble condition on the system or a
 re zone. Follows the operation of the bells. Pressing any key
silences a steady alert tone.
1 Short Beep
is emitted each time a key is pressed or a valid
function is entered.
4 Short Beeps
are emitted when an incorrect key or function
is entered.
Keyboard Backlighting
The keyboard on the 692F lights any time a key is pressed or the
alert buzzer sounds making it easy for a user in a darkened room
to enter their code or perform a command function.
Keypad Function Keys
SILENCE
Press the
SILENCE
key and enter the user code to silence a
system alarm and the keypad sounder. You may also use the
SILENCE
key to silence the bells during the Fire Drill function.
RESET
Press the
RESET
key and enter the user code to reset a zone
after an alarm.
This resets all zone alarm LEDs and momentarily drops power to
the panel’s zones 2 to 5 and smoke power output.
TEST
Press the
TEST
function key and enter the user code to initiate
the panel’s System Test function.
This test rings the panel bells for 2 seconds, checks the battery
charge level, and sends a system test report to the central
station on monitored systems.
CODE
To change the system user code, press
CODE
, enter the current
user code followed by 0 + 1, and then enter the new 4-digit
user code.
The user code must always be 4 digits.

LED Keypad User’s Guide
XR5 User’s Guide
13
Testing the System
It is good practice to test your system at least once each week.
This assures you that the system is working correctly and
identi es any potential problems.
Enter COMMAND + 4 + 1 to perform a system test. The bell
rings for 2 seconds then the battery and communications to the
central station are tested.
You can also initiate a System Test by pressing the TEST function
key followed by your User Code.
User Codes
Use this function to change the current User Code.
Press the CODE key followed by the current User Code. You
hear one beep if successful. Enter 0 (zero) + 1. Enter the new
4-digit User Code.
2-Button Fire Keys
If your system has a label showing a  ame under the TEST
and CODE keys, the optional Fire Panic key function has been
enabled.
Press the two keys over the icon, and hold them down for at
least 2 seconds. The system sends a Fire report to the central
station. The keypad beeps to con rm the Fire key entry.
SPECIAL
Pressing the
SPECIAL
key and entering the user code initiates
the Fire Drill function.
The Fire Drill sounds the alarm bells and keypad sounder for the
duration of the Bell Cutoff time. If the Bell Cutoff time is set to
zero (0), the Fire Drill continues until the bells are silenced by
entering a code. No keypad LEDs are turned on and no reports
are sent to the central station during the Fire Drill.
In the event of a real  re during a  re drill, the system sends a
report to the central station and the LED for any  re-detecting
zone glows red on the 692F.
Manual Fire Alarm
To manually initiate a Fire Alarm, press and hold the
TEST
and
CODE
keys simultaneously for about 2 seconds until the alarm
sounds.
Resetting Sensors
Use this function to reset smoke detectors after an alarm when
the Fire zone light is  ashing in alarm memory.
Enter COMMAND
+ 4 + 7
to perform a Sensor Reset. The system
resets the smoke detectors and stops the  ashing light if the
zone restores to normal.
You can also initiate a Sensor Reset by pressing the RESET
function key followed by your User Code.

14
XR5 User’s Guide
Index
Index
Symbols
2-Button Fire Keys (LED)
13
630F LCD Keypad
1
,
2
692F LED Keypad
1
,
11
A
ALARM LED (630F)
3
Alert Tones (LED)
12
C
CODE Key (LED)
11
COMMAND Key (LCD)
4
COMMAND Key (LED)
11
D
Data Entry Keys (LCD)
4
Data Entry Keys (LED)
11
Display Events (LCD)
7
,
9
DRILL Key (630F)
2
E
End-User Options (LCD)
4
Event Displays (LCD)
Auto Recall
10
Supervisory
10
Zone
10
Zone Bypass
10
F
Fire Command Messages (LCD)
5
Fire Command Tones (LCD)
6
Fire Drill (LCD)
7
,
7, 7
9
Fire System Terms (LCD)
5
Function Keys (630F)
2
K
Keypad Function Keys (LED)
12
Keypad User Menu (LCD)
7
L
LCD Keypad
2
LED Keypad
11
M
Manual Fire Alarm (LED)
13
P
POWER LED (630F)
3
R
Resetting an Alarm Inside Front Cover
Resetting Sensors (LED)
13
RESET Key (630F)
2
RESET Key (LED)
11
S
Sensor Reset (LCD)
7
,
7, 7
8
SILENCE (LED)
11
SILENCE Key (630F)
2
Silencing an Alarm Inside Front Cover
Silencing Bells During Alarm (LCD)
6
Silencing Keypad Trouble Sounder
(LCD)
6
SPECIAL Key (LED)
13
Status LEDs (630F)
ALARM LED
3
POWER LED
3
TROUBLE LED
3
System LEDs (LED)
11
System Test (LCD)
7
,
7, 7
8
T
Testing the System (LED)
13
TEST Key (630F)
2
TEST Key (LED)
11
Tones (LCD)
Fire Alarm tone
6
Key press tone
6
Trouble tone
6
TROUBLE LED (630F)
3
U
User Codes (LCD)
7
,
7, 7
9
User Codes (LED)
13
User Menu (LCD)
7
Z
Zone Alarm and Trouble LEDs (LED)
12

This page intentionally left blank.

LT-0296 1.01
8105
