Overview
PERFORMANCE SPECIFICATIONS
Brightness (±10%)
TITAN Quad 1080p-3D: up to 16,000 ANSI Lumens
TITAN Quad Reference 3D: up to 8,000 ANSI Lumens
Contrast Ratio (±10%)
TITAN Quad 1080p-3D: 2000:1
TITAN Quad Reference 3D: up to 5000:1
Display Type
.95” Darkchip DMD
DMD Specification
1920 x 1080 pixels native, +/-12 deg tilt angle
Fast transit Pixels for smooth greyscale and improved contrast.
Fill Factor
87%
Sealed Optics at DMD™ Interface
Protects DMD’s™ from optical contamination
Source Compatibility
Advanced Front End Processor:
• 3GSDIincluding1080p60fps,24p(4:4:4and4:2:2)and1080i.
• HDMIincludingDeepColorprocessing.
• Graphicsstandardsupto1920x1080resolutionat60fpsviaDVI
 orVGA.
• Componentvideo(SDandHD)viaYPrPb,RGB,orRGBS.
• S-Video(PAL,NTSC&SECAM)
• CompositeVideo(PAL,NTSC&SECAM).
Highbandwidth,pixelmappedpath:
• DualDVIacceptsgraphicsstandardsupto1920x1200@120fps.
• HDMI1.4including3DStandards
• DualPipe(2xDVIorHDMI)
HighBandwidthInput
• 3Dcapable
• PixelMapped-withlowlatency
• FastFrame™MotionBlurReduction
• 120Hzwithnoframedoubling
3D Sync
Sync In - External lock
Sync Out - Shutter glass control
NetworkConnection
IRhandsetwithwiredoptionvia3.5mmjack(withloopthrough).
LANViaRJ45withfullfeaturesetviaprotocol.
DuplicationofOSDservedfromprojectorcontrollerviaRJ45.
RS232Via9Pinconnector.
Lamp Type
Fourx400WHighIntensityDischarge
Lamp Life (typical)1
FullPower:1500hrs(upto3000hrsinlampsequentialmode)
EcoMode:2000hrs(upto4000hrsinlampsequentialmode)
Intelligent Lens Mount
MotorisedandprogrammableFocus,Zoom,andVertical
andHorizontaloffsetswithtenpositionalmemorybanks.
Lens Shift (maximum)
Fixed 1.2:1 and Zoom Lenses:
•Vert:+0.7,-0.5frame;Hor:±0.1875frame
0.73 Fixed lens:
•Vert:±0.11frame;Hor:±0.07frame
Lens Options
0.73 :1 fixed 2.02-2.77 :1zoom
1.2 :1fixed 2.77-4.51 :1zoom
1.26-1.61 :1zoom 4.51-7.53 :1zoom
1.5-2.02 :1zoom 7.5-11.2 :1zoom
•1.2:1Lensesincludemanualaperture
•High-contrastlensesavailablefor0.73:1
andallzoomlenses
Specifications subject to change without notice DP V1.0 09/2011 ©2011 Digital Projection, Inc.
™DLP, Digital Light Processing and DMD are trademarks of Texas Instruments, Inc.
TITAN Quad Series - Home Cinema
TITAN Quad 1080p-3D •TITAN Quad Reference 3D
Mechanical Mounting
•Frontorreartable;Frontorrearceiling
(ceiling mount optional)
•Rugged,stagingtolerantchassiswith
integrated handles
•OptionalRapidRig™framewithintegrated
pitch,rollandyawadjustments
Weight(chassisonly)
39 kg, 86 lbs
VideoProcessing:AdvancedFrontEndprocessor:
• ColorMax
 Eachprojectorisaccuratelycalibratedatthefac-
torywithitsnativeprimarycolorsandwhitepoint
being stored in the on-board memory. User’s choice
toemploytheexternalcontrolapplicationtodownload
hisownmeasuredcolorspace,asspecifictotheoper-
ating environment, and also his preferred Target color
space for primary and secondary colors. Not only is
this the most flexible color management technology
available, but it also enables accurate matching of pro-
jectorsintiledorblendedapplications.
• DualFlashProcessingcanbeusedtomultiplythe
displayed frame rate for 3D sources.
• FastFramemotionblurreduction.
• DualPipeprocessingallowsthedeliveryoftwo
sources in parallel, typically one for the Left Eye and
the other for the Right.
• De-interlacing,VideoenhancementandFrameDelay
Theprojectorautomaticallydetectsinterlacedvideo
and implements 3:2 or 2:2 extraction as appropriate,
withpixelbased,motionadaptiveinterpolationand
auto cadence correction.
• PIP/POP/PAP
 oUser’schoicebetweeninputsforthemainand
sub images (Picture in Picture or PIP). The processing
additionallyofferstheoptiontodisplaytwosources,
side-byside,scaledtotheverticalsizeofthepanel
Picture and Picture or PAP), or alternatively maintain-
ing their original aspect ratios (Picture Opposite Picture
or POP).
TITAN Quad displays also contain the following
capabilities for specialized applications:
• Advancedgeometrycorrection:
 oAccuratewarpmapgenerationbyadjustmentof
an interpolated grid array of up to 16 x 16 nodes. Up to
eightmapscanbegenerated,downloadedandstoredon
theprojectorforselectionviatheOSDorcontrolapplica-
tion.
 oOnboardimplementationofPincushion&Barrel,
Cornerstone,Vertical&HorizontalKeystone,andImage
Rotation.
• HighQualityEdgeBlending&MultiProjectorTiling
 oHighbitdepthprocessinginblendregiontoensure
smooth image.
 oAdjustableS-CurveParameteranddegammafunc-
tions.
o Black Level Uplift to ensure uniformity across blend
in dark images.
o Correction of black level uplift to compensate for
non-active pixels at the edge of the DMD.
 oTheusercanchoosetoassigntheprojectoraposi-
tionwithinanimagematrix.Thevideoprocessingcan
automatically extract the appropriate segment of the input
image and enable blending for the appropriate edges.
• SingleStageScaling
 oResizingandWarpfunctionsarecarriedoutina
singlestageprocessmaximizingtheclarityoftheresult-
ingimage.WhenoperatingBlendinconjunctionwith
Warptheprocessingwillautomaticallysuperimposethe
warped-blendmap,ontothegeometricallycorrected
image.
INPUT CAPABILITIES
Type
Composite
S-Video
HDMI(HDCPcompliant)
Component
Interlaced/StddefY,Cr/Pr,Cb/Pb,S
Graphics
ProgressiveRGB/ProgressiveInterlacedHidef
Y,Cr/Pr,Cb/PB
RGBHV(Progressive)
DigitalRGB
Serial Digital
SD/HD-SDI(SMPTE259M/292M)
DVI-Highbandwidth
Dual - main
Dual - sub
*Themain&subdualDVIinputscanbeusedin
parallel to support dual-pipe 3D connectivity
Connector
BNC
4-pinminiDIN
HDMI1.4
BNCx4
BNCx5
D sub (15-pin)
DVI
BNC
DVI
DVI
Quantity
1
1
2
1
1
1
1
1
1
1
DigitalProjectionInternationalpresentsarevolutioninadvanced3-chip
3D DLP displays with the new TITAN Quad product line. Incredibly
compact and efficient for such brightness capabilities, the TITAN Quad
series incorporates DP’s active 3D connectivity, Intelligent Lens Mount,
ColorMax calibration technology, and a host of advanced features to
suit any large-screen entertainment space imaginable.
Withabrightnessrangeof8,000to16,000lumens,andcontrastupto
5000:1,theTITANQuadshavebrokenthroughthe3Dprojectorbright-
nessbarrierinincomparablefashion.Asefficientastheyarepowerful,
theintroductionof thenewTITAN Quadlineupmarks theworld’sfirst
projectorsofthisbrightness,inachassiswithsuchasmallformfactor.
Incorporating the latest in Texas Instruments’ Darkchip 1080p DLP®
technology,theTITANQuadrepresentsthenewflagshipofDPI’sTITAN
product line, which now encompasses over 30 3D-capable precision
displays.
All TITAN Quad models enlist DPI’s exclusive 3D advances, including:
•HighBandwidthinput>120HzactivestereoscopicDVIwithnoneed
for frame doubling. This capability extends the dynamic range up to 16
bit for improved< contrast and color gamut.
•Dual FlashProcessing™ (DFP)– Enablesdistribution of 3D content
via 60 Hz formats by providing the option to frame-double the signal
withintheprojector.Whenthisoptionisselected,theinputsignal,hav-
ingbeenprocessedandre-sizedtomaptothenativeresolutionofthe
projector,willalsobeframe-doubledto120Hz,andthedoubledframes
interleaved.Thisproducesimagerywiththelowflickercharacteristicsof
anative120Hzsource,butwithouttheinfrastructurecostsassociated
withdistributingandswitchingultra-highbandwidthsignals.
• Projector electronics which provide an interface to drive an infrared
transmitter to synchronize switching glasses with active displayed
frames. The user can elect either to pass through an external sync
pulse, or to use the reference generated internally by the projector.
Adjustments are provided to accommodate the phase and dead time
characteristicsofdifferentswitchingglasses.
• FastFrame™ technology, a revolutionary combination of hardware
andfirmware that provides user adjustmentsto vastlyreduce the arti-
facts and image blur typically associated with rapidly moving display
content.
•For installations using curved screens, all TITAN Quad models pro-
videtheuserwithadvancedWarpandBlendcapabilities,includingthe
ability to make extensive geometric warp correction for screens with
complex geometry.
AsisthecasewithallDigitalProjectiondisplays,ourcarefulengineer-
ing guarantees TITAN projectors provide remarkable resolution, color
saturationand lightoutputforyearstocome.Equally important,DPI’s
legacy in providing superior customer and technical services assures
ourexperiencedsupportstaffisalwaysavailabletoaddressyourneeds.
TITANQuad1080p-3Ddisplays...now,FourisMore.
1080p-3D

Native Color Temperature
HDTV Formats Supported
Scan Rates Supported
Remote Control
Automation Control
Operating/Storage Temperature
Operating Humidity
Thermal Dissipation
Fan Noise
Power Requirements
Power Consumption
PARAMETERS
Projectors Part #
TITAN Quad 1080p-3D 111-872
TITAN Quad Reference 3D 112-145
Accessories Part #
TITAN Quad 3D Lamp & Housing* (4 required) 111-896A
RapidRigTM Frame 107-956
TITAN Quad 3D Series Adjustable Ceiling Mount 111-897A
Infrared Remote (Replacement) 105-023
* Includes high-performance replacement air filter(s)
1Based on 4-6 hour/day operational profile. Venue and application conditions may
impact actual lamp life.
See Digital Projection’s Product Warranty Statement for details on lamp warranty.
Installations requiring horizontal or vertical tilt orientations greater than 15 degrees
may reduce the actual operational hours of one of the two lamps.
ADVANCED TECHNICAL SPECIFICATIONS
DIGITAL PROJECTION, INC. • 55 CHASTAIN ROAD, SUITE 115 KENNESAW, GA. 30144 • T: 770.420.1350 • F: 770.420.1360 • www.digitalprojection.com
DIGITAL PROJECTION, LTD. • GREENSIDE WAY, MIDDLETON MANCHESTER, UK. M24 1XX • T: +44.161.947.3300 • F: +44.161.684.7674 • www.digitalprojection.co.uk
DIGITAL PROJECTION, CHINA • TOWER C, RM C1202, CAI FU JIA YUAN, NO. 19 XIA0 YING STREET, CHAOYANG DISTRICT BEIJING, PR CHINA 100101 • T: +86.10.58239771• F: [phone]
DIGITAL PROJECTION, ASIA • 16 NEW INDUSTRIAL ROAD, #02-10 HUDSON TECHNOCENTRE SINGAPORE 536204 • T: +65.6284.1138 • F: +65.6284.1238
Projector Dimensions
TITAN Quad Series
Projectordimensions(in)
L127.1W121.3H110.2
TM
CORE TECHNOLOGY
Projectordimensions(mm)
L1688W1540H1258
NativeColorTemperature:UserSelectablefrom3200K,to10000K
Signalformats480i,576i480p,576p,720p,1080i(50,59.94and60Hz)and1080p(23.98,24,25,29.97and30Hz).
The3GSDIInputsupportsSD-SDI,HD-SDIand3G-SDIYCbCr4:2:2serialdigitalcomponentvideo.SMPTE292M,SMPTE
259M-CandSMPTE424Mcompliant.Accepts484i,576i,720p,1080iand1080pSinglelinkformatsat270Mb,1.485Gbor
2.97Gbrates.StreamA&StreamB-switchable.
HDMI&DVIInputs-HDMI1.3withorwithoutHDCP,36bitvideocompatible.
DVI-DinputwithorwithoutHDCP.
AddressableIPremotecontrol,wirelessandwiredwithloopthrough.OnBoardkeypad.
LANconnectionviaRJ45/RS2329pinDType.
Operating0-40C.Storage-10to+50C
20 to 80% non-condensing
7161 BTU/hr
TBA
200-265VAC50/60HzSinglePhase.
2100Watts
1080p Lenses HB Part # HC Part #
0.67:1 105-607 107-195
1.12:1 105-608 105-608
1.16 - 1.49:1 109-236 109-359
1.39 - 1.87:1 105-610 107-196
1.87 - 2.56:1 105-611 107-197
2.56 - 4.16:1 105-612 107-198
4.16 - 6.96:1 105-613 107-199
6.92 - 10.36:1 109-235 109-358
1080p-3D
