Digitus DN-80117 User manual

10-INCH 8-PORT GIGABIT
ETHERNET SWITCH, L2 MANAGED
Quick installation guide
DN-80117
1. About Guide
This guide provides instructions to install the Ethernet Switch.
Note: The model you have purchased may appear slightly different from the
illustrations shown in the document. Refer to the Product Instruction and
Technical Specification sections for detailed information about your switch, its
components, network connections, and technical specifications.
This guide mainly divided into 4 parts:
1. About guide: Terminology/Usage
2. Product introduction: functional overview and introduction of panel definitions
3. Hardware installation: step by step hardware installation process
4. Technical Specifications
Terminology / Usage
In this guide, the term "Switch" (first letter capitalized) refers to the Ethernet Switch,
and "switch" (first letter lower case) refers to other Ethernet switches. Some
technologies refer to terms "switch", "bridge" and "switching hubs" interchangeably,
and both are commonly accepted for Ethernet switches.
Note: indicates important information that helps a better use of the device.
Warning: indicates potential property damage or personal injury.
Copyright and trademark
The pictures and data shown in this guide are for reference only, subject to change
without notice.
2. Products Introduction
Thanks for purchasing the Managed Ethernet switch products.
This product is a network management type Gigabit Ethernet Switch. The machine
comes with 8x 10/100/1000 Mbps RJ45 ports which can satisfy the full speed
forwarding of ports. The machine is a small size metal-shell device which is useful for
the small office can home and the IP solution project using, be used on the desktop or
Wall mounting. Excellent performance can help you widely use in wireless, monitoring
and other fields.
Front Panel
The front panel consists of LED indications and network ports
LED Lamp
Power LED: The Power LED lights up when the switch is connected to a power source.
Link/Act indicator: the light indicates the network connection through the
corresponding port. Flicker indicates that the switch is sending or receiving data.
Side Panel
RST: By pressing the Reset button for 5 seconds the switch will change back to the
default configuration and all changes will be lost.
Rear Panel
The rear panel view of the Ethernet switch consists of an AC power connector.
(1) Grounding: use specialized ground lead connect
(2) Connect the power adapter output terminal to this port.
Supports input voltages 100-240VAC
3. Hardware installation
This chapter provides unpacking and installation information for the Managed
Ethernet Switch.
Open a seal
Open the shipping carton and carefully unpack its contents. Please consult the packing
list located in the User Manual to make sure all items are present and undamaged. If
any item is missing or damaged, please contact the local reseller for replacement.
Switch 1pcs
User's manual 1pcs
AC power cord 1pcs
CD ROMs 1pcs
Switch installation
For safe switch installation and operation, it is recommended that you:
Visually inspect the power cord to see that it is secured fully to the AC power
connector.
Make sure that there is proper heat dissipation and adequate ventilation around
the switch.
Do not place heavy objects on the switch.
Installation hole spacing
Connecting power supply
Using the AC power cord to connect to of the into the AC socket on the back of the
switch.
Warning: Do not turn on the power switch before power cables are connected.
Power surge may cause damage to the Switch.
Power failure
As a precaution, the switch should be unplugged in case of power failure. When power
is resumed, plug the switch back in.

Network connection
The Managed Switch can be managed through any port on the device by using the
Web-based management.
Using Web-based Management
After a successful physical installation, you can configure the Switch, monitor the
network status, and display statistics using a web browser.
Supported Web Browsers
The embedded Web-based Management currently supports the following web
browsers:
Internet Explorer 6 or higher version
Netscape 8 or higher version
Mozilla
Firefox 1.5/2.0 or higher version
Connecting to the Switch
You will need the following equipment to begin the web configuration of your device:
1. A PC with a RJ-45 Ethernet connection
2. Standard Ethernet network Line
3. A standard Ethernet cable
Connect the Ethernet cable to any of the ports on the front panel of the switch and to
the Ethernet port on the PC.
Login Web-based Management
1. To access the GUI of the switch, open a browser and type the default management
address http://192.168.0.1 in the address field of the browser, then press the
Enter key.
Note: To log in to the switch, the IP address of your PC should be set in the same
subnet as that of the switch. The IP address is 192.168.0.x
(”x” is any number from 2 to 254). Subnet Mask is 255.255.255.0.
For details, please refer to Appendix B in the User Guide on the resource CD.
2. Enter admin for both the User Name and Password in the lower case letters.
Then click the Login button or press the Enter key.
3. After a successful login, the main page will appear as follows, and you can click the
menu on the left side to configure the corresponding functions.
Note: For more details about how to configure the switch, see the User Guide on the
resource CD.
4. Technical Specifications
Project
describe
Summary
Fixed port
8x10/100/1000Base-TX RJ45 ports
Standards and
protocols
IEEE802.3 10Base-T Ethernet standard
IEEE802.3u 100Base-TX Fast Ethernet standard
IEEE802.3ab 1000Base-T Ethernet standard
IEEE802.3z Gigabit Ethernet (fiber) IEEE802.3x Full
duplex flow control and Backpressure Half duplex flow
control
IEEE802.3ab Link aggregation
Forwarding Rate
10/100/1000Mbps
LED Indicators
Power, Link/Act
AC Input Voltage Range
100V~240V AC, 50/60Hz
Power consumption
10W
Operating temperature
0℃～40℃
Storage temperature
-10℃～70℃
Relative humidity
20%~85% (non-condensing)
Switching Fabric
16G
MAC Addresses
8K
Software Technology
Port Feature
Port Control, Port Isolation, Port Self-loop Detection
Port Mirroring
Multi to 1 Sniffer
VLAN
Port-base & 802.1q Tag-base VLANs
Link Aggregation
Up to 8 maximum aggregation groups, each containing
up to 4GE
Traffic control
IEEE 802.3x full-duplex flow control
Rate Limit
Unit: 64kbps
Spanning Tree
Support STP, RSTP, MSTP
Ring Protocol
Support EAPS
Multicast
Support 256 Multicast groups, Support IGMP Snooping
HOST Static Route
Support Static ARP & Static Routing, up to 32 L3 VLAN
Interface
QoS
4 output queues on each port
Support flexible queue scheduling algorithms: WRR,
Q+WRR
Support port-based / MAC-based / 802.1p / DSCP
classification
ACL
Support Standard IP / Extend IP / MAC IP / ARP, up to
512 entries
Security
Support MAC-based 802.1X authentication
Support AAA/RADIUS authentication
Support WEB/Telnet password protection
Support Accessing privilege mode password protection
SMNP
Support
Configuration File
Support Download/Upload configuration File via WEB /
TFTP
Upgrade Firmware
Support Upgrade Firmware via WEB / TFTP
Management Interface
Support WEB, SNMP, CLI, Telnet,
Reset Button
<5 sec: System reboot
>5 sec: Factory default
Mechanical
Casing
Metal
Dimensions (W x L x H)
252 mm x 150 mm x 44 mm
This is a Class A product. In home environment, this product may cause radio
interference. In this case, the user may be required to take appropriate measures.
Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is part
of the shipping content. If the Declaration of Conformity is missing, you can request it
by post under the below mentioned manufacturer address.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
