Dogtra 3500X User instructions

3500X
MAKE EVERY DOG EXCEPTIONAL
Code Setting Guide
DISCLAIMER OF OTHER WARRANTIES
THE FOREGOING ORIGINAL AND EXTENDED WARRANTIES ARE PROVIDED IN LIEU OF
ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED. DOGTRA DISCLAIMS ANY
IMPLIED WARRANTIES INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Limitation of Remedies
Dogtra’s liability is limited to the cost of repair or replacement of the Dogtra product under the
Original Warranty or Extended Warranty. Any claim or action to enforce the Original and/or
Extended Warranties must be commenced within thirty (30) days of such warranty’s expiration
for your product. Dogtra will not be liable for any indirect, incidental, special, consequential, or
similar damages based on breach of warranty, breach of contract, negligence, strict tort, or any
other legal theory related to Dogtra and its products. Damages that Dogtra will not be responsible
for include, but are not limited to: loss of income or profits; loss of revenue or savings; loss of use
of the product or associated products; cost of any substitute products or services; inconvenience,
downtime, or any other time; loss of goodwill; claims of third parties including customers; and
damage to property.
Legal Rights May Vary By State or Jurisdiction
The Original and Extended Warranties give You specific legal rights, and You may also have
other rights which vary by state or jurisdiction. Some states or jurisdictions do not allow certain
limitations of implied warranties or of incidental or consequential damages or other remedies, so
certain of the foregoing limitations may not apply to You.
If any portion of the Original Warranty or Extended Warranty is held by a court to be invalid or
unenforceable, the remaining portions of such warranties shall remain in full force and effect
and shall in no way be affected or invalidated, and the invalid or unenforceable portion shall be
modified so as to most nearly achieve the intent of the Original Warranty or Extended Warranty.
Product Registration
Dogtra recommends that customers register their products as soon as possible after purchase.
Product registration will facilitate any future warranty service. You may also receive useful
information and updates about your existing and future Dogtra products. To register your product,
visit www.dogtra.com/product-registration. If your product is not registered with Dogtra, You
will be required to provide a receipt or other proof purchase (as provided above) to qualify for
warranty service.
How to Obtain Warranty Service
Should your Dogtra product require warranty service, please contact Customer Service by phone
or email for a warranty evaluation (see below for contact information). Upon approval of your
warranty work, Dogtra will repair or replace (at Dogtra’s election) your product without charge
for labor or parts. You are responsible for shipping, including cost, of your product to Dogtra for
warranty service. Dogtra will handle shipping, including cost, of the repaired or replaced product
back to customers in the USA. Dogtra will not be responsible for shipping, including cost and/or
applicable taxes or fees, for products sent outside the USA. Such costs, taxes, or fees will be borne
by the customer.
Dogtra Customer Service | 22912 Lockness Avenue, Torrance, CA 90501
[phone] [e-mail] Mon – Fri, 8:00 AM to 4:30 PM (PST)
© 2020 Dogtra. All rights reserved. Ver.1

Code Setting the Transmitter
Before coding the transmitter, determine the setup you would like to have.
Depending on where you want the 1st dog coded, the following buttons will
need tobe used:
1st dog on front: use front buttons to code
1st dog on side: use side buttons to code
Depending on if you want a 1-dog or 2-dog setup:
1-dog setup: press Nick/Constant button to code
2-dog setup: press Pager button to code
1. Hold the on/off button on the transmitter until there is a rapid green LED
light on the transmitter and the OLED screen shows "Setting Mode."
2. To code the 1st dog on the front with a 1-dog setup, press the Nick/Constant
button on the front. To code the 1st dog on the front with a 2-dog setup,
press the Pager button on the front.
3. To code the 1st dog on the side with a 1-dog setup, press the Nick/Constant
button on the side. To code the 1st dog on the side with a 2-dog setup,
press the Pager button on the side.
Coding 1st Dog Position
1. Turn the transmitter on by pressing the on/off button and set the Rheostat
Dial to 1.
2. With the receiver turned off, hold down the on/off button on the receiver
until the LED light begins to rapidly blink green.
3. While the green LED is rapidly blinking on the receiver, press the Pager
button and Tone button on the front or side (depending where the 1st dog
is coded) simultaneously. The LED light on the receiver will blink every 4
seconds when coding is complete.
Coding 2nd Dog Position
For 2-dog use, repeat steps 1 and 2 above. While the green LED is
rapidly blinking on the receiver, press the Pager button and Tone button
simultaneously on the opposite side of where the first dog was coded. The
LED light on the receiver will blink every 4 seconds when the coding is
complete.
EXTENDED LIMITED WARRANTY
For Certain Dogtra Products Purchased from Dogtra Authorized Dealers
1+1 Year Extended Warranty
Except as otherwise provided, Dogtra warrants to the original retail purchaser (“You”) that your
Dogtra product shall be free of defects in materials and workmanship for a period of one (1) year
from the date of purchase (“Original Warranty”). As a special promotion, Dogtra further warrants
that your Dogtra product shall be free of defects in materials and workmanship for an additional
one (1) year from the date that your original warranty expires (“Extended Warranty”). The Original
and Extended Warranties cover the cost of repair (parts and labor) or replacement (if repair is not
feasible) of a defective Dogtra product during said warranty periods. For such repaired or replaced
products, the remaining portion of the warranty periods, or ninety (90) days, whichever is longer,
shall apply. Dogtra, at its sole discretion, shall determine whether to repair or replace a product
covered by the Original Warranty or Extended Warranty.
Warranty Conditions
The Original and Extended Warranties are not transferrable and apply to your Dogtra product only if:
(1) You are the original retail purchaser of the product,
(2) You bought the product from a Dogtra Authorized Dealer, and
(3) You present a receipt or other proof of purchase showing a valid purchase date, the name and
address of the Dogtra Authorized Dealer, and the purchased product identified by model and/or
serial number.
Warranty Exclusions
The Original and Extended Warranties do not cover damage, loss, or deterioration to your Dogtra
product caused: by misuse, neglect, abuse, or other improper handling of the product; by failure
to follow use or care instructions; by use of the product for other than its intended purpose; by
accident or natural forces such as fire or flooding; or by normal wear and tear such as scratches to
the product surface.
The Original and Extended Warranties also do not cover Dogtra products that: are purchased from
non-authorized dealers; are purchased outside of the United States or Canada; have been damaged
during shipment (even if Dogtra paid or arranged for shipping); have been modified or tampered
with in any manner; are opened or repaired by anyone other than Dogtra; or have serial numbers
that have been altered or defaced.
Sole Warranties
The Original and Extended Warranties are the only warranties offered by Dogtra for your Dogtra
product during said warranty periods. Other than the Original and Extended Warranties, Dogtra
makes no other representations or warranties whatsoever regarding its products, whether oral or in
any product manual, on any packaging, on any website, or in any other written material. No dealer
of Dogtra products, nor any employee or agent of Dogtra, is authorized to make any additions,
changes, or extensions to the Original Warranty or Extended Warranty. Dogtra, at its sole discretion
and at any time, reserves the right to modify the Original and/or Extended Warranties.
DOGTRA EXTENDED PRODUCT WARRANTY
