Digital Projection HIGHlite Laser 4K Series User manual

Rev AFebruary 2018
HIGHlite 4K Series
High Brightness Digital Video Projector
4INSTALLATION AND QUICK-START GUIDE
4CONNECTION GUIDE
4OPERATING GUIDE
4REFERENCE GUIDE
118-083A

page i
Digital Projection HIGHlite Laser 4K Series
Rev B February 2018
About This Document
Follow the instructions in this manual carefully to ensure safe and long-lasting use of the projector.
Symbols used in this manual
Many pages in this document have a dedicated area for notes. The information in that area is accompanied by the following symbols:
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
LASER WARNING: this symbol indicates that there is a potential hazard of eye exposure to laser radiation unless the
instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice.
Legal notice
Trademarks and trade names mentioned in this document remain the property of their respective owners.
Digital Projection disclaims any proprietary interest in trademarks and trade names other than its own.
Copyright © 2018 Digital Projection Ltd. All rights reserved.
Notes

page ii
Digital Projection HIGHlite Laser 4K Series
Rev B February 2018
Laser Information
Caution-useofcontrolsoradjustmentsorperformanceofproceduresotherthanthosespeciedhereinmayresultin
hazardous radiation exposure.
Notes
CAUTION
Possibly hazardous optical radiation emitted
from this product.
Do not stare at operating lamp.
May be harmful to the eyes.
ATTENTION
Ce produit peut émettre des rayonnements
optiques dangereux.
Ne pas fixer la lampe en fonctionnement.
Peut être nocif pour les yeux.
RISK GROUP 2
AC Input / Entrée CA ( 輸入 / 输入 ) : 200-240Vac 9A 50/60Hz
AC Input / Entrée CA
(
輸入 / 输入
)
: 110-130Vac 11.5A 50/60Hz
Model/Modèle (型號 / 型号): HIGHlite Laser II 3D
DLP PROJECTOR / DLP Projecteur
( 數位投影機 / 数字投影机 )
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
450nm - 460nm < 333.5mW
激光輻射 避免眼睛受到直射 3R类激光產品
波長 : 450nm - 460nm < 333.5 mW
RAYONNEMENT LASER
EXPOSITION DIRECTE DANGEREUSE POUR LES YEUX
APPAREIL À LASER DE CLASSE 3R
450nm - 460nm < 333.5 mW
GB 7247.1-2012 / IEC/EN 60825-1:2007
警告:此為 A 級產品，在生活環境中，該產品可能會造成無線電干擾。
在這種情況下，可能需要用戶對干擾採取切實可行的措施。
This device complies with part 15 of the FCC rules.
Operation is subject tothe following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution : Do not open the cover. No user-serviceable parts inside
Avertissement : ne pas ouvrir le couvercle. Le produit ne contient
aucune pièce interne réparable par l’utilisateur.
警 告 : 請勿打開外殼,設備內無服務性維修之元 件
警 告 : 請勿打開外殼,設備內無服務性維修之元件
Complies with FDA performance standards for laser products except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007
製造商:Digital Projection Limited
Greenside Way Middleton Manchester, M24 1XX UK 製造地:中國/製造地:中國 / Made in China
3264625702
Part No.:116-330
CAN ICE-3(A) / NMB-3(A)
[phone]
KTL ZU10002-16011
MSIP-REM-DVP-LaserII3D
:
:
:
/ :
:
델타 비디오 디스플레이
시스템 (우장) 리미티드
*W651Z***********
MANUFACTURED 2016.51

page iii
Digital Projection HIGHlite Laser 4K Series
Rev B February 2018
Introduction
Congratulations on your purchase of this Digital Projection product.
Your projector has the following key features:
• 4K-UHD projector.
• HDBaseT® for transmission of uncompressed High Denition Video up to 100 m from the source.
• 3G-SDI with loop-through.
• Edge Blend with black-level correction.
• Blanking control for custom input window sizing.
• Cornerstone, Vertical & Horizontal Keystone, Pincushion & Barrel, and Image Rotation.
• Control via LAN and RS232.
• Motorised lens mount.
• Separate control of screen and source aspect ratio.
• Non-linear warp for irregular projection surfaces.
A serial number is located on the side of the projector. Record it here:
Notes

page iv
Digital Projection HIGHlite Laser 4K Series
Rev B February 2018
CONTENTS
INSTALLATION AND QUICK-START GUIDE ..............................1
WHAT’S IN THE BOX? ................................................................... 3
CONNECTING THE POWER SUPPLY ............................................. 4
Voltage selection ................................................................................... 4
PROJECTOR OVERVIEW ............................................................... 5
Front and rear views ............................................................................. 5
CONTROL PANEL.......................................................................... 6
REMOTE CONTROL....................................................................... 7
Infrared reception................................................................................ 10
POSITIONING THE SCREEN AND PROJECTOR........................... 11
Roll and pitch ...................................................................................... 12
CHANGING THE LENS................................................................. 13
The lens hood ..................................................................................... 13
Inserting a new lens ............................................................................ 14
Removing the lens .............................................................................. 15
OPERATING THE PROJECTOR.................................................... 16
Switching the projector on................................................................... 16
Switching the projector off................................................................... 16
Selecting an input signal ..................................................................... 17
Selecting a test pattern ....................................................................... 17
Adjusting the lens................................................................................ 18
Adjusting the image............................................................................. 18
CONNECTION GUIDE ............................................................................19
SIGNAL INPUTS .......................................................................... 21
Digital inputs and outputs.................................................................... 21
Using HDMI/DisplayPort switchers with the projector......................... 22
CONTROL CONNECTIONS........................................................... 23
LAN connection examples .................................................................. 24
RS232 connection example ................................................................ 25
OPERATING GUIDE ................................................................................27
USING THE MENUS ..................................................................... 29
Opening the OSD................................................................................ 29
Opening a menu.................................................................................. 29
Exiting menus and closing the OSD.................................................... 29
Inside a menu...................................................................................... 30
Accessing sub-menus........................................................................... 30

page v
Digital Projection HIGHlite Laser 4K Series
Rev B February 2018
Executing commands............................................................................ 30
Editing projector settings..................................................................... 31
Using a slider to set a value.................................................................... 31
Editing numeric values .......................................................................... 31
USING THE PROJECTOR............................................................. 32
Main menu .......................................................................................... 32
Lens menu .......................................................................................... 33
Lens Control....................................................................................... 33
Lens Memory...................................................................................... 34
Image menu ........................................................................................ 35
Color menu.......................................................................................... 37
Color Space ....................................................................................... 37
Color Mode ........................................................................................ 38
Geometry menu .................................................................................. 43
Aspect Ratio....................................................................................... 43
Digital Zoom....................................................................................... 45
Overscan........................................................................................... 46
Blanking ............................................................................................ 47
Keystone ........................................................................................... 48
4 Corners .......................................................................................... 50
Rotation ............................................................................................ 51
Pincushion / Barrel............................................................................... 52
Custom Warp ..................................................................................... 53
Arc................................................................................................... 54
Edge Blend menu................................................................................ 55
Blend Width........................................................................................ 56
Black Level Uplift ................................................................................. 57
Laser menu ......................................................................................... 58
Setup menu......................................................................................... 59
ColorMax........................................................................................... 62
Power On/Off...................................................................................... 63
Clock Adjust ....................................................................................... 64
OSD Settings...................................................................................... 65
Memory............................................................................................. 65
Network menu..................................................................................... 66
PIP menu ............................................................................................ 67
Information menu ................................................................................ 68
Signal Format ..................................................................................... 68
System Status .................................................................................... 69
Thermal Status.................................................................................... 69
Factory Reset ..................................................................................... 70
SERVED WEB PAGES.................................................................. 71
REFERENCE GUIDE................................................................................81
CHOOSING A LENS ..................................................................... 83
Basic calculation ................................................................................. 84
Basic calculation example................................................................... 85
Full lens calculation............................................................................. 86
Introducing TRC .................................................................................. 86
Calculating TRC .................................................................................. 87
Calculating the throw ratio with TRC ......................................................... 88
Full lens calculation example .............................................................. 89
SCREEN REQUIREMENTS........................................................... 90
Fitting the image to the display ........................................................... 90
CONTENTS (continued)

page vi
Digital Projection HIGHlite Laser 4K Series
Rev B February 2018
4K-UHD images displayed full width ......................................................... 90
4K-UHD images displayed with a height of 2160 pixels.................................. 91
4K-UHD images displayed full height ........................................................ 92
Diagonal screen sizes......................................................................... 93
POSITIONING THE IMAGE........................................................... 94
ASPECT RATIOS EXPLAINED...................................................... 96
Aspect ratio examples......................................................................... 97
APPENDIX A: LENS PART NUMBERS.......................................... 99
APPENDIX B: SUPPORTED SIGNAL INPUT MODES.................. 100
2D formats......................................................................................... 100
SDI Format........................................................................................ 102
APPENDIX C: WIRING DETAILS ................................................ 104
Signal inputs and outputs.................................................................. 104
HDMI 1 and 2 ................................................................................... 104
DisplayPort ...................................................................................... 105
3G-SDI In, 3G-SDI Out........................................................................ 106
Control connections .......................................................................... 107
LAN ............................................................................................... 107
RS232 ............................................................................................ 107
Trigger 1 & Trigger 2 ........................................................................... 108
IR input ........................................................................................... 108
APPENDIX D: GLOSSARY OF TERMS ....................................... 109
CONTENTS (continued)

Digital Projection HIGHlite Laser 4K Series
This page is intentionally left blank.

Rev B February 2018
HIGHlite Laser 4K Series
High Brightness Digital Video Projector
INSTALLATION AND QUICK-START GUIDE
4

Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
IN THIS GUIDE
Rev B February 2018
IN THIS GUIDE
What’s In The Box?............................................................................................. 3
Connecting The Power Supply........................................................................ 4
Voltage selection.........................................................................................................4
Projector Overview............................................................................................. 5
Front and rear views...................................................................................................5
Control Panel........................................................................................................ 6
Remote Control.................................................................................................... 7
Infrared reception......................................................................................................10
Positioning The Screen And Projector....................................................... 11
Roll and pitch ............................................................................................................12
Changing The Lens........................................................................................... 13
The lens hood............................................................................................................13
Inserting a new lens..................................................................................................14
Removing the lens ....................................................................................................15
Operating The Projector ................................................................................. 16
Switching the projector on.......................................................................................16
Switching the projector off.......................................................................................16
Selecting an input signal..........................................................................................17
Selecting a test pattern.............................................................................................17
Adjusting the lens.....................................................................................................18
Adjusting the image..................................................................................................18

page 3
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
WHAT’S IN THE BOX?
Rev B February 2018
What’s In The Box? Notes
Make sure your box contains
everything listed. If any pieces are
missing, contact your dealer.
Only one remote will be supplied
with the projector. For more
information, see Remote Control
further in this guide.
You should save the original box
and packing materials, in case you
ever need to ship your projector.
The projector is shipped without a
lens.
Do not use the short lens hood
with the 4.34 - 6.76 : 1 zoom lens.
For further information about using
the right lens and hood, see The
lens hood further in this guide.
Only one power cable - dependent
on the destination territory - will be
supplied with the projector.
Remote control 2x AAA batteries
User Manual on disc Important Information
Power cable, Europe Power cable, North America
Projector
141.6 [5.57]
357.2 [14.06]
585 [23.03]
675 [26.57]
39.6 [1.56]
293 [11.54]
365 [14.37]
LENS EXTENSION
SEE TABLE
64.7 [2.55]
107 [4.21] 371 [14.61]
20 [0.79]
35 [1.38]
69.9 [ 2.75]
220 [8.66] 182.5 [7.19]
232.5 [9.15]
105 [4.13]
6.30
160.00
20 [0.79]710 [27.95]
155 [6.10]440 [17.32]
22 [0.87] 541 [21.30]
(701 [27.60])
280 [11.02]
307.1 [12.09]
750 [29.53]217 [8.54]
PART NO. THROW RATIO EXTENSION DIM.
110-808
0.77:1
171.7
110-809 1.16:1 145.1
110-803 1.45~1.74:1 115.9
112-878 1.71~2.17:1 80.8
113-852 2.17~2.90:1 81.4
110-806 2.90~4.34:1 80.8
110-807 4.34~6.76:1 84.8
FRONT IR
LENS CENTER
CENTER OF GRAVITY
6-CEILING MOUNT HOLE
SCREW M6*1.0, MAX. L=20mm
IO PORT
AIR IN
12 CFM
AIR IN
49 CFM
AIR IN
18 CFM
REAR IR
AIR OUT
68 CFM
AIR OUT
23 CFM
AIR IN AIR IN
AIR OUT
LENS EXTENSION TABLE
141.6 [5.57]
357.2 [14.06]
585 [23.03]
675 [26.57]
39.6 [1.56]
293 [11.54]
365 [14.37]
LENS EXTENSION
SEE TABLE
64.7 [2.55]
107 [4.21] 371 [14.61]
20 [0.79]
35 [1.38]
69.9 [ 2.75]
220 [8.66] 182.5 [7.19]
232.5 [9.15]
105 [4.13]
6.30
160.00
20 [0.79]710 [27.95]
155 [6.10]440 [17.32]
22 [0.87] 541 [21.30]
(701 [27.60])
280 [11.02]
307.1 [12.09]
750 [29.53]217 [8.54]
Distribution Code
CAD GENERATED DRAWING
DO NOT MAKE MANUAL CHANGES
IF IN DOUBT, ASK.
A2 DRG. No.
3rd Angle Projection DRAWN BS 308
PROPRIETARY INFORMATION
Projection Ltd. It shall be returned immediately upon request. other purpose without the prior written permission of Digital nor disclosed to others,nor used for manufacturing or any shall not be reproduced nor transfered to other documents
TITLE COMPONENT OR DRG.No.
1
2
3
4
5
6
7
ITEM
PRE REVS DESCRIPTION REFER TO
No
OFF
REMARKS
MATERIAL
CODE
FINISH
LAST CHANGE
TOLERANCES
UNLESS OTHERWISE STATED
METRIC: 1.000 = ±0.01
1.00 = ±0.1
1.0 = ±0.2
1 = ±0.4
IMPERIAL Fractional ±1/64"
Decimal ± 0.005"
ANGLES ± 0° 30
REV.
NOTE
DRAWN
APP.DO.
DATE A2:SHEET
ORIGINAL
SCALE
DRAWN
APP.ENG.
DATE
FIRST USED ON
Unless Otherwise Stated
DIMENSIONS IN MILLIMETRES
REMOVE ALL BURRS & SHARP EDGES. DO NOT SCALE DRAWING
THE SURFACE TEXTURE ROUGHNESS NUMBER OF MACHINED
SURFACES SHOULD BE EQUAL TO OR LESS THAN 0.8um (N6 CLA32)
This document contains proprietary information which is
forwarded to you in confidence for a specific purpose.It
1 2 4 3 5 6 7 8 9
A
B
C
D
E
F
PROJECTION
DIGITAL
MIDDLETON M24 1XX
1:12
jcharnley
06-06-17
1 1
A
07-06-17
OF
jcharnley
A
SEE ABOVE SEE ABOVE
141.6 [5.57]
357.2 [14.06]
585 [23.03]
675 [26.57]
39.6 [1.56]
293 [11.54]
365 [14.37]
LENS EXTENSION
SEE TABLE
64.7 [2.55]
107 [4.21] 371 [14.61]
20 [0.79]
35 [1.38]
69.9 [ 2.75]
220 [8.66] 182.5 [7.19]
232.5 [9.15]
105 [4.13]
6.30
160.00
20 [0.79]710 [27.95]
155 [6.10]440 [17.32]
22 [0.87] 541 [21.30]
(701 [27.60])
280 [11.02]
307.1 [12.09]
750 [29.53]217 [8.54]
Power cable, United Kingdom
HDMI cable
Pic Mute
OPEN CLOSE
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DisplayPort1
HD-T 3GSDI
VGA COMP1 COMP2
HDMI3
TEST
HDMI4
DisplayPort2
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
Power cable, China
remote control cable

page 4
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
CONNECTING THE POWER SUPPLY
Rev B February 2018
Connecting The Power Supply
Lift the cable lock up, push the mains connector in rmly and
push the lock down to secure the cable.
1AC mains inlet with cable lock
Voltage selection
The VOLTAGE SELECT switch must be set to match the power supply you are using:
Voltage of power supply used Position of VOLTAGE SELECT switch
AC100V outlet
AC200V (single phase) outlet
Notes
Use only the power cable
provided.
Ensure that the power outlet
includes a ground connection as
this equipment MUST be earthed.
Handle the power cable carefully
and avoid sharp bends. Do not
use a damaged power cable.
When operating on 110V Light
output power is reduced by approx
30%.
1

page 5
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev B February 2018
Projector Overview
Front and rear views
1Connection panel
2Air outlet
3Control panel
4Power switch and power connection
5Lens hood
6Front infrared window
7Air inlet
8Air outlet
9Rear infrared window
10 Adjustable feet
Notes
Do not use the short lens hood
with the 4.34 - 6.76 : 1 zoom lens.
For further information about using
the right lens and hood, see The
lens hood further in this guide.
Front view
4 5
23 1
6
Rear view
141.6 [5.57]
357.2 [14.06]
585 [23.03]
675 [26.57]
39.6 [1.56]
293 [11.54]
365 [14.37]
LENS EXTENSION
SEE TABLE
64.7 [2.55]
107 [4.21] 371 [14.61]
20 [0.79]
35 [1.38]
69.9 [ 2.75]
220 [8.66] 182.5 [7.19]
232.5 [9.15]
105 [4.13]
6.30
160.00
20 [0.79]710 [27.95]
155 [6.10]440 [17.32]
22 [0.87] 541 [21.30]
(701 [27.60])
280 [11.02]
307.1 [12.09]
750 [29.53]217 [8.54]
PART NO. THROW RATIO EXTENSION DIM.
110-808
0.77:1
171.7
110-809 1.16:1 145.1
110-803 1.45~1.74:1 115.9
112-878 1.71~2.17:1 80.8
113-852 2.17~2.90:1 81.4
110-806 2.90~4.34:1 80.8
110-807 4.34~6.76:1 84.8
FRONT IR
LENS CENTER
CENTER OF GRAVITY
6-CEILING MOUNT HOLE
SCREW M6*1.0, MAX. L=20mm
IO PORT
AIR IN
12 CFM
AIR IN
49 CFM
AIR IN
18 CFM
REAR IR
AIR OUT
68 CFM
AIR OUT
23 CFM
AIR IN AIR IN
AIR OUT
LENS EXTENSION TABLE
141.6 [5.57]
357.2 [14.06]
585 [23.03]
675 [26.57]
39.6 [1.56]
293 [11.54]
365 [14.37]
LENS EXTENSION
SEE TABLE
64.7 [2.55]
107 [4.21] 371 [14.61]
20 [0.79]
35 [1.38]
69.9 [ 2.75]
220 [8.66] 182.5 [7.19]
232.5 [9.15]
105 [4.13]
6.30
160.00
20 [0.79]710 [27.95]
155 [6.10]440 [17.32]
22 [0.87] 541 [21.30]
(701 [27.60])
280 [11.02]
307.1 [12.09]
750 [29.53]217 [8.54]
Distribution Code
CAD GENERATED DRAWING
DO NOT MAKE MANUAL CHANGES
IF IN DOUBT, ASK.
A2 DRG. No.
3rd Angle Projection DRAWN BS 308
PROPRIETARY INFORMATION
Projection Ltd. It shall be returned immediately upon request. other purpose without the prior written permission of Digital nor disclosed to others,nor used for manufacturing or any shall not be reproduced nor transfered to other documents
TITLE COMPONENT OR DRG.No.
1
2
3
4
5
6
7
ITEM
PRE REVS DESCRIPTION REFER TO
No
OFF
REMARKS
MATERIAL
CODE
FINISH
LAST CHANGE
TOLERANCES
UNLESS OTHERWISE STATED
METRIC: 1.000 = ±0.01
1.00 = ±0.1
1.0 = ±0.2
1 = ±0.4
IMPERIAL Fractional ±1/64"
Decimal ± 0.005"
ANGLES ± 0° 30
REV.
NOTE
DRAWN
APP.DO.
DATE A2:SHEET
ORIGINAL
SCALE
DRAWN
APP.ENG.
DATE
FIRST USED ON
Unless Otherwise Stated
DIMENSIONS IN MILLIMETRES
REMOVE ALL BURRS & SHARP EDGES. DO NOT SCALE DRAWING
THE SURFACE TEXTURE ROUGHNESS NUMBER OF MACHINED
SURFACES SHOULD BE EQUAL TO OR LESS THAN 0.8um (N6 CLA32)
This document contains proprietary information which is
forwarded to you in confidence for a specific purpose.It
1 2 4 3 5 6 7 8 9
A
B
C
D
E
F
PROJECTION
DIGITAL
MIDDLETON M24 1XX
1:12
jcharnley
06-06-17
1 1
A
07-06-17
OF
jcharnley
A
SEE ABOVE SEE ABOVE
141.6 [5.57]
357.2 [14.06]
585 [23.03]
675 [26.57]
39.6 [1.56]
293 [11.54]
365 [14.37]
LENS EXTENSION
SEE TABLE
64.7 [2.55]
107 [4.21] 371 [14.61]
20 [0.79]
35 [1.38]
69.9 [ 2.75]
220 [8.66] 182.5 [7.19]
232.5 [9.15]
105 [4.13]
6.30
160.00
20 [0.79]710 [27.95]
155 [6.10]440 [17.32]
22 [0.87] 541 [21.30]
(701 [27.60])
280 [11.02]
307.1 [12.09]
750 [29.53]217 [8.54]
10
89
7

page 6
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
CONTROL PANEL
Rev B February 2018
Control Panel
1ON indicator (blue)
Behavior Meaning
Off The projector is switched off.
On The projector is switched ON.
Flashing The projector is warming up or cooling down.
2ERROR indicator (red)
Behavior Meaning
Flash once, then pause Laser failure.
Flash twice, then pause Cover open.
Flash three times, then pause Fan failure.
Flash four times, then pause Over temperature.
On System error.
3STANDBY indicator (green)
Behavior Meaning
On The projector is in STANDBY mode.
Flashing The projector is in STANDBY mode.
It can be switched on with a network command.
4MENU button
Access the projector OSD (on-screen display).
5Navigation (arrow buttons and ENTER)
Navigate the OSD and edit settings with the arrows, conrm choice with ENTER.
6INPUT button
Select input source.
7Focus IN / OUT
Adjust focus.
8Zoom IN / OUT
Adjust zoom.
9Shutter CLOSE / OPEN
Open and close the shutter.
10 POWER button
Switch the projector on and off (in STANDBY mode)
11 EXIT button
Close the OSD.
12 SHIFT button
Press and hold this button, then press the arrow buttons to move the lens.
ERROR STANDBY
INPUT
CLOSE
FOCUS
ZOOM
SHUTTER
OPEN
OUT IN
OUT IN
SHIFT
MENU EXIT
4
5
6
3
8
1
2
9
7
10
12
11
Notes

page 7
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev B February 2018
Remote Control
1Power ON / OFF
Turns power on and off.
2Pic Mute OPEN / CLOSE
Shows and hides the projected image.
When CLOSE is pressed, the light source switches off completely and the screen
becomes black.
2OSD ON / OFF
Enable and disable screen timeout messages and control whether to show the OSD
during projection.
4MENU
Access the OSD. If the OSD is open, press this button to go back to the previous menu.
5Navigation (arrows and OK)
Navigate through the menus with the arrows, conrm your choice with OK.
In lens adjustment modes, the arrows are used to move, zoom or focus the lens. See 11
below.
In lens adjustment modes, or when the OSD is not showing, the OK button switches
between modes: Shift Adjustment and Zoom / Focus Adjustment.
6EXIT
Go up one level in the OSD. When the top level is reached, press to close the OSD.
7FREEZE
Freeze the current frame.
8DEFAULT
When editing a parameter, press this button to restore the default value.
9INFO
Access information about the projector.
10 RE-SYNC
Re-synchronise with the current input signal.
continues on next page...
Pic Mute
OPEN CLOSE
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DisplayPort1 HD-T 3GSDI
VGA COMP1 COMP2
HDMI3
TEST
HDMI4
DisplayPort2
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
1
2
5
6
8
4
9
7
3
10
Notes
This projector does not use the
following options on the remote:
HDMI 3 and 4, DVI, VGA, COMP 1,
COMP 2, 3D, EYE and SWAP

page 8
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev B February 2018
11 LENS adjustment
FOCUS IN / OUT: adjust focus.
SHIFT: press and hold this button, then use the Navigation arrow
buttons to move the lens.
ZOOM IN / OUT: adjust zoom.
12 USER PRESET A, B, C, D
Load user presets.
13 ALT
Press and hold this button to access alternative functions for all
buttons with a green label.
14 DVI / DisplayPort2 / numeric input 3
There is no DVI input on this projector.
There is no DisplayPort2 input on this projector.
15 HDMI 2 / HDMI 4 / numeric input 2
Select the HDMI 2 input.
There is no HDMI 4 input on this projector.
16 HDMI 1 / HDMI 3 / numeric input 1
Select the HDMI 1 input.
There is no HDMI 3 input on this projector.
17 TEST / SWAP / numeric input 0
Show a test pattern. Press again to show the next test pattern:
...Off, White, Black, Red, Green, Blue, CheckerBoard,
CrossHatch, V Burst, H Burst, ColorBar, Screen Layout...
Use with ALT to switch between the Main and Sub PIP display.
continues on next page...
Notes
For further information about
user presets, see Memory in the
Operating Guide.
This projector does not use the
following options on the remote:
Inputs HDMI 3 and 4, DVI, VGA,
COMP 1, COMP 2, 3D, EYE and
SWAP
Remote control
Pic Mute
OPEN CLOSE
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DisplayPort1 HD-T 3GSDI
VGA COMP1 COMP2
HDMI3
TEST
HDMI4
DisplayPort2
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
13
11
12
14
15
16
17

page 9
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev B February 2018
17 DISPLAYPORT / R / numeric input 4
Select DisplayPort input.
Use with ALT to turn the Red channel of the display on and off.
18 HD-T / G / numeric input 5
Select the HDBaseT input.
Use with ALT to turn the Green channel of the display on and off.
19 3GSDI / B / numeric input 6
Select the 3G-SDI input.
Use with ALT to turn the Blue channel of the display on and off.
20 VGA / 3D / numeric input 7
There is no VGA input on this projector.
There is no 3D function on this projector.
21 COMP1 / EYE / numeric input 8
There is no Component 1 input on this projector.
There is no EYE swap for 3D function on this projector.
22 COMP2 / PIP / numeric input 9
There is no Component 2 input on this projector.
Use with ALT to switch on Picture In Picture (PIP) mode.
23 ADDR / ALL (with red indicator at the top)
Assign and unassign an IR remote address.
To assign an address:
1. Press and hold this button until the indicator starts ashing.
2. Release this button and while the indicator is still ashing, enter
a two-digit address using the numeric input buttons. The indicator
will ash three times quickly to conrm the change.
To unassign an address and return to the default address 00,
• Press and hold ALT and this button simultaneously until the
indicator ashes to conrm the change.
Notes
This projector does not use the
following options on the remote:
Inputs HDMI 3 and 4, DVI, VGA,
COMP 1, COMP 2, 3D, EYE and
SWAP
Remote control bottom
Pic Mute
OPEN CLOSE
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DisplayPort1 HD-T 3GSDI
VGA COMP1 COMP2
HDMI3
TEST
HDMI4
DisplayPort2
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
23
18
19
17
20
21
22
Pic Mute
OPEN CLOSE
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DisplayPort1 HD-T 3GSDI
VGA COMP1 COMP2
HDMI3
TEST
HDMI4
DisplayPort2
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
Remote control top

page 10
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev B February 2018
Infrared reception
The projector has infrared sensors at the front and back.
The angle of acceptance is 40°. Make sure that the remote control is within the angle of
acceptance when trying to control the projector.
40°
40°
Infrared reception
Notes

page 11
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
POSITIONING THE SCREEN AND PROJECTOR
Rev B February 2018
Positioning The Screen And Projector
1. Install the screen, ensuring that it is in the best position for viewing by your audience.
2. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to ll the screen. Set the adjustable feet so that
the projector is level, and perpendicular to the screen.
The drawing below shows the positions of the feet for table mounting, and the xing holes for ceiling mounting.
1Four adjustable feet
2Six M6 holes for ceiling mount
The screws should not penetrate more than 15 mm into the
body of the projector.
Notes
Always allow the projector
to cool for 5 minutes before
disconnecting the power or
moving the projector.
Ensure that there is at least 50
cm (20 in) of space between the
ventilation outlets and any wall,
and 30 cm (12 in) on all other
sides.
Do not stack more than 3
projectors.
1
2
1
1
1
2
2
2
2
2

page 12
Digital Projection HIGHlite Laser 4K Series
Installation and Quick-Start Guide
POSITIONING THE SCREEN AND PROJECTOR
Rev B February 2018
Roll and pitch
The projector can be operated in numerous positions.
It is not recommended to position the projector in portrait mode with inputs facing upward, as shown in the diagram.
1Positions to avoid: inputs side up
2Recommended positions
Notes
360° 2
Pitch
30°
330° 2
1
Roll
