Directed Directechs DB3 User manual

403.TL1
v5.07.106
2013 Toyota Highlander (Smart Key)
Functions compatible with the 2013 Toyota Highlander (Smart Key)
*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.
* Odometer
Arm Factory Security
Auto Headlamp Shutoff
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Disarm Factory Security
Door Lock Control
Door Locks Status
Door Unlock
Driver Priority Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Fuel level/EV battery level
Hatch Glass Release
Ignition Status
Immobilizer Bypass-Data No Key Req'd
Remote Start Ready
SmartStart
Tach / RPM Output

Introduction 3
Pre-installation and application warnings 4
Key type 4
OEM remote starter detection 5
Installation 5
Wiring diagram with T-Harness (TLTH1 & THTOD1) 5
Wiring diagram 6
Locating components in the vehicle 7
Vehicle connections 8
Module programming 10
Push-to-Start (PTS) vehicles with CAN 10
Connecting the module 11
LED diagnostics and troubleshooting 12
Soft reset 14
Hard reset 14
Feature programming 15
Feature and option list 16
Limited one year consumer warranty 17
Quick reference guide 18
Contents

3403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
Introduction
DB3 is an all-in-one door lock and override module.
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to <ConnectImportant> for more information.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible TLTH1/THTOD1 Keys required for programming 1Keys required for operation 0
No takeover feature is available on Push-to-Start vehicles. The vehicle will shut down as soon as a door is opened.
To remote start the engine, the hood, hatch, and all doors MUST be closed.
Keyless and Smart Key will remain functional during remote start.
The optional Plug & Play TLTH1/THTOD1 T-Harness is sold separately.
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
All connectors are displayed from the wire side (unless specified otherwise).
Refer to the "Vehicle connections" following the installation diagram.
General notes: This section highlights important information for this specific firmware.
[1] Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D
[2] Connection required ONLY if Pit Stop/Idle mode is desired.
[3] Autolights Interrupt ONLY required if vehicles are equipped with Autolights.
Key type
Some Toyota 2010+ models have different encryption types. Please look at your key blade and identify the markings.
G-stamped keys Standard Key H-stamped keys
H
For vehicles with H-stamped keys, see
the TL10 firmware.
For vehicles with G-stamped keys, see
the TL5 & TL7 firmware.
For vehicles with dot-stamped keys,
see the TL11 firmware.
Note: Some replacement keys
may not have any markings on
the key.
OEM remote starter detection
How to know if the vehicle is equipped with an OEM remote starter
1. An “ENGINE STARTER”
sticker should be on the remote.
ENGI NE
STARTER
2. Remote start the OEM remote starter:
Press the remote control’s lock button twice within 2 seconds, then press and hold the lock
button for 3 seconds.
x2 &Press & Hold
for 3 seconds
The parking lights flash after 3 seconds. The engine starts and the parking lights flash
repeatedly for 20 seconds.
If the vehicle is equipped with an add-on Lexus/Toyota OEM remote starter
The factory remote starter must be permanently disconnected before programming the Directed interface as both modules cannot
coexist. See "Locating the OEM Remote Starter" below.
Locating the OEM Remote Starter
Vehicle OEM Remote Starter & Connector Location
Toyota Camry (Smart Key) 2007-2011 Behind Glove Box & Passenger kick panel.
Toyota Camry Hybrid (Smart Key) 2007-2011 Behind Glove Box & Passenger kick panel.
Toyota Corolla (Smart Key) 2009-2013 Behind Glove Box & Passenger kick panel & Junction Box & Steering column.
Toyota Highlander (Smart Key) 2008-2013 Behind Glove Box & Passenger kick panel.
Toyota Highlander Hybrid (Smart Key) 2008-2013 Behind Glove Box & Passenger kick panel.
Toyota Rav4 (Smart Key) 2009-2012 Behind Glove Box & Junction Box.

4403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
OEM remote starter detection
How to know if the vehicle is equipped with an OEM remote starter
1. An “ENGINE STARTER”
sticker should be on the remote.
ENGI NE
STARTER
2. Remote start the OEM remote starter:
Press the remote control’s lock button twice within 2 seconds, then press and hold the lock
button for 3 seconds.
x2 &Press & Hold
for 3 seconds
The parking lights flash after 3 seconds. The engine starts and the parking lights flash
repeatedly for 20 seconds.
If the vehicle is equipped with an add-on Lexus/Toyota OEM remote starter
The factory remote starter must be permanently disconnected before programming the Directed interface as both modules cannot
coexist. See "Locating the OEM Remote Starter" below.
Locating the OEM Remote Starter
Vehicle OEM Remote Starter & Connector Location
Toyota Camry (Smart Key) 2007-2011 Behind Glove Box & Passenger kick panel.
Toyota Camry Hybrid (Smart Key) 2007-2011 Behind Glove Box & Passenger kick panel.
Toyota Corolla (Smart Key) 2009-2013 Behind Glove Box & Passenger kick panel & Junction Box & Steering column.
Toyota Highlander (Smart Key) 2008-2013 Behind Glove Box & Passenger kick panel.
Toyota Highlander Hybrid (Smart Key) 2008-2013 Behind Glove Box & Passenger kick panel.
Toyota Rav4 (Smart Key) 2009-2012 Behind Glove Box & Junction Box.

5403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
ENGINE
START
STOP
D2D Port
Wiring diagram with T-Harness (TLTH1,THTOD1)
1412
10 42
(-) Parking Light Output
(-) Factory Alarm Re-arm
(-) Ground
(+) 12V Input
Do not
connect
TLTH1/THTOD1
(optional T-Harness)
D2D
only
OBDII
Diagnostic Connector
XKD2D65
12345678910
1112131415161720
19 18
Headlight Switch
(white conn. at
headlight switch)
CUT
(+) Ignition Input
(-) Trunk/Hatch Release Output
(+) Ignition Status Output: Gray/Black:7
(-) Push-to-Start Output: Green/Black:2
(AC) Tach Input
(AC) Tach Output: Violet/White: 5
30
86 85
87
87a
1543 1
811
12 10 9
14
6
13
2
7
PTS Switch
(black conn.
behind PTS button)
(+) 12V,
Black, pin 1
1
Dash Fuse Box
(white conn.)
Do not connect any other accessory, ignition or starter wires
from the remote starter to the vehicle. The interface module
is handling the required vehicle power and start sequence.
(+) Start Stop Switch Output: Yellow
Main Body ECU
(white conn.
under drivers dash)
10 9 8
6 5 43
7
2 1
(-) Push-To-Start:
Pink, pin 7
(+) STSW: Pink
or Yellow, pin 4
Refer to the
Vehicle wiring
reference chart for
more information on
vehicle-specific wiring
connections.
(-) Parking Lights: Lt. Blue, pin 18
Autolight:
Green, pin 19

6403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
ENGINE
START
STOP
D2D Port
1412
10 42
(-) Parking Light Output
(-) Ground
(+) 12V Input
XKD2D65
(+) Ignition Input
(AC) Tach Input
Wiring diagram
OBDII
Diagnostic
Connector
1 8
169
(+) Ignition Status Output: Gray/Black:7
(-) Push-to-Start Output: Green/Black:2
HS CAN High: Tan/Black:3
HS CAN Low: Tan:4
(+) 12V Input: Brown:7
(+) Start Stop Switch Output: Yellow:8
Autolights Interrupt (conn. side): Orange/Red: 10
Autolights Interrupt (veh. side): Yellow/Red: 11
(AC) Tach Output: Violet/White: 5
(+) 12V:
Black,pin 1
1
Dash Fuse Box
(white conn.)
PTS Switch
(black conn.
behind PTS button)
1543 1
811
12 10 9
14
6
13
2
7
(-) Push-To-Start: Pink, pin 7
(-) Parking Lights: Lt. Blue, pin 18
12345678910
1112131415161720
18
Headlight Switch
(white conn. at headlight
switch)
19
CUT
Autolight:
Green, pin 19
HS CAN Low: White, pin 14
HS CAN High: Black or Blue, pin 6
Do not connect any other accessory, ignition or starter wires
from the remote starter to the vehicle. The interface module
is handling the required vehicle power and start sequence.
(-) Trunk/Hatch Release Output
Refer to the
Vehicle wiring
reference chart for
more information on
vehicle-specific wiring
connections.
Main Body ECU
(white conn.
under drivers dash)
10 9 8
6 5 43
7
2 1
(+) STSW: Pink
or Yellow, pin 4

7403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
Locating components in the vehicle

8403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2013 Toyota Highlander (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black (DATA) HS CAN High data link connector, white 16 pin plug, pin 6 data blue
H1/4 Tan (DATA) HS CAN Low data link connector, white 16 pin plug, pin 14 data white
H1/5 Orange/Green No Connection No Connection
H1/6 Orange/Brown No Connection No Connection
H1/7 Brown Relay N.O. (+) 12 Volt Input dash fuse box, white 1 pin plug (1A), pin 1 + black (140A or 150A)
H1/8 Yellow Relay COM. (+) STSW Output Body ECU on back of dash fuse box, white 10 pin plug, pin 4 + pink
H1/9 Orange/Yellow Relay N.C. No Connection No Connection
H1/10 Orange/Red Relay N.C. Auto Light Interrupt (conn. side) [3] headlight switch, black 20 pin plug, pin 19 cut green
H1/11 Yellow/Red Relay COM. Auto Light Interrupt (veh. side) [3] headlight switch, black 20 pin plug, pin 19 cut green
H1/12 Brown/Red Relay N.O. No Connection No Connection
H1/13 Red (+) W2W Only - (+) 12 Volt Input dash fuse box, white 1 pin plug (1A), pin 1 + black (140A or 150A)
H1/14 Black (-) W2W Only - Ground (chassis ground)
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H2/1 Black/White (-) W2W Only - E-Brake Output Remote Starter
H2/2 Green/Black (-) PTS Output [2] engine start stop switch, black 14 pin plug, pin 7 - pink
H2/3 Green/White (-) W2W Only - Door Output Remote Starter
H2/4 Red/Black (-) W2W Only - Trunk Output Remote Starter
H2/5 Violet/White (AC) W2W Only - Tach Output Remote Starter
H2/6 Gray (+) W2W Only - Brake Output Remote Starter
H2/7 Gray/Black (+) Ignition Status Output Remote Starter
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown No Connection No Connection
H2/10 Yellow/Black No Connection No Connection
H2/11 Orange/Black No Connection No Connection
H2/12 Blue/Red (-) W2W Only - Hood Output Remote Starter
Input 10-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color

9403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color
H3/1 Green (-) W2W Only - Lock Input Remote Starter
H3/2 Blue (-) W2W Only - Unlock Input Remote Starter
H3/3 Red/White (-) W2W Only - Trunk Input Remote Starter
H3/4 White/Violet (-) Aux1 Input Remote Starter
H3/5 Violet/Black No Connection No Connection
H3/6 White/Black No Connection No Connection
H3/7 Pink/White No Connection No Connection
H3/8 Violet (+) W2W Only - Starter Input Remote Starter
H3/9 Pink (+) W2W Only - Ignition Input Remote Starter
H3/10 Blue/White (-) W2W Only - Ground When Running (Status) Input Remote Starter
D2D 4-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 Green
H4/2 Black
H4/3 Blue
H4/4 Red
RF 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A
H5/2 N/A
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire Connects To
Wire Location (+/-) Wire Color
12 Volts dash fuse box, white 1 pin plug (1A), pin 1 + black (140A or 150A)
Parking Lights - headlight switch, black 20 pin plug, pin 18 - lt. blue
Trunk/Hatch Release driver kick, gray 12 pin plug, pin 1; black 18 pin plug, pin 13 - yellow (liftgate); beige (glass) (rear handle switch)

10 403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
Push-to-Start (PTS) vehicles with CAN
1Wait until the LED turns ON solid red.
2
Press the Push-to-Start (PTS) button twice to turn the ignition ON. The LED flashes red slowly
for afew seconds to indicate the key is in learning mode. It then turns ON solid green for 3
seconds, before shutting OFF.*
* If the LED starts to flash orange, it indicates the vehicle is equipped with a factory remote
starter. Refer to "LED Diagnostics & Troubleshooting" for more information.
3The module is now programmed. Press the PTS button once more to turn the ignition OFF.
You have successfully completed the module programming sequence.
