Introduction
This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a
digital configuration require the module to be flashed with vehicle specific firmware. Refer to our website (www.directechs.com) and click on
the DIRECTLINK text in the header for additional information.
DS3/DS3+ and DS4/DS4+ modules provide an all-in-one solution for most modern vehicles, and include remote start, keyless entry, security,
and immobilizer bypass capabilities. T-harnesses may also be used in many applications for easy installation.
The following methods are available to configure modules:
• Web: www.directechs.com (DS3/DS3+ and DS4/DS4+)
• Desktop Application: Directlink DT (DS3/DS3+ and DS4/DS4+)
• Mobile Device: Directlink App (DS4/DS4+ only)
When Flashing via Directlink DT (Desktop app) or via the Web, an XKloader2 will be required.
To configure via Web or DirectLink DT (mobile app):
1. Disconnect the main module from any (+) 12V power source.
2. Connect the module to your computer using the XKLoader2.
3. Follow the steps in the pop-up window that will be displayed when the module is detected.
Notes:
•Flashing via web is only possible using Internet Explorer on Windows 8, 8.1, and 10.
•This method is not compatible with any other browser (Edge, Chrome, Firefox, etc.)
•When using Windows 11 or newer, Directlink DT is mandatory.
The DS4/DS4+ module is designed to be configured using the DirectLink application through mobile devices.
To download the DirectLink mobile application, visit the Google Play or Apple store. They can also be
configured via Web and DirectLink DT. The DS4/DS4+ features are built in Bluetooth® 4.0, allowing you to
configure and control your system. The DS3/DS3+ module is not equipped with Bluetooth®, therefore is not
compatible with the DirectLink app for mobile devices.
To configure via DirectLink DT (mobile app):
1. Follow and complete the wiring diagram(s) related to your installation through the app.
2. When installation is complete, select Configure DS4/DS4+.
3. Follow the on-screen instructions.
FLASH REQUIRED!
FLASH REQUIRED!
4 White

4933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Vehicle function compatibilities
This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.
Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart.
Door Lock Control
Door Unlock
Driver Priority Unlock
Trunk / Hatch Release
Control of aftermarket alarm with OEM remote
Fuel level/EV battery level
Immobilizer Bypass-Data No Key Req'd
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Accessory Activation
Ignition Activation
Remote Start Takeover
SmartStart
Start (Crank) Activation
Tach / RPM Output
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Brake Status (foot brake)
E-Brake Status
Ignition Status

5933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Pre-installation and application warnings
START HERE This section highlights important information for this specific firmware and will assist in pricing accordingly, as
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible
THMAN1
AUX
Keys required for
programming 1Keys required for operation 0
Vehicle Takeover Refer to the Quick Reference Guide section for more details.
Firmware notes
Doors: To remote start the engine, the hood, hatch and all doors must be closed.
Runtime: It is normal for the key symbol to flash during remote start runtime.
Caution: In these vehicles, the factory keyless entry module is sensitive to interference and may cease to operate without notice.
Ensure you disconnect the (-) terminal of the battery prior to disconnecting and reconnecting the connectors at the start/stop module
below the steering wheel to avoid damage to the keyless entry module.
T-Harness (THMAN1):
•All T-Harness wires not listed in the diagram are not required for the installation. Loose wires such as Siren Output and
Hood Input may need to be pulled from the tapped section of the T-harness. Refer to the "wiring diagram with T-Harness"
for more information on connections and installation instructions.
•The optional Plug & Play THMAN1 T-Harness is sold separately.
•All T-Harness wires not listed in the diagram are not required for the installation.
Fuses: It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed
on each wiring diagram.
Unless specified otherwise, all connectors are displayed from the wire side.
Refer to the Vehicle connections section following the installation diagram.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
[2] Siren: Only required when enabling the security features during module flashing.
[3] Runtime: Connection required to retain vehicle takeover and OEM remote functionality during remote start runtime.
[4] Parking lights: Connection required when not supported in data. See the Locating components in the vehicle section for more
information about accessing the parking wiring.

6933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).- Important! In these vehicles, the factory keyless entry module is sensitive to interference and may cease to operate without notice. Ensure you disconnect the (-) terminal of the
battery prior to disconnecting and reconnecting the connectors at the start-stop module below the steering wheel to avoid damage to the keyless entry module.
- Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram with T-Harness (THMAN1)
Cut
Parking Light Interrupt (conn. side): Blue
Parking Light Interrupt (veh. side): Blue/White
Hood Pin (-) Hood Input: Gray
Siren
(+) Siren Output: Brown/Red
Parking Light
Switch Assembly
65
4
3
2
1
(-) Parking Lights Output: Lt. Green/Black
Start/Stop Unit
(white conn. at steering column)
Start/Stop Unit
(white conn. at steering column)
THMAN1
(optional T-Harness)
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
(-) GWA Output: Dk. Green/Black
8-pin White Connector
22-pin White Connector
12-pin Black Connector
Relay Pack
5A Fuse Inside
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
30
20
20
15
15
5
(-) Parking Lights:
Yellow, pin 3
Parking Lights
Interr.: Green, pin 4
Refer to the Optional starter
disable connection section for
relay and connection details.

7933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).- Important! In these vehicles, the factory keyless entry module is sensitive to interference and may cease to operate without notice. Ensure you disconnect the (-) terminal of the
battery prior to disconnecting and reconnecting the connectors at the start-stop module below the steering wheel to avoid damage to the keyless entry module.
- Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Cut
30
86 8587
87a
Wiring diagram
(-) GWA Output: Dk. Green/Black: 3
DS4+
Parking Light Interrupt (vehicle side): Blue/White: 1
Parking Light Interrupt (conn. side): Blue: 3
(+) Ignition Output: Lt. Green: 8
(-) Ground: Black: 10
(+) Starter Output: White: 5 & 11
(+) 12V Input: Red: 6 & 12
(-) Parking Lights Output: Lt. Green/Black: 1
(-) Ignition Interrupt Output: Dk. Blue/Black: 9
(-) Push-to-Start Output: Lt. Blue/Black: 10
(+) Accessory 2 Output: Violet/Black: 8
Hood Pin
(+) 12V Input: Lt. Green/Red: 7
(-) Hood Input: Gray: 21
Siren
(+) Siren Output: Brown/Red: 11
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
Start/Stop Unit
(white conn. at steering column)
Start/Stop Unit
(white conn. at
steering column)
(-) PTS: pin 20
Fuse Box
(white conn.
at driver’s kick)
1
(+) 12V:
White, pin 1
16
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18
124 3 56789101112131415
17
24 1314151617 18
192021
2223
12 13 2
45
6
7
8
910
11
(+) Starter:
Brown/Black or Brown,
pin 23
(+) Ignition:
Lt. Green/Red or Pink, pin 10
HS CAN Low:
Red/Yellow
or Red, pin 8
HS CAN High:
White/Black
or White, pin 7
(+) Accessory 2: Brown/Red
or Pink, pin 14
Parking Light
Switch Assembly
65
4
3
2
1
(-) Parking Lights:
Yellow, pin 3
Keyless Data Output: Orange/Black: 7
Keyless Data:
Green/Orange or Green,
pin 9
Cut
Ign. 2 Interr.:
Violet, pin 17
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
30
20
20
15
15
5
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
- Important! In these vehicles, the factory keyless entry module is sensitive to interference and may cease to operate without notice. Please ensure you disconnect the (-) terminal
of the battery prior to disconnecting and reconnecting the connectors at the start-stop module below the steering wheel to avoid damage to the keyless entry module.
- Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Optional
Parking Lights Interrupt:
Green, pin 4
(+)12V
Refer to the Optional starter
disable connection section for
relay and connection details.
1A diode
[1N4002+]

8933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Locating components in the vehicle
1. Grab parking light handle and pull in the direction of the arrow.
2. Push the clip to remove the parking light switch.
3. Remove the white cover to expose the connector.
Accessing the parking light circuit
4.Access the parking light connector and wire.

9933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Optional starter disable connection
When using an external relay, use a 1N4002 diode or larger.
22 812
4 2442
Refer to the
Vehicle connections
section for wire
and connector
details.
(-) Ground When Armed (GWA) Output: Dk. Green/Black: 3
(+) Ignition
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
Starter (connector side)
Starter (vehicle side)
Cut
86 85
30
87a
87
22 812
4 2442
Refer to the
Vehicle connections
section for wire
and connector
details.
(-) Ground When Armed (GWA) Output: Dk. Green/Black: 3
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
1A diode
Important: When flashing your module for Security Only, the Ground When Armed (GWA)
function is pre-configured. When flashing your module for Remote Start & Security, you must
manually assign the designated output to Anti Grind (AG) Starter Kill.
(Applicable to CORE 194+.)

10 933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2016 Mazda CX-5 (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes.
Data harness, 8-pin white connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H1/1 Tan (Data) HS CAN Low Start Stop Unit in steering column, white 24 pin plug, pin 8 Data Red/Yellow (HS CAN) Mandatory
H1/2 Tan/Black (Data) HS CAN High Start Stop Unit in steering column, white 24 pin plug, pin 7 Data White/Black (HS CAN) Mandatory
H1/3 Orange/Brown No Connection No Connection
H1/4 Orange/Green No Connection No Connection
H1/5 Lt. Green No Connection No Connection
H1/6 Violet/Brown (MUX) Lock Output No Connection
H1/7 Orange/Black (Data) Keyless Data Start Stop Unit in steering column, white 32 pin plug, pin 9 Data Green/Orange Mandatory
H1/8 Yellow/Black No Connection No Connection
Analog input/output harness, 22-pin white connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/1 Lt. Green/Black (-) Pk Light Output [4] Parking Light Switch Assembly inside steering column, white 6 pin plug,
pin 3
Connection required when not supported in data.
- Yellow Optional
H2/2 Blue/White No connection No Connection
H2/3 Dk. Green/Black (-) Ground When Armed (GWA) Output Starter:
Start Stop Unit in steering column, white 24 pin plug, pin 23
Ignition:
Start Stop Unit in steering column, white 24 pin plug, pin 10
Must use a relay.
Must use a 1N4002 diode or larger.
+
+
Brown/Black
Lt. Green/Red
Security Only
H2/4 Red/White (-) Trunk Output No Connection
H2/5 Brown/Black (-) Horn Output Horn Switch-Clock Spring, white 14 pin plug, pin 1 - Blue Optional
H2/6 Brown/White No Connection No Connection
H2/7 White (+) No connection No Connection
H2/8 Violet/Black (+) Accessory Output Start Stop Unit in steering column, white 24 pin plug, pin 14 + Brown/Red Mandatory
H2/9 Dk. Blue/Black (-) Ignition Interrupt Output [3] Must use a relay.
Must use a 1N4002 diode or larger.
10A fuse to 12V.
Start Stop Unit in steering column, white 32 pin plug, pin 17
Connection required to retain vehicle takeover and OEM remote
functionality during remote start runtime.
Cut Violet Remote Start
Only
H2/10 Lt. Blue/Black (-) PTS Output Start Stop Unit in steering column, white 32 pin plug, pin 20 - Lt. Green/Red Remote Start
Only
H2/11 Brown/Red (+) Siren Output [2] Only required when enabling the security features during module
flashing.
Security Only
H2/12 Pink No Connection No Connection
