Dometic is a customer driven, world-leading provider of innovative
leisure products for the automotive, caravan, motorhome
and marine markets. Dometic offers a complete range of air
conditioners, refrigerators, awnings, cookers, sanitation systems,
lighting, windows, doors and other equipment that makes leisure
life more comfortable away from home.
Dometic also provides refrigerators for specic use in hotel
rooms, offices, and for storage of medical products and wine
along with comfort products designed for the over-the-road truck
market. Dometic’s products are sold in almost 100 countries
and are produced mainly in Dometic’s own production facilities
around the world. Dometic has more than 4,400 employees.
Dometic Corporation
P.O. Box 15299 • Richmond, VA 23227
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Patents:
7,171,822 • 7,234,315 B2 • 7,140,192 • 7,316,119 • 7,237,397 B2
L-2443 Rev. 20090203 ISO 9001:2000

Dometic Battery--Powered Auxiliary Air Solutions
•CARB approved
•Runs on 12V power from bank of Group 31 AGM
batteries
•Complies with all anti-idle laws
•Suitable for day cabs or sleepers
•7,000 and 10,000 BTU capacities
•Patented split systems with reusable precharged
refrigerant linesets
 • Self-contained package units
•Heating options
•1 to 2 KW built-in electric heat
•Interface with installed diesel-red heaters
•No special tools required to install
•Turnkey package includes all components needed to
complete installation
•Backed by extensive application engineering support
and nationwide service
•Designed and built for over-the-road conditions and
thoroughly eld-tested
You can rely on Dometic Corporation, with its 50 year
heritage in rugged HVAC technology for harsh environment
applications, for thoroughly engineered products designed for
the harshest over-the-road conditions backed by unmatched
factory support and after-sale service.
Visit www.dometictruck.com to get complete details on how
to select, specify, operate and maintain a battery-powered
auxiliary air conditioning system.
Self-Contained UnitAlternator
Control
Inverter
Split unit
Wouldn’t it be great if you could run an
air conditioner in your trucks without
idling the engine or cranking up a
separate diesel generator? Now, thanks
to Dometic engineering, it’s a reality.
Dometic’s battery-powered all-electric
systems run on 12 Volt power from the
truck’s batteries. This means no auxiliary
diesel genset or APU is needed. No noise. No
exhaust emissions. No fuel consumption. No maintenance.
Nothing but clean, quiet comfort. And the CARB-compliant
Dometic solution meets the most stringent clean-air laws
without any future modications.
In addition to the Dometic air conditioning units and associated
ducts, grills and controls, the turnkey system includes a high-
performance alternator with external regulator, DC-AC inverter/
charger, Group 31 AGM batteries and optional shorepower
plug. No special tools are required for system installation or
maintenance.
SPLIT SYSTEMS
Model Cool Capacity
(BTU/hr)
Heat
Capacity Control Height Width Length Weight Cool Amps
Heat
Amps Refrigerant
Internal Unit – Evaporator/Heater/Compressor
ECFQ7 7,000 Cooling Only Smart Digital 11.75" 10.25" 19.25" 53 lb. 7.3 N/A R-417A
EHCFQ7 7,000 1 kW Smart Digital 11.75" 10.25" 19.25" 53 lb. 7.3 8.2 R-417A
ECFQ10 10,000 Cooling Only Smart Digital 11.63" 11.12" 20.19" 60 lb. 11.8 N/A R-417A
EHCFQ10 10,000 7,500 BTU/hr
Espar Ready Smart Digital 11.63" 11.12" 20.19" 60 lb. 11.8 1.0 R-417A
EHCFQ10 10,000 1.5 kW Smart Digital 11.63" 11.12" 20.19" 60 lb. 11.8 13 R-417A
EHCFQ10 10,000 2 kW Smart Digital 11.63" 11.12" 20.19" 60 lb. 11.8 17 R-417A
External Unit – Condenser
ACCD7 7,000 N/A N/A 6.125" 11.3125" 21.875" 10 lb. N/A N/A R-417A
ACCE10 10,000 N/A N/A 6.125" 12.50" 24.50" 12 lb. N/A N/A R-417A
SELF-CONTAINED SYSTEMS
ASCF7 7,000 Cooling Only Mechanical 12.5" 15.25" 21.50" 62 lb. 8.5 N/A R-22
ASCEQ7 7,000 Cooling Only Smart Digital 11.94" 17.75" 24.00" 70 lb. 8.9 N/A R-417A
ASCEQ7 7,000 7,500 BTU/hr
Espar Ready Smart Digital 11.94" 17.75" 24.00" 70 lb. 8.9 1.8 R-417A
ASCEQ7 7,000 1 kW Smart Digital 11.94" 17.75" 24.00" 71 lb. 8.9 9.5 R-417A
ASCEQ7 7,000 1.5 kW Smart Digital 11.94" 17.75" 24.00" 71 lb. 8.9 13.4 R-417A
ASCDQ10 10,000 Cooling Only Smart Digital 12.5" 20.87" 28.25" 91 lb. 12.9 N/A R-22
ASCDQ10 10,000 1.5 kW Smart Digital 12.5" 20.87" 28.25" 91 lb. 12.9 13.9 R-22
ASCDQ10 10,000 2 kW Smart Digital 12.5" 20.87" 28.25" 91 lb. 12.9 18.2 R-22
