Digital Projection LIGHTNING 8gv User manual

The LIGHTNING Display Range of
SUPER-HIGH-BRIGHTNESS DIGITAL VIDEO PROJECTORS
LIGHTNING 22sx, LIGHTNING 25sx, LIGHTNING 28sx,
LIGHTNING 8gv, LIGHTNING 10gv, LIGHTNING 22gv
USER MANUAL
Revision C - 01/03/03
Part Number: LBV00056

Directives covered by this Declaration
89/336/EEC Electromagnetic Compatibility Directive, amended by 92/31/EEC & 93/68/EEC.
73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC.
Products covered by this Directive
Large Screen Projector types LIGHTNING 8gv (20 series chassis) and LIGHTNING 22sx.
Basis on which Conformity is being declared
The products identified above comply with the protection requirements of the above EU
directives, and the manufacturer has applied the following standards:-
EN 55022: 1998 - Limits and Methods of Measurement of Radio Disturbance Characteristics
of Information Technology Equipment.
EN 55024:1998 - Limits and Methods of Measurement of Immunity Characteristics of
Information Technology Equipment.
EN 55103:1997 - Product Family Standard for Audio, Video, Audio-Visual and
Entertainment Lighting Control aparatus for Professional Use.
EN 60950: 1992 - Specification for Safety of Information Technology Equipment,
including Electrical Business Equipment.
The technical documentation required to demonstrate that the products meet the requirements
of the Low Voltage Directive has been compiled by the signatory below and is available for
inspection by the relevant enforcement authorities. The CE mark was first applied in May
2002.
Signed:
Authority: D.J. Quinn, Product Development Director
Date: 9th May 2002
Attention!
The attention of the specifier, purchaser, installer, or user is drawn to special measures and
limitations to use which must be observed when these products are taken into service to
maintain compliance with the above directives. Details of these special measures are
available on request, and are also contained in the product manuals.
Declaration of Conformity
LBV00056; Revision C - 01/03/03

Directives covered by this Declaration
89/336/EEC Electromagnetic Compatibility Directive, amended by 92/31/EEC & 93/68/EEC.
73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC.
Products covered by this Declaration
Large screen video projector types LIGHTNING 22gv, LIGHTNING 25sx
and LIGHTNING 28sx.
Basis on which Conformity is being declared
The products identified above comply with the protection requirements of the above EU
directives, and the manufacturer has applied the following standards:-
EN 55022:1998 - Limits and Methods of Measurement of Radio Disturbance Characteristics
of Information Technology Equipment.
EN 55024:1998 - Limits and Methods of Measurement of Immunity Characteristics of
Information Technology Equipment.
EN 55103:1997 - Product family Standard for Audio, Video, Audio-Visual and
Entertainment Lighting Control apparatus for Professional Use.
EN 60950: 1992 - Specification for Safety of Information Technology Equipment,
including Electrical Business Equipment.
The technical documentation required to demonstrate that the products meet the requirements
of the Low Voltage Directive has been compiled by the signatory below and is available for
inspection by the relevant enforcement authorities. The CE mark was first applied in March
2002.
Signed:
Authority: D.J. Quinn, Product Development Director
Date: 4th March 2002
Attention!
The attention of the specifier, purchaser, installer, or user is drawn to special measures and
limitations to use which must be observed when these products are taken into service to
maintain compliance with the above directives. Details of these special measures are
available on request, and are also contained in the product manuals.
Declaration of Conformity
LBV00056; Revision C - 01/03/03

LBV00056; Revision C - 01/03/03
