Digital Projection E-Vision 6500 Series User manual

Rev D July 2014
USER MANUAL
INSTALLATION AND QUICK-START GUIDE
CONNECTION GUIDE
OPERATING GUIDE
REMOTE COMMUNICATIONS GUIDE
114-758D
LENS SHIFT
ZOOM
–
FOCUS
+
MENU
ENTER RETURN
SOURCE
POWER WARNING LAMP1 LAMP2
AUTO
E-Vision 6500 Series
High Brightness Digital Video Projector

Digital Projection E-Vision 6500 Series
i
Rev D July 2014
i
About This Document
Please follow the instructions in this manual carefully to ensure safe and long-lasting use of the projector.
Keep this manual handy for future reference.
Symbols used in this manual
Many pages in this document have a dedicated area for notes. The information in that area is accompanied by the following symbols:
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice.
Legal notice
Trademarks and trade names mentioned in this document remain the property of their respective owners.
Digital Projection disclaims any proprietary interest in trademarks and trade names other than its own.
Copyright © 2014 Digital Projection Ltd. All rights reserved.
Notes

Digital Projection E-Vision 6500 Series
ii
Rev D July 2014
ii
Introduction
Congratulations on your purchase of this Digital Projection product.
Your projector has the following key features:
• Swappable color wheels for high brightness and color critical applications.
• BrilliantColor™ for increased system brightness.
• DynamicBlack™ for improved black levels in dark scenes.
• Frame sequential 3D support at up to 120Hz with support for DLP® Link™ glasses synchronisation only.
• Independent control of hue, saturation and gain for primary and secondary colors.
• Vertical keystone correction.
• Control via LAN and RS232.
• Motorized lens mount.
A serial number is located on the back of the projector. Please record it here:
Notes

Digital Projection E-Vision 6500 Series
iii
Rev D July 2014
iii
CONTENTS
INSTALLATION AND QUICK-START GUIDE..............................1
WHAT’S IN THE BOX? ................................................................... 3
GETTING TO KNOW THE PROJECTOR.......................................... 4
Front and rear views ............................................................................. 4
Remote control...................................................................................... 4
Control panel and indicators ................................................................. 5
CHANGING THE LENS, LAMPS AND COLOR WHEEL.................... 6
Removing the lens ................................................................................ 6
Fitting the lens....................................................................................... 6
Changing the lamp................................................................................ 7
Changing the color wheel...................................................................... 8
POSITIONING THE SCREEN AND PROJECTOR............................. 9
OPERATING THE PROJECTOR.................................................... 10
Switching the projector on................................................................... 10
Selecting an input signal or test pattern.............................................. 10
Input signal ........................................................................................ 10
Test pattern ........................................................................................ 10
Adjusting the lens................................................................................ 11
Zoom................................................................................................ 11
Focus ............................................................................................... 11
Shift ................................................................................................. 11
Adjusting the image............................................................................. 11
Orientation ......................................................................................... 11
Aspect ratio........................................................................................ 11
Picture .............................................................................................. 11
Switching the projector off................................................................... 12
CONNECTION GUIDE ............................................................................13
SIGNAL INPUTS AND OUTPUTS.................................................. 15
Computer 1 ......................................................................................... 15
Computer 2 ......................................................................................... 15
Computer 3 ......................................................................................... 15
Component.......................................................................................... 15
Video or S-Video ................................................................................. 15
Monitor Out ......................................................................................... 15
SUPPORTED SIGNAL INPUT MODES .......................................... 16
CONTROL CONNECTIONS........................................................... 18
Screen Trigger..................................................................................... 18
USB Service Port ................................................................................ 18
Wired Remote Control......................................................................... 18
RS232 ................................................................................................. 18
LAN ..................................................................................................... 18

Digital Projection E-Vision 6500 Series
iv
Rev D July 2014
iv
WIRING DETAILS......................................................................... 19
Signal inputs and outputs.................................................................... 19
Monitor video output (VGA) .................................................................... 19
Computer 1 video input: analog computer (VGA) ......................................... 19
Computer 2 video input: RGBHV, RGsB or YCbCr........................................ 19
Computer 3 video input: DVI-D................................................................ 20
Component video input ......................................................................... 21
Video input......................................................................................... 22
S-Video input...................................................................................... 22
Control connections ............................................................................ 23
Screen Trigger output ........................................................................... 23
RS232 Serial control input...................................................................... 23
Wired remote control connection ............................................................. 23
LAN connection................................................................................... 24
OPERATING GUIDE ................................................................................25
USING THE REMOTE CONTROL.................................................. 27
USING THE MENUS ..................................................................... 28
Navigating the menus ......................................................................... 28
Submenus........................................................................................... 29
Sliders ................................................................................................. 29
Selecting parameters .......................................................................... 30
Commands.......................................................................................... 31
Editing elds........................................................................................ 31
A TOUR OF THE MENUS.............................................................. 32
Picture menu....................................................................................... 32
Picture Mode ...................................................................................... 32
Brilliant Color ...................................................................................... 32
Brightness, Contrast, Color, Tint, Sharpness ............................................... 32
Reset................................................................................................ 32
Advance Setting submenu ..................................................................... 33
Signal menu ........................................................................................ 35
Horizontal and Vertical Position, Phase, Clock............................................. 35
Reset................................................................................................ 35
Resolution ......................................................................................... 35
Auto Sync .......................................................................................... 35
Video menu ......................................................................................... 36
Overscan........................................................................................... 36
Video System ..................................................................................... 36
Video Setup ....................................................................................... 36
Closed Caption ................................................................................... 36

Digital Projection E-Vision 6500 Series
v
Rev D July 2014
v
Setup menu......................................................................................... 37
Auto Search ....................................................................................... 37
Auto Power Off.................................................................................... 37
Auto Power On.................................................................................... 37
Standby Mode .................................................................................... 37
Background........................................................................................ 38
3D Mode ........................................................................................... 38
Aspect Ratio....................................................................................... 38
Advance Setting submenu ..................................................................... 39
Security Lock...................................................................................... 39
Keypad Lock ...................................................................................... 39
Image Capture .................................................................................... 39
Wall Color.......................................................................................... 39
Digital Zoom....................................................................................... 39
Messaging ......................................................................................... 40
Installation menu................................................................................. 41
Language .......................................................................................... 41
Lamp Control...................................................................................... 41
Lamp Mode........................................................................................ 41
Projection Mode .................................................................................. 41
Fan Mode .......................................................................................... 41
Test Pattern........................................................................................ 41
Advance Setting .................................................................................. 42
Communication Speed .......................................................................... 42
Network ............................................................................................ 43
Reset................................................................................................ 44
Information......................................................................................... 44
MENU MAP .................................................................................. 45
REMOTE COMMUNICATIONS GUIDE ..........................................49
INTRODUCTION........................................................................... 51
RS232 CONTROL COMMANDS .................................................... 52
Header code........................................................................................ 52
Examples .......................................................................................... 52
The commands ................................................................................... 53
Command Group 00 ............................................................................. 53
Command Group 01 ............................................................................. 53
Command Group 02 ............................................................................. 54
Command Group 03 ............................................................................. 54
Command Group 04 (Remote Control buttons)............................................ 55
PJLINK ........................................................................................ 57
Settings ............................................................................................... 57
Host Name......................................................................................... 57
Domain Name..................................................................................... 57
Mail.................................................................................................. 57
PJLink .............................................................................................. 57
LAN CONTROL UTILITY............................................................... 58
Power ON/STANDBY.......................................................................... 58
Picture controls ................................................................................... 58
Input Select ......................................................................................... 58
AV Mute............................................................................................... 58
Status.................................................................................................. 58

Rev D July 2014
E-Vision 6500 Series
High Brightness Digital Video Projector
INSTALLATION AND QUICK-START GUIDE
LENS SHIFT
ZOOM
–
FOCUS
+
MENU
ENTER RETURN
SOURCE
POWER WARNING LAMP1 LAMP2
AUTO

Digital Projection E-Vision 6500 Series IN THIS GUIDE Installation and Quick-Start Guide
Rev D July 2014
IN THIS GUIDE
What’s In The Box?............................................................................................. 3
Getting To Know The Projector...................................................................... 4
Front and rear views ...................................................................................................4
Remote control............................................................................................................4
Control panel and indicators .....................................................................................5
Changing The Lens, Lamps And Color Wheel............................................ 6
Removing the lens ......................................................................................................6
Fitting the lens.............................................................................................................6
Changing the lamp......................................................................................................7
Changing the color wheel ..........................................................................................8
Positioning The Screen And Projector......................................................... 9
Operating The Projector ................................................................................. 10
Switching the projector on.......................................................................................10
Selecting an input signal or test pattern.................................................................10
Input signal......................................................................................................................10
Test pattern .....................................................................................................................10
Adjusting the lens .....................................................................................................11
Zoom...............................................................................................................................11
Focus ..............................................................................................................................11
Shift.................................................................................................................................11
Adjusting the image..................................................................................................11
Orientation ......................................................................................................................11
Aspect ratio .....................................................................................................................11
Picture.............................................................................................................................11
Switching the projector off.......................................................................................12

Digital Projection E-Vision 6500 Series What’s In The Box? Installation and Quick-Start Guide
3
Rev D July 2014
What’s In The Box? Notes
Make sure your box contains
everything listed. If any pieces are
missing, contact your dealer.
You should save the original box
and packing materials, in case you
ever need to ship your Projector.
Only one power cable - dependent
on the destination territory - will be
supplied with the projector.
Remote control
(112-377)
User Manual on disc
(115-759) Important Information
(114-759)
Power cable 10A, United
Kingdom (102-180)
Power cable 10A,
Europe (102-163)
Power cable 13A, North
America (102-165)
Projector
Lens cap Color wheel
Power cable,
China (112-472)
LENSSHIFT
ZOOM
–
FOCUS
+
MENU
ENTER RETURN
SOURCE
POWER WARNING LAMP1 LAMP2
AUTO

Digital Projection E-Vision 6500 Series Getting To Know The Projector Installation and Quick-Start Guide
4
Rev D July 2014
Getting To Know The Projector
Front and rear views
Notes
The projector uses an infra-red
remote control.
Some of the controls are duplicated
on the projector control panel, as
shown on the next page.
For full details of how to use the
controls and the menu system, see
the Operating Guide.
 Theairltersshouldbecleanedor
changed regularly, depending on the
installation environment.
 Theltersshouldbechangedatthe
same time as the lamp is changed.
The projector lens is shipped
separately.
LENSSHIFT
ZOOM
–
FOCUS
+
MENU
ENTER RETURN
SOURCE
POWER WARNING LAMP1 LAMP2
AUTO
Lens
Connection
panel
Mains
input
Control
panel
Adjustable
foot
Front
infra-red
window
Rear
infra-red
window
Remote control
Infra-red
reception
40°
40°
Air
inlet
Air
inlet
Air
outlet
Lamp and color
wheel cover
Air lter
cover
Air lter
cover

Digital Projection E-Vision 6500 Series Getting To Know The Projector Installation and Quick-Start Guide
5
Rev D July 2014
Control panel and indicators
Some of the controls from the remote control are duplicated on the projector control panel, as
shown on the right.
The CANCEL button has the same function as the RETURN button on the remote control.
The SOURCE and AUTO buttons have the same function as the INPUT and AUTO SYNC
buttons on the remote control.
The Power indicator will show amber when in standby and green when the projector is on,
and will ash when the projector is warming up or cooling down.
The Warning indicator will ash to show any error situations.
The Lamp indicators will show which lamp is in use, and whether the projector is in Normal
or Eco mode, and will ash to show lamp status.
The chart below shows all possible combinations of indicator lamp color.
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.
Lens
controls
Menu
controls
Power Input

Digital Projection E-Vision 6500 Series Changing The Lens, Lamps And Color Wheel Installation and Quick-Start Guide
6
Rev D July 2014
Changing The Lens, Lamps And Color Wheel
Removing the lens
1. Remove the lens cap.
2. Push in the lens release lever, and turn the lens anti-clockwise.
3. Remove the lens.
Fitting the lens
1. Position the lens so that the label marked ‘O’ is at the top, push in the lens release lever and and gently insert the lens all the way into the
lens mount.
2. Turn the lens clockwise until it clicks into place.
12
1
2
3
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
The projector lens is shipped
separately.

Digital Projection E-Vision 6500 Series Changing The Lens, Lamps And Color Wheel Installation and Quick-Start Guide
7
Rev D July 2014
Changing the lamp
1. Slide open the lamp compartment cover as shown in the picture.
2. Unscrew the two captive screws securing the lamp module.
3. Pull rmly upwards on the handle to remove the lamp module.
4. Insert a new lamp module.
5. Fasten the screws.
6. Replace the lamp compartment cover.
12 3
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
The lamp must be changed only
by suitably qualied personnel.
The projector will shut down if the
cover is opened whilst in operation.
 Theltersshouldbechangedatthe
same time as the lamp is changed.
456

Digital Projection E-Vision 6500 Series Changing The Lens, Lamps And Color Wheel Installation and Quick-Start Guide
8
Rev D July 2014
Changing the color wheel
1. Slide open the lamp compartment cover as shown in the picture.
2. Unscrew the four captive screws securing the color wheel.
3. Remove the color wheel.
4. Insert a new color wheel.
5. Fasten the screws.
6. Replace the lamp compartment cover.
4 5 6
3
2
1
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
The color wheel must be changed
only by suitably qualied
personnel.
The projector will shut down if the
cover is opened whilst in operation.

Digital Projection E-Vision 6500 Series Positioning The Screen And Projector Installation and Quick-Start Guide
9
Rev D July 2014
Positioning The Screen And Projector
1. Install the screen, ensuring that it is in the best position for viewing by your audience.
2. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to ll the screen. Set the adjustable feet so that
the projector is level, and perpendicular to the screen.
Alternatively, ve M4 bolts (max length 12 mm [0.5 in]) can be used to attach the projector to a ceiling mount (optional accessory,).
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
Ensure that there is at least
50cm (20in) of space between the
ventilation outlets and any wall,
and 10cm (4in) on all other sides.
If ceiling mounting, ensure there
is 30cm (12in) of space between
the projector and ceiling.
Do not stack the projectors.
Do not tilt the projector more than
±10° from side to side when in
use, as this may cause serious
lamp failure, damage the lamp
module and cause extra cost on
replacement.
If you position the projector at an
angle, remember to adjust the fan
speed accordingly.
±10° ±360°
1
2
3
4 5
Location of the ceiling mount holes at the bottom of the projector

Digital Projection E-Vision 6500 Series Operating The Projector Installation and Quick-Start Guide
10
Rev D July 2014
Operating The Projector
Switching the projector on
• Connect the power cable between the mains supply and the projector. Switch on at the switch next to the power connector.
• Wait until the self-test has completed and the Power indicator on the projector control panel shows amber. The lamp will be off and the
projector will be in STANDBY mode.
• Press on the control panel or POWER ON on the remote control.
The Power indicator on the control panel will ash green for a few seconds whilst the lamp comes up to full brightness. When the
projector is ready for use, the Power indicator will show steady green.
Selecting an input signal or test pattern
Input signal
• Connect an image source to the projector. The signal should be automatically detected by the projector, and should be displayed within a
two or three seconds.
• If more than one signal is connected, then select the image you want to display:
Press SOURCE on the control panel to cycle through the inputs,
or press INPUT on the remote control, then or to cycle through the inputs.
Test pattern
If you have no image source connected to the projector, then you can display a test pattern instead:
Press TEST PATTERN on the remote control, then or to cycle through the patterns,
or select a Test Pattern from the Installation menu.
Notes
Before switching on the projector
for the rst time, make sure
the electric circuit is grounded.
Poor grounding may damage the
projector.
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
For full details of how to connect an
image source to the projector, see
the Connection Guide.
For full details of how to use the
controls and the menu system, see
the Operating Guide.

Digital Projection E-Vision 6500 Series Operating The Projector Installation and Quick-Start Guide
11
Rev D July 2014
Adjusting the lens
Zoom
• Use the ZOOM +/− buttons on the control panel or on the remote control to adjust the
lens so that the image lls the screen.
Focus
• Use the FOCUS +/− buttons on the control panel or on the remote control to adjust the
lens until the image is sharp.
Shift
• Use the LENS SHIFT buttons , , and on the control panel to adjust the
position of the image,
or press the LENS SHIFT button on the remote control then use , , and
to adjust the position of the image.
Adjusting the image
Orientation
• Use the Projection Mode settings, in the Installation Menu.
Aspect ratio
• Press the ASPECT button on the remote control to cycle through all the available
settings.
or use the Aspect Ratio setting in the Setup Menu.
• Press PICTURE on the remote control or use the menu controls, to open the Picture
Menu.
Use the sliders in the Picture menu to adjust the brightness, contract etc.
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.

Digital Projection E-Vision 6500 Series Operating The Projector Installation and Quick-Start Guide
12
Rev D July 2014
Switching the projector off
• Press on the control panel or STANDBY on the remote control, then press the button a second time within 5 seconds to conrm your
intention to switch off.
The lamp will go off, and the Power indicator on the control panel will ash amber for a few seconds whilst the lamp cools. The Power
indicator on the control panel will then show amber and the projector will be in Standby mode.
• Switch off at the switch next to the power connector. Disconnect the power cable from the projector.
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
