Digital Projection E-Vision 8000 Series User manual

Rev A April 2012
USER GUIDES
INSTALLATION AND QUICK-START GUIDE
CONNECTION GUIDE
OPERATING GUIDE
REMOTE COMMUNICATIONS GUIDE
112-796A
E-Vision 8000 Series
High Brightness Digital Video Projector
BOOK CONTENTS
About these Guides
Symbols used in these guides
Warnings
Notes
Product revision

Digital Projection E-Vision series
Rev A April 2012
About these Guides
Please read this guide carefully before using the projector, and keep it handy for future reference.
A serial number is located on the back of the projector. Record it here:
Symbols used in these guides
Warnings
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
Notes
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice. Projectors built prior to this revision of the Operating Guide may therefore not include all the features described.

Rev A April 2012
E-Vision 8000 Series
High Brightness Digital Video Projector
INSTALLATION AND QUICK-START GUIDE
BOOK CONTENTS
INSTALLATION AND QUICK-START GUIDE
What’s in the Box?
Getting to Know the Projector
Front and rear views

Digital Projection E-Vision 8000 series CONTENTS Installation and Quick-Start Guide
Rev A April 2012
CONTENTS
What’s in the Box?...............................................................................Inst_1
Getting to Know the Projector....................................................Inst_2
Front and rear views .............................................................................Inst_2
Remote control......................................................................................Inst_2
Control panel .........................................................................................Inst_3
Indicators ...............................................................................................Inst_3
Changing the lens, lamps, lters and colour wheel ....Inst_4
Removing the lens ................................................................................Inst_4
Fitting the lens.......................................................................................Inst_4
Changing a lamp ...................................................................................Inst_5
Changing the lters...............................................................................Inst_5
Changing the colour wheel ..................................................................Inst_6
Positioning the Screen and Projector....................................Inst_7
Operating the Projector...................................................................Inst_8
Switching the Projector On ..................................................................Inst_8
Selecting an Input Signal or Test Pattern ...........................................Inst_8
Input signal....................................................................................Inst_8
Test pattern ...................................................................................Inst_8
Adjusting the Lens................................................................................Inst_9
Zoom.............................................................................................Inst_9
Focus ............................................................................................Inst_9
Shift...............................................................................................Inst_9
Adjusting the Image..............................................................................Inst_9
Orientation.....................................................................................Inst_9
Aspect Ratio..................................................................................Inst_9
Picture...........................................................................................Inst_9
Switching the Projector Off................................................................Inst_10

Digital Projection E-Vision 8000 series WHAT'S IN THE BOX? Installation and Quick-Start Guide
Page Inst_1Rev A April 2012
What’s in the Box? Notes
Make sure your box contains
everything listed. If any pieces are
missing, contact your dealer.
You should save the original box
and packing materials, in case you
ever need to ship your Projector.
Only one power cable - dependent
on the destination territory - will be
supplied with the projector.
Remote control
(112-532)
2x AAA batteries
User Guides on CD
(112-456) Important Information
(112-797)
Projector
Lens cap
Power cable,
China
(112-817)
Power cable,
United Kingdom
(112-814)
Power cable,
Europe
(112-816)
Power cable,
North America
(112-815)

Digital Projection E-Vision 8000 series GETTING TO KNOW THE PROJECTOR Installation and Quick-Start Guide
Page Inst_2Rev A April 2012
Getting to Know the Projector
Front and rear views
Notes
The projector can use an infra-red or
a wired remote control.
Some of the controls are duplicated
on the projector control panel, as
shown on the next page.
For full details of how to use the
controls and the menu system, see
the Operating Guide.
 Theairltersshouldbecleanedor
changed regularly, depending on the
installation environment.
 Theltersshouldbechangedatthe
same time as the lamp is changed.
The projector lens is shipped
separately.
Lens Connection
panel
Mains
input
Control
panel
Adjustable
feet
Front
infra-red
window
Rear
infra-red
window
Remote control
Infra-red
reception
40°
40°
Air
inlet
Air
inlet
Air
outlets
Colour wheel
cover
Air lter
cover
Air lter
cover
Lamp
covers
Indicator
panel

Digital Projection E-Vision 8000 series GETTING TO KNOW THE PROJECTOR Installation and Quick-Start Guide
Page Inst_3Rev A April 2012
Control panel
Some of the controls from the remote control are duplicated on the projector control panel, as
shown below.
The EXIT button has the same function as the RETURN button on the remote control.
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.
Indicators
SHUTTER off = OPEN green = CLOSED
TEMP off = NO ERROR ashing red = ERROR (temperature)
LAMPS 1,2 off = OFF
ashing red = LAMP ERROR red = END OF LIFE
ashing green = LAMP WARM-UP green = ON
STATUS off = NO ERROR
ashing red (1 ash) = COVER OPEN ashing red (4 ashes) = FAN ERROR
red = SYSTEM ERROR
POWER off = NO POWER
green = normal RUNNING mode red = STANDBY mode
ashing green = PROJECTOR WARM UP
ashing amber = PROJECTOR COOL DOWN

Digital Projection E-Vision 8000 series CHANGING THE LENS, LAMPS, FILTERS AND COLOUR WHEEL Installation and Quick-Start Guide
Page Inst_4Rev A April 2012
Changing the lens, lamps, lters and colour wheel
Removing the lens
• Push in the lens release lever, and turn the lens anti-clockwise.
• Remove the lens.
Fitting the lens
• Remove the lens cap.
• Position the lens so that the labels are at the top, and gently insert it all the way into the
lens mount.
• Push the lens in rmly, and turn it clockwise until it clicks into place.
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
- changing the lamp
The projector lens is shipped
separately.

Digital Projection E-Vision 8000 series CHANGING THE LENS, LAMPS, FILTERS AND COLOUR WHEEL Installation and Quick-Start Guide
Page Inst_5Rev A April 2012
Changing a lamp
• Unscrew the two captive screws securing the cover for the lamp that needs changing.
• Open the lamp compartment.
• Unscrew the three captive screws securing the lamp module.
• Pull rmly on the handle to remove the lamp module.
• Insert a new lamp module and fasten the screws.
• Replace the lamp compartment cover and fasten the screws.
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
- changing the lamp
The lamp and colour wheel must
be changed only by suitably
qualied personnel.
Note that the projector will shut
down if any of the covers is opened
whilst in operation.
 Theltersshouldbechangedatthe
same time as the lamp is changed.
Lamp 1 Lamp 2
Cover
screws
Lamp compartment
Lamp module
screws
Lamp 1 Lamp 2
Handle
Changing the lters
• Unscrew the captive screws securing the cover for the
side air inlet.
• Replace the lter, making sure that the arrow showing
the air ow direction is pointed inwards.
• Replace the cover and fasten the screws.
• Remove the cover for the side air inlet by pushing it
rmly to the right, as shown.
• Replace the lter, making sure that the arrow showing
the air ow direction is pointed inwards.
• Replace the cover.
Front air inlet
lter
Side air inlet
lter

Digital Projection E-Vision 8000 series CHANGING THE LENS, LAMPS, FILTERS AND COLOUR WHEEL Installation and Quick-Start Guide
Page Inst_6Rev A April 2012
Changing the colour wheel
• Unscrew the captive screw securing the
colour wheel compartment cover.
• Open the colour wheel compartment.
• Unscrew the four captive screws securing
the colour wheel.
• Remove the colour wheel.
• Insert a new colour wheel and fasten the
screws.
• Replace the cover and fasten the screw.
Cover
screw
Colour wheel
compartment
Colour
wheel
screws
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
- changing the lamp
The lamp and colour wheel must
be changed only by suitably
qualied personnel.
 Theprojectorrmwareiscolour
wheelspecic,andsowillneedto
be changed at the same time as the
wheel.
For assistance, contact your dealer.
Note that the projector will shut
down if any of the covers is opened
whilst in operation.

Digital Projection E-Vision 8000 series POSITIONING THE SCREEN AND PROJECTOR Installation and Quick-Start Guide
Page Inst_7Rev A April 2012
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
Ensure that there is at least
70cm (28in) of space between
the ventilation outlets and any
wall, and 50cm (20in) on all other
sides.
If ceiling mounting, ensure there
is 30cm (12in) of space between
the projector and ceiling.
Backup safety chains or wires
should always be used with
ceiling mount installations.
Do not stack the projectors.
Do not tilt the projector more
than ±12° in either direction, in
desktop or ceiling mode, when in
use, as this may cause serious
lamp failure, damage the lamp
module and cause extra cost on
replacement.
±10°
±360°
±10°
Desktop
Ceiling
Positioning the Screen and Projector
• Install the screen, ensuring that it is in the best position for viewing by your audience.
• Mount the projector, ensuring that it is at a suitable distance from the screen for the image to ll the screen. Set the adjustable feet so that
the projector is level, and perpendicular to the screen.
• The dimension drawing below shows the positions of the feet for table mounting, and the xing holes for ceiling mounting.
All dimensions are in mm.

Digital Projection E-Vision 8000 series OPERATING THE PROJECTOR Installation and Quick-Start Guide
Page Inst_8Rev A April 2012
Operating the Projector
Switching the Projector On
• Connect the power cable between the mains supply and the projector. Switch on at the switch next to the power connector.
• Wait until the self-test has completed and the Power indicator on the projector control panel shows red. The lamp will be off and the
projector will be in STANDBY mode.
• Press POWER on the control panel or POWER ON on the remote control.
The Power indicator on the control panel will ash green for a few seconds whilst the lamp comes up to full brightness. When the
projector is ready for use, the Power indicator will show steady green.
Selecting an Input Signal or Test Pattern
Input signal
• Connect an image source to the projector. The signal should be automatically detected by the projector, and should be displayed within a
two or three seconds.
• If more than one signal is connected, then select the image you want to display:
Press INPUT repeatedly on the control panel or remote control to cycle through the inputs.
or use Input Selection in the INPUT menu.
Test pattern
If you have an image source connected to the projector, then you can display a test pattern instead:
Press TEST PATTERN repeatedly on the remote control to cycle through the test patterns,
or select a Test Pattern from the INPUT menu.
To return to viewing the image from your image source, scroll through the test pattern list to Off.
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
For full details of how to connect an
image source to the projector, see
the Connection Guide.
For full details of how to use the
controls and the menu system, see
the Operating Guide.
If there is no image source
connected to the projector, then
the Test Pattern feature is NOT
available.

Digital Projection E-Vision 8000 series OPERATING THE PROJECTOR Installation and Quick-Start Guide
Page Inst_9Rev A April 2012
Adjusting the Lens
Zoom
• Use the ZOOM +/− buttons on the control panel or on the remote control to adjust the
lens so that the image lls the screen.
or use Lens Control in the ALIGNMENT Menu.
Focus
• Use the FOCUS +/− buttons on the control panel or on the remote control to adjust the
lens until the image is sharp.
or use Lens Control in the ALIGNMENT Menu.
Shift
• Use the LENS SHIFT buttons , , and on the control panel to adjust the
position of the image,
or press the LENS SHIFT button on the remote control then use , , and
to adjust the position of the image.
or use Lens Control in the ALIGNMENT Menu.
Adjusting the Image
Orientation
• Use the Rear Projection or Ceiling Mode settings, in the ALIGNMENT Menu.
Aspect Ratio
• Press the RESIZE button on the control panel or the ASPECT button on the remote
control to cycle through all the available settings.
or use the Aspect Ratio setting in the PICTURE Menu.
• Press PICTURE on the remote control or use the menu controls, to open the PICTURE
Menu.
Use the sliders in the PICTURE menu to adjust the brightness, contrast etc.
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.

Digital Projection E-Vision 8000 series OPERATING THE PROJECTOR Installation and Quick-Start Guide
Page Inst_10Rev A April 2012
Switching the Projector Off
• Press and hold POWER on the control panel or POWER OFF on the remote control for 5 seconds.
The lamp will go off, and the Power indicator on the control panel will ash amber for a few seconds whilst the lamp cools. The Power
indicator on the control panel will then show red and the projector will be in Standby mode.
• Switch off at the switch next to the power connector. Disconnect the power cable from the projector.
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector

Rev A April 2012
E-Vision 8000 Series
High Brightness Digital Video Projector
CONNECTION GUIDE
BOOK CONTENTS
CONNECTION GUIDE
Signal Inputs and Outputs
3G-SDI IN
3G-SDI OUT

Digital Projection E-Vision 8000 series CONTENTS Connection Guide
Rev A April 2012
CONTENTS
Signal Inputs and Outputs .......................................................... Conn_1
3G-SDI IN............................................................................................. Conn_1
3G-SDI OUT......................................................................................... Conn_1
HDMI .................................................................................................... Conn_1
DVI-D.................................................................................................... Conn_1
VGA...................................................................................................... Conn_1
COMPONENT...................................................................................... Conn_1
S-Video ................................................................................................ Conn_1
Video.................................................................................................... Conn_1
Supported Signal Input Modes................................................. Conn_2
Control Connections .......................................................................Conn_3
LAN...................................................................................................... Conn_3
RS232 .................................................................................................. Conn_3
Wired Remote Control ....................................................................... Conn_3
Screen Trigger .................................................................................... Conn_3
Wiring Details....................................................................................... Conn_4
Signal inputs and outputs ................................................................. Conn_4
3G-SDI .......................................................................................Conn_4
HDMI input .................................................................................Conn_4
DVI-D .........................................................................................Conn_5
VGA............................................................................................Conn_6
COMPONENT............................................................................ Conn_6
S-Video input.............................................................................. Conn_7
Video input ................................................................................. Conn_7
Control connections .......................................................................... Conn_8
LAN connection.......................................................................... Conn_8
RS232 Serial control input ......................................................... Conn_9
Wired Remote control connection.............................................. Conn_9
Screen Trigger output................................................................. Conn_9

Digital Projection E-Vision 8000 series SIGNAL INPUTS AND OUTPUTS Connection Guide
Page Conn_1Rev A April 2012
Signal Inputs and Outputs
3G-SDI IN
• Connect a 3G-SDI cable to the left hand SDI BNC.
3G-SDI OUT
• Connect a 3G-SDI cable to the right hand SDI BNC, to distribute the signal to another
projector.
HDMI
• Connect a HDMI cable to the HDMI connector.
DVI-D
• Connect a DVI-D cable to the DVI connector.
VGA
• If necessary, use the VGA Setup controls in the PICTURE menu. For more information,
see the Operating Guide.
• Set Color Space in the INPUT menu to Auto or RGB-PC.
COMPONENT
RGBHV, RGsB or RGBS
• Set Color Space in the INPUT menu to Auto or RGB-Video.
YPbPr or YCbCr
• Set Color Space in the INPUT menu to YPbPr or YCbCr.
S-Video
• Connect an S-Video cable to the 4-pin mini-DIN.
Video
• Connect a composite video cable to the single RCA phono connector.
• Set Video Standard in the INPUT menu to Auto, PAL, SECAM, or NTSC
COMPONENT
Notes
For a complete listing of pin
congurationsforallsignaland
control connectors, see Wiring
Details later in this Guide.
VGA
DVI-D S-VIDEO
3G-SDI
IN OUT HDMI VIDEO
OPTION
BOARD

Digital Projection E-Vision 8000 series SUPPORTED SIGNAL INPUT MODES Connection Guide
Page Conn_2Rev A April 2012
Supported Signal Input Modes
Signal Resolution Refresh
Rate
( Hz )
Total
number
of lines
Horizontal
Frequency
(kHz)
VIDEO
S-VIDEO
COMPONENT
VGA
DVI/HDMI
SDI
SDTV 480i 720 x 480 59.94 525 15.73 ü ü ü ü
576i 720 x 576 50 625 15.63 ü ü ü ü
HDTV 480p 720 x 480 59.94 525 31.47 ü ü
576p 720 x 576 50 625 31.25 ü ü
720p50 1280 x 720 50 750 37.50 ü ü ü
720p60 1280 x 720 60 750 45.00 ü ü ü
1080p24 1920 x 1080 24 1125 27.00 ü ü ü
1080i50 1920 x 1080 50 1125 28.13 ü ü
1080p25 1920 x 1080 25 1125 28.13 ü ü ü
1080i60 1920 x 1080 60 1125 33.75 ü
1080p30 1920 x 1080 30 1125 33.75 ü ü ü
1080p50 1920 x 1080 50 1125 56.24 ü ü
1080p60 1920 x 1080 60 1125 67.48 ü ü
COMPUTER 480p 640 x 480 60 525 31.47 ü ü
VGA75 640 x 480 75 500 37.50 ü ü
SVGA60 800 x 600 60 628 37.88 ü ü ü
XGA60 1024 x 768 60 806 48.36 ü ü ü
XGA70 1024 x 768 70 806 56.48 ü ü
XGA85 1024 x 768 85 808 68.68 ü ü
WXGA60 1280 x 768 60 798 47.78 ü ü
WXGA+60 1440 x 900 60 934 55.94 ü ü
SXGA60 1280 x 1024 60 1066 63.98 ü ü
SXGA+60 1400 x 1050 60 1089 65.32 ü ü
UXGA60 1600 x 1200 60 1245 75.00 ü ü
VESA 1080p 1920 x 1080 60 1120 67.5 ü ü
WUXGA60 1920 x 1200 60 1235 74.038 ü ü

Digital Projection E-Vision 8000 series CONTROL CONNECTIONS Connection Guide
Page Conn_3Rev A April 2012
Control Connections
LAN
• All of the projector’s features can be controlled via a LAN connection, using the control
strings described in the Remote Communications Guide..
• The LAN IP Address of the projector can be set by using the LAN IP Conguration
Utility. To see what the Address is set to, you can view the current Network settings in
the CONTROL Menu.
For more information about these settings, see the Operating Guide.
RS232
• The RS232 port can be used to download rmware updates, issued from time to time by
Digital Projection.
• All of the projector’s features can be controlled via a serial connection, using the control
strings described in the Remote Communications Guide.
Wired Remote Control
• If infrared signals from the remote control cannot reach the projector due to excessive
distance or obstructions such as walls or cabinet doors, you can connect an external
IR repeater to the Remote control input, and position its IR sensor within range of the
operator.
Note that plugging in the remote control cable will disable the infra-red.
Screen Trigger
• The Trigger output can be connected to an electrically operated screen, automatically
deploying the screen when the projector is switched on, or activating curtains when the
aspect ratio is changed.
Notes
For a complete listing of pin
congurationsforallsignaland
control connectors, see Wiring
Details later in this Guide.
Eco Network Power must be set to
Standard, if you wish to control the
projector via the LAN connection.
Only one remote connection can be
used at any one time as determined
by the Projector Control setting in
the CONTROL menu.
For full details of how to use the
menu system, see the Operating
Guide.
LAN RS232
SCREEN
TRIGGER
MAINS
WIRED
REMOTE

Digital Projection E-Vision 8000 series WIRING DETAILS Connection Guide
Page Conn_4Rev A April 2012
Wiring Details
Signal inputs and outputs
3G-SDI
75 ohm BNC
SMPTE 292 / HD-SDI signals are very high speed digital signals which require better quality
coaxial cable than conventional analogue video. The data rate is 1.5 Gigabits per second.
In choosing cable length and connectors for any installation the frequency response loss
in decibels should be proportional to √f, from 1MHz, to 1.5GHz. The following or similar
cable specication should be used to ensure fault free communication between source and
projector:
Belden 8281 cable or equivalent
HDMI input
19 way type A connector
1 TMDS Data 2+
2 TMDS Data 2 Shield
3 TMDS Data 2-
4 TMDS Data 1+
5 TMDS Data 1 Shield
6 TMDS Data 1-
7 TMDS Data 0+
8 TMDS Data 0 Shield
9 TMDS Data 0-
10 TMDS Clock+
11 TMDS Clock Shield
12 TMDS Clock-
13 CEC
14 not connected
Notes
For full details of all input settings,
see the INPUT menu in the
Operating Guide.
15 SCL (DDC Clock)
16 SCA (DDC Data)
17 DDC/CEC Ground
18 +5 V Power
19 Hot Plug Detect
pin view of panel connector
