Directed parkmate PTS411 Series User manual

User
Manual
PTS411 Series
Parking Assist System
4 Sensor Parking Assist System
www.directed.com.au
www.directed.co.nz
All Images, Information and Content are Copyright © 2020
Directed Electronics Australia Pty Ltd. All Rights Reserved.
www.parkmate.com.au | www.parkmatehd.co.nz

01
User Manual
Our products are to assist and aid the driver,
not to replace the manual function of the person
operating the vehicle.
Although the PTS is a visual aid and will allow you
to view what is behind the vehicle, it does not
remove the responsibility of driving the vehicle from
the driver. Legal responsibility and safe driving
practise remains with the driver at all times. You
have purchased this product with the understanding
that its use is as an aid only. We highly recommend
that you have this product professionally installed to
ensure that it will provide the functions it is set out
to perform.
Parking Assist System (PTS) helps to provide
assistance when reversing and parking. Driving
skills such as slowing down, use of mirrors are
always essential.
1.
This system is for vehicles with DC 9~27V only.
2. This system should be installed by a
professional auto technician.
3. Route wiring harness away from heat source
and electrical components.
4. It is strongly recommended to check the
position of the sensors before the actual drilling
of the holes.
5. Perform a functional test after installation.
Important notice
Disclaimer
Contents
01
01
02
02
02
03
03
04
04
05
05
06
06
07
07
08
09
11
13
16
19
19
20
21
21
22
29
30
31
34
35
36
Important Notice ---------------------------------------
Disclaimer -----------------------------------------------
About the Product -------------------------------------
2 or 4-Sensor Automatic Recognition ------------
Key features --------------------------------------------
Optional Extension Cable ---------------------------
Specifications -------------------------------------------
PTS411 Volume and Frequency Adjustment---
PTS411 Front or Rear System Optional ---------
PTS411 Sensor Installation Height ----------------
PTS411 Activated by Pressing Footbrake -------
PTS411-M6 Volume and Frequency Adjustment
PTS411-M6 Front or Rear System Optional
-----
PTS411-M6 Sensor Installation Height -----------
PTS411-M6 Activated by Pressing Footbrake --
Dual Intelligent Function for Spare Wheel ------
Self-Testing Function ---------------------------------
Learning Function -------------------------------------
How does the system work -------------------------
Different Scenarios for System --------------------
Attention -------------------------------------------------
Sensor Maintenance ---------------------------------
Brief Installation Diagram ----------------------------
Includes --------------------------------------------------
Installation Tools ---------------------------------------
Sensor Installation -------------------------------------
PTS411 Installation
-----------------------------------
PTS411-M6 Installation ------------------------------
Wiring Diagram -----------------------------------------
Functional Test
-----------------------------------------
Troubleshooting ----------------------------------------
Notes -----------------------------------------------------
User Manual Installation Manual

02 03
The PTS411 is a 4-sensor parking system that
can be used as a front or rear ultrasonic distance
monitoring device (Dual-purpose). It
electronically detects the area in front or behind
the vehicle while reversing and driving forward.
If the system detects an obstacle, it will provide
alerts with audible tones and visual warnings,
depending on the model purchased. The system
assists the driver when parking and in
manoeuvring situations.
All the detachable sensors are waterproof and
can be easily changed. Combined with
anti-interference and anti-false alert technology,
the system can detect obstacles in a wide variety
of weather conditions and respond quickly. The
system has intelligent detection, which is ideal
for vehicles with a tow-bar or spare tire.
Each element of this system has passed the
most stringent test before being released to the
market. It is reliable at a wide storage
temperature range and becomes very useful
when you are parking on a raining day, snowing
day or at night etc. With the help of a parking
assist system, you can enjoy a comfortable,
relaxed and safer parking experience.
About the Product
DC 9~27V
<250mA
80±10dB
Operating voltage:
Operating current:
Buzzer SPL:
Operating temperature:
ECU:
PTS411:
PTS411-M6:
Storage temperature:
ECU:
PTS411:
PTS411-M6:
Detection range:
Front:
Rear:
Specifications
2 or 4-Sensor Automatic Recognition
The parking system can be used as a 2-sensor
system when fitted on either the front or rear of
your vehicle. When using as a 2-sensor system,
make sure you connect the sensors to either
B&C port or A&D port on the ECU.
(please refer to page 30-33)
When fitting this system on the front of a vehicle,
we highly recommend purchasing a set of
sensor cable extensions.
These extend the supplied 2.3m sensor cable by
2.3m making the sensor cables 4.6m long.
Only applicable for PTS411.
Optional Extension Cable
Key Features
Dual-purpose parking assist system, can be
used as a front or rear kit
Can be used as a 2-sensor system
(2 front or 2 rear)
Buzzer can be upgraded with a visual display.
Please contact your local dealer for purchasing
accessories.
Self-testing function
Anti-false alert technology
Dual intelligent function together with learning
function for vehicle with tow-bar, spare wheel or
other protrusions
0.30~0.99m
0.30~0.59m
(reversing)
0.30~2.59m
-40�C~+85�C
-40�C~+85�C
-40�C~+85�C
-40�C~+80�C
-40�C~+80�C
-40�C~+80�C

04 05
PTS411 Volume and Frequency Adjustment
PTS411 Front or Rear System Optional
Volume adjustment
Tips: If the PTS411 is installed together with the front sensor system, it is
recommended to use low frequency "L" sound alarm for rear system and
high frequency "H" sound alarm for the front system for distinguish
between the 2 system alarms easily.
Low volume
Medium volume
High volume
Volume switch
High frequency sound
Low frequency sound
Frequency switch
Frequency adjustment
The PTS411 sound frequency can be adjusted to
High / Low by turning the frequency switch.
PTS411 Sensor Installation Height
PTS411 Activated by Pressing Footbrake (Front System)
The system can be used as a front or rear parking system. You can select your preference by changing a
jumper on the ECU before instalation.
54cm~65cm
45cm~54cm
54cm~65cm
45cm~54cm
The system can vary the sensor installation height, achieved by changing a jumper on the ECU before
instalation.
Jumper position: "R"
The system used as a Rear system
F
R
Jumper position: "F"
The system used as a Front system
F
R
This function is for a front sensor system (jumper position in “F”). The front system is activated by pressing
the footbrake. When you press the footbrake and release it, the system will continue to work for the period of
time you configure:
F
1
2
RF
1
2
R
1
8
Recommended for Automatic Cars Recommended for Manual Cars

PTS411-M6 Volume and Frequency Adjustment
PTS411-M6 Front or Rear System Optional
Turn your vehicle ignition to "Accessories" on and press the SET button once. You will hear a beep as
the front system enters volume adjustment mode. When reverse gear is selected, press the SET button
once. You will hear a beep as the rear system enters volume adjustment mode. In either mode, press
the SET button again to select the volume level, it will save and exit after 1 second. To change the
volume setting, press the SET button multiple times: ’0’ for mute, ‘1’ for Min, ‘2’ for Max.
PTS411-M6 Sensor Installation Height
PTS411-M6 Activated by Pressing Footbrake (Front System)
The system can be used as a front or rear parking system. You can select your preference by changing a
jumper on the ECU before instalation.
54cm~65cm
45cm~54cm
54cm~65cm
45cm~54cm
The system can vary the sensor installation height, achieved by changing a jumper on the ECU before
instalation.
F
1
2
RF
1
2
R
Jumper position: "R"
The system is being as Rear system
F
R
Jumper position: "F"
The system is being as Front system
F
R
Make these settings to set up as a front parking system (jumper position in “F”). The front system is activated
by pressing the footbrake. When you press the footbrake and release it, the system will continue to work for
the period of time you configure:
1
8
06 07
Recommended for Automatic Cars Recommended for Manual Cars

08 09
Dual Intelligent Function for Spare Wheel (Rear System)
Make these settings to set up as a rear parking system (jumper position in “R”).
When this function is ON, the detected distance will increase 20cm (from 30cm to 50cm) between
the sensor and obstacles. This extra distance is designed to factor in a tow-bar or spare wheel.
0.3m
F
1
2
R
1
F
1
2
R
Note: The optional dispaly will still show a reading or 0.3m before -P when the jumper is in position 2.
Self-Testing Function
For Front System:
Once your vehicle ACCESSORIES is turned on, the system will test all front sensors automotically.
If all sensors are working properly, the buzzer will not sound alert.
If a damaged or defective sensor is detected, then then system will “BEEP” 3 times for alarm.
BEEP - BEEP - BEEP
Notes:
• If sensors are damaged or defective, the buzzer will BEEP 3 times.
• The locations of damaged / defective sensors will be shown on the display.
• The system will not sound alert when sensors (A&D) or (B&C) are damaged or defective as it will
work as 2-sensor front system automatically.
After completing the self-testing function, the system will continue working for 8 seconds (jumper
position “1” in ECU) or 20 seconds (jumper position “2” in ECU) when the vehicle is moving towards or
away from obstacles.
No "BEEP"
0.3m
0.5m
BEEP
For Model PTS411
For Model PTS411-M6
BEEP
No "BEEP" BEEP - BEEP - BEEP

Please find a location without obstacles to activate this function.
1. With the ignition “ON”, press and release the footbrake 10 times in 1 second intervals.
2. On the 10th time, hold the footbrake down , the buzzer will "BEEP" once after 5 seconds, then will do
a long “BEEP” for 2 seconds after 3 seconds to complete the learning process.
Clear the learning function:
1. With the ignition “ON”, press and release the footbrake 12 times in 1 second intervals.
2. On the 12th time, hold the footbrake down, the buzzer will "BEEP" once after 5 seconds, then
"BEEP" once again after 3 seconds to complete the clearing process.
Learning Function
10 11
Note:
• This function is valid and achievable only if all sensors are working properly.
• The above procedure must be carried out within 3 minutes of the ignition being switched on. If the
ignition has been on for over 3 minutes, turn the ignition off and back on again.
• If you make a mistake while carrying out the above procedure, release the footbrake for 3 seconds
to clear the system memory and then start the procedure again.
• If the vehicle does not have nudge bars or other protrusions, you do not need to use this function.
• Perform a functional test after the learning function is set.
Learning function for cars with nudge bars or other protrusions (Front System)
For Rear System:
When reverse gear is selected, the system will test all rear sensors automatically.
If all sensors are working properly, the buzzer will "BEEP" once.
If a damaged or defective sensor is detected, then then system will “BEEP” 3 times for alarm.
For Model PTS411
For Model PTS411-M6
Notes:
• If sensors are damaged or defective, the buzzer will BEEP 3 times.
• The locations of damaged / defective sensors will be shown on the display.
• The system will not sound alert when sensors (A&D) or (B&C) are damaged or defective as it will
work as a 2-sensor rear system automatically.
No "BEEP" BEEP - BEEP - BEEP
No "BEEP" BEEP - BEEP - BEEP
BEEP

13
How Does the System Work (Front System)
12
Please find a location without obstacles to activate this function.
1. With the ignition “ON”, change the gear from “N” to “R” 10 times
(Each gear change must be within 1 second).
2. On the 10th time, leave the gear in “R” position, the buzzer will "BEEP" once after 2 seconds, then will do
a long "BEEP" sound for 2 seconds after 3 seconds to complete the learning process.
3. When the learning function is activated, the system will ignore the tow-bar or spare wheel and only
detect behind the vehicle.
Clear the learning function:
1. With the ignition “ON”, change the gear from “N” to “R” 12 times
(each gear change must be within 1 second).
2. On the 12th time, leave the gear in “R” position , the buzzer will "BEEP" once after 2 seconds, then
"BEEP" once again after 2 seconds to complete the clearing process.
Note:
• This function is valid and achievable only if all sensors are working properly.
• If you make a mistake while carrying out the above procedure, leave the gear in “R” position
for 2 seconds to clear the system memory and then start the procedure again.
• If the vehicle does not have a tow-bar or spare wheel, you do not need to use this function.
• Perform a functional test after the learning function is set.
Note: The max. detection range of outside (A&D) sensors is 0.69m.
The max. detection range of central (B&C) sensors is 0.89m.
BEEP - BEEP BEEP
Distance: >1.0m Distance: <0.3mDistance: 0.6m
Distance: >1.0m Distance: <0.3mDistance: 0.6m
No "BEEP"
Driving forward, press footbrake
For PTS411:
For PTS411-M6:
+12V +12V +12V
Learning Function for Cars with Tow-Bar or Spare Wheel (Rear System)
BEEP
No "BEEP" BEEP
BEEP - BEEP

14 15
ReversingReversing
For PTS411: For PTS411:
Note: The max. detection range of outside (A&D) sensors is 0.69m
The max. detection range of central (B&C) sensors is 0.59m
Note: The max. detection range of outside (A&D) sensors is 0.99m.
The max. detection range of central (B&C) sensors is 1.49m.
How Does The System Work (Rear System)
For PTS411-M6: For PTS411-M6:
BEEP - BEEP
BEEP
Distance: >0.7mDistance: <0.3m Distance: 0.4m
No "BEEP"
Distance: <0.3m Distance: >0.7mDistance: 0.4m
BEEP BEEP - BEEP No "BEEP"
BEEP - BEEP BEEP
Distance: >1.5m Distance: <0.3mDistance: 0.6m
No "BEEP"
Distance: >1.5m Distance: <0.3mDistance: 0.6m
No "BEEP" BEEP
BEEP - BEEP

Different Scenarios for System (Front System)
1716
Reversing:Braking:
PTS411 PTS411-M6
Backlight
<0.30m
0.30-0.39m
0.40-0.59m
0.60-0.79m
0.80-0.89m
0.90-0.99m
PTS411 PTS411-M6
Backlight
<0.30m
0.40-0.49m
0.50-0.59m
>0.6m
0.30-0.39m
NO BEEP
NO BEEP
BEEP--- BEEP---
BEEP--- BEEP---
BEEP-- BEEP--
BEEP- BEEP- BEEP- BEEP- BEEP-
BEEP--------- BEEP---------
BEEP- BEEP-
BEEP- BEEP-
BEEP- BEEP-
BEEP- BEEP-

18 19
Attention Sensor Maintenance
• After installation, perform a functional
test before use.
• Heavy rain, dirty or damaged sensors may
cause a false alarm occasionally.
• Ensure that the self-testing procedure is
completed and all sensors are are functioning
properly before using the system.
False detection may occur in the following
situations:
Do not wash the sensor with a pressure
washer or scrub them forcibly.
Wash car with low-pressure spray.
Melt snow with water when the sensors are
covered.
Clean the sensors with a cloth or low-pressure
spray when the sensors are covered by dirt.
Different Scenarios for System with Buzzer (Rear System)
PTS411 PTS411-M6
Backlight Distance
<0.3m
0.3-0.5m
0.5-0.9m
0.9-1.3m
1.3-1.5m
<0.3m
0.3-0.5m
0.5-0.6m
0.6-0.9m
0.9-1.1m
1.1-1.3m
1.3-2.5m
BEEP--- BEEP---
BEEP-- BEEP--
BEEP---------
BEEP- BEEP-
BEEP- BEEP-
BEEP- BEEP-
BEEP-

20 21
The above graphics are for reference only.
*When you
purchase PTS411
*When you
purchase PTS411-M6
60' - 80'
Includes
Installation tools
Installation Manual
Brief Installation Diagram
A
B
C
D
While it is possible to install this product yourself with some intermediate experience, we recommend that
you read the installation instructions first and seek professional installation if you are unsure.
We highly recommend that you have this product professionally installed to ensure that it will perform and
function as it is has been manufactured and designed to.

22 23
The sensor head angle can be changed to compensate for angled bumpers. See the instructions overleaf.
Sensor Installation
H > 45cm/
H < 65cm
H > 65cm
=1 / 8L
=2 / 8L
=1 / 8L
< 45cm < 45cm < 45cm
H < 45cm
a
b
c
c b a a b c
45cm < H < 65cm
1
L1 L2 L1
H
H > 45cm
H < 65cm
1.5m
1.0m
35cm<L1<45cm
45cm<L2<55cm
45cm<H<65cm
Notes:
For a 2-sensor front sensor system it is recommended to install 2
sensors in position D&A for the best performance.
On some vehicles, due to the number plates location or bumper
design, the distance between the centre of two sensors (L2) will
be greater, i.e. L2>60cm. The kit will still function, however the
detection of narrow objects i.e. posts will be reduced.
1.
2.
2
D C B A

24 25
Change of sensor cover.
(Built-in)
Tips: Make sure the degree
marking is on the top of the
sensor plug after assembly.
3
00 40 100
4
Note: Check that the size of
the hole saw included with
this product matches the
diameter of the sensors
before drilling any holes.

26 27
A
B
CD
A
B
C
D
Bumper
Gap
Hint: If a gap exists between your bumper and 10osensor cover after installation, adjust the angle
of the hole shown as below.
Angle
56 7
8

28 29
9
PTS411 Installation

30 31
PTS411-M6 Installation
Installation mode 3
Installation mode 1 Installation mode 2
Tear off sticker and fix the display on the
dashboard firmly for the driver to easily see.
Tear off sticker and fix the display on the top of
the rear mirror.
Tear off sticker and fix the display on the roof of the rear windshield.
Screw the display on
the rear roof of the
windshield.
Clip the cover on.
A
A
B
C
D
B C D
Note: Connect A&D or B&C sensors to use as Front 2 sensor system
PTS411
PTS411-M6

32 33
Insulation (not used)
Insulation (not used)
PTS411
PTS411-M6
PTS411
PTS411-M6
Note: Connect A&D or B&C sensors to use as rear 2 sensor system
Note: Connect A&D or B&C sensors to use as rear 2 sensor system
Note: The Pink ACC+ wire is used to supply
a clean live power to the kit when the feed to
the reverse light is low voltage or pulsed (not
a clean liver power).

34 35
Troubleshooting
1. After installation, the buzzer doesn't work.
• Make sure the wires are connected properly
• Make sure the vehicle has ACCESSORIES
powered ON
• Make sure reverse gear is selected
(the reversing light should be lighted on)
2. Damaged sensor detected
• Make sure ALL sensors are plugged into the
ECU correctly and tightly
• Make sure no snow or dirt is covering the
sensor
• Please check if the sensor is damaged
3. False alarm
• Make sure ALL sensors are plugged tightly
into the ECU in the correct position
• Please check if any of sensors are
"grounding"
• Please check if the rubber ring of the sensor
has come loose (if sensor comes with
rubber ring)
4. Buzzer alarm sound is too low or too high
• Press volume button to adjust the volume to
a suitable level.
5. Learning function is invalid
• Sensor(s) is/are damaged
• Make sure ALL sensors are plugged into the
ECU correctly and tightly
Plug the certified sensors into the ECU and
perform a functional test again
6. If the problem persists:
• For end users: Please contact your nearest
dealer or customer service center
• For installers/dealers:
a) Test the sensors with a certified ECU by
performing a functional test.
b) Replace another ECU and retest the sensors.
Functional Test
Functional testing is
performed by holding a
wooden board (0.3 x1.0m)
standing at the front or rear
of the car, and drive the car
forward and backward to test
each function respectively as
shown in this manual.
1.0m
Rear sensor functional test
Front sensor functional test
0.3m
2.5m

36
Warranty Terms & Conditions
37
Our goods come with guarantees that cannot be excluded under the Australian & New Zealand
Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
This warranty is provided in addition to your rights under the Australian & New Zealand Consumer
Law.
Directed Electronics Australia Pty Ltd (Directed Electronics) warrants that this product is free from
defects in material and workmanship for a period of 12 months from the date of purchase or for the
period stated on the packaging. This warranty is only valid where you have used the product in
accordance with any recommendations or instructions provided by Directed Electronics.
This warranty excludes defects resulting from alterations of the product, accident, misuse, abuse or
neglect.
In order to claim the warranty, you must return the product to the retailer from which it was
purchased or if that retailer is part of a National network, a store within that chain, along with
satisfactory proof of purchase. The retailer will then return the goods to Directed Electronics.
Directed Electronics will repair, replace or refurbish the product at its discretion. The retailer will
contact you when the product is ready for collection. All costs involved in claiming this warranty,
including the cost of the retailer sending the product to Directed Electronics, will be borne by you.
Directed Electronics Address: 115-119 Link Road Melbourne Airport, 3045 Victoria. Australia
Ph: [phone] Email: [email protected]
To view the complete Parkmate range or for details on how to contact us, please visit our website at
www.parkmate.com.au | www.parkmatehd.co.nz
INDEMNITY
YOU AGREE TO DEFEND, INDEMNIFY AND HOLD HARMLESS PARKMATE AND ITS
SUBSIDIARIES AND AFFILIATES FROM AND AGAINST ANY AND ALL CLAIMS, PROCEEDINGS,
INJURIES, LIABILITIES, LOSSES, COSTS AND EXPENSES (INCLUDING REASONABLE LEGAL
FEES), INCLUDING BUT NOT LIMITED TO, CLAIMS ALLEGING NEGLIGENCE, INVASION OF
PRIVACY, COPYRIGHT INFRINGEMENT AND/OR TRADEMARK INFRINGEMENT AGAINST
PARKMATE AND ITS SUBSIDIARIES AND AFFILIATES OR THE PARKMATE SERVICES,
RELATING TO OR ARISING OUT OF YOUR BREACH OF ANY PROVISION OF THESE TERMS,
YOUR MISUSE OF THE PARKMATE OR PARKMATE SERVICES, OR YOUR UNAUTHORIZED
MODIFICATION OR ALTERATION OF PRODUCTS OR SOFTWARE.
WARRANTY AND WARRANTY DISCLAIMER
PARKMATE HAS A LIMITED WARRANTY ON WHEREBY PARKMATE WARRANTS TO YOU AND
ONLY TO YOU THAT THE PARKMATE VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS,
FRONT, REAR AND REVERSING CAMERAS, MIRROR MONITOR DEVICES AND SENSORS
WILL BE FREE FROM DEFECTS IN MATERIALS AND WORKMANSHIP FOR ONE (1) YEAR
FROM THE DATE OF YOUR PURCHASE OF THE PARKMATE VEHICLE DASH CAMERAS,
MIRROR DASH CAMERAS, FRONT, REAR AND REVERSING CAMERAS, MIRROR MONITOR
DEVICES AND SENSORS (UNLESS A LONGER WARRANTY PERIOD IS REQUIRED BY LAW).
THE SPECIFICS OF THIS PARKMATE LIMITED WARRANTY ARE AT
HTTPS://WWW.PARKMATE.COM.AU/WARRANTY
TO THE EXTENT POSSIBLE UNDER GOVERNING LAW, OTHER THAN THE ABOVE PRODUCT
WARRANTY FOR THE PARKMATE VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS,
FRONT, REAR AND REVERSING CAMERAS, MIRROR MONITOR DEVICES AND SENSORS,
YOU UNDERSTAND AND AGREE THAT THE PARKMATE SERVICES ARE PROVIDED ON AN "AS
IS" AND "AS AVAILABLE" BASIS. PARKMATE MAKES NO WARRANTY THAT THE PARKMATE
SERVICES WILL MEET YOUR REQUIREMENTS OR THAT USE OF THE PARKMATE SERVICES
WILL BE UNINTERRUPTED, TIMELY, SECURE OR ERROR-FREE NOR DOES PARKMATE MAKE
ANY WARRANTY AS TO THE ACCURACY OR RELIABILITY OF ANY INFORMATION OBTAINED
THROUGH THE PARKMATE SERVICES (INCLUDING THIRD PARTY CONTENT), THAT ANY
DEFECTS IN THE PARKMATE SERVICES WILL BE CORRECTED OR THAT THE PARKMATE
