INSTALLATION GUIDE
DS3+ / DS4+
2015 Toyota Sienna (Smart Key). 933.TL2 4.12.193.2
© 2021 Directed, Vista CA
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.

Introduction 3
Vehicle function compatibilities 3
Pre-installation and application warnings 4
OEM remote starter detection 4
Installation 6
Wiring diagram with T-Harness (THTON6) 6
Wiring diagram 7
Locating components in the vehicle 8
Vehicle connections 9
Connecting the module 12
Important! 12
8556T Temperature Sensor 12
8504D Combo Sensor 12
RF Systems 13
When used in conjunction with SmartStart 13
D2D port configuration 13
Manual Transmission 14
Module programming 15
(For security-only programming, see next section.) 15
Module programming for security-only installations 16
LED diagnostics and troubleshooting 17
Soft reset 19
Hard reset 19
Learning the Tach (not needed with Virtual Tach) 20
Initializing Virtual Tach (not needed with hardwired or data tach applications) 20
Limited lifetime consumer warranty 21
Quick reference guide 22
Contents

3933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Introduction
DS3+ is a complete solution for remote start, security (when security features are enabled) and bypass. This guide provides
information on the installation of the module as a digital solution. Please refer to www.directechs.com for more information about
which configuration is best for your application.
Warning! This module can be configured using the web tool located at www.directechs.com. The DS3/DS3+ module is not
equipped with Bluetooth, therefore the blue LED will not flash during module programming or when performing a soft or hard reset.
DS4+ is a complete solution for remote start, security (when security features are enabled), bypass, and features
built in Bluetooth 4.0 allowing you to configure and control your system. This guide provides information on the
installation of the module as a digital solution. Please refer to the DirectLink application or www.directechs.com
for more information about which configuration is best for your application.
Warning! This module is designed to be configured using the DirectLink application for mobile devices,
however it can also be configured using the web tool located at www.directechs.com. To download the DirectLink mobile
application, please visit the Google Play or Apple store.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart.
Auto Headlamp Shutoff
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Sliding Door Control Driver
Sliding Door Control Passenger
Trunk / Hatch Release
Control of aftermarket alarm with OEM remote
* Fuel Level
* Odometer
Immobilizer Bypass-Data No Key Req'd
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Accessory Activation
Ignition Activation
SmartStart
Start (Crank) Activation
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Brake Status (foot brake)
E-Brake Status
Ignition Status

4933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible THTON6 Keys required for programming 1Keys required for operation 0
Warning! No takeover feature is available on Push-to-Start vehicles.
The keyless and Smart Key will remain functional during remote start.
All Hybrid vehicles: for best results, set Engine Checking to OFF when flashing.
If the vehicle is already equipped with an OEM remote starter, the installer must disconnect it before installing the DS4 plus
module, otherwise it will not program.
The optional Plug & Play THTON6 T-Harness is sold separately.
Important! All T-Harness wires NOT listed in the diagram are NOT required for the installation. Loose wires such as Siren
Output and Hood Input may need to be pulled from the tapped section of the T-Harness. Refer to the “Wiring diagram with
T-Harness” for more information on connections and installation instructions.
All T-Harness wires NOT listed in the diagram are NOT required for the installation.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each
wiring diagram.
Refer to the "Vehicle connections" following the installation diagram.
General notes: This section highlights important information for this specific firmware.
[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.
[2] The siren is ONLY required when enabling the security features during module flashing.
[3] Connection required ONLY if Pit-Stop/Idle mode is desired.
[4] For Security Only Installations, refer to 'Locating components in the vehicle' for the optional starter disable connection.

5933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
OEM remote starter detection
If the vehicle has an active OEM remote starter it will program into convenience only (no immobilizer bypass). The reason for this
is to allow aftermarket security to be installed while keeping the factory remote starter active. If you wish for the interface to control
the remote start sequence, perform one of the following:
If the vehicle is equipped with an Add-On Lexus/Toyota OEM remote starter:
Some Lexus/Toyota vehicles may have an Add-On remote starter. If the OEM unit is installed, whether Active or Inactive, it MUST
be permanently disconnected, as both modules cannot coexist. Refer to 'Physical OEM remote start locations" in the chart below
and always physically inspect and disconnect any OEM remote starter before programming any Directed products.
Physical OEM remote start locations
Make Model OEM remote starter & connectors location
Toyota Venza (Smart Key) Behind glove box.
Lexus RX 450h (Smart Key) Behind glove box.
Lexus RX 350 (Smart Key) Behind glove box.
Toyota 4Runner (Smart Key) Behind glove box & passenger kick panel.
Toyota Sienna (Smart Key) Behind glove box & passenger kick panel.
Lexus HS 250h (Smart Key) Behind glove box.
Prius Prius (Smart Key) Under dash panel & driver kick panel.
Lexus CT 200h Behind glove box.
Lexus GX 460 (Smart Key) Behind glove box.
Toyota Prius V (Smart Key) Behind glove box.
If the vehicle is equipped with a BCM Enabled Lexus/Toyota OEM remote starter:
The vehicle does not have a physical remote starter and only one module can be programed at a time. In this case temporarily
disable the OEM remote start system using the following process:
1. Remove the fuse powering the OEM Remote Starter. See "OEM remote start fuse location"
2. Perform a "Soft reset" or "Hard reset".
3. Perform the "Module programming".
4. After programming is successful, re-insert the fuse powering the OEM Remote Starter.
OEM remote start fuse location
Make Model Fuse Location Fuse Name Fuse
Value
Lexus CT 200h (Smart Key) Engine room relay box, left side of engine compartment. MAYDAY 10A
Lexus GX 460 (Smart Key) Engine room relay box, left side of engine compartment. MAYDAY 7.5A
Lexus RX 350 (Smart Key) Engine room relay box, left side of engine compartment. MAYDAY/TEL 7.5A
Lexus RX 450h (Smart Key) Engine room relay box, left side of engine compartment. MAYDAY 7.5A

6933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Refer to the
Optional starter disable
connection section for relay
and connection details.
Cut the Tan & Tan/Black loops labelled
CAN 1 and extend the wires coming
from the module side and connect them
to the CAN wires on the OBDII.
Wiring diagram with T-Harness (THTON6)
16
8
9
1
Diagnostic Connector OBDII
(connector side view)
HS CAN Low: White
or Red, pin 14
Steering Lock
(black 7-pin connector)
Main Body
ECU
Siren
Hood Pin
ENGINE
START
STOP
Black
connector
1
3
4
5
1214 11 10 8
2
9
6
13
7
(-) Push-to-Start Output: Lt. Blue/Black
(-) Hood Input: Gray
(+) Siren Output: Brown/Red
(-) Push-To-Start:
Blue or Lt. Green, pin 7
Body ECU Connector
(middle conn. left side
of steering column)
TL8
TL6
TL2
NOT USED
CONNECT the white 12-pin
connector to the 12-pin
connector labeled TL2.
(-) GWA Output: Blue/White
HS CAN High: Red or Violet, pin 6HS CAN High: Red or Violet, pin 6
Cut the
Dk.Green/Black
and Dk/Blue/Black
loops labelled
Lock/Unlock.
THTON6
(optional T-Harness)
8-pin White Connector
22-pin White Connector
12-pin Black Connector
HS CAN Low: Tan
HS CAN High: Tan/Black
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
5
30
20
20
*Connectors color may
differ depending on
the T-Harness revision.
*
*
*
Engine Start Stop Switch
(black conn)

7933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Refer to the
Optional starter disable
connection section for relay
and connection details.
Wiring diagram
16
8
9
1
1235 47 6
Diagnostic Connector OBDII
(connector side view)
HS CAN Low: White
or Red, pin 14
HS CAN High: Red or Violet, pin 6
Steering Lock
(black 7-pin connector)
BTX: Pin 16
Body ECU
(White or Black 30-pin
connector)
Main Body
ECU
1 7
2 8
3
6
9
21
22
25
10
13
23
26
11
14
29
24
27
12
15
18
20
19
4
16 28
30
(-) Parking Lights: Pin 30
BRX: Pin 4
Siren
Hood Pin
ENGINE
START
STOP
Black
connector
1
3
4
5
1214 11 10 8
2
9
6
13
7
(+) 12V: Pin 16
(-) SLP Output: Blue: 3
(-) Ground: Black: 10
HS CAN Low: Tan: 1
(-) Push-to-Start Output: Lt. Blue/Black: 10
(-) Parking Lights Output: Lt. Green/Black: 1
HS CAN High: Tan/Black: 2
Immo Data 1: Yellow/Black: 8
Immo Data 2: Orange/Black: 7
(+) 12V Input: Red: 6 & 12
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
(-) SLP: Green or
Lt. Blue, pin 4
(-) Push-To-Start:
Blue or Lt. Green, pin 7
(-) Ground: Blue/Red: 2
5
17
(-) GWA Output: Blue/White: 2
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
5
30
20
20
Engine Start Stop Switch
(black conn)

8933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Locating components in the vehicle
(-) Ground When Armed (GWA) Output: Blue/White: 2
86 85
30
87a
87
Optional starter disable connection
Cut
Starter (conn. side)
Starter (veh. side)
(+) Ignition
Refer to the
Vehicle connections
section for wire and
connector details.
22 812
4 2442
When using an external relay, use a 1N4002 diode or larger.
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
1A diode [1N4002+ ]

9933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2015 Toyota Sienna (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data harness, 8-pin white connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H1/1 Tan (Data) HS CAN Low OBD-Data Link Connector, white 16 pin plug, pin 14 data white Mandatory
H1/2 Tan/Black (Data) HS CAN High OBD-Data Link Connector, white 16 pin plug, pin 6 data red Mandatory
H1/3 Orange/Brown No Connection No Connection
H1/4 Orange/Green No Connection No Connection
H1/5 Lt. Green No Connection No Connection
H1/6 Violet/Brown No Connection No Connection
H1/7 Orange/Black (Data) Immo Data 2 Body ECU on dash fuse box, white 30 pin plug, pin 16 data blue (BTX) Remote Start
Only
H1/8 Yellow/Black (Data) Immo Data 1 Body ECU on dash fuse box, white 30 pin plug, pin 4 data black (BRX) Remote Start
Only
Analog input/output harness, 22-pin white connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/1 Lt. Green/Black (-) Pk Light Output Body ECU on dash fuse box, white 30 pin plug, pin 30 - yellow Mandatory
H2/2 Blue/White (-) Ground When Armed (GWA) Output [2] Starter:
Power Management ECU behind glove box, white 30 pin plug,
pin 3
Ignition:
dash fuse box, white 40 pin plug (2F), pin 6
Must use a relay.
Must use a 1A 1N4002 or larger diode.
+
+
pink
red
Security Only
H2/3 Dk. Green/Black No Connection No Connection
H2/4 Red/White No Connection No Connection
H2/5 Brown/Black No Connection No Connection
H2/6 Brown/White No Connection No Connection
H2/7 White (+) No Connection No Connection
H2/8 Violet/Black No Connection No Connection
H2/9 Dk. Blue/Black No Connection No Connection
H2/10 Lt. Blue/Black (-) PTS Output [3] engine start stop switch, black 14 pin plug, pin 7 - blue Remote Start
Only
H2/11 Brown/Red (+) Siren Output [2] Security Only
H2/12 Pink No Connection No Connection
H2/13 Violet No Connection No Connection
H2/14 Brown No Connection No Connection
H2/15 White/Blue No Connection No Connection
H2/16 Red/Blue No Connection No Connection

10 933.TL2 4.12.193.2 2015 Toyota Sienna (Smart Key)
© 2021-02-19 Directed. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/17 Black/White No Connection No Connection
H2/18 Orange/Black No Connection No Connection
H2/19 Blue No Connection No Connection
H2/20 Green No Connection No Connection
H2/21 Gray (-) Hood Switch Input [1]
H2/22 Violet/White No Connection No Connection
Main harness, 12-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H3/1 Blue/White Relay N.C. No Connection No Connection
H3/2 Blue/Red Relay N.O. (-) Ground (chassis ground) Remote Start
Only
H3/3 Blue Relay COM (-) SLP Output steering lock actuator on steering column, black 7 pin plug, pin
4
- green Remote Start
Only
H3/4 White/Brown Relay N.C. No Connection No Connection
H3/5 White Relay COM No Connection No Connection
H3/6 Red (+) 12 Volt Input OBD-Data Link Connector, white 16 pin plug, pin 16 + black (7.5A) Mandatory
H3/7 Lt. Green/Red Relay N.O. No Connection No Connection
H3/8 Lt. Green Relay COM No Connection No Connection
H3/9 Lt. Green/White Relay N.C. No Connection No Connection
H3/10 Black (-) Ground (chassis ground) Mandatory
H3/11 White Relay COM No Connection No Connection
H3/12 Red (+) 12 Volt Input OBD-Data Link Connector, white 16 pin plug, pin 16 + black (7.5A) Mandatory
Relay harness, 10-pin white connector (H4)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/1 N/A No Connection No Connection
H4/2 Red/Black No Connection No Connection
H4/3 Pink/Black No Connection No Connection
H4/4 Pink/White No Connection No Connection
H4/5 Red No Connection No Connection
H4/6 Green No Connection No Connection
H4/7 Violet No Connection No Connection
H4/8 Orange No Connection No Connection
H4/9 Red/White No Connection No Connection
H4/10 Pink No Connection No Connection
