Please read this instruction manual carefully before installation and first
use, and store it in a safe place. If you pass on the product to another
person, hand over this instruction manual along with it.
Contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Target group for this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
7 Installing and connecting the DC kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8 Using the DC kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
9 Maintaining and cleaning the DC kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
10 Rectifying faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
11 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
12 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
DC-Kit1--IO-16s.book Seite 5 Dienstag, 21. März 2017 2:05 14

EN
Explanation of symbols DC-Kit1
6
1 Explanation of symbols
D
!
A
I
2 General safety instructions
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences and excess voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
2.1 General safety
!WARNING!
•Observe the safety instructions in the installation and operating man-
ual for the components supplied and your Dometic roof air
conditioner.
•Use the device only as intended.
•People whose physical sensory or mental capacities prevent them
from using this device safely should not operate it without the
supervision of a responsible adult.
•Electrical devices are not toys!
Always keep and use the device out of the reach of children.
DANGER!
Safety instruction: Failure to observe this instruction will cause fatal or
serious injury.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
DC-Kit1--IO-16s.book Seite 6 Dienstag, 21. März 2017 2:05 14

EN
DC-Kit1 General safety instructions
7
•Children must be supervised to ensure that they do not play with the
device.
•Maintenance and repair work may only be carried out by qualified
personnel who are familiar with the risks involved and the relevant reg-
ulations.
2.2 Safety when installing and repairing
!WARNING!
•Installing and repairing the device may only be performed by qualified
personnel who are familiar with the risks as well as the guidelines and
safety precautions to be applied.
2.3 Safe operation
!
•Only operate the system if you are certain that all the housings and
cables are not damaged.
•The 12 V connection cables are designed for high levels of current. Do
not make any changes to the cable. If necessary, get a specialist to do
this for you.
•Make sure the air inlets and outlets of the device are not covered.
•Ensure good ventilation. The inverter produces dissipated heat which
has to be diverted.
•Always disconnect the power supply when working on the device.
WARNING!
Note the following basic safety information when using electrical
devices to protect against:
•Electric shock
•Fire hazards
•Injury
DC-Kit1--IO-16s.book Seite 7 Dienstag, 21. März 2017 2:05 14

EN
Scope of delivery DC-Kit1
8
3Scopeofdelivery
Before starting the system, check that all the parts belonging to the scope of delivery
are present.
4 Target group for this manual
The installation information in this manual is only intended for qualified personnel at
workshops, who are familiar with the guidelines and safety precautions to be applied
during the installation of vehicle accessory parts.
All other chapters are intended for the users.
5 Intended use
The DC-Kit1 extension kit (rwef. no. 9100300003) is suitable for equipping the
CA1000 and FJ1100 Dometic roof air conditioner for 12 V g driving operation.
Quantity Description Ref. number
1 Charging current distributor ECL-76 9600000483
1 Inverter with priority circuit PP1002 9600000022
1 Sensing cable for CA1000 4441300084
1 Connection cable
Black supply line (16 mm², 1.5 m long)
Red supply line (16 mm², 1.5 m long)
9600000270
1 Sensing cable for FreshJet/FreshLight 4441300221
1 Inverter adapter 9103530084
1 Remote control for the inverter MCR9 9600000091
1 Installation and operating manual 4445101952
DC-Kit1--IO-16s.book Seite 8 Dienstag, 21. März 2017 2:05 14

EN
DC-Kit1 Technical description
9
6 Technical description
The DC-Kit1 extension kit enables Dometic roof air conditioners to be used in vehi-
cles with 12 Vg. The extension kit consists of the following components:
•The ECL-76 charging current distributor with low voltage protection regulates
the power distribution between the starter battery, supply battery and light-
machine. This prevents the battery and the electronics in the vehicle from over-
loading.
•The PP1002 inverter supplies the roof air conditioner with the required input
voltage of 230 Vw. The inverter generates the 230 V input voltage from the 12 V
on-board electricity supply in the vehicle.
The accompanying remote control can switch the inverter on and off.
The integrated priority circuit can be used for distributing the voltage in the
vehicle with two available power sources. If a mains voltage and voltage created
by the inverter (vehicle battery) are both connected to the device, the use of the
mains voltage has priority. If the only voltage available is that generated by the
inverter, the power supply from the battery is used. This ensures that the limited
power of the battery is not used unnecessarily.
•The inverter adapter ensures that the condenser fan for the roof air conditioner
can control the speed.
7 Installing and connecting the DC kit
A
A
NOTICE!
The DC kit may only be installed by a qualified workshop.
The following information is intended for specialists who are familiar with
the guidelines and safety precautions to be applied.
NOTICE!
Observe the information in the installation and operating manuals when
installing the components supplied
•PP1002 inverter
•Inverter adapter
•MCR9 remote control
•ECL-76 charging current distributor
and for your Dometic roof air conditioner
•CA1000
•FJ 1100
DC-Kit1--IO-16s.book Seite 9 Dienstag, 21. März 2017 2:05 14

EN
Installing and connecting the DC kit DC-Kit1
10
Note the following safety instructions during installation:
A
Observe the following safety instructions for the electrical connections:
A
Observe the following instructions when selecting the location for installing the
components:
•Make sure the cables are of the correct length.
•Choose a well-ventilated installation location near the supply battery.
7.1 Preparing the installation
➤Disconnect the following voltage supplies in the vehicle:
– Positive battery terminal
– External voltage supply
NOTICE!
•Note the location of wiring harnesses, wiring and other components
within the installation area.
•Install the DC kit using the following instructions. Improper installa-
tion of the DC kit can put the safety of the user at risk and lead to
irreparable damage to the DC kit or other devices.
•Disconnect all power supply lines to the individual components and
the roof air conditioner.
NOTICE! Risk of short circuit!
•First, disconnect the 230 V external power supply to the caravan.
•Disconnect the earth connection to the supply battery.
•Disconnect the connection to the starter battery.
•If you have to feed cables through metal walls or other walls with
sharp edges, use ducts or tubes to prevent damage.
•Do not lay cables which are loose or bent next to electrically
conductive material (metal).
•Fasten the cables securely.
•Ensure the 12 V cables are especially well-protected.
•Check whether you need to fit any additional fuses.
•Do not pull on the cables.
•Do not lay the 230 V mains cable and the 12/24 V DC cable in the
same duct.
•Lay the cables so that they cannot be tripped over or damaged.
