Digitus DN-95323 User manual

8 Ports
Fast Ethernet PoE Switch
Manual
DN-95323

8 Ports PoE Ethernet Switch
8 ports PoE Ethernet Switch is a surveillance security Ethernet switch which
aims at Ethernet high definition surveillance, Ethernet project security system.
The product fully combines the characteristic of surveillance security, provides
fast packet forwarding ability and abundant backplane bandwidth, which
ensures clear image and fluent transmission. Inserted static, surge protection
circuit can improve product stability. The product supports one key VLAN mode,
can achieve VLAN, QoS priority after configuration, control the Net storm,
protect the information security, prevent the viral transmission and Ethernet
attack, fully satisfy the Ethernet video surveillance security system and
Ethernet project needs.
Feature
1. Major ports: 1 pc 100Mbps up link Ethernet port, 8 pcs 100Mbps down link
Ethernet ports , every port supports MDI/MDIX;
2. Special function: One key VLAN mode;1～8 downlink ports can only
communicate with uplink port;
3. Power input: DC48V～57V;
4. Transmission Distance: 0～100m; ( VLAN model : 0~250m )
5. Standard: Meet IEEE802.3, IEEE802.3u, IEEE802.3 af/at standards,
6. PoE use End-Span, the spare cable can be of other use;
7. Protection: Excellent anti-thunder, anti-static and anti-interference ability;
8. Appearance: Delicate design and easy installation, configure the anti-theft
lock hole, guard against theft;
9. Operation: Plug and Play, No Setting required.

Notice The transmission distance is related to the connected cable. We
suggest standard Cat5e/6 network cable, so the transmission distance cans up
to 100m!
Board Diagram
Description
1) The equipment must connect the ground according to the request.
2) Turn the dial switch for left, the equipment can enter surveillance module
after providing equipment power.
Installation steps
Please check the following items before installation, if it is missing, please
contact the dealer Please check the following items before installation, if it is
missing, please contact the dealer.
8 ports PoE Ethernet Switch 1pc
Power adaptor 1pc
ACpowercable 1pc
Accessory 1set
User manual 1set

Please follow below the installation steps:
1. Please turn off the signal power and display device power before
installation; installation with power will damage the transmission
equipment
2. Use network cable connect PoE IP camera and 1～8 down link ports of
product respectively
3. Use a network cable connects equipment up link port and NVR or
computer
4. Turn on the power of the equipment
5. Check if the installation is correct, equipment is in good condition, the
connection is stable, then provide power for system
6. Ensure the Ethernet equipment with power and work properly.
Specification
Item Description
Power
Power Supply Power Adaptor
Voltage Range DC48V~54V
Consumption ＜5W , PoE output < 120W
Ethernet
Speed
1-4 port:Default:10/100Mbps;
VLAN:10Mbps;
UPLINK:100Mbps
Transmission
Distance
1-4 port:Default:0～100m;
VLAN:0~250m;
UPLINK:100m
Network Switch
Ethernet Standard IEEE 802.3/802.3u/802.3af/at
Backplane Bandwidth 1.8G
Packet Forwarding 1.34Mbps
Packet Buffer 768K
MAC 2K
Status Indicator
Power Light 1pcs(Red)
Ethernet Port Light 2pcs(Yellow & Green) on RJ45,
Yellow indicates PoE, Green indicates Link/Act
VLAN 1pcs(Green), green indicates VLAN
Protection
Level
Pluse Group Level 2
Standard: IEC61000-4-4
ESD
1a Contact Discharge Level 3
1b Air Discharge Level 3
Standard: IEC61000-4-2
Anti-thunder Level Level 3
Standard: IEC61000-4-5
Working
Environment
Working Temperature 0℃~55℃
Storage Temperature -40℃~85℃
Humidity(Non- 0~95%
Mechanical
Dimension(L*W*H) 200mm×101.8mm×27mm
Out Shell Galvanized Sheet
Color Black
Weight 500g
Stability MTBF ≥50,000h
Product is subject to change without prior notice.

Trouble Shooting
1. Make sure the equipment is installed according to the manufactures
installation guide.
2. Confirm RJ45 cable order meets EIA/TIA568A or 568B standard.
3. Every PoE port can provide PoE equipment maximum power less than
30W,
4. Please do not connect the PoE equipment with power over 30W.
5. Replace the equipment that cannot work with a proper functioning 8
ports PoE Ethernet switch to check if the equipment is damaged.
6. Please contact your vendor if trouble still exists.
