Digital Sputnik DS 1 User manual

DS 1 Assembly
digitalsputnik.com
FIG 1
FIG 2 INSERTING AND LOCKING
THE LIGHT MODULE LOCK
This guide helps You to
assemble one module light
fixture and also explains the
basis of the Controls
SLIDE
PUSH LOCK
LOCK
OPEN/LOOSE
LOCK
CLOSED/TIGHT
LOCK
TIGHTEN
CONTROLS
FIG 3
FIG 5
FIG 4
FIG 2
CONNECTING THE LIGHT MODULE
AND DIMMER WITH CABLE
CONNECTING DIMMER AND
LIGHT MODULE
SLIDE
All Color DS fixtures are driven by 4 Controls:
1. Intensity (0-100%)
2. Temperature (1500K-10000K)
3. Saturation (-100% - 100%)
If Hue is 120° (default value) then Saturation acts as +/- green
4. Hue (0°-360°)
0° Red / 60° Yellow / 120° Green / 180° Cyan / 240° Blue /
300° Magenta
To move around the menu rotate the wheel button.
It’s possible to change the value of a parameter by
pressing on the wheel button and then rotating it.
After the value is changed press the wheel button again
to confirm the value. In the SETUP menu it’s possible to
change the module and remote settings.
CONNECTORS
Ds Light Module
DMX in
DMX out
DC (12-36 V)
RED (0°)
MAGENTA (300°)
YELLOW (60°)
BLUE (240°)
GREEN (120°)
CYAN (180°)
RED (0°)
WHITE POINT CAN BE CHANGED FROM 1500 K TO 10000 K
MAGENTA (300°)
YELLOW (60°)
BLUE (240°)
1500 K
GREEN (120°)
CYAN (180
°)
SATURATION SATURATION
0% 100%
-100%
H
U
E
10000 K
SATURATION SATURATION
0%
H
U
E
100%
-100%
COLOR
ALL
SETUP
0%
56OOK
O%
0
1
2
3
4
