Directed Directechs DB3 User manual

Designed by Installers for Installers
INSTALLATION GUIDE
DB3
2018 Mitsubishi RVR (Smart Key). 403.MIT5 1.06
© 2021 Directed, Vista CA
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.

Introduction 3
Vehicle function compatibilities 4
Pre-installation and application warnings 5
Wiring diagram 6
Locating components in the vehicle 7
Vehicle connections 8
Module programming 10
Connecting the module 11
LED diagnostics and troubleshooting 12
Soft reset 14
Hard reset 14
Feature programming 15
Feature and option list 16
Limited one year consumer warranty 17
Quick Reference Guide 18
Contents

3403.MIT5 1.06 2018 Mitsubishi RVR (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to “Connecting the module” for more information.

4403.MIT5 1.06 2018 Mitsubishi RVR (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Control of aftermarket alarm with OEM remote
* Fuel Level
* Odometer
Immobilizer Bypass-Data No Key Req'd
Remote Start Ready
Remote Start Takeover
SmartStart
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Brake Status (foot brake)
E-Brake Status
Ignition Status

5403.MIT5 1.06 2018 Mitsubishi RVR (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in pricing
accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Keys
required for
programming
1Keys required
for operation 0
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Refer to the "Vehicle connections" following the installation diagram.
General notes: This section highlights important information for this specific firmware.
[1] Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D. Also please note that by
default, the tach is set to 1000 rpm on hybrid vehicles.
[2] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin. or if NOT
supported in data.

6403.MIT5 1.06 2018 Mitsubishi RVR (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
D2D Port
(-) Ground (-) Ground
(+) Ignition Output
(+) Accessory Output
(+) Starter Output
(+) 12V Input
HS CAN High 1: Tan/Black: 3
HS CAN Low 1: Tan: 4
1412
10 42
Wiring diagram
(+) Parking Lights Output
XKD2D65
(+) PTS 1 Output: Violet/Brown: 9
(AC) Tach Output: Violet/White: 5
(-) PTS 2 Output: Green/Black: 2
HS CAN High 2: Orange/Green: 5
HS CAN Low 2: Orange/Brown: 6
C-408
(black conn.
at fuse box.)
C-413
(white conn. at fuse box.)
1
2
1
83
10
12
2
94
11
1317
5
1418
6
1519
7
1620
(+) 12V:
Black/Red,
pin 1
(+) Parking Lights:
Pink, pin 13
(+) Parking Lights:
Yellow or Blue, pin 10
(+) PTS 1:
Pink, pin 4
(-) PTS 2:
Blue, pin 2
Start / Stop Switch
(white conn. at push button.)
42
(+) Starter:
Lt. Blue or Pink, pin 7
C-415
(white conn.
at fuse box.)
7
CAN-B Low:
Red, pin 7
CAN-B High:
Green, pin 6
C-411
(white an black
conn. at fuse box.)
15 14 13
12
11 10 9 8
7 6 5 4 3 2 1
(+) Ignition:
White, pin 6
C-417
(white conn. at fuse box.)
C-408
C-413
C-415
C-411
C-417
ETACS / Fuse Box
(connectors at ETACS or fuse box)
12
11
24
17 6 5 4
CAN C High: Blue or Red,
pin 5
CAN C Low:
Pink or
White,
pin 4
(+) Accessory:
Lt. Green or
Green, pin 7
(AC) Tach Input
6A
Diodes
(-) Hood pin Input

7403.MIT5 1.06 2018 Mitsubishi RVR (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Locating components in the vehicle

8403.MIT5 1.06 2018 Mitsubishi RVR (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2018 Mitsubishi RVR (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black (DATA) HS CAN 1 High Dash Fuse Box, white 24 pin plug (C-411), pin 5 Data Red (CAN-C)
H1/4 Tan (DATA) HS CAN 1 Low Dash Fuse Box, white 24 pin plug (C-411), pin 4 Data White (CAN-C)
H1/5 Orange/Green (DATA) HS CAN 2 High Dash Fuse Box, white 24 pin plug (C-411), pin 6 Data Green (CAN-B)
H1/6 Orange/Brown (DATA) HS CAN 2 Low Dash Fuse Box, white 24 pin plug (C-411), pin 7 Data Red (CAN-B)
H1/7 Brown Relay N.O. No Connection No Connection
H1/8 Yellow Relay COM No Connection No Connection
H1/9 Orange/Yellow Relay N.C. No Connection No Connection
H1/10 Orange/Red Relay N.C. No Connection No Connection
H1/11 Yellow/Red Relay COM No Connection No Connection
H1/12 Brown/Red Relay N.O. No Connection No Connection
H1/13 Red (+) W2W Only - 12 Volt Dash Fuse Box, black 2 pin plug (C-408), pin 1 + Black/Red (80A)
H1/14 Black (-) W2W Only - Ground (chassis ground)
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White (-) W2W Only - E-Brake Output Remote Starter
H2/2 Green/Black (-) PTS 2 Output Engine Start Stop Switch, white 10 pin plug, pin 2 - Blue
H2/3 Green/White (-) W2W Only - Door Output Remote Starter
H2/4 Red/Black (-) W2W Only - Trunk Output Remote Starter
H2/5 Violet/White (AC) W2W Only - Tach Output [1] Remote Starter
H2/6 Gray (+) W2W Only - Brake Output Remote Starter
H2/7 Gray/Black No Connection No Connection
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown (+) PTS 1 Output Engine Start Stop Switch, white 10 pin plug, pin 4 + Pink
H2/10 Yellow/Black No Connection No Connection
H2/11 Orange/Black No Connection No Connection
H2/12 Blue/Red (-) W2W Only - Hood Output Remote Starter
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green (-) Lock Input Remote Starter

9403.MIT5 1.06 2018 Mitsubishi RVR (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/2 Blue (-) Unlock Input Remote Starter
H3/3 Red/White No Connection No Connection
H3/4 White/Violet No Connection No Connection
H3/5 Violet/Black No Connection No Connection
H3/6 White/Black No Connection No Connection
H3/7 Pink/White No Connection No Connection
H3/8 Violet No Connection No Connection
H3/9 Pink No Connection No Connection
H3/10 Blue/White (-) Ground When Running (Status) Input Remote Starter
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Green (Data) TX
H4/2 Black (-) Ground
H4/3 Blue (Data) RX
H4/4 Red (+) 12 Volt
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A No Connection
H5/2 N/A No Connection
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire Connects To
Wire Location (+/-) Wire Color
12 Volts Dash Fuse Box, black 2 pin plug (C-408), pin 1 + Black/Red (80A)
Accessory Dash Fuse Box, white 15 pin plug (C-417), pin 7 + Green
Hood Pin Dash Fuse Box, white 16 pin plug (C-410), pin 12 - Pink
Ignition Dash Fuse Box, white 15 pin plug (C-417), pin 6 + White
Parking Lights - Must use a diode Dash Fuse Box, white 20 pin plug (C-413), pin 10 (L);
pin 13 (R)
+ Blue (L); Pink (R)
Starter Dash Fuse Box, white 19 pin plug (C-415), pin 7 + Pink
Tachometer Any Fuel Injector, gray 2 pin plug, pin 2 AC Lt. Green, Yellow, Green, or White

10 403.MIT5 1.06 2018 Mitsubishi RVR (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
1Wait until the LED turns ON solid red.
2Press on the Push-To-Start (PTS) button twice to turn the ignition ON.The LED flashes
orange.
3Wait until the LED turns ON solid green for 3 seconds, then turns OFF.
4Press the PTS button once more to turn the ignition OFF.
You have successfully completed the module programming sequence.
