Directed Xpresskit DBALL2 User manual

Installation Guide
Update Alert: Firmware updates are posted the web on a regular basis. We recommendon
that you check for firmware and/or install guide updates prior to installing this product.
Vehicle Application Guide ....... .................. ..................................... ............................... ......................................................
Key2 & 1 .............. ....... .................. ....GO KEY ................................ ............................... ......................................................
Installation s s(Wiring Diagram & Vehicle Wiring Reference Chart )
Type 1.............. ..... .................................................................................................................... ..........................................
Type .............. ..... ..........................................2 .......................................................................... ..........................................
Type 3.................................................................................................................................................................................
Programming
Module Programming ...................... .............................................................................. .......... ...........................................
Keyport Location........ ...................... .............................................................................. .......... ...........................................
Module Reset.. ...................................................................................................................................................................
Hard ... ....Reset.. ................................................................................................................................................................
Feature & Option List..........................................................................................................................................................
Feature Programming.........................................................................................................................................................
LED Diagnostics & Troubleshooting...................................................................................................................................
Limited One-Year Consumer ........Warranty.......................................................................................................................
Quick Reference Guide......................................................................................................................................................
02
03
04
07
09
11
13
14
14
15
16
17
19
20
Index
®, Chevrolet and GMC their respective companiesBuick, Cadillac are registered trademarks and property of .
Key2 is required.GO
Important!
▪This guide is compatible with the 9 firmware version 2.0 and later.GM 6
The 9 firmware for 2 is an all-in-one door lock and override module compatible withGM DBALL
specific Buick, Cadillac, Chevrolet and GMC vehicles.
This module can only be flashed and configured using Xpress at www.directechs.com orVIP
using the Directechs Mobile application for smartphones. Refer to the Module Programming
section 11on page for more information.
Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.

Vehicle Application Guide Page 2
The following table lists the vehicles and features which are compatible with this product. The number assigned to each
year allows you to determine which installation type should be used for your vehicle.
Vehicles
2018
2017
2016
2015
2014
2013
2012
2011
2010
PK-Immobilizer Bypass-Data No Key Req'd
DL-Arm Factory Security
DL-Disarm Factory Security
DL-Door Lock Control
DL-Door Unlock
DL-Driver Priority Unlock
DL-Trunk / Hatch Release
FOB-Control of aftermarket alarm with OEM remote
Key2GO
RS-RAP Shut Down (Retained ACC Power)
RS-Tach / RPM Output
SS-Entry Monitoring ALL Door Pins
SS-Entry Monitoring Hood Pin
SS-Entry Monitoring Trunk/Hatch Pin
SS-Factory Alarm Trigger Monitoring
ST-Brake Status (foot brake)
ST-E-Brake Status
ST-Ignition Status
Buick
LaCrosse(SmartKey) 1111111•••••••D••••••D•••
Regal (Smart Key) 1 1 1 1 1 1 1 •••••••D••••••D•••
Verano(SmartKey) 111111 •••••••D••••••D•••
Cadillac
ATS(SmartKey) 2222 •••••••D••••••D•••
CTS Sedan (Smart Key) 2 2 2 •••••••D••••••D•••
Escalade(SmartKey) 222 •••••••D••••••D•••
SRX(SmartKey) 1111111•••••••D••••••D•••
XTS(SmartKey) 1111 •••••••D••••••D•••
Chevrolet
Cruze(SmartKey) 111111 •••••••D••••••D•••
Impala(SmartKey) 11111 •••••••D••••••D•••
Malibu(SmartKey) 33111 •••••••D••••••D•••
Suburban (Smart Key) 2 2 2 •••••••D••••••D•••
Tahoe (Smart Key) 2 2 2 •••••••D••••••D•••
GMC
Yukon(SmartKey) 222 •••••••D••••••D•••
Legend:
D: Data-to-Data (D2D) only PK: Transponder & Immobilizer Override
•: D2D & Wire-to-Wire (W2W)
DL: OE Door Lock & Alarm Controls
FOB: Sync CAN Interface w/ FOB Remote
RS: Engine Start & Status
SS: Entry Point Status-Security
ST: Function/Feature Status
Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.

Page 3
This feature is mandatory to control the immobilizer override in this firmware.
Key2 has been designed and developed to bypass the advanced encryption layers found in modern vehicles. It usesGO
an array of servers to generate a duplicate of the original key, the installation of a remote starter without having toallowing
give up a key.
The advantage is that this feature allows you to use one original key and the server to configure the bypass in the vehicle.
All Key2 -compatible firmware are clearly indicated in the function list of each vehicle search result page and will alsoGO
appear on the flash page. Any first-time user must re-register to gain access to Key2 , and some additional informationGO
will be required to complete the registration process, such as your Directed account number and store name.
Key2 is compatible with Xpress 4.5 or higher and requires an oader.GO VIP XKL
Refer to page 2 of this guide for instructions on how to program features using Key2 .1GO
Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.

1234
5678
910
17
23
16
22
11 12
18
24
13
19
25
14
20
26
15
21
27
1234
5
89
10 11 12 13 14
15 17 19
23 25
16
22
18 20
24 26
67
Not required in D2D mode.
1: (-) Lock InputGreen:
2: (-) Unlock InputBlue:
3: (-)Red/White: Trunk Release Input
4: (-)White/Violet: Tailgate Input
8: (+) Starter InputViolet:
9: (+) Ignition InputPink:
10: (-) (Status) InputBlue/White: GWR
Single Wire : 1CAN Light Green:
SW CAN: pin 22
180Ω
HS CAN Low:
pin 23
HS CAN High:
pin 24
HS CAN High: 3Tan/Black:
HS CAN Low: 4Tan:
(-) Clutch Output: 11Yellow/Red:
(-) Ground 12: Brown/Red:
(-) Ground: 14Black:(-) Ground
(+) 12V: 13Red:
(+) 12V
( ) Tach OutputAC : 5Violet/White:
(+) Brake Status Output: 6Gray:
(-) E-Brake Status 1: Black/White:
(-) E-Brake Status Input
(-) Door/Trunk Status: 3Green/White:
(+) Ignition Status Output: 7Gray/Black:
Immo. Data (conn. side): 10Yellow/Black:
(MUX) Brake Activation Output: 9Violet/Brown:
(-) Hood Status: 12Blue/Red:
Remote
Starter
(-) (Status)GWR Output
(+) Ignition putIn
(-) OutputLock
(+) Starter Output
(-) OutputAUX
(-) OutputUnlock
(-) Trunk Release Output
(-) Trunk Status InputDoor/
(-) Parking Lights Output
(-) Hood Status Input
(+) Brake Status Input
( ) Tach InputAC
(-) Ground
(+) 12V Input
(-) Parking Lights in 22P:
Immo. Data Interr. (conn. side): 8Yellow:
Immo. Data Interr. (veh. side): 9Orange/Yellow:
1
8910 11 12 13 14
17
23
15
21
16
22
18
24
19 20
25
234567
Immo. Data:
Green/Violet
or Lt. Blue,
pin 2
White at BCM
Green at BCM Lt. Blue at BCM (+) 12V: pin 4
Brake: pin 7
BCM
BrownBlue Green Gray White PinkBlack
CUT
ABC
Clutch: in Bp
Clutch Switch
(b .)lack 3-pin conn
Page 4
Installation Type 1
[2] Required for manual transmission vehicles.ONLY
[1] Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
Refer to "Vehicle Wiring Reference Chart - Type 1" on next page for more information on vehicle-specific connections.
With the exception of the Diagno tic connector, all adapters are displayed from the wire side (unless specified otherwise).OBDII s
P#: 2D65XKD
TX
(-) Ground
RX
(+)12V
10
RF
Prog Button.
LED
4
14 12 2
2DBALL
[3]
[2]
[2]
[2]
[3]
[1]
[1]
[3] Cadillac .SRX ONLY
Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.

Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.
Wire colors should only be used as a reference. You should always test a wire's function before connecting to it.
Page 5
Type 1 - Vehicle Wiring Reference Chart
Function Color Pin Polarity Location Color Pins
Buick LaCrosse (Smart key) 2010
Immo. Data Lt. Blue 2 Data BCM under drivers dash. Green 25
Parking Lights Lt. Blue 22 (-) BCM under drivers dash. White 26
SW CAN Dk. Green 22 Data BCM under drivers dash. Blue 27
HS CAN High Tan/Black 24 Data BCM under drivers dash. Blue 27
HS CAN Low Tan 23 Data BCM under drivers dash. Blue 27
Brake Yellow 7 MUX BCM under drivers dash. Blue 27
12V Red/White 4 (+) BCM under drivers dash. Blue 27
Buick LaCrosse (Smart key) 2011-2012
Immo. Data Green/Violet 2 Data BCM under drivers dash. Green 25
Parking Lights Lt. Green 22 (-) BCM under drivers dash. White 26
SW CAN Lt. Green 22 Data BCM under drivers dash. Blue 27
HS CAN High Dk. Blue 24 Data BCM under drivers dash. Blue 27
HS CAN Low White 23 Data BCM under drivers dash. Blue 27
Brake Dk. Blue 7 MUX BCM under drivers dash. Blue 27
12V Red/Violet 4 (+) BCM under drivers dash. Blue 27
Buick LaCrosse (Smart key) 2013-2016
Immo. Data Green/Violet 2 Data BCM under drivers dash. Green 25
Parking Lights Green/Brown or Lt. Green 22 (-) BCM under drivers dash. White 26
SW CAN Lt. Green 22 Data BCM under drivers dash. Blue 27
HS CAN High Dk. Blue 24 Data BCM under drivers dash. Blue 27
HS CAN Low
Dk. Blue/Yellow 23 Data BCM under drivers dash. Blue 27
Brake Yellow 7 MUX BCM under drivers dash. Blue 27
12V Red/Violet 4 (+) BCM under drivers dash. Blue 27
Buick Regal (Smart Key) 2012-2014
Immo. Data Green/Violet 2 Data BCM under drivers dash. Green 25
Parking Lights Green/Gray 22 (-) BCM under drivers dash. White 26
SW CAN Green 22 Data BCM under drivers dash. Blue 27
HS CAN High Blue 24 Data BCM under drivers dash. Blue 27
HS CAN Low White 23 Data BCM under drivers dash. Blue 27
Brake Blue/Yellow 7 MUX BCM under drivers dash. Blue 27
12V Red/White or Red/Brown 4 (+) BCM under drivers dash. Blue 27
Clutch Output [3] Yellow B MUX Clutch switch. Black 3
Buick Verano (Smart Key) 2012-2016
Immo. Data Green/Violet 2 Data BCM passenger side center console. Green 25
Parking Lights Green/Gray 22 (-) BCM passenger side center console. White 26
SW CAN Green 22 Data BCM passenger side center console. Blue 27
HS CAN High Blue 24 Data BCM passenger side center console. Blue 27
HS CAN Low White 23 Data BCM passenger side center console. Blue 27
Brake Blue/Yellow 7 MUX BCM passenger side center console. Blue 27
12V Red/Brown 4 (+) BCM passenger side center console. Blue 27
Clutch Output [3] Yellow B MUX Clutch switch. Black 3
Wire Information Connector Information

Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.
Page 6
Type 1 - Vehicle Wiring Reference Chart
Function Color Pin Polarity Location Color Pins
Cadillac SRX (Smart Key) 2010-2012
Immo. Data Green/Violet 2 Data BCM under drivers dash. Green 25
Parking Lights
Green/Brown or Lt. Green 22 (-) BCM under drivers dash. White 26
SW CAN Lt. Green 22 Data BCM under drivers dash. Blue 27
HS CAN High Dk. Blue 24 Data BCM under drivers dash. Blue 27
HS CAN Low Dk. Blue/Yellow 23 Data BCM under drivers dash. Blue 27
Brake Yellow 7 MUX BCM under drivers dash. Blue 27
12V Red/Violet 4 (+) BCM under drivers dash. Blue 27
Cadillac SRX (Smart Key) 2013-2016
Immo. Data Lt. Green/Violet 2 Data BCM under drivers dash. Green 25
Parking Lights Lt. Green/Gray 22 (-) BCM under drivers dash. White 26
SW CAN Green 22 Data BCM under drivers dash. Blue 27
HS CAN High Tan/Black 24 Data BCM under drivers dash. Blue 27
HS CAN Low Tan 23 Data BCM under drivers dash. Blue 27
Brake Blue/Yellow 7 MUX BCM under drivers dash. Blue 27
12V Red/Violet 4 (+) BCM under drivers dash. Blue 27
Cadillac XTS (Smart Key) 2013-2016
Immo. Data Lt. Green/Violet 2 Data BCM under drivers dash. Green 25
Parking Lights Lt. Green/Gray 22 (-) BCM under drivers dash. White 26
SW CAN Lt. Green 22 Data BCM under drivers dash. Blue 27
HS CAN High Lt. Blue 24 Data BCM under drivers dash. Blue 27
HS CAN Low White 23 Data BCM under drivers dash. Blue 27
Brake Blue/Yellow 7 MUX BCM under drivers dash. Blue 27
12V Red/Violet 4 (+) BCM under drivers dash. Blue 27
Chevrolet Cruze (Smart Key) 2012-2016
Immo. Data Green/Violet 2 Data BCM passenger side center console. Green 25
Parking Lights Green/Gray 22 (-) BCM passenger side center console. White 26
SW CAN Green 22 Data BCM passenger side center console. Blue 27
HS CAN High Blue 24 Data BCM passenger side center console. Blue 27
HS CAN Low White 23 Data BCM passenger side center console. Blue 27
Brake Blue/Yellow 7 MUX BCM passenger side center console. Blue 27
12V Red/Gray 4 (+) BCM passenger side center console. Blue 27
Clutch Output [3] Yellow B MUX Clutch switch. Black 4
Chevrolet Impala (Smart Key) 2014-2016
Immo. Data Green/Violet 2 Data BCM under drivers dash. Green 25
Parking Lights Green/Gray 22 (-) BCM under drivers dash. White 26
SW CAN Lt. Green 22 Data BCM under drivers dash. Blue 27
HS CAN High Blue 24 Data BCM under drivers dash. Blue 27
HS CAN Low White 23 Data BCM under drivers dash. Blue 27
Brake Blue/Yellow 7 MUX BCM under drivers dash. Blue 27
12V Red/Violet 4 (+) BCM under drivers dash. Blue 27
Chevrolet Malibu (Smart Key) 2013-2015
Immo. Data Green/Violet 2 Data BCM under drivers dash. Green 25
Parking Lights Gray 22 (-) BCM under drivers dash. White 26
SW CAN Green 22 Data BCM under drivers dash. Blue 27
HS CAN High Blue 24 Data BCM under drivers dash. Blue 27
HS CAN Low White 23 Data BCM under drivers dash. Blue 27
Brake Blue 7 MUX BCM under drivers dash. Blue 27
12V Red/Violet 4 (+) BCM under drivers dash. Blue 27
Wire Information Connector Information

Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.
1234
5678
910
17
23
16
22
11 12
18
24
13
19
25
14
20
26
15
21
27
1234
5
89
10 11 12 13 14
15
21
17 19
23 25
16
22
18 20
24 26
67
Not required in D2D mode.
1: (-) Lock InputGreen:
2: (-) Unlock InputBlue:
3: (-)Red/White: Trunk Release Input
8: (+) Starter InputViolet:
9: (+) Ignition InputPink:
10: (-) (Status) InputBlue/White: GWR
Single Wire : 1CAN Light Green:
SW CAN:
, pin 23Green
HS CAN Low:
, pin 24White
HS CAN High: , pin 25Blue (+) 12V: Red/Gray or
Red/Violet, pin 4
Immo. Data:
,Green/Violet
pin 2
HS CAN High: 3Tan/Black:
HS CAN Low: 4Tan:
(-) Ground: 14Black:(-) Ground
(+) 12V: 13Red:
(+) 12V
( ) Tach OutputAC : 5Violet/White:
(+) Brake Status Output: 6Gray:
(-) E-Brake Status 1: Black/White:
(-) E-Brake Input Status
(-) Door/Trunk Status: 3Green/White:
(+) Ignition Status Output: 7Gray/Black:
Immo. Data (conn. side): 10Yellow/Black:
(MUX) Brake Activation Output: 9Violet/Brown:
(-) Hood Status: 12Blue/Red:
Remote
Starter
(-) (Status)GWR Output
(+) Ignition Input
(-) OutputLock
(+) Starter Output
(-) OutputUnlock
(-) Trunk Release Output
(-) Trunk Status InputDoor/
(-) Parking Lights Output
(-) Hood Status Input
(+) Brake Status Input
( ) Tach InputAC
BCM
(-) Parking
Lights Gray:
or Green/Gray,
pin 22
Immo. Data Interr. (conn. side): 8Yellow:
Immo. Data Interr. (veh. side): 9Orange/Yellow:
1
8910 11 12 13 14
17
23
15
21
16
22
18
24
19 20
25
234567
(+) 12V
123
456789
10 11 12 13 14 15 16
17 18 19 20 21
22 24 25 2623
White at BCM
Green at BCM
Lt. Blue at BCM Gray at BCM
Brake:
inBlue, p 7
BrownBlue Green Gray White PinkBlack
(-) Ground
CUT
(-) Clutch Output: 11Yellow/Red:
(-) Ground 12: Brown/Red:
180Ω
ABC
Clutch: in BP
Clutch Switch
(b .)lack 3-pin conn
Page 7
Installation Type 2
[1] Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
P#: 2D65XKD
TX
(-) Ground
RX
(+)12V
10
RF
Prog Button.
LED
4
14 12 2
2DBALL
Refer to "Vehicle Wiring Reference Chart - Type 2" on next page for more information on vehicle-specific connections.
With the exception of the Diagno tic connector, all adapters are displayed from the wire side (unless specified otherwise).OBDII s
[1]
[1]
[]3
[]3
[]3
[3] Required for manual transmission vehicles.ONLY

Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.
Wire colors should only be used as a reference. You should always test a wire's function and pin location before
connecting to it.
Page 8
Type - Vehicle Wiring Reference Chart2
Function Color Pin Polarity Location Color Pins
Cadillac ATS (Smart Key) 2013-2015
Immo. Data Green/Violet 2 Data BCM behind glove box. Green 25
Parking Lights Gray or Green/Gray 22 (-) BCM behind glove box. White 26
HS CAN High Blue 25 Data BCM behind glove box. White 26
HS CAN Low White 24 Data BCM behind glove box. White 26
SW CAN Green 23 Data BCM behind glove box. Gray 26
Brake Blue/Yellow 7 MUX BCM behind glove box. Blue 27
12V Red/Gray 4 (+) BCM behind glove box. Blue 27
Clutch Output [3] Yellow B MUX Clutch switch. Black 3
Cadillac CTS (Smart Key) 2013-2015
Immo. Data Green/Violet 2 Data BCM under driver dash. Green 25
Parking Lights Gray or Green/Gray 22 (-) BCM under driver dash. White 26
HS CAN High Blue 25 Data BCM under driver dash. White 26
HS CAN Low White 24 Data BCM under driver dash. White 26
SW CAN Green 23 Data BCM under driver dash. Gray 26
Brake Blue/Yellow 7 MUX BCM under driver dash. Blue 27
12V Red/Gray 4 (+) BCM under driver dash. Blue 27
Chevrolet Suburban (Smart Key) 2015
Immo. Data Green/Violet 2 Data BCM under driver dash. Green 25
Parking Lights Green/Gray 22 (-) BCM under driver dash. White 26
HS CAN High Blue 25 Data BCM under driver dash. White 26
HS CAN Low White 24 Data BCM under driver dash. White 26
SW CAN Green 23 Data BCM under driver dash. Gray 26
Brake White/Green 7 MUX BCM under driver dash. Blue 27
12V Red/Violet 4 (+) BCM under driver dash. Blue 27
Chevrolet Tahoe (Smart Key) 2015-2016
Immo. Data Green/Violet 2 Data BCM under driver dash. Green 25
Parking Lights Green/Gray 22 (-) BCM under driver dash. White 26
HS CAN High Blue 25 Data BCM under driver dash. White 26
HS CAN Low White 24 Data BCM under driver dash. White 26
SW CAN Green 23 Data BCM under driver dash. Gray 26
Brake White/Green 7 MUX BCM under driver dash. Blue 27
12V Red/Violet 4 (+) BCM under driver dash. Blue 27
Cadillac Escalade (Smart Key) 2015-2016
Immo. Data Green/Violet 2 Data BCM under driver dash. Green 25
Parking Lights Green/Gray 22 (-) BCM under driver dash. White 26
HS CAN High Blue 25 Data BCM under driver dash. White 26
HS CAN Low White 24 Data BCM under driver dash. White 26
SW CAN Green 23 Data BCM under driver dash. Gray 26
Brake White/Green 7 MUX BCM under driver dash. Blue 27
12V Red/Violet 4 (+) BCM under driver dash. Blue 27
GMC Yukon (Smart Key) 2015-2016
Immo. Data Green/Violet 2 Data BCM under driver dash. Green 25
Parking Lights Green/Gray 22 (-) BCM under driver dash. White 26
HS CAN High Blue 25 Data BCM under driver dash. White 26
HS CAN Low White 24 Data BCM under driver dash. White 26
SW CAN Green 23 Data BCM under driver dash. Gray 26
Brake White/Green 7 MUX BCM under driver dash. Blue 27
12V Red/Violet 4 (+) BCM under driver dash. Blue 27
Wire Information Connector Information

1234
5678
910
17
23
16
22
11 12
18
24
13
19
25
14
20
26
15
21
27
1234
5
89
10 11 12 13 14
15 17 19
23 25
16
22
18 20
24 26
67
Not required in D2D mode.
1: (-) Lock InputGreen:
2: (-) Unlock InputBlue:
3: (-) Trunk Release InputRed/White:
8: (+) Starter InputViolet:
9: (+) Ignition InputPink:
10: (-) (Status) InputBlue/White: GWR
Single Wire : 1CAN Light Green:
SW CAN:
in 22Green, p
Brake:
in 7Blue, p
HS CAN Low:
White, p 4in 2
HS CAN , p 5High: in 2Blue
HS CAN High: 3Tan/Black:
HS CAN Low: 4Tan:
(-) Ground: 14Black:(-) Ground
(+) 12V: 13Red:
(+) 12V
( ) Tach OutputAC : 5Violet/White:
(+) Brake Status Output: 6Gray:
(-) E-Brake Status 1: Black/White:
(-) E-Brake Status
(-) Door/Trunk Status: 3Green/White:
(+) Ignition Status Output: 7Gray/Black:
Immo. Data (conn. side): 10Yellow/Black:
(MUX) Brake Activation Output: 9Violet/Brown:
(-) Hood Status: 12Blue/Red:
Remote
Starter
(-) (Status)GWR
(+) Ignition putIn
(-) OutputLock
(+) Starter Output
(-) OutputUnlock
(-) Trunk Release Output
(-) Trunk Status InputDoor/
(-) Parking Lights
(-) Hood Status
(+) Brake Status
( ) Tach InputAC
(+) 12V
(-) Parking
Lights Gray,:
in 22p
Immo. Data Interr. (conn. side): 8Yellow:
Immo. Data Interr. (veh. side): 9Orange/Yellow:
1
8910 11 12 13 14
17
23
15
21
16
22
18
24
19 20
25
234567
Immo. Data:
Green/Violet,
in 2p
White at BCM
Green at BCM
Lt. Blue at BCM
(+) 12V:
Red/Brown,
pin 4
BrownBlue Green Gray White PinkBlack
(-) Ground
BCM
CUT
Page 9
Installation Type 3
[1] Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
With the exception of the Diagno tic connector, all adapters are displayed from the wire side (unless specified otherwise).OBDII s
P#: 2D65XKD
TX
(-) Ground
RX
(+)12V
10
RF
Prog Button.
LED
4
14 12 2
2DBALL
Refer to "Vehicle Wiring Reference Chart - Type " on next page for more information on vehicle-specific connections.3
[1]
[1]
Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.

Rev.: 20 0817 28
Platform: DBALL2
Firmware G 9:Mv.2.0 +6
© 2017 Directed. All rights reserved.
Wire colors should only be used as a reference. You should always test a wire's function before connecting to it.
Page 10
Type - Vehicle Wiring Reference Chart3
Function Color Pin Polarity Location Color Pins
Chevrolet Malibu (Smart Key) 2016
Immo. Data Green/Violet 2 Data BCM passenger side center console. Green 25
Parking Lights Gray 22 (-) BCM passenger side center console. White 26
HS CAN High Blue 25 Data BCM passenger side center console. White 26
HS CAN Low White 24 Data BCM passenger side center console. White 26
SW CAN Green 22 Data BCM passenger side center console. Blue 27
Brake Blue/Yellow 7 MUX BCM passenger side center console. Blue 27
12V
Red/Brown 4 (+) BCM passenger side center console. Blue 27
Wire Information Connector Information
