INSTALLATION GUIDE
DS3+ / DS4+
2019 Nissan Qashqai (Smart Key). 933.NISS06 3.23.195.3
© 2021 Directed, Vista CA
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.

Introduction 3
Vehicle function compatibilities 3
Pre-installation and application warnings 4
Installation 4
Wiring diagram with T-Harness (THNIN5) 4
Wiring diagram 6
Locating components in the vehicle 7
Vehicle connections 8
Connecting the module 13
Important! 13
8556T Temperature Sensor 13
8504D Combo Sensor 13
RF Systems 14
When used in conjunction with SmartStart 14
D2D port configuration 14
Manual Transmission 15
Module programming 16
(For security-only programming, see next section.) 16
Module programming for security-only installations 17
LED diagnostics and troubleshooting 18
Soft reset 20
Hard reset 20
Learning the Tach (not needed with Virtual Tach) 21
Initializing Virtual Tach (not needed with hardwired or data tach applications) 21
Limited lifetime consumer warranty 22
Quick reference guide 23
Contents

3933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Introduction
DS3+ is a complete solution for remote start, security (when security features are enabled) and bypass. This guide provides
information on the installation of the module as a digital solution. Please refer to www.directechs.com for more information about
which configuration is best for your application.
Warning! This module can be configured using the web tool located at www.directechs.com. The DS3/DS3+ module is not
equipped with Bluetooth, therefore the blue LED will not flash during module programming or when performing a soft or hard reset.
DS4+ is a complete solution for remote start, security (when security features are enabled), bypass, and features
built in Bluetooth 4.0 allowing you to configure and control your system. This guide provides information on the
installation of the module as a digital solution. Please refer to the DirectLink application or www.directechs.com
for more information about which configuration is best for your application.
Warning! This module is designed to be configured using the DirectLink application for mobile devices,
however it can also be configured using the web tool located at www.directechs.com. To download the DirectLink mobile
application, please visit the Google Play or Apple store.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart.
Parking Lights Control
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Trunk / Hatch Release
Control of aftermarket alarm with OEM remote
* Fuel Level
* Odometer
Immobilizer Bypass-Data No Key Req'd
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Accessory Activation
Ignition Activation
Remote Start Takeover
SmartStart
Start (Crank) Activation
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Brake Status (foot brake)
Door Locks Status
E-Brake Status
Ignition Status

4933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in pricing accordingly,
as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible THNIN5 Keys required for
programming 1Keys required for operation 0
The optional Plug & Play THNIN5 T-Harness is sold separately.
All T-Harness wires NOT listed in the diagram are NOT required for the installation. Loose wires such as Siren Output and Hood Input
may need to be pulled from the tapped section of the T-harness. Refer to the "wiring diagram with T-Harness" for more information on
connections and installation instructions.
All connectors are displayed from the wire side (unless specified otherwise).
It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each wiring diagram.
Refer to the "Vehicle connections" following the installation diagram.
General notes: This section highlights important information for this specific firmware.
[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin or if NOT supported
in data.
[2] The siren is ONLY required when enabling the security features during module flashing.
[3] The vehicle MUST be disarmed for the power tailgate to operate.
[4] For security-only installations, refer to the "Locating components in the vehicle" section for optional starter disable connection.

5933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Hood Pin
Siren
(+) Siren Output: Brown/Red
THNIN5
(Optional T-Harness)
(-) Hood Pin Input: Gray
Wiring diagram with T-Harness (THNIN5)
BCM
E29
M19
M18
B16
BCM Connector M18
(grey conn. at BCM)
BCM Connector M19
(black conn. at BCM) BCM Connector B16 (green conn. at BCM)
BCM Connector E29
(black conn. at BCM)
M10
BCM Connector M10
(brown conn. at BCM)
(+) Starter Disable Output: Violet/Black
Refer to the
Optional starter
disable
connection
section for relay
and connection
details.
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
5
30
20
20
15
15
8-pin White connector
22-pin White connector
12-pin Black connector
Do NOT cut the
Lt. Green/Black
loop.

6933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
(-) Hazards Output: White: 5 & 11
(-) Ground: Black: 10
(+) 12V Input: Red: 6 & 12
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21
20 19 18 17 16 15 14 13 12
11 10
98 7 6543 2 1
BCM Connector M18
(grey conn. at BCM)
(-) Accessory 2:
Lavender/Pink, pin 25
(-) Ignition:
Lavender/L.t Green, pin 27
(-) Accessory 1:
Lavender/Blue, pin 28
(-) Hazards:
Lavender/Yellow, pin 11
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
(-) PTS:
Red,
pin 9
(-) Arm:
Brown,
pin 12
(-) Disarm:
Pink, pin 13
(+) 12V:
Blue, pin 1
BCM Connector M19
(black conn. at BCM)
White conn.
(back of dash
fuse box)
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21
20 19 18 17 16 15 14
13 12
11 10 8
9
7 6 5 4 3 21
1
(-) Starter:
Blue, pin 19
18 1524 20 16 1322 1921 17 1423
63
12 841
10 7
9
5
2
11
BCM Connector E29
(black conn. at BCM)
HS CAN Low: Pink
or Lavender/Pink,pin 40
HS CAN High: Blue
or Lavender/Blue, pin 20
123456789
10111213141516
17
1819
20
212223242526272829303132
33
343536373839
40
BCM Connector B16 (green conn. at BCM)
Siren
Hood Pin
(+) Siren Output: Brown/Red: 11
(-) Ignition Output: Brown/White: 6
(-) Accessory Output: Brown/Black: 5
(-) Disarm Output: Dk. Blue/Black: 9
(-) Push-to-Start Output: Lt.Green/Black: 1
(-) Accessory 2 Output: Blue/White: 2
(-) Starter Output: Lt. Blue/Black: 10
(-) Hood Input: Gray: 21
(-) Lock:
Gray, pin 10
(-) Arm Output: Orange/Black: 7
(-) Lock Output: Yellow/Black: 8
BCM
E29
M19
M18
B16
M10
(+) Starter Disable Output: Violet/Black: 8
Refer to the
Optional starter
disable
connection
section for relay
and connection
details.
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
5
30
20
20
15
15

7933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Locating components in the vehicle
Cut
(-) Starter: Green
or Blue, pin 19
18 1524 20 16 1322 1921 17 1423
63
12 841
10 7
9
5
2
11
BCM Connector E29
(Black conn. at BCM)
Optional starter disable connection
When using an external relay, use a 1N4002 diode or larger.
22 812
4 2442
(+) Starter Disable Output: Violet/Black: 8
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
86 85
30
87a
87
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21
20 19 18 17 16 15 14 13 12 11 10 9876543 2 1
BCM Connector M18
(Grey conn. at BCM)
(-) Ignition: Yellow or
Lavender/L.t Green, pin 27
1A Diode (1N4002+)
Important: When flashing your module for Security Only, the Ground When Armed (GWA)
function is pre-configured. When flashing your module for Remote Start & Security, you must
manually assign the designated output to Anti Grind (AG) Starter Kill.
(Applicable to CORE 194+.)

8933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2019 Nissan Qashqai (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data harness, 8-pin white connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H1/1 Tan (Data) HS CAN Low BCM under driver dash, green 40 pin plug, pin 40
BCM under driver dash, green 40 pin plug, pin 40
Not Applicable
Data
Data
Lavender/Pink
Lavender/Pink
Mandatory
H1/2 Tan HS CAN Low 1 BCM under driver dash, green 40 pin plug, pin 40 Data Lavender/Pink Mandatory
H1/3 Tan/Black HS CAN High 1 BCM under driver dash, green 40 pin plug, pin 20 Data Lavender/Blue Mandatory
H1/4 Tan/Black (Data) HS CAN High BCM under driver dash, green 40 pin plug, pin 20
BCM under driver dash, green 40 pin plug, pin 20
Not Applicable
Data
Data
Lavender/Blue
Lavender/Blue
Mandatory
H1/5 Orange/Brown No Connection No Connection
H1/6 Orange/Brown HS CAN Low 2 No Connection
H1/7 Orange/Green HS CAN High 2 No Connection
H1/8 Orange/Green No Connection No Connection
H1/9 Lt. Green No Connection No Connection
H1/10 Lt. Green No Connection No Connection
H1/11 Violet/Brown No Connection No Connection
H1/12 Violet/Brown No Connection No Connection
H1/13 Orange/Black (-) Arm Output BCM under driver dash, black 40 pin plug, pin 12 - Brown (key lock) Mandatory
H1/14 Orange/Black No Connection No Connection
H1/15 Yellow/Black No Connection No Connection
H1/16 Yellow/Black (-) Lock Output BCM under driver dash, gray 40 pin plug, pin 10 - Gray Mandatory
Analog input/output harness, 22-pin white connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/1 Lt. Green/Black (-) PTS Output BCM under driver dash, black 40 pin plug, pin 9 - Red Remote Start
Only
H2/2 Lt. Green/Black (-) Factory Alarm Arm (FAA) Output No Connection
H2/3 Blue/White (-) Ground When Running (Status) Output No Connection
H2/4 Blue/White (-) Accessory 2 Output BCM under driver dash, gray 40 pin plug, pin 25 - Lavender/Pink Remote Start
Only
H2/5 Dk. Green/Black (-) Lock Output No Connection
H2/6 Dk. Green/Black (-) Lock Output No Connection
H2/7 Red/White (-) Trunk Output No Connection
H2/8 Red/White (-) Trunk Release Output No Connection
H2/9 Brown/Black (-) Accessory Output BCM under driver dash, gray 40 pin plug, pin 28 - Lavender/Blue Remote Start
Only
H2/10 Brown/Black (-) Horn Output No Connection

9933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/11 Brown/White N/A No Connection
H2/12 Brown/White (-) Ignition Output BCM under driver dash, gray 40 pin plug, pin 27 - Lavender/Lt. Green Remote Start
Only
H2/13 White (+) AUX 1 Output No Connection
H2/14 White (+) AUX 1 Output No Connection
H2/15 Violet/Black (+) AUX 4 Output No Connection
H2/16 Violet/Black (+) Starter Disable Output [4] Starter:
BCM under driver dash, black 24 pin plug, pin 19
Ignition:
BCM under driver dash, gray 40 pin plug, pin 27
Must use a relay.
Must use a 1N4002 diode or larger.
-
-
Blue
Lavender/Lt. Green
Security Only
H2/17 Dk. Blue/Black (-) Disarm Output BCM under driver dash, black 40 pin plug, pin 13 Doubl
e -
Pink (key unlock) Mandatory
H2/18 Dk. Blue/Black (-) Unlock Output No Connection
H2/19 Lt. Blue/Black (-) Factory Alarm Disarm (FAD) Output No Connection
H2/20 Lt. Blue/Black (-) Starter Output BCM under driver dash, black 24 pin plug, pin 19 - Blue Remote Start
Only
H2/21 Brown/Red (+) Siren Output [2] Security Only
H2/22 Brown/Red (+) Siren Output Mandatory
H2/23 Pink (+) Ignition Sense Input No Connection
H2/24 Pink (+) Ignition Sense Input No Connection
H2/25 Violet (+) Door Trigger Input No Connection
H2/26 Violet (+) Door Input No Connection
H2/27 Brown (+) Brake Input No Connection
H2/28 Brown (+) Brake Input No Connection
H2/29 White/Blue (-) Activation Input No Connection
H2/30 White/Blue (-) Activation Input No Connection
H2/31 Red/Blue (-) Trigger Input No Connection
H2/32 Red/Blue No Connection No Connection
H2/33 Black/White (-) E-Brake Input No Connection
H2/34 Black/White (-) E-Brake Input (manual transmission) No Connection
H2/35 Orange/Black (+) Valet Switch Input No Connection
H2/36 Orange/Black (+) Instant Alarm Input No Connection
H2/37 Blue (-) Trunk Trigger Input No Connection
H2/38 Blue (-) Trunk Input No Connection
H2/39 Green (-) Door Input No Connection
H2/40 Green (-) Door Trigger Input No Connection
H2/41 Gray (-) Hood Switch Input [1]
H2/42 Gray (-) Hood Input Mandatory
H2/43 Violet/White (AC) Tach Input No Connection

10 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/44 Violet/White (AC) Tach Input No Connection
Main harness, 12-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H3/1 Blue/White Relay N.C. No Connection No Connection
H3/2 Blue/White Relay 1 N.C. – No Connection No Connection
H3/3 Blue/Red Relay 1 N.O. – No Connection No Connection
H3/4 Blue/Red Relay N.O. No Connection No Connection
H3/5 Blue Relay COM No Connection No Connection
H3/6 Blue Relay 1 COM – No Connection No Connection
H3/7 White/Brown Relay 3 N.C. – No Connection No Connection
H3/8 White/Brown Relay N.C. No Connection No Connection
H3/9 White Relay COM. (-) Hazards Output BCM under driver dash, gray 40 pin plug, pin 11 - Lavender/Yellow Mandatory
H3/10 White Relay 3 COM – No Connection No Connection
H3/11 Red (+) 12 Volt (Battery) Dash Fuse Box, rear, white 1 pin plug, pin 1 + Blue (30A) Mandatory
H3/12 Red (+) 12 Volt Input Dash Fuse Box, rear, white 1 pin plug, pin 1
Dash Fuse Box, rear, white 1 pin plug, pin 1
Not Applicable
+
+
Blue (30A)
Blue (30A)
Mandatory
H3/13 Lt. Green/Red Relay N.O. No Connection No Connection
H3/14 Lt. Green/Red Relay 2 N.O. – No Connection No Connection
H3/15 Lt. Green Relay 2 COM – No Connection No Connection
H3/16 Lt. Green Relay COM No Connection No Connection
H3/17 Lt. Green/White Relay N.C. No Connection No Connection
H3/18 Lt. Green/White Relay 2 N.C. – No Connection No Connection
H3/19 Black (-) Ground (chassis ground) Mandatory
H3/20 Black (-) Ground Not Applicable (chassis ground)
(chassis ground)
Mandatory
H3/21 White Relay COM. (-) Hazards Output BCM under driver dash, gray 40 pin plug, pin 11 - Lavender/Yellow Mandatory
H3/22 White Relay 3 COM – No Connection No Connection
H3/23 Red (+) 12 Volt (Battery) Dash Fuse Box, rear, white 1 pin plug, pin 1 + Blue (30A) Mandatory
H3/24 Red (+) 12 Volt Input Dash Fuse Box, rear, white 1 pin plug, pin 1
Dash Fuse Box, rear, white 1 pin plug, pin 1
Not Applicable
+
+
Blue (30A)
Blue (30A)
Mandatory
Relay harness, 10-pin white connector (H4)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/1 N/A No Connection No Connection
H4/2 N/A No Connection No Connection

11 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/3 Red/Black (+) 12 Volt Input (Accessory/Starter) No Connection
H4/4 Red/Black (+) 12 Volt Input No Connection
H4/5 Pink/Black Flex Relay (pin 87a) No Connection
H4/6 Pink/Black Relay N.C. – No Connection No Connection
H4/7 Pink/White Relay COM – Flex No Connection
H4/8 Pink/White (+) Flex Relay Output No Connection
H4/9 Red (+) 12 Volt Input No Connection
H4/10 Red (+) 12 Volt Input (Ignition) No Connection
H4/11 Green Relay COM – (+) Starter No Connection
H4/12 Green Starter Input (conn. side) No Connection
H4/13 Violet (+) Starter Output (vehicle side) No Connection
H4/14 Violet Relay N.C. – (+) Starter No Connection
H4/15 Orange Relay COM – (+) Accessory No Connection
H4/16 Orange (+) Accessory Output No Connection
H4/17 Red/White (+) 12 Volt Input No Connection
H4/18 Red/White (+) 12 Volt Input (Flex) No Connection
H4/19 Pink Relay COM – (+) Ignition No Connection
H4/20 Pink (+) Ignition Input/Output No Connection
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A RF Loop
H5/2 N/A RF Loop
H5/3 N/A RF Loop
H5/4 N/A RF Loop
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin Color Description
H6/1 Blue (Data) TX
H6/2 Blue (Data) TX
H6/3 Black (-) Ground
H6/4 Black (-) Ground
H6/5 Green (Data) RX
H6/6 Green (Data) RX
H6/7 Red (+) 12 Volt
H6/8 Red (+) 12 Volt

12 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Temperature sensor harness, 2-pin black connector (H7)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor Mandatory
H7/3 Black Temperature Sensor Mandatory
H7/4 Black Temperature Sensor

13 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Configuring the system
DS3+
Flashing the module using your computer:
1. Disconnect the main module from any (+) 12V power source, then connect it to your computer using the XKLoader2.
2. Go to www.directechs.com using Internet Explorer; the configuration wizard will be displayed automatically. Follow the
instructions in the pop-up window that will be displayed when the module is detected.
DS4+
Once the module is installed in the vehicle, follow the wiring diagram(s) related to your installation. Launch the DirectLink
application on your mobile device, and select Configure DS4/DS4+. Follow the on-screen instructions to configure the system.
Note: Your system can also be configured using XKLoader2 on www.directechs.com.
8556T Temperature Sensor
The 8556T Temperature Sensor is optional, but included with your DS3+/DS4+ module.
When used, the Temperature Sensor must be plugged into the 2-pin black connector of your module.
Note: When the system is configured as a remote starter, the temperature is reported by the 8556T
Temperature Sensor. When security features are enabled, it is reported by the 8504D Combo Sensor.
8504D Combo Sensor
The 8504D Combo Sensor is optional, but included with the purchase of a DS4SU security package.
The Combo Sensor is preset for the majority of applications; however, it can be adjusted using the DirectLink
application, as well as a compatible LED or LCD remote. Please refer to the instructions included with the DS4SU
for more information on how to make adjustments.
Note: When the system is configured as a remote starter, the temperature is reported by the 8556T Temperature
Sensor. When security features are enabled, it is reported by the 8504D Combo Sensor.
IMPORTANT: The Combo Sensor must be paired to the device before it can be used.
Pairing
To enter pairing:
1Open the driver side door.
2
Turn the vehicle ignition to the ON position.
OR
Press the PTS button to turn the ignition ON.
* The number of times the PTS button is pressed depends on the vehicle.
START
Key OUT
ON
OFF
START
Key IN
ON
OFF
START
Key IN
ON
OFF
START
Key IN
ON
OFF
OR
3
Within 10 seconds, press and release once, and then press and hold
the programming button on the Control Center (antenna) or the
LED/Valet Pod (standalone switch) until the LED starts flashing then
release the button.
* Your antenna may differ from the model shown in the illustration.
Press &
Release
& && OR
*
*
Note: Connected devices become registered within 4 to 6 seconds.

14 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
RF Systems
An RF System consists of one or multiple remotes, a Control Center (antenna), and an antenna cable – various combinations exist.
An RF System allows the vehicle owner to control the system with enhanced range. Two-way models are available. Please follow
the instructions included with the kit for appropriate installation and programming information.
When used in conjunction with SmartStart
To enable D2D communication between the DS3+/DS4+ and the SmartStart one of the following actions must be performed
before providing power to the SmartStart unit:
• SmartStart with Loops – The brown loop must be cut.
• SmartStart with Pigtails – The gray wire must be connected to a ground source.
Loops Pigtails
DO NOT connect the SmartStart 2-pin power harness when using the DS3+/DS4+. Power and ground will be provided by
the D2D connector on the module. Refer to the SmartStart documentation for further details.
D2D port configuration
The system will automatically configure the D2D ports based on your selections in the module programming. The white D2D port is
reserved for SmartStart. To ensure proper functionality with SmartStart, it is important that it is selected in the system programming
of the DirectLink application or via the online web tool.
Note: Both black D2D ports are reserved for the Control Center (antenna) and 8504D Combo Sensor.

15 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Manual Transmission
IMPORTANT! Directed does not approve nor support installations of manual transmission, remote starts on any convertible vehicle
or a vehicle with a removable top, including but not limited to Jeep Wrangler, Honda S2000, Mazda Miata etc...
This system supports manual transmission installations.
Refer to “Directwire” section at www.directechs.com for further information on vehicle-specific wiring connections.
When flashing the module for Manual Transmission on the Directechs website:
1. In the Remote Start Features section, select the desired configurations for Manual Transmission Initialization & Manual
Transmission Completion.
Manual Transmission Initialization
Sets how the manual transmission sequence is initialized
Remote (Default)
2x Parking Brake
1x Parking Brake
With foot on brake, set e-brake, remove foot brake, press ANY button on Directed
remote. Ready mode is activated. Parking lights will flash 5 times confirming.
With foot on brake, setting the parking brake ON, OFF, ON within 10 seconds
then removing foot brake will initialize the manual transmission ready mode.
Parking lights will flash 5 times confirming.
Feature visible to Installer
With foot on brake, setting the parking brake ON then removing foot brake will
initialize the manual transmission ready mode. Parking lights will flash 5 times
confirming.
Manual Transmission Completion
Sets how the manual transmission sequence is ended.
Note 1: For PTS vehicle specific instructions, please see the bottom of the “Vehicle Specific Install
Guide” for manual transmission sequence procedures.
Note 2: The trunk input trigger is considered a “door” for manual ready mode. If trunk or any other
door is opened, manual transmission ready mode will be canceled.
Door closed &
Remote (Default)
Door closed with
passive locking
Door closed
To complete the manual ready mode sequence and shut down the remote start,
turn off the ignition (engine stays running), exit the vehicle with your keys, shut all
doors and press lock on the Directed remote.
To complete the manual ready mode sequence and shut down the remote start,
turn off the ignition (engine stays running), exit the vehicle with your keys, 8
seconds after the last door is closed, the remote starter will shut down, the door
will automatically lock and the system will arm at the same time.
To complete the manual ready mode sequence and shut down the remote start,
turn off the ignition (engine stays running), exit the vehicle with your keys, 8
seconds after the last door is closed, the remote starter will shut down. Doors will
stay unlocked.
Feature visible to Installer
2. In addition, if no Clutch Output is pre-configured in the firmware, an output can be configured when flashing the module
under the Programmable Input/Output section. Use any available positive (+) or negative (-) outputs depending on the
polarity of the clutch switch listed on Directwire, set it to Starter.
3. Note: A Relay may be required depending on your vehicle.
See Tech Tips 10000 - Clutch Bypass for Remote Start - https://directechs.blob.core.windows.net/techtips/10000.pdf
4. Additional connections may be required if these functions are not supported by the firmware.
Connection Description
(-) E-Brake Status Input
(Black/White, pin 17)
Must be connected to a working emergency brake in the vehicle. Although most vehicles have simple
(-) trigger emergency brake circuits note some vehicles do not and may require unique integration
methodologies.
(-) Door Trigger Input
(Green, pin 20) OR
(+) Door Input (Violet, pin
13)
Must be connected to a working door trigger in the vehicle, which monitors all doors. The unit must monitor
the door pins to allow the Ready Mode process to be enabled.
Note: Some vehicles may require unique integration methodologies for this circuit. For more information, refer
to www.directechs.com.
(AC) Tachometer Input
(Violet/White, pin 22)
Must be connected to a working tachometer signal in the vehicle (fuel injector, ignition coil, true tach, etc.)
and learned successfully to the DS4+.
See Tech Tips 10001 - https://directechs.blob.core.windows.net/techtips/10001.pdf

16 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Module programming
Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes.
(For security-only programming, see next section.)
1Please ensure that the vehicle is in a safe location, and cannot move forward during
programming. For vehicles equipped with a manual transmission, make sure the
gearshift lever is in the neutral position.
2
DS3+: Connect the 12-pin main power harness to the DS3+ module FIRST.
Wait until the LED turns ON solid red before proceeding to the next step.
DS4+: Connect the 12-pin main power harness to the DS4+ module FIRST.
The LED will turn ON solid Blue for 1 second to confirm Bluetooth communication.
Wait until the LED turns ON solid red before proceeding to the next step.
3
Connect the remaining harnesses to the module.
Note: To skip the transponder programming and use convenience features only, press
the programming button 5 times. Wait until the LED turns ON solid orange, then
proceed with step 4.
4
Press the Push-to-Start button once to turn ON ignition. The LED turns on solid green for
3 seconds then shuts OFF.
Note: If the bypass was skipped, the LED flashes orange, then turns ON solid orange
for 3 seconds before turning OFF.
5Press the PTS button once more to turn the ignition OFF, once the module is successfully
programmed.
6Pair remotes (if applicable). For information on how to pair a specific remote, please
refer to its corresponding owner documentation, which can be found inside the product
packaging of the complete system or on www.directechs.com.*
7
DATA Tach: Firmware using DATA Tach, the tachometer is preprogrammed for the
vehicle and no further action is required. For instructions on how to adjust tach or use
Virtual tach, refer to "Initialize Virtual Tach" (not needed with hardwired or data tach
applications).
Hardwire Tach: Firmware using the Violet/White Hardwire Tach input will require
programming. For instructions on how to program or adjust tach or use Virtual tach,
refer to "Initialize Virtual Tach" (not needed with hardwired or data tach applications).
* Your aftermarket remote may differ from the model shown in the illustrations.
You have successfully completed the module programming sequence.

17 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Module programming for security-only installations
Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
To connect the module:
1
Please ensure that the vehicle is in a safe location and cannot move forward during
programming. For vehicles equipped with a manual transmission, make sure the gearshift
lever is in the neutral position.
2
DS3+: Connect the 12-pin main power harness to the DS3+ module FIRST.
Wait until the LED turns ON solid orange before proceeding to the next step.
Solid
Must connect
12-pin FIRST
4 2442
22 810 12
DS3/DS3+
DS4+: Connect the 12-pin main power harness to the DS4+ module FIRST.
The LED will turn ON solid blue for 1 second to confirm Bluetooth communication.
Wait until the LED turns ON solid orange before proceeding to the next step.
SolidSolid
x1 Sec
Must connect
12-pin FIRST
4 2442
22 810 12
DS4/DS4+
3Connect the remaining harnesses to the module. Connect
remaining
harnesses
4Press once on the Push-to-Start (PTS) button to turn the ignition ON, and wait until the LED
turns OFF. &Off
5Press once more on the PTS button to turn the ignition OFF.
6
Pair remotes (if applicable). For information on how to pair a specific remote, please
refer to its corresponding owner documentation, which can be found inside the product
packaging of the complete system or on www.directechs.com.* Pair
remotes*
* Your aftermarket remote may differ from the model shown in the illustrations.
You have successfully completed the module programming sequence.

18 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
LED diagnostics and troubleshooting
This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation.
Module Programming
LED Description Troubleshooting
Off Module has no power. Make sure the D2D harness is connected and that 12 Volt is present between the red and black
wires. If 12 Volt is present, the module may be defective.
Solid blue
Confirmation of Bluetooth communication.
(Applicable to DS4/DS4+ ONLY.) Normal operation.
Solid red
Waiting to begin the programming
sequence. Ensure the correct programming procedure is being followed.
Flashes green &
red
Initialization failed. Reset the module and complete the programming again. If the issue persists, please contact
Technical Support.
Solid orange Transponder functions were skipped. (If compatible) when RXT mode is not desired or convenience features are needed, please reset
the and reprogram the module.
Flashes green
All required CAN networks has been
detected. Normal operation.
Flashes orange 1 of 2 CAN networks has been detected. Normal operation.
Flashes orange
slowly
Key2GO initiated. Please follow the steps indicated in “Module programming” to complete the Key2GO
programming.
Solid green x 3
secs
Module was successfully programmed
with all functions. Normal operation.
Solid orange x 3
secs
Module was successfully programmed
without transponder functions. Normal operation.
Analog Error Codes
LED Description Troubleshooting
Flashes red, green
& orange
DEI feature error. A feature config file mismatch was detected. Please contact Technical Support.
Module Programming - Error codes
LED Description Troubleshooting
Flashes red x 1 CAN2 not detected.
Check the CAN2 Orange/Green and Orange/Brown wire connections. Wake up the data bus
by turning the ignition on and try again. If your installation does not require this connection, skip
this step by pressing the programming button 5 times.
Flashes red x 1 J1850 not detected. Check the J1850 wire connection. Wake up the data bus by turning the ignition on and try
again.
Flashes red x 2 CAN1 not detected.
Check the CAN1 Tan and Tan/Black wire connections. Wake up the data bus by turning the
ignition on and try again. If your installation does not require this connection, skip this step by
pressing the programming button 5 times.
Flashes red x 3 Bypass data not detected. Check the bypass line connection. If more than one wire is used, make sure they are not inverted.
Ensure the vehicle still operates correctly using the factory key.
Flashes red x 4 Bypass processing error. The bypass calculation failed. Reset the module and try again. If the condition persists, please
contact Technical Support.
Flashes red x 5 ISO 1 not detected. The Yellow/Black wire did not detect the expected signal. Refer to “Installation (wiring diagrams
& vehicle wiring reference charts)” to check the connections.
Flashes red x 6 ISO 2 not detected. The Orange/Black wire did not detect the expected signal. Refer to “Installation (wiring diagrams
& vehicle wiring reference charts)” to check the connections.
Flashes red x 7 MUX not detected. The Violet/Green or Violet/Brown wire did not detect the expected voltage value. Refer to
“Installation (wiring diagrams & vehicle wiring reference charts)” to check the connections.

19 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
External Module Synchronization
LED Description Troubleshooting
(Flashes red, red,
then orange) x 10
OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited.
Active Ground When Running (Status)
LED Description Troubleshooting
Flashes green
Ground When Running (Status) command
received. The module has initialized the remote start sequence.
Flashes red &
orange
Ignition ON command received. The module has received the Ignition ON command and is processing the remote start sequence.
Flashes green
quickly
Start ON command received. The module has received the Start ON command and is processing the remote start sequence.
Flashes red x 10 PTS shutdown error. The PTS output from the module was not activated due to safety protection.
Flashes red x 21 CAN bus incorrectly detected. Verify the CAN1 and CAN2 connections. Refer to “Installation (wiring diagrams & vehicle wiring
reference charts)” to check the connections.
Commands
LED Description Troubleshooting
Flashes orange x 1 LOCK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 2 UNLOCK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 3 TRUNK command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 4 AUX1 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 5 AUX2 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Flashes orange x 6 AUX3 command received. If the bypass module fails to flash, it did not receive the signal. Commands can come from RF or
D2D.
Shutdown Codes
LED Description Troubleshooting
Flashes green x 1 Takeover successful. Normal operation.
Flashes red x 1 Runsafe was not disabled. No UNLOCK command was received prior to opening the door, or the 45 second timer expired
in takeover mode.
Flashes red x 2 Brake was not detected. The brakes were not detected, which prevents the system from shutting down the vehicle.
Flashes red x 3 Smart key was not detected. The smart key was not detected, which prevents the system from shutting down the vehicle.
Flashes red x 4 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down.

20 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Soft reset
A module reset will only erase the steps perfomed in “Module Programming”. The firmware and settings flashed to the module will
not be affected.
1
If required for your installation, connect all the harnesses to the module, EXCEPT the 12-pin
main power harness. Press and hold the programming button, then connect the 12-pin
harness to the module.
Connect all but the
12-pin harness
2
DS3+: Wait 3 seconds until the LED turns ON solid orange then release the programming
button. The LED turns ON solid red. &&
Solid Solid
Release
DS4+: Wait 3 seconds until the LED turns ON solid orange then release the
programming button. The LED turns ON blue for 1 second then solid red. & &&
Solid Solid
Release Solid
x1 Sec
Hard reset
Warning Against Executing a Hard Reset!
A hard reset will revert the flashed firmware back to its default factory settings. Depending on the installation, some settings
may need to be reconfigured. Connect your module to a computer and use the web configuration tool to edit its programmable
features.
1
If required for your installation, connect all the harnesses to the module, EXCEPT the 12-pin
main power harness. Press and hold the programming button, then connect the 12-pin
harness to the module.
Connect all but the
12-pin harness
2After 3 seconds the LED turns ON solid orange. Keep holding the programming button until
the LED flashes red, then orange slowly. Solid Flashes
&&
Hold
3
DS3+: Release the programming button. The LED turns solid red. &Solid
Release
DS4+: Release the programming button. The LED turns ON blue for 1 second then solid
red. & & Solid
Release Solid
x1 Sec
