Dometic FW3000 User manual

Dometic WAECO International GmbH
Hollefeldstrasse 63
D-48282 Emsdetten
dometic.com
B
C
A
A
B
A
B
C B D
A
Ø 32 mm
A
B
Ø
32 mm
324 mm
96 mm
Ø
32 mm
123 mm
96 mm
12
3 4 5 6 7
89
FreshWell3000
1 2
6
3 4
5
4445101820 ST0194 825 02 01-98 03/2017
FreshWell3000-I-16s.book Seite 1 Mittwoch, 8. März 2017 9:42 21

59 mm
X + 29,5 mm
X
50 mm
Y
93,5 mm
Y + 47
DC-Kit
IR LIN1 12 VLIN2
POWER
DC-Kit 1, 4 Inverter 2, 5 Remote On 3, 6 Economy
LIN 1, 3, 4, 5 GND 2 LIN 6 NC
13
4
123456
6
CN1
COMP
COM
COM
HEATER
4V IN FAN
CN1
CN7CN4
CN10CN3
CN2
OUT FAN
AC-L1
N2-N3
N1-N4 N5-N6
CN1
CN5 CN4
CN3
CN2
LIN1 LIN2
ge
sw
ge
ge
br
bl
sw
br
bl or
sw
rt
rt
rt
bl ge
sw
sw
ws
br
br
ws
gn
rt
ws
gn
1
2
1
2
LIN 1 AUX LIN 2
+
–
1
2
bl ge ws
rt br
T1 – Line T2 – Neutral T3 – Ground 230 Vw
12 Vg
2
1
11
10
5
5
5
7
8
6
2
1
3
4
9
b
c
EN DE FR ES PT IT NL DA SV NO FI RU PL SK CS HU
bl Blue Blau Bleu Azul Azul Blu Blauw Blå Blå Blå Sininen Синий Niebieski Modrá Modrá Kék br Brown Braun Marron Marrón Castanho Marrone Bruin Brun Brun Brun Ruskea Коричневый Brązowy Hnedá Hněda Barna cy Cyan Cyan Cyan Cian Ciano Cyan Cyaan Cyan Cyan Cyan Syaani Голубой Cyjan Azúrová Azurová Cián ge Yell ow Gelb Jaune Amarillo Amarelo Giallo Geel Gul Gul Gul Keltainen Желтый Żółty Žltá Žlutá Sárga gn Green Grün Vert Verde Verde Verde Groen Grøn Grön Grønn Vihreä Зеленый Zielony Zelená Zelená Zöld gr Grey Grau Gris Gris Cinzento Grigio Grijs Grå Grå Grå Harmaa Серый Szary Sivá Šedá Szürke or Orange Orange Orange Naranja Cor de
laranja
Arancione Oranje Orange Orange Oransje Oranssi Оранжевый Pomarańczowy Oranžová Oranžová Narancs
pk Pink Pink Rosa Rose Cor de
rosa
Rosa Roze Lyserøde Rosa Rosa Pinkki Розовый Różowy Ružová Růžová Rózsaszín
rt Red Rot Rouge Rojo Vermelho Rosso Rood Rød Röd Rød Punainen Красный Czerwony Červená Červená Piros sw Black Schwarz Noir Negro Preto Nero Zwart Sort Svart Svart Musta Черный Czarny Čierna Černá Fekete vt Violet Violett Violeta Lila Violeta Violetto Paars Violet Violett Fiolett Violetti Фиолетовый Fioletowy Fialová Fialová Ibolya ws White Weiß Blanc Blanco Branco Bianco Wit Hvid Vit Hvit Valkoinen Белый Biały Biela Bílá Fehér
a
9
07
8
FreshWell3000-I-16s.book Seite 2 Mittwoch, 8. März 2017 9:42 21

FW3000
Under-bench air conditioner
Installation Manual. . . . . . . . . . . . . . . . . . . . .2
Staukastenklimaanlage
Montageanleitung. . . . . . . . . . . . . . . . . . . . 17
Climatiseur de coffre
Instructions de montage . . . . . . . . . . . . . . .33
Equipo de aire acondicionado de
cajón
Instrucciones de montaje . . . . . . . . . . . . . .49
Sistema de climatização para caixa
de arrumação
Instruções de montagem . . . . . . . . . . . . . .65
Climatizzatore per vano di carico
Indicazioni di montaggio . . . . . . . . . . . . . .82
Airco onder de bank
Montagehandleiding . . . . . . . . . . . . . . . . .97
Klimaanlæg til montering i et
magasin
Monteringsvejledning. . . . . . . . . . . . . . . . 114
Klimatanläggning för
förvaringsutrymmen
Monteringsanvisning . . . . . . . . . . . . . . . . 130
Takboksklimaanlegg
Monteringsanvisning . . . . . . . . . . . . . . . . 144
Kaappi-ilmastointilaite
Asennusohje . . . . . . . . . . . . . . . . . . . . . . . 159
Встраиваемый вбагажный ящик
кондиционер
Инструкция по монтажу. . . . . . . . . . . . . . 174
Klimatyzator umieszczany
wschowku
Instrukcja montażu . . . . . . . . . . . . . . . . . . 190
Klimatizačné zariadenie do
úložného priestoru
Návod na montáž. . . . . . . . . . . . . . . . . . . 205
Klimatizace do zavazadlového
prostoru
Návod k montáži . . . . . . . . . . . . . . . . . . . . 219
Tárolóládás klímaberendezés
Szerelési útmutató . . . . . . . . . . . . . . . . . . 233
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
AIR CONDITIONERS
FRESHWELL
FreshWell3000-I-16s.book Seite 1 Mittwoch, 8. März 2017 9:07 21

EN
Explanation of symbols FreshWell3000
2
Please read this instruction manual carefully before installation and first
use, and store it in a safe place. If you pass on the product to another
person, hand over this instruction manual along with it.
Table of contents
1Explanationofsymbols...........................................2
2Safetyandinstallationinstructions........ . . . . . . . . . . . . . . . . . . . . . . . . . .3
3Targetgroupforthisinstructionmanual..... . . . . . . . . . . . . . . . . . . . . . . . .4
4Scopeofdelivery...............................................5
5Intendeduse...................................................5
6Labels.........................................................5
7Installation.....................................................6
8Troubleshooting...............................................12
9Disposal......................................................13
10 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
1 Explanation of symbols
!
!
A
I
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
FreshWell3000-I-16s.book Seite 2 Mittwoch, 8. März 2017 9:07 21

EN
FreshWell3000 Safety and installation instructions
3
2 Safety and installation instructions
Pleaseobserve the prescribed safetyinstructions andstipulations fromthe
vehicle manufacturer and service workshops.
The manufacturer accepts no liability for damage in the following cases:
•Damage to the product resulting from mechanical influences and excess voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
Note the following basic safety information when using electrical devices to protect
against:
•Electric shock
•Fire hazards
•Injury
2.1 Handling the device
!WARNING!
•Installation and repair of the under-bench air conditioner may only be
carried out by qualified personnel who are familiar with the risks
involved and the relevant regulations. Inadequate repairs may cause
serious hazards. For repair service, please contact the service centre in
your country (addresses on the back page).
•Electrical devices are not toys.
Keep electrical devices out of reach of children or infirm persons. Do
not allow them to use electrical devices without supervision.
•Persons whose physical, sensory or mental capabilities or whose lack
of experience and knowledge prevent them from using the device
safely should not use it without supervision or instruction by a
responsible person.
•In the event of a fire only use approved extinguishing agents. Do not
use water to extinguish fires.
!CAUTION!
•The under-bench air conditioner must be installed securely so that it
cannot fall down.
•Only operate the under-bench air conditioner if you are certain that
the housing and the cables are not damaged.
FreshWell3000-I-16s.book Seite 3 Mittwoch, 8. März 2017 9:07 21

EN
Target group for this instruction manual FreshWell3000
4
•Do not use the under-bench air conditioner near flammable fluids.
•Make sure no combustible objects are stored or installed near the air
outlet. A distance of at least 50 cm must be kept.
•Do not reach into air outlets or insert any foreign objects in the device.
ANOTICE!
•Only use the device as intended.
•The under-bench air conditioner isnot suitable for use in agricultural or
construction vehicles.
•Do not make any alterations or conversions to the device.
•If faults occur in this refrigerant circuit, the system must be checked by
a specialist company and repaired properly. The refrigerant must
never be released into the air.
2.2 Handling electrical cables
!WARNING!
•The electrical power supply may only be connected by a qualified
electrician (e.g. VDE 0100, Part 721 in Germany).
!CAUTION!
•Attach and lay the cables so that they cannot be tripped over or
damaged.
ANOTICE!
•Use cable ducts to lay cables through walls with sharp edges.
•Do not lay loose or bent cables next to electrically conductive
materials (metal).
•Do not pull on the cables.
3 Target group for this instruction manual
The instructions in this manual are intended for qualified personnel at workshops
who are familiar with the guidelines and safety precautions to be applied.
FreshWell3000-I-16s.book Seite 4 Mittwoch, 8. März 2017 9:07 21

EN
FreshWell3000 Scope of delivery
5
4Scopeofdelivery
5 Intended use
The Dometic FreshWell3000 under-bench air conditioner (ref. no. 9105306670) is
designed for use in motorcaravans, caravans and other vehicles with habitation
compartments only. It is not suitable for houses and appartments.
The under-bench air conditioner is not suitable for installation in construction
machines, agricultural machines or similar equipment. It will not work properly if
exposed to strong vibrations.
The operating mode of FreshWell3000 is guaranteed for temperatures between
0°Cand52°C.
I
6Labels
Labels are attached to the Dometic FreshWell under-bench air conditioners. These
labels provide the user and fitter with information on specifications of the device.
No. in fig. 1Qunatity Description
1 1 Under-bench air conditioner
2 1 Remote control
31Receiver
4 4 Air filter
5 2 Angle section
6 4 Fastening bracket
7 14 Fastening screw
8 2 Drain pipe
9 2 External grids
– 1 Assembly template
NOTE
You can find additional information on under-bench air conditioners in
the operating manual, such as the technical description or the controls.
FreshWell3000-I-16s.book Seite 5 Mittwoch, 8. März 2017 9:07 21

EN
Installation FreshWell3000
6
7 Installation
!
7.1 Note on installation
Read this installation manual completely before installing the under-bench air
conditioner.
The following tips and instructions must be observed while installing the under-
bench air conditioner:
D
!
A
Note on transport
•Always have someone help you carry the under-bench air conditioner.
•Always lift the under-bench air conditioner to move it and never drag it over the
floor (fig. 2A).
•Do not use the ventilation slots to lift it (fig. 2B).
CAUTION! Beware of injury
The under-bench air conditioner may only be installed by qualified
personnel from a specialist company. The following information is
intended for technicians who are familiar with the guidelines and safety
precautions to be applied.
DANGER! Danger of electrocution
Disconnect all power supplies when working on the under-bench air
conditioner.
CAUTION! Beware of injury
•Improper installation of the under-bench air conditioner can result in
irreparable damage to the device and put the safety of the user at
risk.
•The manufacturer assumes no liability for malfunctions and for the
safety of the under-bench air conditioner, especially for injury and/or
damage to property, if the under-bench air conditioner is not fitted in
accordance with these installation instructions.
•Always wear the recommended protective clothing (e.g. protective
goggles, gloves).
NOTICE! Beware of damage
Observe the structural engineering of the vehicle and seal of all open-
ings made when installing the under-bench air conditioner.
FreshWell3000-I-16s.book Seite 6 Mittwoch, 8. März 2017 9:07 21

EN
FreshWell3000 Installation
7
Note on installation location
•To install the machine it is necessary to create openings in the floor. These open-
ings must be accessible and must not be covered by any parts of the vehicle.
•Before installing the under-bench air conditioner, check whether any vehicle
components could be damaged by the installation of the under-bench air
conditioner (such as lamps, cupboards, doors).
•Make sure no combustible objects are stored or installed near the air outlet. A
distance of at least 50 cm should be kept.
•The inclination of the installation surface may not exceed 10°.
•For safety reasons, note the location of existing wiring harnesses, wires and other
components within the installation area, in particular those which are not visible,
when installing the under-bench air conditioner (when drilling or screwing etc.).
•To obtain the optimal air-conditioning in the vehicle, install the under-bench air
conditioner in a central position, in a compartment or a similar housing.
•Choose a place that is easily accessible for servicing as well as disassembling and
installing.
•Place the assembly template into the chosen compartment and check the space
available for the openings in the floor.
•To minimize the transmission of noise and vibration during operation, the under-
bench air conditioner should have a all around minimum clearance of 30 mm to
walls and furniture.
•The under-bench air conditioner must be installed on the floor.
•Keep a distance of 200 mm between the front of the under-bench air conditioner
and the walls of the compartment to facilitate filter replacement.
•Installing the under-bench air conditioner into an external compartment (e.g.
false bottoms), the air to be treated must be drawn in from the vehicle’s
passenger compartment.
•Suctioning of outside air can significantly reduce the power of the system.
FreshWell3000-I-16s.book Seite 7 Mittwoch, 8. März 2017 9:07 21

EN
Installation FreshWell3000
8
Note on electrical system (see fig. c)
•Only a qualified electrician should connect the under-bench air conditioner to
the electrical power.
•Check that the voltage specification on the type plate is the same as that of the
power supply.
•Do not lay cables which are loose or bent next to electrically conductive material
(metal).
•Install an all-pole switch with a contact opening width of at least 3 mm on the
installation side.
No. in fig. cDescription
1 Motor ventilator (inner)
2 Motor ventilator (outer)
3Capacitor
4Compressor
5 Temperature sensor
6PCB
7 PCB display
8 PCB interface
9 Soft start
10 Valve
11 Resistor
FreshWell3000-I-16s.book Seite 8 Mittwoch, 8. März 2017 9:07 21
