DNP DS?RX1 Use and care manual
Version1.1.0
DS‐RX1
PrinterFirmwareUpdateManual
DSRX1FirmwareUpdateManual
VersionNumber:1.10
2
Installing 2x6 Double Cut Software
Contents
Installation Flow Chart......................................................................................................................................3
Run the DS-RX1 Version Up Tool execute file (*.EXE).......................................................................4
1.Starting the Update.................................................................................................................................4
2.Finishing the update...............................................................................................................................5
3.Reboot the computer..............................................................................................................................6
Driver Removal..................................................................................................................................................7
4.Remove the driver..................................................................................................................................8
4.Turn off the RX1 Printer.......................................................................................................................11
5.Reboot the computer.............................................................................................................................11
Installing the New Driver.................................................................................................................................12
1.Open the driver package.......................................................................................................................12
6.Finish Install.........................................................................................................................................14
7.Turn on the Printer...............................................................................................................................15
8.Reboot the computer............................................................................................................................15
Configuring the New Driver............................................................................................................................15
4.Enable2InchCut.................................................................................................................................16
Printing with 2 Inch Cut...................................................................................................................................17
DSRX1FirmwareUpdateManual
VersionNumber:1.10
3
Installation Flow Chart
DSRX1FirmwareUpdateManual
VersionNumber:1.10
4
Update the RX1 Firmware
***Note, your computer must have already been connected to an RX1 Printer and the driver
installed. If it has not, please skip to “Installing the RX1 Driver”, then come back to this section.
To begin with, turn on the printer and connect it to the host computer with the USB cable.
Check that there is paper and ribbon set in the printer, the cover is closed, and there are no errors
(the printer LED should be green).
Run the DS-RX1 Version Up Tool execute file (*.EXE).
When running DS-RX1 Version Up Tool, if there are multiple printer ports, the following printer
select window will open.
Select the appropriate printer, and click “OK”.
1. Starting the Update
On the DS-RX1 Version Up Tool window, click the “START” button to begin the update.
DSRX1FirmwareUpdateManual
VersionNumber:1.10
5
When you click “START” and start the update, the window display will change to the following, and you
can check the update progress status.
！Notice！
While updating, do not disconnect the USB cable or
turn the power off.
Also, do not start or run other software at the same
time.
2. Finishing the update
When all the updates are complete, the window display will look like the
following. Also, the printer LED will revert from flashing green to green.
Confirm the New Firmware and New CWD Ver boxes are checked, and click the “END” button
or close the window to end DS-RX1 Version Up Tool.
DSRX1FirmwareUpdateManual
VersionNumber:1.10
6
3. Reboot the computer
DSRX1FirmwareUpdateManual
VersionNumber:1.10
7
Driver Removal
***Before removing the printer-driver, shut down all other applications.
Also, in the “Devices and Printers” window, select the printer icon of the printer you want
to remove, check the bottom of the window that there are no documents in queue, and start
removal of the driver.
1.
Select “Start”, “Devices and Printers”.
2.
From the “Devices and
Printers” window, select the DS-RX1 printer, display the
pull-down menu with the right click, and click on “Remove device”.
DSRX1FirmwareUpdateManual
VersionNumber:1.10
8
3. “Are you sure you want to remove this device?” appears, click on “Yes”.
4. Remove the driver.
5. After the DS-RX1 printer has been removed, select another printer (for example:
Fax), and click on “Print server properties” in the menu bar.
6. When the Print Server Properties window appears, click on the Drivers tab. From
the list of installed printer drivers, select “DS-RX1”, and click the “Remove”
DSRX1FirmwareUpdateManual
VersionNumber:1.10
9
button.
7. When the Remove Driver and Package window appears, select “Remove driver
only”, and click on ”OK” button.
8. When the Print Server Properties confirmation window appears, click on the “Yes”
button.
DSRX1FirmwareUpdateManual
VersionNumber:1.10
10
1. Uninstalling a Driver Package
1. Select “Start”, then “Control Panel”, and open the control panel. Click on
“Uninstall a program” in the control panel
2. When the “Uninstall or change a program” window appears, double-click on
“Windows Driver Package - Dai Nippon Printing DS-RX1 (mm/dd/yyyy x.x.x.x)”
(mm/dd/yyyy = the date, x.x.x.x = the version).
DSRX1FirmwareUpdateManual
VersionNumber:1.10
11
3. When the “Uninstall Driver Package” window appears, click on “Yes”. The
Uninstall will be completed.
4. Turn off the RX1 Printer.
5. Reboot the computer.
6. Do not turn on the printer until the new driver has been installed.
DSRX1FirmwareUpdateManual
VersionNumber:1.10
12
Installing the New Driver
***Note if Windows 7 DO NOT CONNECT THE PRINTER until the driver is
installed.
1. Open the driver package
Start Explorer, and click on the corresponding drive. (If the AutoPlay
function is on, select “Open folder to view files - using
Windows
Explorer”.)
Select the following folders from the accessory CD.
Drive of CD:\DS-RX1_Driver\English\7
In the selected folder, double click on the file “DriverInstall.CMD”. (Depending on
your operating environment, the .CMD extension may not be shown.)
DSRX1FirmwareUpdateManual
VersionNumber:1.10
13
The best Driver Package Installer for your operating system (32 or 64 bit) will
automatically be selected.
2. If the User Account Control dialog appears, click on “Yes”.
3. When the “Welcome to the Device Driver Installation Wizard!” window appears, click
on “Next>”.
DSRX1FirmwareUpdateManual
VersionNumber:1.10
14
4. If the Windows Security confirmation window appears, click on “Install this driver
software anyway”.
5. This starts the Driver Package installation. Please wait until it is complete. When the
“Completing the Device Driver Installation Wizard” window appears,
6. Finish Install
DSRX1FirmwareUpdateManual
VersionNumber:1.10
15
7. Turn on the Printer
8. Reboot the computer
Configuring the New Driver
1.
Select “Start”, “Devices and Printers”.
2. SelectPrinterPreferences
3. Clickthe“AdvancedTab”
DSRX1FirmwareUpdateManual
VersionNumber:1.10
16
4. Enable2InchCut
5. ClickOK.
DSRX1FirmwareUpdateManual
VersionNumber:1.10
17
6. ClickOk
Printing with 2 Inch Cut
1. OpenPicture
DSRX1FirmwareUpdateManual
VersionNumber:1.10
18
2. Select(6x4,6x8orPR4x6)
3. Print
