DOLD INFOMASTER SMS RP 5812 User manual

122.02.13 en / 313
Monitoring Technique
INFOMASTER SMS
SMS-Telecontrol Module
RP 5812
Your Advantage
•Easy remote control of unit via mobile phone
•Easy configuration of unit via mobile phone
•SMS-status request of all i/p’s - and o/p’s via configurable shortcuts
•SMS text messages via customers SIM card
•Cyclic SMS message with configurable time interval (watchdog function)
Features
•According to directive 1999/5/EC (RTTE) for radio equipment and
telecommunications terminal equipment
•4 digital inputs and 4 relay outputs
•Variant RP 5812/001 with 2 digital and 2 analogue inputs and
1 analogue - and 2 relay outputs
•Auxiliary voltage DC 24 V
•DC 24 V digital inputs
•Automatic SMS messages for status changes
•Quad-Band GSM-Module for 850, 900, 1800 and 1900 MHz
(GSM = Global System for Mobile)
•Pin protection of SIM card
•Caller password protection against unauthorised access
•User Dialogue language for: German, English or French
•Configurable authorization levels for up to 16 users
•Assignment of different I/O’s to different users
•Automatic sending of SMS when digital inputs change state
I.e. come on or go off or both (on rising edge or falling edge)
•Automatic sending of SMS when analogue inputs
- exceed preset lower and upper limits or
- when signal is within the preset window
- and when the signal returns to good state
•Adjustable
- Hysteresis for analogue inputs
- Time delay for each input
- Repeat time for SMS-transmitting
- Time delay for output status after starting the unit
- Time delay for activation of the output
•SMS for device status to the system administrators
•SMS-counter to monitor the remaining account
•No interruption of operation after Voltage failure due to integrated
Li-Ion battery backup 24Hours
•Compact width: 70 mm
0265719
Approvals and Markings
Application
•Remote monitoring control and operation of
- Machinery and installations for industry and building automation.
- Small power plants
- Remote buildings
- Unmanned production plants
- Air-conditioning and refrigeration systems
- Heating systems
- Elevators and escalators
- Alarm systems, burglar alarms
- Smoke, fire and gas warning systems
- Doors, gates and windows
- Flood warning systems
•Level alarm in pumping stations
•Remote shut down of rental equipment when payment overdue
•Level monitoring in silos, tanks, etc.
Circuit Diagrams
M9987_b
0403 13 14
GND
I0
A1
(+)
AGND AGND
AGND
AI1
I1
A2
I0 AGND AGND
AGND
(+)
AO0
0...10V
0...10V0...10V
GND
I1
04
03
14
13
AI0
AO0
AI0
(+) AI1 (+)
RP 5812S, RP 5812PS, RP 5812PC
RP 5812S/001, RP 5812PS/001, RP 5812PC/001
M9985_c
0403 13 14 23 24 33 34
A1
(+) A2
GND
I3
I2
I1
I0
I0 I2
GND
I1 I3
04
03
14
13
24
23
34
33
All technical data in this list relate to the state at the moment of edition. We reserve the right
for technical improvements and changes at any time.

222.02.13 en / 313
Settings
Settings
Safety remarks
 • The SMS-Telecontrol module must not be used for safety relevant
control functions due to signal availability.
•The use of the SMS-Telecontrol module in medical rooms must
be evaluated thoroughly as medical equipment such as pacema-
kers etc may react to the radiofrequency of the SMS-Telecontrol
module. Also be aware that the radio frequency of the SMS-Tele-
control module may disturb the function of insufficiently protected
PCs, monitors and other electronic equipment.
•Delays in the transmission of I/O status may take place due to
network problems.
General settings
•If the SMS-Telecontrol module is disconnected for a long period, (e.g. as
when delivered) the battery must be charged. To do this the SMS-Tele-
control module needs to be connected to the supply Voltage for up to 6 h.
Only after this time is correct operation is possible.
Attention
On delivery the battery is disconnected. Before the batteries can
be charged the connection has to be made by changing the slide
switch at the bottom edge of the unit to the ON position.
•On first activation a SIM card with a pin code of 1234 has to be inserted.
This pin can then be changed by an SMS command. After pin change
only the SIM card with the changed pin can to be used. If the pin number
on the SIM card is different to the one in the configuration the SIM card
may be locked when connecting to the GSM network. A locked SIM card
can be unlocked by placing it in a mobile Phone and entering the PUK
or Master pin.
•If the Reset/Default Konf. button on the front of the unit is pressed for 3-4
seconds while the unit is powered up, the SMS-Telecontrol module is reset.
This means, that the any connection to an SMS network is disconnected
and reconnected. If the reset button is pressed for more than 5 sec the
configuration is reset to default and the unit makes a factory reset.
•Due to the internal battery back up, the function of the SMS-Telecontrol
module is still available even if the power supply is disconnected for up
to 24 hours.
Attention
It is your responsibility as an end user to dispose old batteries
correctly. Of course, you may return replaced batteries to us.
Technical Data
Input
Auxiliary Voltage A1-A2 (UH): DC 24 V,
Nominal consumption A1-A2: max. 4.5 W at DC 24V
Inputs (digital)
RP 5812: 4 x i/p; I0 ... I3
DC 24 V with galvanic separation
RP 5812/001: 2 x i/p; I0 ... I1
DC 24 V with galvanic separation
Inputs (analogue)
RP 5812/001: 2 x i/p; AI0 ... AI1
DC 0 .. 10 V resolution 100 mV
Indication
green LED „UH“: on when supply connected
yellow LED „GSM“
off: SMS-Telecontrol module is off
flashes 600ms on / 600 ms off: SMS-Telecontrol module searches for
available network and logs on
flashes 75ms on / 3s off: SMS-Telecontrol module is registered on
GSM network.
on: Data transmission in GSM network
is taking place
yellow LED „Status“
off: Configuration correct,
SMS-Telecontrol module is working
correctly
flashes: Indication of failure code, see table
“Fault indication by flashing code”
on: SMS transmission take place
Set up procedure of SMS-Telecontrol module
•Wire the i/p’s- o/p’s and the auxiliary supply connections
•Press the SIM eject button (use pen tip), insert the SIM-card with the
Preconfigured pin 1234 into the SMS-Telecontrol module
•Power up the SMS-Telecontrol module
•Send the necessary configuration commands via text to the
SMS-Telecontrol module (see manual)
Examples for configuration and communication of the SMS module
via SMS:
Demand:
The SMS module located in the pump station, should be named
“Pump station“ and then answer with this name.
The following SMS is created and sent:
CFGDN§Pump station#
Demand:
Input I0 shall send an SMS on the negative edge (turning off)
of the input signal
The following SMS is created and sent:
DISEND§0§FE#
Demand:
Input I0 shall be named „ Pump“
The following SMS is created and sent:
DISYMB§0§Pump#
Demand:
The status „0“ of input I0 shall be named „ Pump stopped“
The following SMS is created and sent:
DITXTLO§0§Pump stopped#
An SMS is generated and sent by the SMS module caused by a defective
Pump,it appears as follows:
Answer: „Pump station:Pump stopped“
Demand:
The current status of the (2 or 4) digital inputs can be called up.
The following SMS is created and sent:
?DIALL#
Answer: „Pump station:Pump stopped; Level to high“
and for the 2 analogue inputs:
and to call up the 2 analogue inputs if previously configured for level and
motor temperature
?AIALL#
Answer: „Pump station: Level:180cm; pump temp: 85°C“
Safety notes
Attention: •It is important, that the connected voltage of the analogue
inputs and tha analogue outputs of the variant /001 are no
larger that are spezified in the Technical Data.
 • The Li-Ion battery can not be changed by the user.
Is there a need to replaced the battery please send the
device back to the manufacturer.
• Please note, before using, the other safety instructions of
the manual INFOMASTER SMS-Telecontrol module RP 5812.

322.02.13 en / 313
Standard Types
RP 5812S DC 24 V
Article number: 0065147
•Auxiliary Voltage UH: DC 24 V
•Inputs: 4 digital inputs DC 24 V
•Outputs: 4 relay outputs N/O contacts
•Width: 70 mm
RP 5812S/001 DC 24 V
Article number: 0065148
•Auxiliary voltage UH: DC 24 V
•Inputs: 2 digital inputs DC 24 V
2 analogue inputs 0 ... 10 V
•Outputs: 2 relay outputs N/O contacts
1 analogue output 0 ... 10 V
•Width: 70 mm
Outputs
Contacts:
RP 5812: 4 N/O contacts
RP 5812/001: 2 N/O contacts
Thermal current Ith : 2A
Switching capacity IEC/EN 60947-5-1
to AC 15: 3 A / AC 230 V (secondary voltage)
Electrical life
to AC15 at 1A / 230V: ≥1,5 x 106switch. cycl. IEC/EN 60 947-5-1
Max. fuse rating: 4A gL IEC/EN 60947-5-1
Mechanical life: ≥30 x 106switching cycles
Output (analogue)
RP 5812/001: AO0
DC 0..10V resolution 100 mV
GSM
Frequency band: 850 / 900 / 1800 / 1900 MHz
Power class: GSM 850 / 900 MHz: 4 (2 W)
GSM 1800 / 1900 MHz: 1 (1 W)
SIM-card: 1.8V and 3 V SIM cards are supported
Aerial jack: SMA (male)
General Data
Nominal operating mode: continuous operation
Temperature range: 0 ... + 40°C
Clearance and creepage distance:
Rated impulse Voltage /
pollution degree: 4 kV / 2 IEC 60 664-1
EMC
Electrostatic discharge: 8 kV (air) IEC/EN 61 000-4-2
HF irradiation: 10 V / m IEC/EN 61 000-4-3
Fast transients: 2 kV IEC/EN 61 000-4-4
Surge
between
wires for power supply: 1 kV IEC/EN 61 000-4-5
wire and ground: 2 kV IEC/EN 61 000-4-5
Interference suppression: Limit value class B EN 55011
Degree of protection:
Housing, Cover IP 30 IEC/EN 60 529
Terminals IP 20 IEC/EN 60 529
Housing: thermoplastic with VO behaviour acc. to
UL subject 94
Vibration resistance: Amplitude 0,35 mm
Frequency 10 ... 55 HzIEC/EN 60 068-2-6
Climate resistance: 00 / 040 / 04 IEC/EN 60 068-1
Terminal designation: EN 50 005
Wire connection: DIN 46 228/-1/-2/-3/-4
fixed screw terminal (S): 0,2 ... 4 mm2solid or
0,2 ... 1,5 mm2stranded wire with sleeve
plug in screw terminal (PS) : 0,1 .. 2,5 mm2solid or
0,1 .. 1,5 mm2stranded wire with sleeve
plug in cage clamp terminals (PC): 0,2 .. 2,5 mm2solid or
0,2 .. 1,5 mm2stranded wire with sleeve
Wire fixing:
fixed screw terminal (S),
plug in screw terminal (PS): Captive plus-minus-terminal screws M2,5
with self raising terminal box
plug in cage clamp terminals (PC): spring terminal for direct
plug in of wires,
screw driver 0,6 x 3,5 for
spring releasing
Mounting: DIN rail IEC/EN 60175
Weight: 216 g
Dimensions
Width x height x depth: 70 x 95 x 80 mm
Technial Data
Ordering Example
RP 5812 _ _ / 0 0 _ AC/DC 19 ... 30 V
Auxiliary Voltage
Inputs / Outputs
0: 4 digital inputs,
4 relay outputs
1: 2 digital inputs,
2 analogue inputs
2 relay outputs,
1 analogue outputs
Type of Terminals
S: Terminal blocks fixed,
with screw terminals
PC (plug in cage clamp):
Plug in terminal blocks with
cage clamp terminals
PS (plug in screw):
Plug in terminal blocks with
screw terminals
Type

422.02.13 en / 313
Accessories
OA 5810/900: GSM-aerial, 90° angle
Article number: 0062212
OA 5810/901: GSM magnetic foot areal with 2,5 m
connecting lead
Article number: 0062213
Fault indicated by Flashing Code
The current state of the SMS-Telecontrol module is indicated by the flashing
code on the status LED.The number of flashing pulses followed by a longer
space relates to the failure code in the following table.After the longer space
the flashing cycle is repeated until the state on the unit changes.
State LED Description
OFF No status for indication, normal operation
ON SMS transmission
2 * flashes Internal system failure,
please contact the manufacturer
3 * flashes
Invalid configuration. When this failure occurs, the unit
tries to reset the configuration to factory settings followed
by a device test. If the failure remains, please contact
manufacturer.
4 * flashes
No access on SIM-card
Cause: no SIM-card inserted or
invalid PIN for inserted SIM card
5 * flashes
No GSM network available
Cause:insufficient radio signal, aerial placed
in a poor location.
6 * flashes
In the configuration, the service centre for SMS transmis-
sion is not yet defined.
Cause:The CFGINT command sequence SMS has not
been sent to the module
7 * flashes
No administrator for using are defined.
No user administrator is defined
Cause:The CFGINT command sequence SMS has not
been sent to the module
LEDs for each I/O on the front of the unit indicate the status of the in- and
outputs.
E. DOLD & SÖHNE KG • D-78114 Furtwangen
e-mail: dold-relays @dold.com • internet: http://www.dold.com
• POBox1251•Telephone(+49)77 23 / 654-0 •Telefax (+49) 77 23 / 654-356
