Dimplex IN-STUD V1525BT User manual

Owner’s Manual
Model
V1525BT
V1525RT
7208630100R03
IMPORTANT SAFETY INFORMATION: Always read this manual rst before
attempting to install or use this replace. For your safety, always comply with all
warnings and safety instructions contained in this manual to prevent personal
injury or property damage.
To view the full line of Dimplex products, please visit
www.dimplex.com

2 www.dimplex.com
Table of Contents
Always use a qualied technician or
service agency to repair this replace.
!NOTE: Procedures and
techniques that are considered
important enough to emphasize.
CAUTION: Procedures and
techniques which, if not carefully
followed, will result in damage to the
equipment.
WARNING: Procedures and
techniques which, if not carefully
followed, will expose the user to
the risk of re, serious injury, or
death.
Welcome & Congratulations ..................3
IMPORTANT INSTRUCTIONS ................4
Fireplace Installation ........................7
Wall Mounting Instructions ....................8
Built-In Instructions .........................11
Bathroom Installation .......................13
Operation ................................14
Maintenance .............................16
Warranty ................................18
Replacement Parts .........................20

3
Welcome & Congratulations
Thank you and congratulations for
choosing to purchase an electric
replace from Dimplex, the world
leader in electric replaces.
Please carefully read and save
these instructions.
CAUTION: Read all instructions
and warnings carefully before starting
installation. Failure to follow these
instructions may result in a possible
electric shock, re hazard and will
void the warranty.
Please record your model and serial
numbers below for future reference:
model and serial numbers can
be found on the Model and Serial
Number Label of your replace.
Model Number
Label
Serial Number
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)
Monday to Friday 8:00 a.m. to 4:30 p.m. EST
Please have your model number and product serial
number ready. (See above)

4 www.dimplex.com
When using electrical appliances,
basic precautions should always
be followed to reduce the risk of
fire, electric shock, and injury to
persons, including the following:
① Read all instructions before
using this appliance.
② The heater is hot when in use.
To avoid burns, do not let bare
skin touch hot surfaces. The trim
around the heater outlet becomes
hot during heater operation.
Keep combustible materials, such
as furniture, pillows, bedding,
papers, clothes, and curtains at
least 3 feet (0.9m) from the front
of the unit and keep them away
from the sides and rear..
③ Extreme caution is neces-
sary when any heater is used by
or near children or invalids and
whenever the unit is left operating
and unattended.
④ Always unplug the fireplace
when not in use.
⑤ Do not operate any heater
after it malfunctions. Disconnect
power at the service panel and
have the heater inspected by a
reputable electrician before reus-
ing.
⑥ Do not operate any unit with
a damaged cord or plug, or if the
IMPORTANT INSTRUCTIONS
heater has malfunctioned, or if
the electric replace has been
dropped or damaged in any man-
ner, contact Dimplex Technical
Service at 1-888-346-7539.
⑦ Do not use outdoors.
⑧ Never locate heater where it
may fall into a bathtub or other
water container.
⑨ Do not run the cord under
carpeting (for units supplied with
a cord). Do not cover cord with
throw rugs, runners or the like.
Arrange cord away from traf-
c area and where it will not be
tripped over.
⑩ To disconnect the unit, turn
the controls off, then remove the
plug from the outlet or switch off
at main power supply panel if the
unit is hardwired.
⑪ Do not insert or allow foreign
objects to enter any ventilation
or exhaust opening as this may
cause an electric shock or re, or
damage to the heater.
⑫ To prevent a possible re, do
not block air intake or exhaust in
any manner.
⑬ All electrical heaters have
hot and arcing or sparking parts
inside. Do not use in areas where

5
SAVE THESE INSTRUCTIONS
gasoline, paint, or ammable
liquids are used or stored.
⑭ Do not modify the replace.
Use it only as described in this
manual. Any other use not rec-
ommended by the manufacturer
may cause re, electric shock or
injury to persons.
⑮ To reduce the risk of electric
shock, this appliance has a polar-
ized plug (one blade is wider than
the other). This plug will t in a
polarized outlet only one way. If
the plug does not t fully in the
outlet, reverse the plug. If it still
does not t, contact a qualied
electrician to install the proper
outlet. Do not change the plug in
any way.
⑯ Always plug heaters directly
into a wall outlet/receptacle.
Never use with an extension cord
or relocatable power tap (outlet/
power strip).
⑰ Do not burn wood or other
materials in the replace.
⑱ Do not strike the glass front.
⑲ Always use a certied electri-
cian for build-in hard-wired instal-
lation.
⑳ Always use properly grounded,
fused and polarized outlets.
㉑ Disconnect all main power
supply (unplug the unit or switch
off at main service panel) before
performing any cleaning, mainte-
nance or relocation of the unit.
㉒ Do not operate the replace
without the glass assembly and/
or frame.
㉓When transporting or stor-
ing the unit and cord, keep in a
dry place, free from excessive
vibration and store so as to avoid
damage.
㉔ Do not put combustible mate-
rial, liquid or small articles such
as sand inside glass assembly.
IMPORTANT INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICEABLE PARTS INSIDE

6 www.dimplex.com
CAUTION: This equipment has
been tested and found to comply with
the limits for Class B digital device,
pursuant to part 15 of the FCC
Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses and can radiate
radio frequency energy and, if not
installed and used in accordance with
the instructions, may cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between
the equipment and the receiver.
• Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
• Consult the dealer or an
experienced radio/TV technician
for help.
Operation is subject to the following
two conditions: (1) this device may
not cause interference and (2) this
device must accept any interference,
including interference that may cause
undesired operation of the device.
IMPORTANT INSTRUCTIONS
WARNING: Remote control
contains small batteries. Keep away
from children. If swallowed, seek
medical attention immediately.
WARNING: Do not install battery
backwards, charge, put in re or mix
with used or other battery types - may
explode or leak causing injury.
!NOTE: Changes or modications
not expressly approved by the party
responsible for compliance could
void user's authority to operate the
equipment.

7
Fireplace Installation
Figure 1
WARNING: Ensure the power
cord is not installed so that it is
pinched or against a sharp edge
and ensure that the power cord is
stored or secured to avoid tripping
or snagging to reduce the risk
of re, electric shock or injury to
persons.
WARNING: Construction
and electrical outlet wiring must
comply with local building codes
and other applicable regulations
to reduce the risk of re, electric
shock and injury to persons.
WARNING: Do not attempt
to wire your own new outlets or
circuits. To reduce the risk of re,
electric shock or injury to persons,
always use a licensed electrician.
WARNING: To reduce the risk
of re, do not store or use gaso-
line or other ammable vapors or
liquids in the vicinity of the heater.
!NOTE: A 15amp, 120-volt cir-
cuit is required. A dedicated cir-
cuit is preferred but not essential
in all cases. A dedicated circuit
will be required if, after installa-
tion, the circuit breaker trips or
the fuse blows on a regular basis
when the heater is operating. Ad-
ditional appliances on the same
circuit may exceed the current
rating of the circuit breaker.
WARNING: The In-Stud
replace is wall mountable and
can be build-in the wall space 16”
(406 mm) over-center between
2” (51 mm) x 4” (102 mm) wall
studs. Follow the installation in-
structions for either wall mount or
built-in mounting; failure to do so
may cause damage or injury.
!NOTE: Remove glass as-
sembly before installing re-
place on or into a wall.
CAUTION: High temperature,
risk of re, keep electrical

8 www.dimplex.com
Fireplace Installation
Figure 2
cords, drapery, furnishings,
and other combustibles at
least 3 feet (0.9 m) from the
front of the heater.
1. Remove screws securing
glass assembly on the mount-
ing tabs. (Figure 1)
2. Use both handles on the
sides of the glass assembly,
lift and remove the assembly
from the replace.
3. Please glass assembly with
it’s back facing down on a at
surface.
Wall Mounting Instructions
1. Leave the trim uninstalled
until step 9.
2. Select a location for the
replace, preferably above
an electrical outlet and there
must be at least one wall stud
behind for the replace to
mount onto. The bottom of
the unit must be a minimum
of 4” (102 mm) space above
the oor (mounting holes
29.5” (750 mm) minimum
above the oor). Access
to the electrical outlet must
be maintained. Ensure the
installation meets the national
and state/provincial electrical
codes.
!NOTE: It is recommended
that the bottom of the unit not be
mounted higher than 48” (122 cm)
from the ground to maintain an
optimized viewing angle of the
ame.
CAUTION: The replace must
be mounted at two points, one of
which must be on a wall stud.
WARNING: High temperatures
may be generated under certain
abnormal conditions. Do not
partially or fully cover or obstruct
the front of this heater. Bottom
of unit must be a minimum of 4”
(102 mm) above oor or any sur-
face such as a tabletop to ensure

9
Air
Circulation
Figure 3
Fireplace Installation
adequate ventilation through air
intake located at the bottom of the
replace. (Figure 3)
3. With a wall stud nder, locate
the center of the wall stud,
drive a wood screw into stud
and leave approximately 1/8”
(3 mm) exposed threads for
the replace to hang on.
4. The second mounting point
should be picked such that it
is farthest (to the left or right)
relative to the rst one among
the seven keyholes (A to G
shown in gure 2) on the re-
place for wall mounting, these
keyholes are 2” (51 mm)
apart. For example, if you
plan to use hole B as the rst
mounting hole, the second
mounting hole must be G.
Other available combinations
are A-G, C-G, A-F, A-E, A-D
and D-G.
5. Mark the second mounting
screw location; ensure that
is level with the rst with the
help of the provided bubble
level and the replace itself.
Screw the threaded drywall
anchor in the drywall with a
Philip’s head screwdriver until
the head is at against the
wall surface. Caution should
be taken when using a power
tool to install a threaded
drywall anchor as the drywall
may distort, tear or slightly
buckle as a result of over-
torque.
6. With a Philip’s head screw
driver, screw that drywall
anchor screw into the dry-
wall anchor already in the
wall, leave about 1/8” (3 mm)
exposed threads for mounting
the replace.
7. With the glass assembly tak-
en off, mount the rebox onto
the two mounting screws.
8. Tighten both mounting screws
with a screwdriver. Be cau-
tion not to over tighten the
one mated with the drywall

10 www.dimplex.com
Fireplace Installation
1. Install supplied
brackets as shown on
both sides of frame
3. Secure frame on
replace with supplied
self-tapping screws
2. Install frame on to
replace
Figure 4
Figure 5 Figure 6

11
Fireplace Installation
anchor.
9. Screw supplied wood screw
into corresponding hole that
aligns with stud. (Figure 2)
10. Re-install glass assembly into
replace.
11. Install frame onto the rebox
as shown in Figure 4.
Built-In Instructions
WARNING: The installation
of the replace unit must com-
ply with the applicable local
and/or national electrical codes
and utility requirements. This
installation should be entrusted
to duly qualied personnel
where required by law.
1. Leave the frame uninstalled
from the replace chassis
until step 13.
2. Prepare a wall opening fol-
lowing the dimensions shown
in Figure 5. Note that 4” (102
mm) minimum depth includ-
ing thickness of dry wall is
required. Make sure there
is enough clearance for the
cable coming out from the
bottom of the replace.
!NOTE: Where there are close
tolerances involved in wall build-
ing or applications which require
a great degree of precision, we
recommend that the product itself
be used to make the actual mea-
surements for the wall opening.
Dimplex North America will not
be responsible for inaccuracies
in the design or manufacture of
enclosures.
WARNING: Ensure method of
installation does not obscure the
air intake slots on bottom of unit
in any manner. Keep minimum 4”
(102 mm) clearance from bottom
of unit to any surface such as the
top of a cabinet.
3. Wire a dedicated, prop-
erly fused circuit with 120V,
15amp rating. Allow up to 8 ft
(244 cm) of service cable
for connecting power supply
to junction box on replace
when installing after nishing
wall.
CAUTION: Use two conduc-
tor, non-metallic sheath cable
with ground wire (3 wires total)
for the incoming power supply on
replace inserts. Use appropriate
wire to meet local and national
electrical codes for rated power
consumption.
4. Remove the outer jacket and
strip the individual conductor

12 www.dimplex.com
Fireplace Installation
Figure 7
Figure 8
from the end.
5. Loosen the screw securing
the junction box cover and
remove the cover.
6. Take the cables out from the
junction box, loosen the two
wire twist nuts and remove
the cord set. (Figure 6.)
7. Route the power supply wire
through the knockout on sup-
plied alternative junction box
cover and secure with a wire
clamp (not supplied) (Figure
7)
8. Connect the black wire (live)
from the unit to the black wire
from power supply. (Figure 7)
9. Connect the white wire
(neutral) from the unit to the
white wire from power supply.
(Figure 7)
10. Connect the green wire
(ground) from the unit to the
green wire from power supply.
(Figure 7)
11. Place all connectors inside
the unit and secure the junc-
tion box cover to unit. Ensure
that the cable clamp grips
only the jacket of service
cable.
!NOTE: All wiring must be

13
Fireplace Installation
completed prior to installing the
unit into the wall.
12. Place unit in position in the
opening, push straight in and
attach unit to studs using No.
10 fasteners. Attach supplied
wall cover brackets to the top
and the bottom of replace to
cover the gap on the dry wall
(Figure 8)
13. Attach replace frame as
shown in gure 4.
Bathroom Installation
This rebox must be protected
by a GFI receptacle or circuit for
bathroom use. If receptacle is
used it must be readily acces-
sible.
This unit is an electrical appliance
that is not watertight and must
be installed as to prevent water
from entering the unit to prevent
electrical shock. This unit must
be installed away from showers,
tubs, etc.
Never locate replace where it
may fall into a bathtub or other
water containers. Keep towels
and other combustible materials
3 ft (0.9 m) away from the front of
the unit.
WIRING
M
M
ELEMENTS
THERMOSTAT
3-POSITION
SWITCH
N
L
CUTOUT
HEAT
SWITCH
FLICKER
MOTOR
LOWER
LIGHTS
BLOWER
MOTOR
INTEGRAL
ON-OFF R/C
CAPACITOR
GROUND

14 www.dimplex.com
Operation
WARNING: This electric
rebox must be properly installed
before it is used.
Manual Controls
The controls are located on the
right hand side of the replace.
Figure 9.
A. 3-Position Switch
The switch has two ON positions
marked with and “ON”.
The “ON” position is for manual
operation. In this position the
built-in remote control is by-
passed.
The position is for operating
the unit with the provided remote
control.
When in position the unit is
operated with the ON and OFF
buttons of the remote control.
When the switch is in the center
position the unit is off.
B. Heater On/Off Switch
The Heater On/Off Switch sup-
plies power to the heater fan and
the heater element. When the
switch is in the ON position the
heater operates if the thermostat
calls for heat.
!NOTE: The heater on your
replace may emit a slight, harmless
odor when rst used. This odor is a
normal condition caused by the initial
heating of internal heater parts and
will not occur again.
C. Heater Thermostat Control
To adjust the temperature to your
individual requirements, turn the
thermostat control upward all the
way to turn on the heater. When
the room reaches the desired
temperature, turn the thermostat
knob downward until you hear
a click. Leave in this position to
maintain the room temperature at
this setting. For additional heat,
turn upward until you hear the
click again and the heater will turn
on.
Resetting The Temperature
Cutoff Switch
Should the heater overheat, an
automatic cut out will turn the re-
Figure 9
C. Thermostat
B. Heater
ON/OFF
Switch
A. 3-Position
Switch

15
3. Within 10 seconds of re-
acquiring power, press the On
button located on the remote
control.
This will synchronize the remote
control and receiver.
Battery Replacement
To replace the battery:
1. Slide battery cover open on
the remote control.
2. Install one 12-volt (A23) bat-
tery in the battery holder.
3. Close the battery cover.
Battery must be recycled
or disposed of properly.
Check with your Local
Authority or Retailer for recycling
advice in your area.
place off and it will not come back
on without being reset. It can
be reset by switching the 3-Posi-
tion switch to OFF and waiting 5
minutes before switching the unit
back on.
CAUTION: If you need to continu-
ously reset the heater, disconnect
power and call Dimplex customer
service at 1-888-DIMPLEX (1-888-
346-7539).
Remote Control
The Fireplace is supplied with an
integrated on/off remote control
Note: Ensure that the replace
3-Position switch is set to the
remote Control setting.
To operate, push the ON button
to turn replace on, push the OFF
button to turn the replace off.
!NOTE: Before attempting any
operation with the remote control,
pull the plastic insulator strip out
from between the remote casing
and battery cover.
Remote Control Initialization/
Reprogramming
1. Disconnect power to re-
place.
2. Wait a minimum of 5 seconds
and then re-acquire power to
replace.
Operation
Figure 10
Off
Button
On
Button
Battery
cover
Plastic
strip

16 www.dimplex.com
 WARNING: Disconnect power be-
fore attempting any maintenance
or cleaning to reduce the risk of
re, electric shock or damage to
persons.
!NOTE: The replace should not
be operated with an accumulation of
dust or dirt on or in the unit, as this
can cause a build up of heat and
eventual damage. For this reason the
heater must be inspected regularly,
depending upon conditions and at
least at yearly intervals.
Light Bulb Replacement
Light bulbs need to be replaced
when you notice a dark section
of the ame or when the clar-
ity and detail of the log exterior
disappears. There are two bulbs,
which generate the ames and
embers.
Helpful Hints: It is a good idea to
replace all light bulbs at one time
if they are close to the end of their
rated life. Group replacement will
reduce the number of times you
need to open the unit to replace
light bulbs.
Light Bulb Requirements:
Quantity of two 40W Chandelier
or candelabra bulbs with E-12
(small) socket base, 120 Volt.
DO NOT EXCEED 40 WATTS
PER BULB
Bulb Replacement Instructions:
CAUTION: Turn unit off, allow
at least 5 minutes for light bulbs
to cool before touching bulbs to
avoid accidental burning of skin.
1. Disconnect power supply to
the replace either by unplug-
ging the replace or switch off
at the breaker panel.
2. Remove replace front trim.
3. Remove glass assembly.
Remove the screws securing
the glass assembly on the
chassis. Hold on to the han-
dles on the glass assembly
with both hands then lift the
whole assembly straight up to
remove. Figure 11.
4. Remove the two screws
securing the light block as
shown in Figure 12, then
remove the light block.
5. Reach in and turn the burnt-
out bulb(s) counter-clockwise
to remove.
6. Replace with new bulbs.
7. Reassemble light block, glass
assembly and replace frame
in reverse order.
Glass Cleaning
The front glass is cleaned in the
factory during the assembly op-
Maintenance

17
Handles
LIFT TO
REMOVE
Figure 11
Glass
Assembly
Figure 12
Light Block
Maintenance
eration. During shipment, instal-
lation, handling, etc., the front
glass may collect dust particles,
these can be removed by dusting
lightly with a clean dry cloth.
To remove ngerprints or other
marks, the glass can be cleaned
with a damp cloth. The glass
should be completely dried with
a lint free cloth to prevent water
spots. To prevent scratching,
do not use abrasive cleaners or
spray liquids on the glass surface.
Fireplace Surface Cleaning
To remove ngerprints or other
marks, the exterior nish can be
cleaned with a damp cloth with
a mild detergent. The surface
should be completely dried with
a lint free cloth to prevent water
spots.
Servicing
Except for light bulb replacement
and cleaning described above, an
authorized service representative
should perform any other servic-
ing.

18 www.dimplex.com
Products to which this limited warranty
applies
This limited warranty applies to the fol-
lowing models of your newly purchased
Dimplex electric replace V1525 and to
newly purchased Dimplex replace sur-
rounds and trims. This limited warranty
applies only to purchases made in any
province of Canada except for Yukon Terri-
tory, Nunavut, or Northwest Territories or
in any of the 50 States of the USA (and
the District of Columbia) except for Hawaii
and Alaska. This limited warranty applies
to the original purchaser of the product
only and is not transferable.
Products excluded from this limited war-
ranty
Light bulbs are not covered by this limited
warranty and are the sole responsibility of
the owner/purchaser. Products purchased
in Yukon Territory, Nunavut, Northwest
Territories, Hawaii, or Alaska are not
covered by this limited warranty. Products
purchased in these States, provinces, or
territories are sold AS IS without war-
ranty or condition of any kind (including,
without limitation, any implied warranties
or conditions of merchantability or tness
for a particular purpose) and the entire risk
of as to the quality and performance of the
products is with the purchaser, and in the
event of a defect the purchaser assumes
the entire cost of all necessary servicing
or repair.
What this limited warranty covers and for
how long
Products, other than replace surrounds
(mantels) and trims, covered by this
limited warranty have been tested and
inspected prior to shipment and, subject
to the provisions of this warranty, Dimplex
warrants such products to be free from
defects in material and workmanship for a
period of 1 year from the date of the rst
purchase of such products.
The limited 1 year warranty period also
applies to any implied warranties that may
exist under applicable law. Some jurisdic-
tions do not allow limitations on how long
an implied warranty lasts, so the above
limitation may not apply to the purchaser.
What this limited warranty does not cover
This limited warranty does not apply to
products that have been repaired (except
by Dimplex or its authorized service
representatives) or otherwise altered. This
limited warranty does further not apply
to defects resulting from misuse, abuse,
accident, neglect, incorrect installation,
improper maintenance or handling, or
operation with an incorrect power source.
What you must do to get service under
this limited warranty
Defects must be brought to the attention of
Dimplex Technical Service by contacting
Dimplex at 1-888-DIMPLEX (1-888-346-
7539), or 1367 Industrial Road, Cam-
bridge Ontario, Canada N1R 7G8. Please
have proof of purchase, catalogue/model
and serial numbers available when calling.
Limited warranty service requires a proof
of purchase of the product.
What Dimplex will do in the event of a
defect?
In the event a product or part covered by
this limited warranty is proven to be defec-
tive in material or workmanship during the
1 year limited warranty period you have
the following rights:
• Dimplex will in its sole discretion either
repair or replace such defective prod-
Warranty

19
uct or part without charge. If Dimplex
is unable to repair or replace such
product or part, or if repair or replace-
ment is not commercially practicable or
cannot be timely made, Dimplex may,
in lieu of repair or replacement, choose
to refund the purchase price for such
product or part.
• This limited warranty does not entitle
the purchaser to on-site or in-home
services. On-site or in-home services
may be performed at the purchaser’s
specic request and expense at
Dimplex’s then-current rates for such
services.
• Limited warranty service will be
performed solely by dealers or service
agents of Dimplex authorized to pro-
vide limited warranty services.
• Dimplex will not be responsible for,
and the limited warranty services shall
not include, any expense incurred for
installation or removal of the product
or part (or any replacement product
or part) or any labour or transporta-
tion costs. Such costs shall be the
purchaser’s responsibility.
What Dimplex and its dealers and service
agents are also not responsible for:
IN NO EVENT WILL DIMPLEX, OR ITS
DIRECTORS, OFFICERS, OR AGENTS,
BE LIABLE TO THE PURCHASER OR
ANY THIRD PARTY, WHETHER IN CON-
TRACT, IN TORT, OR ON ANY OTHER
BASIS, FOR ANY INDIRECT, SPECIAL,
PUNITIVE, EXEMPLARY, CONSEQUEN-
TIAL, OR INCIDENTAL LOSS, COST,
OR DAMAGE ARISING OUT OF OR
IN CONNECTION WITH THE SALE,
MAINTENANCE, USE, OR INABILITY TO
USE THE PRODUCT, EVEN IF DIMPLEX
OR ITS DIRECTORS, OFFICERS, OR
AGENTS HAVE BEEN ADVISED OF
THE POSSIBILITY OF SUCH LOSSES,
COSTS OR DAMAGES, OR IF SUCH
LOSSES, COSTS, OR DAMAGES ARE
FORESEEABLE. IN NO EVENT WILL
DIMPLEX, OR ITS OFFICERS, DIREC-
TORS, OR AGENTS BE LIABLE FOR
ANY DIRECT LOSSES, COSTS, OR
DAMAGES THAT EXCEED THE PUR-
CHASE PRICE OF THE PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO
THE PURCHASER.
How State and Provincial law apply
This limited warranty gives you specic
legal rights, and you may also have other
rights which vary from jurisdiction to juris-
diction. The provisions of the United Na-
tions Convention on Contracts for the Sale
of Goods shall not apply to this limited
warranty or the sale of products covered
by this limited warranty.
Warranty

20 www.dimplex.com
Flicker Motor .................................2000210200RP
Flicker Rod ..................................5901110100RP
Heater Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6904280100RP
Thermostat ..................................2300150100RP
Heater On/Off Switch. . . . . . . . . . . . . . . . . . . . . . . . . . .2800070700RP
3 Position Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2800071100RP
Terminal Block ................................4000070100RP
Power Cord ..................................9600160100RP
Light Harness with Cover .......................4200090200RP
Partially Reective Glass ........................5901010100RP
Front Glass ..................................5901020100RP
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3000370500RP
Remote Control Receiver . . . . . . . . . . . . . . . . . . . . . . . . .3000380200RP
Thermostat Knob. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8801080100RP
Beveled Trim - Black ...........................6903790159RP
Gun Metal . . . . . . . . . . . . . . . . . . . . . . .6903790186RP
Rectangular Trim - Black ........................6903850159RP
Gun Metal ....................6903850186RP
Media Tray. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0439500100RP
Media Tray Retaining Bracket ....................1020410159RP
© 2013 Dimplex North America Limited
Dimplex North America Limited
1367 Industrial Road
Cambridge ON
Canada N1R 7G8
Replacement Parts
