Directed DS3+ User manual

DS3+ / DS4+ 933.TL10
v2.29.195.3
2017 Toyota Camry (H Key)
THTON4 Compatible
(Sold Separately)

Introduction 3
Vehicle function compatibilities 4
Pre-installation and application warnings 5
Key type 5
Installation 6
Wiring diagram with T-Harness (THTON4) 6
Wiring diagram with T-Harness (THTON9) 7
Wiring diagram 8
Locating components in the vehicle 9
Vehicle connections 10
Module programming 13
(For security-only programming, see next section.) 13
Module programming for security-only installations 14
Pairing remotes 15
Connecting the module 15
8556T Temperature Sensor 15
8504D Combo Sensor 15
RF Systems 15
When used in conjunction with SmartStart 16
D2D port configuration 16
Manual transmission 17
LED diagnostics and troubleshooting 18
Soft reset 20
Hard reset 20
Tach learning procedure (not needed with Virtual Tach) 21
Initializing Virtual Tach (not needed with hardwired or data tach applications) 21
Limited lifetime consumer warranty 22
Quick reference guide 23
Contents

3933.TL10 2.29.195.3 2017 Toyota Camry (H Key)
©2022 VOXX•DEI LLC. All rights reserved.
Introduction
This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a
digital configuration require the module to be flashed with vehicle specific firmware. Refer to our website (www.directechs.com) and click on
the DIRECTLINK text in the header for additional information.
DS3/DS3+ and DS4/DS4+ modules provide an all-in-one solution for most modern vehicles, and include remote start, keyless entry, security,
and immobilizer bypass capabilities. T-harnesses may also be used in many applications for easy installation.
The following methods are available to configure modules:
• Web: www.directechs.com (DS3/DS3+ and DS4/DS4+)
• Desktop Application: Directlink DT (DS3/DS3+ and DS4/DS4+)
• Mobile Device: Directlink App (DS4/DS4+ only)
When Flashing via Directlink DT (Desktop app) or via the Web, an XKloader2 will be required.
To configure via Web or DirectLink DT (mobile app):
1. Disconnect the main module from any (+) 12V power source.
2. Connect the module to your computer using the XKLoader2.
3. Follow the steps in the pop-up window that will be displayed when the module is detected.
Notes:
•Flashing via web is only possible using Internet Explorer on Windows 8, 8.1, and 10.
•This method is not compatible with any other browser (Edge, Chrome, Firefox, etc.)
•When using Windows 11 or newer, Directlink DT is mandatory.
The DS4/DS4+ module is designed to be configured using the DirectLink application through mobile devices.
To download the DirectLink mobile application, visit the Google Play or Apple store. They can also be
configured via Web and DirectLink DT. The DS4/DS4+ features are built in Bluetooth® 4.0, allowing you to
configure and control your system. The DS3/DS3+ module is not equipped with Bluetooth®, therefore is not
compatible with the DirectLink app for mobile devices.
To configure via DirectLink DT (mobile app):
1. Follow and complete the wiring diagram(s) related to your installation through the app.
2. When installation is complete, select Configure DS4/DS4+.
3. Follow the on-screen instructions.
FLASH REQUIRED!
FLASH REQUIRED!
4 White

4933.TL10 2.29.195.3 2017 Toyota Camry (H Key)
©2022 VOXX•DEI LLC. All rights reserved.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart.
Auto Headlamp Shutoff
Parking Lights Control
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
Trunk / Hatch Release
DS4+/DS3+/VSM3 Only
Control of aftermarket alarm with OEM remote
Fuel level/EV battery level
* Odometer
Immobilizer Bypass-Data No Key Req'd
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Accessory Activation
Ignition Activation
Remote Start Takeover
SmartStart
Start (Crank) Activation
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Brake Status (foot brake)
Door Locks Status
E-Brake Status
Ignition Status

5933.TL10 2.29.195.3 2017 Toyota Camry (H Key)
©2022 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible THTON4 or THTON9 Keys required for programming 1Keys required for operation 0
It is important to make sure you DO NOT connect the keysense wire in the installation for each of these vehicles or you will
encounter issues when attempting to start the vehicle.
The optional Plug & Play THTON4 or THTON9 T-Harness is sold separately.
Important! All T-Harness wires NOT listed in the diagram are NOT required for the installation. Loose wires such as Siren
Output and Hood Input may need to be pulled from the tapped section of the T-Harness. Refer to the "Wiring diagram with
T-Harness" for more information on connections and installation instructions.
The T-harness can be used for multiple vehicle installation and therefore it is important to connect ONLY the specific wires
associated with your vehicle. Refer to the "Wiring diagram with T-Harness" and follow the diagrams connections.
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each
wiring diagram.
Refer to the "Vehicle connections" following the installation diagram.
General notes: This section highlights important information for this specific firmware.
[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.
[2] The siren is ONLY required when enabling the security features during module flashing.
[3] The Green wire is ONLY required for starter disable and antigrind applications.
[4] Autolight Interrupt connection required only if the vehicle is equipped with automatic headlights.
[5] Parking lights, trunk release, lock and unlock connections required when not available through Data.
[6] Depending on the vehicle's trim, the TPMS Ignition Interrupt connection may be required to obtain OEM remote functionality
during runtime. Please note the TPMS light may flash during runtime.
Key type
Some Toyota 2010+ models have different encryption types. Please look at your key blade and identify the markings.
G-stamped keys Standard Key H-stamped keys
H
For vehicles with H-stamped keys, see
the TL10 firmware.
For vehicles with G-stamped keys, see
the TL5 & TL7 firmware.
For vehicles with dot-stamped keys,
see the TL11 firmware.
Note: Some replacement keys
may not have any markings on
the key.

6933.TL10 2.29.195.3 2017 Toyota Camry (H Key)
©2022 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram with T-Harness (THTON4)
Body ECU
Connector
456
1617 18 131415
10
11
12
1
23
789
19
Autolight: Green, pin 20
20
Headlight Switch
Autolight Interrupt (veh. side): Lt. Green
Autolight Interrupt (conn. side): Lt. Green/White
Ignition Connector
RDA: Orange/Black
Body ECU Connector
(middle conn. left side of steering column)
4 56
161718
28 2930
131415
252627
101112
222324
123
789
192021
RDA: Blue, pin 16
THTON4
(optional T-Harness)
Diagnostic Connector OBDII
16
8
9
1
Cut
Refer to the "Vehicle wiring reference
chart" for more specific T-harness
compatibility.
Siren
Hood Pin
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
TPMS Ignition Interrupt (conn. side): Blue/White
(-) Parking Lights Output: Lt.Green/Black
TPMS Ignition Interrupt (veh. side): Blue
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
IMPORTANT:
Position the
fuses correctly!
Slide to open
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
5
30
20
20
15
12-pin Black Connector
10-pin White Connector
8-pin White Connector

7933.TL10 2.29.195.3 2017 Toyota Camry (H Key)
©2022 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram with T-Harness (THTON9)
Ignition Connector
THTON9
(optional T-Harness)
12-pin Black Connector
Cut the
Violet/White loop
labeled Tach.
NOT USED
TPMS Ignition Interrupt (veh. side): Blue
TPMS Ignition Interrupt (conn. side): Blue/White
Siren
Hood Pin (-) Hood Input: Gray
(+) Siren Output: Brown/Red
NOT USED
C
A
B
Diagnostic Connector OBDII
Cut the
Dk. Green/Black and
Dk. Blue/Black loops
labeled Lock/Unlock.
CONNECT the white
12-pin connector to
the 12-pin Blue
connector labeled B.
Cut the Lt.
Green/Black loop
labeled PKL if
available through
Data.
22-pin White Connector
8-pin White Connector
10-pin White Connector
Body ECU
(White middle conn. left side
of steering column)
Body ECU
Connector
Cut the
Orange/Green and
Orange/Brown loops
labeled CAN2.
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
IMPORTANT:
Position the
fuses correctly!
Slide to open
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
5
30
20
20
15
Cut the
Blue/White loop
labeled A/B if
vehicle is
equipped with
Autolights .

8933.TL10 2.29.195.3 2017 Toyota Camry (H Key)
©2022 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
Body ECU
Connector
456
1617
18
131415
10
11
12
1
23
789
19
Autolight: Green, pin 20
16
8
9
1
Diagnostic
Connector OBDII
HS CAN Low: White, pin 14
HS CAN High:
Blue, pin 6
SIL Data: Gray, pin 7
20
Headlight Switch
(-) Hood Input: Gray: 21
(+) Siren Output: Brown/Red: 11
Siren
Hood Pin
Autolight Interr. (veh. side): Lt. Green: 8
Autolight Interr. (conn. side): Lt. Green/White: 9
(+) Starter 2 Output: White: 5 & 11
(+) 12V Input: Red: 6 & 12
HS CAN Low 1: Tan: 1
HS CAN High 1: Tan/Black: 2
RDA: Orange/Black: 7
SIL Data: Yellow/Black: 8
Body ECU Connector
(middle conn. left side of steering column)
456
161718
282930
131415
252627
101112
222324
123
789
192021
RDA: Blue, pin 16
Cut
(+) Ignition Input/Output: Pink: 10
(+) 12V Input: Red: 5
(+) Accessory Output: Orange: 8
(+) 12V Input: Red/White: 9
(+) 12V Input: Red/Black: 2
(+) Ignition 2 Output: Pink/White: 4
(+) Starter Output (veh. side): Violet: 7
Starter Input (conn. side): Green: 6
67
1234
85
(+) Ignition 2:
Pink, pin 1
(+) Ignition 1:
Black, pin 6
(+) Accessory: White, pin 2
(+) Starter:
Blue, pin 7
(+) Starter 2
Lt. Green, pin 3
(+) 12V:
Green, pin 5
Ignition
Connector
(-) Ground: Black: 10
TPMS Ignition Interrupt (conn. side): Blue/White: 1
TPMS Ignition Interrupt (veh. side): Blue: 3
Cut
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
IMPORTANT:
Position the
fuses correctly!
Slide to open
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
5
30
20
20
15
(-) Parking Lights Output: Lt.Green/Black: 1

9933.TL10 2.29.195.3 2017 Toyota Camry (H Key)
©2022 VOXX•DEI LLC. All rights reserved.
Locating components in the vehicle

10 933.TL10 2.29.195.3 2017 Toyota Camry (H Key)
©2022 VOXX•DEI LLC. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2017 Toyota Camry (H Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data harness, 8-pin white connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H1/1 Tan (Data) HS CAN Low OBD-Data Link Connector, white 16 pin plug, pin 14 Data White Mandatory
H1/2 Tan/Black (Data) HS CAN High OBD-Data Link Connector, white 16 pin plug, pin 6 Data Blue Mandatory
H1/3 Orange/Brown (Data) HS CAN Low No Connection
H1/4 Orange/Green (Data) HS CAN High No Connection
H1/5 Lt. Green No Connection No Connection
H1/6 Violet/Brown No Connection No Connection
H1/7 Orange/Black (Data) RDA Body ECU on dash fuse box, white 30 pin plug, pin 16 Data Blue Mandatory
H1/8 Yellow/Black (Data) SIL Data OBD-Data Link Connector, white 16 pin plug, pin 7 Data Gray Remote Start
Only
Analog input/output harness, 22-pin white connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/1 Lt. Green/Black (-) Pk Light Output [5] Headlight Switch, black 20 pin plug, pin 18
Parking lights connection required when not available through Data
- Black Optional
H2/2 Blue/White No Connection No Connection
H2/3 Dk. Green/Black No Connection No Connection
H2/4 Red/White (-) Trunk Output No Connection
H2/5 Brown/Black No Connection No Connection
H2/6 Brown/White No Connection No Connection
H2/7 White (+) No Connection No Connection
H2/8 Violet/Black No Connection No Connection
H2/9 Dk. Blue/Black No Connection No Connection
H2/10 Lt. Blue/Black No Connection No Connection
H2/11 Brown/Red (+) Siren Output [2] Security Only
H2/12 Pink No Connection No Connection
H2/13 Violet No Connection No Connection
H2/14 Brown No Connection No Connection
H2/15 White/Blue No Connection No Connection
H2/16 Red/Blue No Connection No Connection
H2/17 Black/White No Connection No Connection
H2/18 Orange/Black No Connection No Connection
H2/19 Blue No Connection No Connection
H2/20 Green No Connection No Connection
H2/21 Gray (-) Hood Switch Input [1]
