DITEC DAB305 User manual

Swing Door Operator
Ditec DAB305
User Manual

Backtrack information: folder:Workspace Main, version:a720, Date:2022-03-10 time:05:57:33, state: Frozen
1020517-DImulti-4.0Issue 2022-04-222

Swing Door Operator
Ditec DAB305
User Manual
Original instructions
3Issue 2022-04-221020517-DImulti-4.0
EI

CONTENTS
5Presentation of notes and warning signs ....................................................................................
5
WARNING: Important safety instructions. It is important for the safety of persons to
follow these instructions. Save these instructions. ..................................................................
8Congratulations on your new automatic door! ........................................................................
8Electronic equipment reception interference ...........................................................................
8Environmental requirements ..........................................................................................................
8Product liability ...................................................................................................................................
9Service .....................................................................................................................................................
9Intended use .........................................................................................................................................
9Technical specification ......................................................................................................................
10How the Ditec DAB305 works ........................................................................................................
11Regular safety checks .........................................................................................................................
14General accessories ............................................................................................................................
14Safety accessories ................................................................................................................................
14Troubleshooting ..................................................................................................................................
14Other products from Ditec ..............................................................................................................
15Declaration of incorporation ..........................................................................................................
© All rights in and to this material are the sole property of ASSA ABLOY Entrance Systems AB. Copying,
scanning, alterations or modifications are expressly forbidden without the prior written consent of ASSA ABLOY
Entrance Systems AB. Rights reserved for changes without prior notice.
1020517-DImulti-4.0Issue 2022-04-224

Presentation of notes and warning signs
Various symbols and texts are used in this manual for easier understanding and identification.
Note!When you see Note!it contains useful advice and information to ensure correct and compliant
usage of the system.
Potential hazardous situation that can lead to either minor or severe injuries
or death and cause either minor or substantial property damage.
Potential hazardous situation that could lead to danger of electric shock and
cause serious injury or death.
WARNING: Important safety instructions. It is important
for the safety of persons to follow these instructions. Save
these instructions.
•Failure to observe the information in this manual may
result in personal injury or damage to equipment.
•To reduce the risk of injury to persons - use this oper-
ator with single or double pedestrian swinging or
folding doors only.
•The mains power supply shall be installed with protec-
tion and an all-pole mains switch with isolating capab-
ility of Category III, shall be installed according to local
regulations.
•Frequently examine the installation for imbalance
where applicable and signs of wear or damage to
cables, springs and mounting. Do not use if repair or
adjustment is necessary.
5Issue 2022-04-221020517-DImulti-4.0
EI

•Do not use the equipment if repair or adjustment is
necessary.
•WARNING: the drive shall be disconnected from its
power source during cleaning, maintenance and when
replacing parts.
•The operator can be used by children over 8 years of
age if they have been instructed by a person in charge
of their safety concerning use of the appliance in a safe
way and understand the hazards involved.
•The operator can be used by children 8 years of age
or younger if they are supervised by a person respons-
ible for their safety.
•The operator can be used by persons with impaired
physical, sensory or mental capacity if they have been
instructed by a person in charge of their safety concern-
ing use of the appliance in a safe way and understand
the hazards involved.
•Cleaning and user maintenance shall not be made by
children.
•Do not let children or anyone climb on or play with
the door or the fixed/remote controls.
•The doorset can be operated automatically by sensors
ormanuallybyactivators.Itcanalsobeusedmanually
as a door closer.
•Do not dash through a closing door.
1020517-DImulti-4.0Issue 2022-04-226

•This appliance may contain batteries that are only re-
placeable by skilled persons.
- The battery must be removed from the appliance
before it is scrapped
- The appliance must be disconnected from the sup-
ply mains when removing the battery.
- The battery is to be disposed of safely.
•Ensure that controls that can be set for a locked posi-
tion are only activated when there are no other per-
sons in the room.
7Issue 2022-04-221020517-DImulti-4.0
EI

Congratulations on your new automatic door!
ASSA ABLOY Entrance Systems AB has developed automatic doors for more than 50 years. State-of-
the-art technology and carefully tested materials and components provide you with a superior
product.
As with all other technical products, your automatic door requires periodic maintenance and service.
It is essential that you know your automatic door (system) and that you recognize the importance
of maintaining it in compliance with applicable standards for safety.
Your local Ditec-authorized representative is familiar with these standards, as well as applicable
local codes and Ditec recommendations for power-operated pedestrian doors. Service and adjust-
ments performed by your Ditec-authorized representative, will ensure safe and proper operation
of your automatic door unit.
Electronic equipment reception interference
The equipment may generate and use radio frequency energy and if not installed and used properly,
it may cause interference to radio, television reception or other radio frequency type systems.
If other equipment does not fully comply with immunity requirements, interference may occur.
There is no guarantee that interference will not occur in a particular installation. If this equipment
does cause interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Re-orient the receiving antenna.
•Relocate the receiver with respect to the equipment.
•Move the receiver away from the equipment.
•Plug the receiver into a different outlet so that equipment and receiver are on different branch
circuits.
•Check that protective earth (PE) is connected.
If necessary, the user should consult the dealer or an experienced electronics technician for additional
suggestions.
Environmental requirements
Ditec products are equipped with electronics and may also be equipped with batteries containing
materials which are hazardous to the environment. Disconnect power before removing electronics
and battery and make sure it is disposed of properly according to local regulations (how and where)
as was done with the packaging material.
Product liability
According to regulations, the following are the responsibility of the owner or caretaker of the
equipment
•that the equipment operates correctly, so that it gives sufficient protection in regard to safety
and health
•that the equipment is operated and regularly maintained, inspected and serviced by someone
with documented competence in the equipment and in applicable regulations
•that the provided “Service Log Book”and “Site Acceptance Test and Risk Assessment”documents
are kept available for maintenance and service records
•that inspection covers the emergency opening function (when applicable)
•that the closing force is appropriate for the door size on fire-approved door systems (when ap-
plicable).
1020517-DImulti-4.0Issue 2022-04-228

Service
Inspections should be done regularly by a trained and qualified person. The frequency of these in-
spections should be according to national regulations (or according to industry standard if there
are no national regulations). This is especially important when the installation concerns a fire-ap-
proved door or a door with an emergency-opening function. To extend the life of your investment
and ensure safe and reliable operation of the door, we recommend a minimum of 2 visits per year
or more, depending on usage and operating conditions. Environmental aspects shall also be con-
sidered.
Talk to your Ditec representative to learn more about our service offering.
Intended use
The Ditec DAB305 is an automatic swing door operator developed to facilitate entrances to buildings
and within buildings through swing doors. The Ditec DAB305 is an electromechanical operator ap-
proved for fire door applications. It is to be installed indoors where it is suitable for almost all types
of external and internal swing doors. This widely-used operator can be found on applications ranging
from handicapped-access in private homes to high-traffic retail operations.
The door is designed to offer continuous use, a high degree of safety and maximum lifetime. The
system is self-adjusting to the effects caused by normal variations in the weather conditions and to
minor friction changes caused by e.g. dust and dirt.
For escape in emergency situations the doorset is opened manually, but can also be opened with
motor under certain circumstances.
For installation and maintenance see Installation and Service manual 1020527.
Save these instructions for future reference.
Technical specification
ASSA ABLOY Entrance Systems ABManufacturer:
Lodjursgatan 10, SE-261 44 Landskrona, SwedenAddress:
Ditec DAB305Type:
100-240 V AC +10/-15%, 50/60 HzMains power supply:
Max. 300 WPower consumption:
IP20Class of protection:
Sound pressure:
Third party approvals from established certification organizations valid
for safety in use, see Declaration of Incorporation.
Approvals:
9Issue 2022-04-221020517-DImulti-4.0
EI

How the Ditec DAB305 works
The swing door operator Ditec DAB305 uses a DC motor and a gear-reduction system to drive an
arm system which opens the door. Closing power is provided by a motor and a closing spring. A
highly sophisticated electronic control unit uses a motor encoder and a microprocessor to control
the door’s movement.
To activate the operator you can use a manual activator (elbow switch) or an automatic activator
(radar device). It is also possible –where local standards allow –to activate the operator by just
pushing the door, if Push & Go is selected.
After the door has been activated it will open and stay open for a specified Hold Open Time (HOT).
When the HOT has elapsed the door will close.
The Ditec DAB305 can be set in three or four different modes, depending on programme selector
type, see table below.
In fully manual use (or in case of a power failure) the Ditec DAB305 acts as a normal door closer.
FunctionPosition
The door can be opened with the inner and outer manual and/or automatic ac-
tivators. The electric strike, if fitted, is open.
AUTO
Normal
position
The door is closed. The door cannot be opened with inner and outer activation
units. The door is locked if an electromechanical locking device has been fitted.
The door can be opened with a key switch (if fitted).
OFF
The door is held permanently open by the motor.OPEN
Passage from inside only. The door is normally locked if an electromechanical
locking device has been fitted. The door can only be opened with the inner activ-
ation unit and with a key switch (if fitted).
EXIT
1020517-DImulti-4.0Issue 2022-04-2210

Regular safety checks
To help you fulfill the national/international requirements and to avoid malfunction and risk for in-
juries, we have provided the following checklist.
Do not use the operator if repair or adjustment is necessary.
Disconnect mains power supply
14
when cleaning or other maintenance is to
be carried out.
If problem
occurs
Daily Action
Activate your operator and check visually, fastening and any damage of
•operator
1
•arm system
2
•cables
3
•control switch
4
•hinges
5
•door and glass
6
Also inspect your operator and check visually for
•sharp edges on the door leaf and door frame (if any)
7
•condition of door seals
8
•finger protection
9
•and finally that the complete door runs properly and closes slowly in a smooth way
Set the mode selector to OFF and check that the operator and electromechanical lock (if fitted)
work together. Also check that the lock
10
really secures the door.
Activate the manual activation units
11
, if any, and walk towards the door. Check that the door
has opened appropriately while you pass the entrance/exit.
Then proceed with the automatic activation units
12
in the same way.
Check the safety sensors
13
if any, by standing in the swing path and activate the operator. The
door must not hit you when opening nor when closing.
If you are unsure of which type of sensor you have, please contact your Ditec representative.
Set the programme selector in AUTO mode. Push the door manually
in escape direction and make sure that no object or function will
prevent the door from opening. Also make sure the escape route is
free for use.
By law, these tests must be performed regularly by trained personnel.
Doors in
escape
doors
Let the door close after an impulse ensuring nothing prevents the
door from closing and locking (if regulations require it).
Fire
doors
Take appropriate measures.=
Contact your Ditec representative.=
11Issue 2022-04-221020517-DImulti-4.0
EI

FUNCTION AND VISUAL INSPECTION
6
7
10
12
8
3
3
3
11
13
9
5
2
3
14
4
1
4
CLEANING
The best way to remove dust and dirt from the Ditec DAB305 is to use water and a soft cloth or a sponge.
Agentledetergentmay beused. To maintainthe qualityof thesurface treatment,the surfacesshould becleaned
once/four months period. The cleaning should be documented. To avoid damages to the profiles the
brushes/weather stripping must be vacuum-cleaned weekly.
•Do not expose windows, doors or profiles to alkalis. Both aluminium and glass are sensitive to alkalis.
•Do not clean with high pressure water. Operator, mode selector and sensor may be damaged and water
may enter the profiles.
•Do not use polishing detergent.
•Do not scrub with materials like Scotch-brite, as this will cause mechanical damage.
1020517-DImulti-4.0Issue 2022-04-2212

SIGNAGE
Keep clear
Automatic
door
Click!
Click!
800 mm
F
B
No entry
1100 mm
No entry
E
D
H
C
40 mm
G
K
A
ASSA ABLOY E. S. AB
Lodjursgatan 10 Landskrona Sweden Factory No. X Made in XXX
DESIGNATIONART.NO.
YEAR+MONTH
1008458
XXXXXXX XXXXXXXXXXXXX
TYPE
XXXXXXXXXX
TEMPERATURE
XXXXXXXXXXXXXXX
LOAD
XXXXX
PROD.VERSION
XXXXXXX
XXXXXX
XX/XX
Hz
PROJECT/SERIALNO.
XXX
1 2 3 4 5 6 7 8
XXXXXXX
W
XXXX
AVAC
SÜD
CLASSIFICATION DIN18650-1:2010
1002
CERTIFIERING
KONTROLL
xxxxxxx
xxxxxxx
If problem
occurs
Action
Check that all required signage is applied and intact. Mandatory indicates that the signage is re-
quired by European directives and equivalent national legislation outside the European Union.
Product label: Mandatory
A
Emergency break-out: Mandatory, if approved for escape route.
B
Door sticker. Mandatory, if applicable to highlight the presence of the glass (applied to all
glass sections that are moving).
C
Supervision of child (applied to both sides of the door): Mandatory according to national
regulations. Recommended, if the risk analysis shows use by children.
D
Operator designed for disabled people:
Recommended, if applicable (applied to both sides of the door).
E
Activation by disabled people: Recommended, if applicable.
F
Automatic door.
Only mandatory in GB.
G
No entry, identifying one-way traffic: Mandatory in GB, if applicable, not included in the
product.
H
Keep clear.
Only mandatory in GB.
I
Contact your Ditec service representative.=
13Issue 2022-04-221020517-DImulti-4.0
EI

General accessories
Your Ditec DAB305 can be further improved with the following add-ons (please contact your local
Ditec dealer for detailed description).
•Control switch
4
,see page 12
•Electrical lock
10
,see page 12
•Key switch
11
,see page 12
•Elbow switch
11
,see page 12
•Radar
12
,see page 12
•Wireless transmitters (not illustrated)
•Access control (not illustrated)
•Door stop (not illustrated)
Safety accessories
Even though the Ditec DAB305 is installed to comply with all applicable safety regulations, it is
possible to enhance safety/comfort with the following add-ons (please contact your local ASSA
ABLOY Entrance Systems company for detailed description).
•Safety sensors
13
,see page 12.
•Finger protection
9
,see page 12.
Troubleshooting
RemediesWhat´s wrong?
The door does not open
Change the setting of the mode selector.
(See page 10).
The motor does not start
Check that there are no objects in the detection zone if a sensor is
fitted.
Check the mains power and fuse in the building.
Unlock the mechanical locks.The motor starts but
door(s) will not open Check that nothing is jammed beneath the door.
Change the setting of the mode selector.
(See page 10).
The door does not close
Check that there are no objects in the detection zone if a sensor is
fitted.
Check that nothing is jammed beneath the door.
Check that there are no moving objects within 1-1.5 m (39"-59")
from the door if an automatic activation unit is fitted.
The door opens and closes
continuously
If the problem continues, please contact your Ditec representative.
Other products from Ditec
•Door Systems
•Sliding doors
•Automatic and manual activation units
1020517-DImulti-4.0Issue 2022-04-2214

We
ASSA ABLOY Entrance Systems AB
Lodjursgatan 10
SE-261 44 Landskrona
Sweden
declare under our sole responsibility that the type of equipment:
Ditec DAB305 Swing door operator
complies with the following directives:
2014/30/EU ElectroMagnetic Compatibility Directive (EMCD)
2006/42/EC Machinery Directive (MD) the following essential health and safety requirements:
1.1.2, 1.1.3, 1.2.1, 1.2.2, 1.2.3, 1.2.4.2, 1.2.6, 1.3.9, 1.4.3, 1.5.1, 1.5.2, 1.5.11, 1.7.2, 1.7.4, 1.7.4.1, 1.7.4.2. Tech-
nical documentation for safe integration is provided.
2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment
with the applicable amendments (RoHS)
Harmonized European standards which have been applied:
EN 61000-6-2:2005EN 60335-2-103:2015
EN ISO 13849-1:2015EN 61000-6-3:2007+A1:2011
EN 60335-1:2012/AC:2014+A11:2014+A13:2017
+A1:2019+A14:2019+A2:2019
EN 16005:2012/AC:2015
Other standards or technical specifications, which have been applied:
BVLBBR
IEC 60335-1:2010 ed. 5DIN 18263-4:1997
EN 1158:1997+A1:2002+AC:2006IEC 60335-2-103:2002 ed. 1/2011 ed. 2.1
EN 1634-1:2008
Certificate issued by a notified or competent body concerning the equipment:
RISE C900020
Relevant technical documentation has been compiled according to 2006/42/EC annex VII section B.
The manufacturing process ensures the compliance of the equipment with the technical file.
Relevant information about the partly completed machine will be handed over at a motivated and specified request
from national authorities.
The equipment must not be used until the final installed automatic door system has been declared in compliance
with the machinery directive 2006/42/EC.
The CE mark was first applied 2020-03-17.
Compilation of technical documentation applicable to the listed essential health and safety requirements:
Matteo Fino
Business Area PGA
Ditec S.p.A.
Largo U. Boccioni, 1 - 21040 Origgio (VA) - Italy.
Signed for and on behalf of ASSA ABLOY Entrance Systems AB by:
Position
President B.A. PGA
Signature
Matteo Fino
Date
2021-11-11
Place
Origgio
Declaration of incorporation
DoI 1020516-DIen-4.0
15Issue 2022-04-221020517-DImulti-4.0
EI

1020517-DImulti-4.0Issue 2022-04-2216

Automatismoperporteabattente
Ditec DAB305
Manuale dell'utente
Traduzione delle istruzioni originali
17Issue 2022-04-221020517-DImulti-4.0
IT

INDICE
19Presentazione di note e segnalazioni di avvertenza ................................................................
19
AVVERTENZA: Istruzioni di sicurezza importanti. È fondamentale attenersi alle presenti
istruzioni per salvaguardare la sicurezza delle persone. Conservare queste istruzioni. .
22Congratulazioni per l'acquisto della vostra nuova porta automatica! .............................
22Ricezione di interferenze da apparecchi elettronici ...............................................................
22Requisiti ambientali ...........................................................................................................................
22Responsabilità del prodotto ............................................................................................................
23Assistenza ..............................................................................................................................................
23Destinazione d'uso .............................................................................................................................
23Specifiche tecniche ............................................................................................................................
24Come funziona il Ditec DAB305 ....................................................................................................
25Controlli di sicurezza regolari .........................................................................................................
28Accessori generali ...............................................................................................................................
28Accessori di sicurezza ........................................................................................................................
28Risoluzione dei problemi .................................................................................................................
28Altri prodotti di Ditec ........................................................................................................................
29Dichiarazione di incorporazione ...................................................................................................
© Tutti i diritti su e a questo materiale sono di esclusiva proprietà di ASSA ABLOY Entrance Systems AB.
Copie, scansioni, ritocchi o modifiche sono espressamente vietate senza preventivo consenso scritto di ASSA
ABLOY Entrance Systems AB. Ci riserviamo il diritto di apportare eventuali modifiche senza preavviso.
1020517-DImulti-4.0Issue 2022-04-2218

Presentazione di note e segnalazioni di avvertenza
In questo manuale vengono utilizzati diversi simboli e testi per facilitare la comprensione e l'identi-
ficazione.
Nota: La dicitura Nota! è utilizzata per segnalare utili consigli e informazioni per garantire un uti-
lizzo corretto e conforme del sistema.
Situazione potenzialmente pericolosa che può condurre a infortuni leggeri o
più gravi, se non addirittura fatali, e causare danni leggeri o più pesanti alla
proprietà.
Situazioni potenzialmente pericolose che possono causare pericoli di folgo-
razione e infortuni gravi o fatali.
AVVERTENZA: Istruzioni di sicurezza importanti. È
fondamentale attenersi alle presenti istruzioni per
salvaguardare la sicurezza delle persone. Conservare
queste istruzioni.
•La mancata osservanza delle informazioni contenute
nel presente manuale può dare luogo a infortuni per-
sonali o danni all'apparecchio.
•Per ridurre i rischio di infortuni - utilizzare questo au-
tomatismo esclusivamente per porte pedonali singole
o doppie, a battente o a soffietto.
•L'alimentazione di rete deve essere installata dotata
di protezione con interruttore generale omnipolare
con capacità d'isolamento di Categoria III installato
nel rispetto delle normative locali.
19Issue 2022-04-221020517-DImulti-4.0
IT

•Controllare frequentemente l'installazione per indivi-
duare eventuali squilibri dove applicabile, oppure segni
di usura, danni a cavi e molle o ancora problemi di
montaggio.Non azionare se sono necessarie regolazio-
ni o riparazioni.
•Non utilizzare l'apparecchiatura se sono necessarie
regolazioni o riparazioni.
•AVVERTENZA: l'azionamento deve essere scollegato
dall'alimentazione durante la pulizia, la manutenzione
e in caso di sostituzione di componenti.
•L'automatismo può essere azionato da bambini di età
superiore a 8 anni, se adeguatamente istruiti da un
responsabile della loro sicurezza in termini di utilizzo
sicuro dell'apparecchiatura e piena comprensione dei
rischi correlati.
•L'automatismo può essere utilizzato da bambini di età
anche inferiore a 8 anni, se adeguatamente tenuti
sotto controllo da un responsabile della loro sicurezza.
•L'automatismo può essere utilizzato da persone con
capacità fisiche, sensoriali o mentali ridotte se adegua-
tamente istruite da un responsabile della loro sicurezza
in termini di utilizzo sicuro dell'apparecchiatura e
piena comprensione dei rischi correlati.
•La pulizia e la manutenzione a cura dell'utente non
devono essere eseguite da bambini.
•Impedire a chiunque, bambini compresi, di arrampi-
carsi sulla porta o di giocare con essa o con i comandi
fissi o a distanza.
1020517-DImulti-4.0Issue 2022-04-2220
