Directed Ford9 User manual

Directed Digital System

FORD9

Firmware Specific Guide

This product is intended for installation by a professional

installer only! Attempts to install this product by a person

other than a trained professional may result in severe

damage to a vehicle’s electrical system and components.

Directed Digital System 2016-01

Contents

Warning! Safety first ....................................................................................................................... 3

Introduction .................................................................................................................................... 4

Vehicle application guide ........................................................................................................... 4

Key2GO........................................................................................................................................ 5

Wiring connections ......................................................................................................................... 6

Main power harness (H1), 12-pin thick gauge connector ............................................................... 6

Auxiliary output harness (H2), 16-pin black connector .................................................................. 6

Analog harness (H3), 18-pin white connector .............................................................................. 7

MC501 harness (H4), 8 thick-gauge wires (relay pack) ................................................................. 7

Installation...................................................................................................................................... 8

Wiring Diagram........................................................................................................................ 8

Vehicle wiring reference charts ......................................................................................................... 9

Locating Components in the Vehicle........................................................................................... 10

Connecting the module .................................................................................................................. 11

Important! .............................................................................................................................. 11

Manual or automatic transmission selection ................................................................................ 11

Optional sensors ..................................................................................................................... 12

RF kits.................................................................................................................................... 12

When used in conjunction with SmartStart.................................................................................. 12

Module programming.............................................................................................................. 13

Web programming (for Key2GO) ............................................................................................. 14

LED diagnostics and troubleshooting.......................................................................................... 15

Hard reset .............................................................................................................................. 17

Learning the Tach (not needed with Virtual Tach) ............................................................................... 18

Initializing Virtual Tach (not needed with hardwired or data tach applications) ..................................... 18

Limited lifetime consumer warranty .................................................................................................. 19

Quick Reference Guide – Viper, Clifford, Python, Avital & Automate.................................................... 20

Quick Reference Guide – Autostart.................................................................................................. 22

3Directed Digital System FORD9

Warning! Safety ﬁrst

The following safety warnings must be observed at all times:

• Due to the complexity of this system, installation of this product must only be performed by an authorized

Directed dealer.

• When properly installed, this system can start the vehicle via a command signal from the remote control.

Therefore, never operate the system in an area that does not have adequate ventilation.

The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:

• Never use a test light or logic probe when installing this unit. Always use a multimeter.

• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).

• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the

remote start system must be disabled using the installed toggle switch. It is the user’s sole responsibility to

properly handle and keep out of reach from children all remote controls to assure that the system does not

unintentionally remote start the vehicle.

• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT

TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR

PARTIALLY ENCLOSED VEHICLE STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.

Use of this product in a manner contrary to its intended mode of operation may result in property damage,

personal injury, or death. Except when performing the Safety Check outlined in this installation guide, (1) Never

remotely start the vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the

ignition. The user is responsible for having the neutral safety feature of the vehicle periodically checked, wherein

the vehicle must not remotely start while the car is in gear. This testing should be performed by an authorized

Directed dealer in accordance with the Safety Check outlined in this product installation guide. If the vehicle

starts in gear, cease remote start operation immediately and consult with the user to ﬁx the problem immediately.

OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS

INTENDED MODE OF OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS

MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT

AND REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE. DIRECTED WILL NOT BE HELD

RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.

Remote starters for manual transmission pose signiﬁcant risks if not properly installed and operated. When testing

to ensure the installation is working properly, only remote start the vehicle in neutral gear, on a ﬂat surface and

with a functional, fully engaged parking brake. Do not allow anyone to stand in front of or behind the vehicle.

This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission.

Installation in such vehicles may pose certain risk.

4Directed Digital System FORD9

Introduction

The FORD9 ﬁrmware for Directed Digital Systems is a complete solution for remote start,

security (if applicable), bypass interface, and convenience needs compatible with speciﬁc

Ford and Lincoln vehicles.

Warning! This module can only be programmed via the web tool, which can be found on

www.directechs.com or using the Directechs Mobile application for smartphones. Features

and functions will become accessible when you connect the module using the XKLoader.

Vehicle application guide

The table below lists the vehicles and features which are compatible with this product. Refer to the following

pages for more information on installation wiring, programming and troubleshooting for these vehicles.

Vehicles

2012

2011

2010

2009

PK-Immobilizer Bypass-Data No Key Req'd

DL-Arm Factory Security

DL-Disarm Factory Security

DL-Door Lock Control

DL-Door Unlock

DL-Trunk / Hatch Release

FOB-Control of aftermarket alarm with OEM remote

Key2GO

RS-3x LOCK START (Start control using OEM Remote)

RS-RAP Shut Down (Retained ACC Power)

RS-SmartStart

RS-Tach / RPM Output

SS-Entry Monitoring ALL Door Pins

SS-Entry Monitoring Driver Door Pin

SS-Entry Monitoring Hood Pin

SS-Entry Monitoring Trunk/Hatch Pin

ST-Brake Status (foot brake)

ST-E-Brake Status

ST-Ignition Status

Taurus (Smart Key) ••• •••••••••••••••••••

MKS (Smart Key) •••••••••••••••••••••••

MKT (Smart Key) ••• •••••••••••••••••••

Legend:

PK: Transponder & Immobilizer Override

DL: OE Door Lock & Alarm Controls

FOB: Sync CAN Interface w/ FOB Remote

RS: Remote Start & Engine Controls

SS: Integrated Security & Monitoring

ST: Function/Feature Status

Ford

Lincoln

5Directed Digital System FORD9

Key2GO

This feature is mandatory to control the immobilizer override in this ﬁrmware.

Key2GO has been designed and developed to bypass the advanced encryption layers found in modern

vehicles. It uses an array of servers to generate a duplicate of the original key, allowing the installation of a

remote starter without having to give up a key.

The advantage is that this feature allows you to use one original key and the server to conﬁgure the bypass in the

vehicle.

All Key2GO-compatible ﬁrmware are clearly indicated in the function list of each vehicle search result page

and will also appear on the ﬂash page. Any ﬁrst-time user must re-register to gain access to Key2GO, and

some additional information will be required to complete the registration process, such as your Directed account

number and store name. Key2GO requires an XKLoader.

Refer to "Web programming (for Key2GO)" on page 14 of this guide for instructions on how to program

features using Key2GO.

6Directed Digital System FORD9

Wiring connections

The wiring connections listed below are speciﬁc to this ﬁrwmare.

Main power harness (H1), 12-pin thick gauge connector

Conn./Pin Color Description

H1/1 White Relay 3 COM – Parking Light Output 1

H1/2 White/Brown Relay 3 N.O.– Parking Light Input 1

H1/3 Brown/Red Relay 2 N.O.– No Connection

H1/4 Yellow/Red Relay 2 COM – Door Pin (Interrupt)

H1/5 Orange/Red Relay 2 N.C. –Door Pin (Interrupt)

H1/6 Yellow Relay 1 COM – Immobilizer Data (Interrupt -Vehicle Side)

H1/7 White Relay 3 COM – Parking Light Output (30) 1

H1/8 White/Brown Relay 3 N.O.– Parking Light Input (87) 1

H1/9 Black (-) Ground

H1/10 Red (+) 12 Volt (Battery)

H1/11 Orange/Yellow Relay 1 N.C. – Immobilizer Data (Interrupt - Connector Side)

H1/12 Brown Relay 1 N.O.– No Connection 1

Auxiliary output harness (H2), 16-pin black connector

Conn./Pin Color Description

H2/1 Violet/Brown No Connection

H2/2 Yellow/Black Immobilizer Clock

H2/3 Orange/Black Immobilizer Data (Connector Side)

H2/4 Tan MS CAN Low

H2/5 Tan/Black MS CAN High

H2/6 Light Green No Connection

H2/7 Orange/Green HS CAN High

H2/8 Orange/Brown HS CAN Low

H2/9 Violet/Green No Connection

H2/10 Green/Black No Connection 2

H2/11 White/Violet No Connection 2

H2/12 White/Red Brake Activation Output

H2/13 Lt. Blue/Black (-) PUSH-TO-START 2

H2/14 Green/Red No Connection 2

H2/15 N/A No Connection

H2/16 Violet/Yellow No Connection

1. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed.

2. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed. Note that they are

low current and a relay may be necessary.

7Directed Digital System FORD9

Analog harness (H3), 18-pin white connector

Conn./Pin Color Description

H3/1 Lt. Blue/Red No Connection

H3/2 Black/White (-) Parking Brake Input (Manual Transmission) 2

H3/3 Gray (-) Hood Input 2

H3/4 N/A No Connection

H3/5 Gray/Black (+) Glow Plug Input 2

H3/6 Violet/White (AC) Tach Input 2

H3/7 Dark Blue No Connection 1

H3/8 Brown/Black No Connection 1

H3/9 Red/White (-) Trunk Release Output 1

H3/10 White/Green (-) Door Input 2

H3/11 Yellow/Green (+) Door Input 2

H3/12 Blue/Red No Connection

H3/13 Light Blue (-) Trunk Trigger Input 2

H3/14 Pink/Yellow (-) Activation (Start Trigger) Input

H3/15 Dark Green No Connection 1

H3/16 Brown/White (+) Brake Input 2

H3/17 Brown (+) Siren Output 1

H3/18 Blue/White No Connection 1

MC501 harness (H4), 8 thick-gauge wires (relay pack)

Conn./Pin Color Description

H4/1 Pink/White No Connection

H4/2 Red/White No Connection

H4/3 Pink No Connection

H4/4 Red No Connection

H4/5 Orange No Connection

H4/6 Red No Connection

H4/7 Green No Connection

H4/8 Violet No Connection

1. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed. Note that they are

low current and a relay may be necessary.

2. These connections are only required if the corresponding statuses are not supported by the ﬁrmware. See "Vehicle application guide"

on page 4 for a list of compatible features.

8Directed Digital System FORD9

Installation

Wiring Diagram

Refer to "Vehicle wiring reference charts" on page 9 for more information on vehicle-speciﬁc connections.

2314

138

12345

2314

1 2 3 4 5

813

8 9 1011

151617181920

16 Black 3 Wh

4 White 12 White4 Red

7 White 2 Wh

2 Bk6 Green

18 White

Manual/Auto. Transmission Type Prog.

Button

Manual/Auto. Transmission Type

Prog.

Button

10: Red: (+) 12V

9: Black: (-) Ground Ground

4: Yellow/Red: RAP Off

[2] (+) Siren Output: Brown: 17

(+) Brake Activation Output: White/Red: 12

(-) Push-to-Start Output: Lt. Blue/Black: 13

Wire jump template

2 & 8: White/Brown: (+) Parking Light Input

1 & 7: White: (+) Parking Light Output

Siren

MS CAN Low: Tan: 4

MS CAN High: Tan/Black: 5

5: Orange/Red: RAP Off

6: Yellow: Immo. Data (car side)

Immo. Clock: Yellow/Black: 2

Immo. Data (conn. side): Orange/Black: 3

11: Orange/Yellow: Immo. Data (conn. side)

MS CAN High:

Gray/Orange,

pin 12 MS CAN Low:

Violet/Orange,

pin 13

HS CAN High:

White/Blue,

pin 21

(SmartStart

ONLY)

HS CAN Low:

White,

pin 22

(SmartStart

ONLY)

Immo. Clock:

Yellow/Gray,

pin 16

(+) Parking Lights:

Violet/White,

pin 6

Immo. Data:

White/Blue,

pin 15

Green C2153B

at RFA module

White C2153D

at RFA module

HS CAN Low: Orange/Green: 7

HS CAN High: Orange/Brown: 8

(-) PTS:

Yellow/Orange,

pin 4

Brake: Violet/White

or Yellow/Green, pin 2

Brown C2153E

at RFA module

SJB

Gray C2280E

RFA

(Remote Function Actuator)

see component location in Vehicle wiring

reference charts

C2153B

C2153C C2153D C2153E

(-) Trunk Output: Red/White: 9

(-) Trunk

Brown/Yellow,

pin 15

(ONLY:

Ford Taurus and

Lincoln MKS)

The Remote Start

Safety Override

Switch MUST be in

the ON position.

Remote Start Safety

Override Switch

All adapters are displayed from the wire side (unless specified otherwise).

[1] The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin.

[2] The siren is optional.

Hood Pin

[1] (-) Hood Input: Gray: 3

Blue C2153C

at RFA module

(+) 12V:

Blue/Red,

pin 1 23

138

2 3 4 5

2314

1 2 3 4 5

1516

Cutoff

C2280C Blue Connector

Driver Door Pin:

Green/Violet,

pin 9

310

713

9 1011 12

16171819202122

9 1011 12

171819202122

1516

9 1011 12

171819202122

(-) Power Liftgate:

Gray/Yellow, pin 6

(ONLY: Lincoln MKT 2010-12)

Black, C2269

at Liftgate

switch (center

of driver dash)

86 85

87a

(-) Ground

(+) 12V

Fuse 10A

9Directed Digital System FORD9

Vehicle wiring reference charts

Refer to www.directechs.com for more information on any additional connections.

Wire Information Connector Information

Function Color Pin Polarity Location Color Pins

Ford Taurus 2010-12

MSCAN High Gray/Orange 12 (DATA) C2153D located at RFA behind glove box White 23 pin

MSCAN Low Violet/Orange 13 (DATA) C2153D located at RFA behind glove box White 23 pin

HSCAN High White/Blue 21 (DATA) C2153D located at RFA behind glove box White 23 pin

HSCAN Low White 22 (DATA) C2153D located at RFA behind glove box White 23 pin

Immobilizer Data White/Blue 15 (DATA) C2153B located at RFA behind glove box Green 23 pin

Immobilizer Clock Yellow/Gray 16 (DATA) C2153B located at RFA behind glove box Green 23 pin

12V Blue/Red 1 (+) C2153C located at RFA behind glove box Blue 23 pin

Brake Violet/White 2 (+) C2153E located at RFA behind glove box Brown 23 pin

PTS Yellow/Orange 4 (-) C2153E located at RFA behind glove box Brown 23 pin

Parking Light Violet/White 6 (+) C2280E located at BCM driver side dashboard Gray 13 pin

Door Pin Green/Violet 9 (DATA) C2280C located at BCM driver side dashboard Blue 26 pin

Trunk Brown/Yellow 15 (-) C2153E located at RFA behind glove box Brown 23 pin

Lincoln MKS 2009-12
