Remote Control
User's Guide
Remote Control
User's Guide
TM
2
UHF
PRO
2
UHF
PRO

then

C-3
Quick Setup
1
UHF
PRO
RECORD
Turn your receiver and
TV on, and press SYSTEM
INFO on the front
of the receiver.
Confirm that you
see the System
Information screen.
Press RECORD on
your remote. The remote
address will probably
change on the screen.
Confirm that your remote operates your
receiver by pressing remote buttons. If
your remote has a blue number 2 key, you
may need to go to your remote TV2 location to
confirm your remote operates your receiver.
If this is not working, go back to step 5.
Making the Remote Work
With Your Receiver
4
3
2
1
5
6
4
REMOTE
ANTENNA
If you installed a UHF
key, make sure the
UHF antenna is
installed on the back
of the
receiver.
Green
(not black)
UHF Pro Symbol
1
UHF
PRO
UHF
UHF
PRO
1
2
UHF
PRO
If you installed one of these keys,
continue with step 2 on this page. If you installed this key, go to page 11
inside this guide.

C-4
Quick Setup
TV
Turn your
TV on.
Press & hold the
TV Mode button
until all Mode
buttons light up.
Press
POWER.
Press the UP
ARROW
repeatedly (about 1
press per second)
until your TV
turns off.
Press
POUND.
The TV Mode button
will flash three times.
Press the POWER
button to turn the TV on
and try other buttons
to make sure the code
works. If you want to try
another code, start over
from step 1.
Program the Remote to
Control Your TV
12
34
5 6
#

C-5
Quick Setup
Programming the
Recover Button for
TV2 Operation
For TV2 Remote Controls on
DISH Player-DVR 522, 625, 942,
ViP222 and ViP622 DVR Receivers
Press
STAR.
#
Press
POUND.
1 2
TV
Press & hold the
TV Mode button
until all Mode
buttons light up. Enter the channel
number you tune
your TV to when you
watch satellite
programming.
4
3
2
Use the RECOVER button as described in
If You Lose Your Picture on the next page (C-6).
2
UHF
PRO
Programming your RECOVER button allows
you to easily regain satellite programming
if you accidentally change TV channels or inputs.
1 2 3
4 5 6
7 8 9
0

Quick Setup/Operation
C-6
SELECT
Press and hold RECOVER until all
mode buttons light up.
If you see the System Information
screen, proceed to step 4.
Otherwise, continue to step 3.
Press RECOVER again & wait until
the mode lights stop flashing. If you
see the System Information screen,
go to step 4. If not, repeat this step
until you do.
SAT
TV VCR
AUX
Press SELECT to resume watching TV.
Use the RECOVER button to get back to watching
satellite programming if you accidentally change
channels or inputs on your TV.
Placing Your Remote
in Limited Mode
If You Lose Your Picture
(How to Use the RECOVER Button)
#
Press
POUND.
TV
Press & hold the
TV Mode button
until all Mode
buttons light up.
23
1
1
2
3
4
Press the
PAGE UP
button.
PAGE
To take the remote out of Limited Mode, use the PAGE DOWN
button instead of the PAGE UP button in step 2.
(Your screen may be different)
Limited Mode locks out all the TV mode operations except for
TV power, Mute, and Volume. This prevents you from accidentally
tuning away from satellite programming.

C-7
Operation
2
UHF
PRO
2
UHF
PRO
Remote Operation
SAT Mode
SAT
Remote key may
be different than
what is shown here
Receiver Power
& TV Power
Receiver Menu
Program Guide
Arrows/Select
Buttons
View Satellite
Programming
Digital Video
Recorder (DVR)
Buttons
Picture-In-Picture
(PIP) Buttons
Number Buttons
Top button turns
the receiver on/off,
bottom button
turns the TV on/off
Programming required
(see C-4)
Channel up/down,
navigate through
menus/guides and
select a desired
option
Exit out of any menu/
guide and go back to
viewing live TV
DISH
Explore interactive
TV features
Browse
See what is on other
channels while
watching TV
Enter a channel
number, or select
menu items
Search
Search for a program
Watch two separate
programs at once
Recover
Recovers satellite
programming if your
TV input or channel
has changed
Format
Format the picture
to the desired width
to match the program
you are viewing
Display current and
future satellite
program listings
Page Buttons
Page up/down in
menus
Control TV volume
Programming required (see C-4)
Access receiver
features and settings
Themes
Search for programs
using Themes
Recall
Go back to last
channel viewed
Info
Display program info
Pause live TV and
play or record
programming
Volume & Mute Buttons
To use the features described in this section, make
sure you are in SAT mode by pressing the SAT Mode button.
Note: Some features may not be available depending on your receiver model.
Press this
button for
SAT Mode

2
UHF
PRO
2
UHF
PRO
Remote key may
be different than
what is shown here
C-8
Operation
Remote Operation
TV Mode
TV Power
TV Menu
Up/Down Arrow
Buttons
Picture-In-Picture
(PIP) Buttons
Number Buttons
Top & bottom
button
Turn TV on/off
Channel up/down
on TV
Enter a desired
channel number
on TV
Display PIP features
on some TVs with
PIP capabilities
Volume
Control TV
volume
Access menu
features available on
some TVs
TV/Video
Switch between
TV inputs
Mute
Turn TV volume
on or off
Recall
Go back to last
TV channel viewed
To use the features described in this section, make
sure you are in TV mode by pressing the TV Mode button.
Remote programming is required. See C-4 for instructions.
TVTV
Note: Remote operation is different on DISH Network TVs.
See your DISH Network TV User's Guide for proper operation.
Press this
button for
TV Mode
Remote key may
be different than
what is shown here

2
UHF
PRO
2
UHF
PRO
Remote key may
be different than
what is shown here
C-9
Operation
Remote Operation
VCR Mode
VCR
VCR/DVD Power
& TV Power
TV/Video Up/Down Arrow
Buttons
FWD
Number Buttons
Top button turns
VCR/DVD player
on/off, bottom
button turns the
TV on/off
Channel up/down
on VCR
Forward a videotape
or DVD
Play
Play a videotape or
DVD
Pause
Pause a videotape or
DVD
Enter a desired
channel number
on VCR
Switch VCR between
its TV & VCR mode
Back
Rewind a videotape
or reverse a DVD
Stop
Stop playing
or recording a
videotape, stop
playing a DVD
Record
Record on a
videotape
To use the features described in this section, make
sure you are in VCR mode by pressing the VCR Mode button.
You can use this mode to operate your DVD player instead of a VCR.
Remote programming is required. See page 2 for instructions.
Press this
button for
VCR Mode

Table of Contents
COLOR PAGES
Quick setup
Confirm Your Receiver Model then Select the Right
Key ....................................................................................... C-1
Install Your Selected Key................................................... C-2
Insert the Batteries ............................................................. C-2
Making the Remote Work with Your Receiver.................. C-3
Program the Remote to Control Your TV.......................... C-4
Programming the Recover Button for TV2 Operation..... C-5
Placing Your Remote in Limited Mode.............................. C-6
Operation
If You Lose Your Picture..................................................... C-6
SAT Mode............................................................................. C-7
TV Mode............................................................................... C-8
VCR Mode............................................................................ C-9
IN THIS GUIDE
Remote Control Overview...................................................... 1
Using the Guide ...................................................................... 1
Remote Control Modes .......................................................... 1
How the Remote Communicates...........................................2
Programming for Other Equipment ...................................... 2
Combination Equipment (for example, TV/VCR) ..........2
Limited Mode ...................................................................3
Programming Using Equipment Code Tables ..............3
Scanning for Equipment Codes.....................................4
Switching Between TV and Amplifier Volume
Control..............................................................................6
Programming the Remote to Control a Second Receiver
in Aux Mode..................................................................7
Reading Out the Remote Control Codes.............................. 8
Discrete Codes for Learning Remotes ................................. 9
Avoiding Remote Conflicts.................................................... 9
Changing the Remote and Receiver Address...............9
Changing the UHF Frequency Using the A/B Switch (DISH
Player-DVR 942, ViP222, and ViP622 DVR Only).....10
Setting Up a TV1 UHF Pro Remote for the DISH Player-DVR
522 and 625 Only............................................................ 11
Equipment Codes ................................................................. 13
Troubleshooting.................................................................... 21
Limited Warranty................................................................... 23
Your Remote Control Codes................................................ 26
6.3 Replacement.book Page 1 Tuesday, November 7, 2006 11:56 AM

1
REMOTE CONTROL OVERVIEW
Use this full-function remote to control a variety of DISH Network
receivers, such as Standard Definition, High Definition, and Digital
Video Recorder receivers. Also, you can program the remote to control
most of the popular brands of audio/video equipment like a TV, VCR,
DVD player, or a second DISH Network satellite receiver. See
Programming for Other Equipment on page 2.
Note: This remote control may have features not used by your
receiver.
USING THE GUIDE
This guide makes it easy to set up and use your remote control. By now
you’ve noticed that the cover contains information on quick set up and
remote operation.
The rest of the guide contains in-depth information to help you get the
most from your remote control, including controlling other equipment
like TVs, VCRs, and DVD players.
REMOTE CONTROL MODES
Use the remote control’s mode buttons to set the remote to the correct
mode for the equipment. Be sure to program the remote to control other
equipment as described on page 2.
To change the mode, press the button for the equipment you want to
control. The mode button lights for two seconds to show you’ve set the
remote to that mode.
Great Idea: Whenever you finish using
other equipment (TV, VCR, DVD, etc.) be
sure to put the remote back in SAT mode.
6.3 Replacement.book Page 1 Tuesday, November 7, 2006 11:56 AM

2
If you program the remote to control other equipment, refer to the
following for remote control operation instructions:
•TVs, page C-8.
•VCRs and DVD players, page C-9.
•DISH Network satellite receivers, page C-7.
•Stereo equipment, use only these buttons: SELECT (change
inputs), MUTE, VOLUME, and POWER.
HOW THE REMOTE COMMUNICATES
Depending on how the remote is set up, the remote control may use
UHF radio signals, IR signals, or both to control the receiver.
However, only IR signals are used to control other equipment.
•IR signals travel short distances (up to 40 feet), and cannot go
through walls or other solid objects. Point the remote control
directly at the equipment you want to control, with no objects to
block the signal path.
•UHF signals travel long distances and can go through walls and
other solid objects. Because these signals travel so far, the
receiver may respond to signals from other nearby remote
controls. To handle this problem, you may want to change the
remote and receiver addresses (see page 9).
•If you’re set up to use UHF, make sure that the UHF remote
antenna is attached to the receiver’s back panel UHF Remote
Antenna input so it can receive the UHF remote signals.
PROGRAMMING FOR OTHER EQUIPMENT
Page C-4 shows you how to program the remote to control a TV. This
section uses a different method to program the remote to control a TV
or other equipment (such as a VCR, DVD player, tuner, amplifier, or a
second TV). You can program the remote by either following the
instructions in Programming Using Equipment Code Tables on page 3,
or the Scanning for Equipment Codes procedure described on page 4.
COMBINATION EQUIPMENT (FOR EXAMPLE, TV/VCR)
When programming the remote to control combination equipment,
such as a TV/VCR or a TV/DVD, program the remote control in one
mode, and then repeat the procedure in the other mode. For example, to
program the remote to control a TV/VCR using code 748, follow the
instructions to program the remote to control the TV using code 748,
and then repeat the instructions for the VCR using the same code. Put
6.3 Replacement.book Page 2 Tuesday, November 7, 2006 11:56 AM

3
the remote in TV mode to use the TV, and VCR mode to use the VCR.
LIMITED MODE
You can program your remote control in Limited Mode to keep from
accidentally changing the channel on your TV or VCR. When you use
the remote to control your TV in Limited Mode, you will only be able
to use the POWER, MUTE, and VOLUME buttons to control your
TV. Also, when you use the remote to control your VCR in Limited
Mode, you will only be able to use the POWER and VCR function
buttons. The section Programming Using the Equipment Code Tables
has a step that tells the remote control to go into Limited Mode. Also, a
quick way to put the remote in Limited Mode is on page C-6.
Note: Limited Mode cannot be used with audio amplifiers.
PROGRAMMING USING EQUIPMENT CODE TABLES
You can set up the remote to control other equipment using the
equipment codes listed on page 13 and the modes as shown on page 2.
Instructions Additional Information
1Turn the equipment on. Use the equipment’s front panel
buttons or its remote control.
2Find the brand name of the
equipment in the tables
starting on page 13.
If the brand isn’t listed, see
Scanning for Equipment Codes
on page 4.
3Press and hold the mode
button until all the other
mode buttons light up, and
then let go of the button.
The mode button flashes.
For example, hold the TV mode
button for a TV until all of the
other mode buttons light. When
you let go, TV will flash.
4For AUX mode only. Press
0 for a second TV, or 1 for
a second VCR, or 2 for a
tuner, or amplifier.
This step is for programming
the kind of equipment that
should be programmed in AUX
mode. If you’re not
programming in AUX mode,
skip to step 5.
6.3 Replacement.book Page 3 Tuesday, November 7, 2006 11:56 AM

4
SCANNING FOR EQUIPMENT CODES
5Enter one of the three-digit
equipment codes from the
table using the number
buttons.
The three-digit equipment code
should be for the brand name of
your equipment that you found
in step 2.
6If you want to program
Limited Mode, press 1.
If not, skip to step 7.
See Limited Mode on page 3 for
more information.
7Press POUND (#). If you entered the code
correctly, the mode button
flashes three times.
8Press POWER to turn off
the equipment. If the equip-
ment does not turn off, go
to step 10.
If the code works, the
equipment should turn off.
9Turn the equipment back
on and try some other but-
tons to make sure they
work. If the code works for
other buttons, stop here.
For example, sometimes
POWER works when other
buttons don’t.
10 If the code doesn’t work,
repeat steps 3 through 9
with another equipment
code from the tables.
Try every code listed for your
brand until one works for your
equipment.
11 If you can’t find a code that
works, try Scanning for
Equipment Codes that
follows.
Instructions Additional Information
1Turn the equipment on. Use the equipment’s front panel
buttons or its remote control.
Instructions Additional Information
6.3 Replacement.book Page 4 Tuesday, November 7, 2006 11:56 AM

5
2Press and hold the mode
button until all the other
mode buttons light up, and
then let go of the button.
The mode button flashes.
For example, hold TV for a TV
until all of the other mode
buttons light. When you let go,
TV will flash.
3For AUX mode only. Press
0 for a second TV, or 1 for
a second VCR, or 2 for a
tuner, or amplifier. Then
press the STAR (*) button.
This step is for programming
which kind of equipment that
should be programmed in AUX
mode. If you’re not
programming in AUX mode,
skip to step 4.
4Press POWER. This puts your remote in the
scan mode.
5Press the UP or DOWN
ARROW repeatedly until
the equipment turns off.
As you press the UPor DOWN
ARROW, the remote tries each
code in the memory to see if it
can turn off your equipment.
When the equipment turns off,
you have found a code that
might work.
Note: The mode button for the
equipment will flash rapidly
eight times when you’ve
scanned all the codes for that
equipment.
6Press POUND (#). The mode button flashes three
times if you have entered the
code correctly. This stores the
code you found.
7Turn the equipment back
on and try some other but-
tons to make sure they
work.
Press POWER to turn the
equipment back on. Try some
other buttons to make sure they
work. Sometimes POWER
works when other buttons
don’t.
Instructions Additional Information
6.3 Replacement.book Page 5 Tuesday, November 7, 2006 11:56 AM

6
SWITCHING BETWEEN TV AND AMPLIFIER VOLUME
CONTROL
When you set up the remote to control a TV, the MUTE and VOLUME
buttons control the TV volume, even if your remote control is in SAT
mode. However, if you want to use the AUX mode to control a tuner or
amplifier that has a volume setting, you can set up the remote to control
the equipment’s volume instead of the TV volume while your remote
control is in SAT mode. Follow the instructions in the left column. To
change back to controlling the TV volume in SAT mode, follow the
instructions in the right column.
8If necessary, repeat this
procedureuntilyou’vetried
all the codes.
You may need to repeat the
scan to find the best code for
your equipment.
Control Amplifier Volume Control TV Volume
1Press and hold the AUX
mode button for three sec-
onds, and then let go of it.
The AUX mode button will
blink.
1Press and hold the TV
mode button for three sec-
onds, and then let go of it.
The TV mode button will
blink.
2Press the POUND (#) but-
ton. 2Press the POUND (#) button.
3Press the plus (+) side of
the VOLUME button. 3Press the plus (+) side of the VOLUME button.
4Press the 0number button. 4Press the 0number button.
5Press the POUND (#) but-
ton. 5Press the POUND (#) button.
The AUX mode button
flashes three times. The TV mode button
flashes three times.
MAKE SURE THE REMOTE
CONTROLS THE AMPLIFIER’S
VOLUME:
MAKE SURE THE REMOTE
CONTROLS THE TV’SVOLUME:
6Press the SAT mode but-
ton. 6Press the SAT mode but- ton.
Instructions Additional Information
6.3 Replacement.book Page 6 Tuesday, November 7, 2006 11:56 AM

7
PROGRAMMING THE REMOTE TO CONTROL ASECOND
RECEIVER IN AUX MODE
If you have another DISH Network satellite receiver installed, you can
use this remote in AUX mode to control it along with your new
receiver. When you program the remote to control the other receiver,
the remote will send out IR and UHF (not UHF Pro) signals to the
receiver. You can program the remote to control any other DISH
Network satellite receiver, except for following:
•TV2 on DISH 322, DISH Player-DVR models 522, 625, 942 and
ViP222 & ViP622 DVR
•DishPlayer 7100/7200
1Turn on the other receiver and display the System Info screen
(see the receiver user’s guide for information on how to display
the screen).
Write down the address shown:
2Press and hold the AUX button until all the other mode buttons
light up, and then let go of the button. The AUX button flashes.
3Press the 3button.
4Use the NUMBER PAD to enter the address you wrote in
step 1.
5Press POUND (#). The AUX button blinks three times.
6Press RECORD to make sure the address and the remote matches
the address on the receiver.
7Press the plus (+) and
minus (-) sides of the VOL-
UME button.
7Press the plus (+) and
minus (-) sides of the VOL-
UME button.
8The equipment’s volume
changes and the AUXmode
button lights instead of the
TV mode button.
8The TV’s volume changes
and the TV mode button
lights instead of the AUX
mode button
Control Amplifier Volume Control TV Volume
6.3 Replacement.book Page 7 Tuesday, November 7, 2006 11:56 AM

8
READING OUT THE REMOTE CONTROL CODES
These instructions explain how to check the remote control code you
put in the remote control when you set it up. Be sure to write them in
the spaces provided below.
Instructions Additional Information
1Press and hold the mode
button for the equipment
you want the remote to con-
trol. When all the other
mode buttons light up, let
go of the mode button - that
mode button should now be
flashing.
For example, hold the TV mode
button for a TV until all of the
other mode buttons light. When
you let go, the TV mode light
will flash.
2Press the POUND (#) but-
ton twice. The mode button
flashes the number for each
digit of the equipment
code, with a pause between
the groups of flashes. A
quick flash is for zero.
For example, if the code is 570,
the mode button flashes five
times, pauses, flashes seven
times, pauses, and flashes once
quickly.
For AUX mode, the first
group of flashes tells you
what the AUX mode
controls. A quick flash
(zero) before the three-digit
code is for a TV; one
regular flash is for a VCR
or DVD player; and two
flashes is for a tuner or
amplifier.
For example, if the TV code is
570, the AUX mode button
flashes once quickly, pauses,
flashes five times, pauses,
flashes seven times, pauses, and
flashes once quickly.
6.3 Replacement.book Page 8 Tuesday, November 7, 2006 11:56 AM
