Digitus DN-60021-2 User manual

16-Port/24-Port 10/100Mbps
Ethernet Switch
User Manual
DN-60011-2 DN-60021-2

Package Contents
Check the following contents of your package:
 Network Switch x1
 User Manual x1
 Power Cord x1
 Accessories (Rack Mount Accessory Kit x2, Rubber Feet x4, screw x8)
If any part is lost and damaged, please contact your local agent immediately.
Introduction
This DIGITUS Unmanaged Switch offer 16 port (DN-60011-2) and 24 port
(DN-60021-2) 10/100Mbps RJ45 port. Using store and forward technology, combined
with dynamic memory allocation, to ensure the effective allocation of bandwidth to
each port. It is easy to manage and maintain which can meet a lot of networking
environment, such as Business building, Community, Hotel, Office etc.

Specifications
Model DN-60011-2 DN-60021-2
Description 16 Port Fast Ethernet
Switch
24 Port Fast Ethernet
Switch
Standard IEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x
Network Media 10BASE-T: UTP category 3,4,5 cable (≤100m)
100BASE-TX: UTP category 5 cable (≤100m)
MAC Address Table 8K, Auto-learning, Auto-aging
Transfer mode Store-and-Forward
Frame Forward Rate 10Base-T: 14881pps/Port
100Base-TX: 148810pps/Port
Switching Capacity 3.2Gbps 4.8Gbps
Forwarding Rate 2.4Mpps 3.6Mpps
Packet buffer 2M bit
Dimensions (L*W*H) 280 *179 *44 mm
Fan Fanless
Power Input AC: 100~240V, 50/60Hz
Temperature Operating Temperature: 0°C ~ 40 °C (32 °F ~104°F)
Storage Temperature: -40 °C ~ 70 °C (-40 °F ~158°F)
Humidity Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
Green energy saving IEEE 802.3az
MTBF >50000 hours

Hardware Description
Front Panel
The Front Panel Consists of Ethernet Ports. The LED indicators are also
located on the panel.
16 Port Network Switch
24 Port Network Switch
2
4
*
1
0/
1
00
M
bp
s Port
LED indicator
16*10
/
100Mb
p
s Port
LED indicator

LED indicator
LED Color Function
PWR Green
Off: No Power supply.
Light: Indicates the switch has power.
LNK/ACT Green
Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is
successfully established at 10/100Mbps.
Blink: Indicates that the Switch is actively sending or
receiving data over that port.
Rear Panel
The rear panel of the Switch indicates an AC inlet power socket, which accepts input
power from 100 to 240V AC, 50/60HZ.
Power Socket
Grounding Column

Power socket
Connect the female connector of the power cord here, and the male connector to
the AC (Alternating Current) power outlet. Please make sure the voltage of the power
supply meets the requirement of the input voltage
Grounding column
The switch already comes with lightning protection mechanism. You can also ground
the switch through the PE (Protecting Earth) cable of AC cord or with Ground Cable.
Installation the Switch
This part describes how to install your Ethernet Switch and make connections to it.
Please follow the following instructions in avoid of incorrect installation causing
device damage and security threat.
Before cleaning the switch, unplug the power plug of the switch first. Do not clean
the switch with wet cloth or liquid.
Do not place the switch near water or any damp area. Prevent water or moisture
from entering the switch chassis.
Do not place the switch on an unstable case or desk. The switch might be
damaged severely in case of a fall.
Ensure proper ventilation of the equipment room and keep the ventilation vents of
the switch free of obstruction.
Make sure that the operating voltage is the same one labeled on the switch.
Do not open the chassis while the switch is operating or when electrical hazards
are present to avoid electrical shocks.

Desktop Installation
Install the Switch on a desktop, please attach these cushioning rubber feet provided
on the bottom at each corner of the Switch in case of the external vibration. Allow
adequate space for ventilation between the device and the objects around it.

Rack-mountable Installation
The switch is rack-mountable and can be installed on an EIA-19 inch equipment rack.
To do this, first, please install the mounting brackets on the switch’s side panels (one
on each side), secure them with the included screws, and then use the screws
provided with the equipment rack to mount the switch on the 19 inch rack.

Turn on the switch
Please connect the AC power cord into the rear of the switch and to an electrical
outlet (preferably one that is grounded). When the switch is powered on, the LED
indicators flash momentarily for one second, which represents a resetting of the
system. The Power LED indicator turns on green.
Note:
Please confirm the voltage is correct before power on, otherwise the switch will be
damaged. (The power input is: 100V-240Vac, 50/60Hz.)

This is a Class A product. In home environment, this product may cause radio interference. In this
case, the user may be required to take appropriate measures.
Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is part of the
shipping content. If the Declaration of Conformity is missing, you can request it by post under the
below mentioned manufacturer address.
