Dometic ACC3100D User manual

CLIMATE CONTROL
ROOF TOP
VENTILATION SYSTEM
ACC3100D
EN Ventilation system
Installation manual........................................ 10
DE Lüftungsanlage
Montageanleitung........................................20
FR Système de ventilation
Instructions de montage................................31
ES Sistema de ventilación
Instrucciones de montaje.............................. 42
PT Sistema de ventilação
Instruções de montagem.............................. 53
IT Sistema di ventilazione
Indicazioni di montaggio.............................. 64
NL Ventilatiesysteem
Montagehandleiding....................................75
DA Ventilationssystem
Monteringsvejledning...................................86
SV Ventilationssystem
Monteringsanvisning.................................... 97
NO Ventilasjonssystem
Monteringsanvisning...................................108
FI Ilmanvaihtolaite
Asennusohje...............................................118
PL System wentylacji
Instrukcja montażu......................................129
SK Vetrací systém
Návod na montáž.......................................140
CS Ventilační systém
Návod kmontáži.........................................151
HU Szellőztetőrendszer
Szerelési útmutató...................................... 162
HR Sustav za prozračivanje
Upute za montažu...................................... 173
TR Havalandırma sistemi
Montaj Kılavuzu..........................................184
SL Prezračevalni sistem
Navodilo zamontažo.................................. 195
RO Sistem de ventilare
Instrucţiuni de montaj................................. 206
BG Вентилационна система
Инструкция за монтаж................................ 217
ET Ventilatsioonisüsteem
Paigaldusjuhend........................................ 228
EL Σύστημα εξαερισμού
Οδηγίες τοποθέτησης..............................239
LT Ventiliacijos sistema
Montavimo vadovas....................................251
LV Ventilācijas sistēma
Uzstādīšanas rokasgrāmata..........................262

EN
List of Figures

BA

A
Y
Y
Ø
X
X
1. 2.
3.

W
W
A
WW
1. 2.
1

EN 

B
1.
3.
2.

100 mm
2

EN

1.
2.
400 x 400 mm 355 x 355 mm

1.
2.
3.
3

EN 

1.
2.
C5
C2
C4
C3
3.

h
WW

1.
2.
4

EN

W
W
2.
1.
1,2
W

3.
2.
1.
5

EN 

2.
4.
3.
1.

4.
3.
2.
1.

C3 C2 C5
C4
C1 C12
C11
7 6 5
1
324
C7
C6
6

EN


2.
1.
7

EN 

8

Copyright
© 2023 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design
law. The underlying technical design and the products contained herein may be protected by design, patent or be
patent pending. The trademarks mentioned in this manual belong to Dometic Sweden AB. All rights are reserved.

EN 
English
1Important notes.............................................................................................................................10
2Explanation of symbols.................................................................................................................. 10
3Safety instructions.......................................................................................................................... 11
4Scope of delivery.......................................................................................................................... 12
5Accessories.................................................................................................................................. 12
6Target group.................................................................................................................................13
7Intended use................................................................................................................................ 13
8Installation....................................................................................................................................13
9Disposal.......................................................................................................................................18
10 Warranty...................................................................................................................................... 18
11 Technical data............................................................................................................................... 19
1 Important notes
Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure that you install, use, and maintain
the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and that you understand and agree to abide by the terms and
conditions as set forth herein. You agree to use this product only for the intended purpose and application and in accordance with the instructions, guidelines, and warnings as
set forth in this product manual as well as in accordance with all applicable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may
result in an injury to yourself and others, damage to your product or damage to other property in the vicinity. This product manual, including the instructions, guidelines, and
warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit documents.dometic.com.
2 Explanation of symbols
WARNING!
Indicates a hazardous situation that, if not avoided, could result in death or serious injury.
CAUTION!
Indicates a hazardous situation that, if not avoided, could result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
Note Supplementary information for operating the product.
10

EN
3 Safety instructions
WARNING! Failure to obey these warnings could result in death or serious injury.
• Repair of the appliance may only be carried out by qualified personnel who are familiar with the risks
involved and the relevant regulations. Inadequate repairs may cause serious hazards. For repair ser-
vice, contact the service center in your country (see dometic.com/dealer).
• The appliance shall be installed in accordance with national electrical and mechanical installation
regulations.
•Electrical appliances are not toys. Keep electrical appliances out of reach of children or infirm
persons. Do not allow them to use electrical appliances without supervision.
• Persons whose physical, sensory or mental capabilities or whose lack of experience and knowledge
prevent them from using the appliance safely should not use it without supervision or instruction by
a responsible person.
• Do not undo the upper cover of the appliance in the event of a fire. Use approved extinguishing
agents instead. Do not use water to extinguish fires.
• The appliance shall be stored in a room without continuously operating open flames (for example an
operating gas appliance) and ignition sources (for example an operating electric heater).
• The appliance shall be stored horizontally at a dry, ventilated and covered location.
• Do not pierce or burn the appliance.
CAUTION! Failure to obey these cautions could result in minor or moderate injury.
• Only start up the appliance if you are certain that the housing and the cables are not damaged.
• Do not use the appliance near flammable fluids or in closed rooms.
• Ensure that no combustible objects are stored or installed near the air outlet. A distance of at least
10 cm must be kept.
• Do not reach into air outlets or insert any foreign objects in the appliance.
• Always wear protective goggles and gloves.
NOTICE! Damage hazard
• The appliance shall be stored so as to prevent mechanical damage from occurring.
• Before installation, check whether any vehicle components could be damaged by the installation of
the appliance (such as lamps, cupboards, doors). The vehicle manufacturer may have already pro-
vided points where the opening for the installation of the appliance can be made without any risk of
weakening the construction or cutting power cables.
• Before installation, consult the vehicle manufacturer whether the construction is designed for the
static weight and the loads of the ventilation system when the vehicle is in motion.
• Seal all openings made when installing the ventilation system.
• Select a flat and sufficiently level area at the center of the vehicle roof between two longitudinal sec-
tions for installation.
• Ensure that there are no objects within the vehicle which could obstruct the attachment of the air
distribution box (ADB) or the fresh air from flowing through the air outlets.
• Do not make any alterations or conversions to the appliance.
• Never drive through automatic car washes when the appliance is mounted.
11

EN 
4 Scope of delivery
Item Quantity Description
1 1 Roof top unit with center ring (only for roof openings 400× 400 mm)
2 1 Heat exchanger unit
3 1 Interior cover
4 1 Air filter
5 1 Center cover
– 1 Installation kit (to be ordered seperatly for ACC3100DWH(A))
– 1 Short operating manual
– – Depending on the model: Installation manuals for accessories
5 Accessories
Product Ref. no.
Air purifier 9620005077
12

EN
Product Ref. no.
LED light 9620005081
Performance booster 9600050054
Solar kit 9620005074
Inside air filter
Outside air filter
407157522
6 Target group
The mechanical and electrical installation and setup of the device must be performed by a qualified tech-
nician who has demonstrated skill and knowledge related to the construction and operation of automotive
equipment and installations, and who is familiar with the applicable regulations of the country in which the
equipment is to be installed and/or used, and has received safety training to identify and avoid the haz-
ards involved.
7 Intended use
The ventilation system is intended to be installed in motor caravans, leisure boats, caravans and recreational vehicles.
The device is not suitable for:
• Houses
• Apartments
• Cruiseline
• Construction machines
• Agricultural machines
• Trucks
This product is only suitable for the intended purpose and application in accordance with these instructions.
This manual provides information that is necessary for proper installation and/or operation of the product. Poor in-
stallation and/or improper operating or maintenance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product specifications.
8 Installation
WARNING! Electrocution hazard
13

EN 
• The electrical power supply must be connected by a qualified electrician who has demonstrated
skill and knowledge related to the construction and operation of electrical equipment and installa-
tions and has received safety training to identify and avoid the hazards involved.
• Disconnect all power supplies when working on the ventilation system.
• Ensure that the appliance cannot be reconnected.
WARNING! Electrocution hazard
• The appliance shall be installed in accordance with national wiring regulations.
• If the appliance replaces a window or hatch with a safety relevant forced venting function, an addi-
tional safety venting device (e.g. a mushroom fan or similar) needs to be added. In doubt consult the
vehicle manufacturer.
CAUTION! Beware of injury
• Improper installation of the ventilation system can result in irreparable damage to the appliance and
put the safety of the user at risk.
• Always have someone to help you carrying or lifting the ventilation system.
• Before installation, check the location of existing wiring harnesses, wires and other components
within the installation area, in particular those which are not visible, when installing the appliance
(when drilling or screwing etc.).
• Attach and lay the cables so that they cannot be tripped over or damaged.
• Always wear the protective goggles and gloves.
NOTICE! Damage hazard
• Use cable ducts to lay cables through walls with sharp edges.
• Do not lay loose or bent cables next to electrically conductive materials (metal).
• Do not pull on the cables.
• Observe the structural strength of the roof of the vehicle. The roof of the vehicle must be able to
bear the weight of the ventilation system without being indented or deformed. In doubt consult the
vehicle manufacturer.
Choosing the way of installing the ventilation system
Choose your way of installing the ventilation system:
Fig. on page1
• Make a new opening (A). In this case the opening must be reinforced by an appropriate frame.
• Use an existing opening in the vehicle (B) such as a roof hatch or replacing an old device.
Making a new opening
1. Select an area at the center on the roof between two longitudinal supports.
2. Mark the position and size of the opening.
Fig. on page1
Version 1 Version 2
X 355 mm 400 mm
Y 5 mm 12 mm
14

EN
Ø 10 mm 24 mm
3. Drill out the corners.
NOTICE! Damage hazard
Ensure that no electrical power cables are damaged. Check where the electrical cables are located.
4. Carefully cut out the opening on the roof using a keyhole saw or a similar tool.
5. Check whether the roof hole needs reinforcing.
Note The edges must be parallel to each other.
Fig. on page1
6. If needed, remove the foam according to the width of your reinforcing rails (not in scope of delivery).
7. Fit the reinforcing rails.
Installing in an existing opening
1. Remove all screws and fixtures of the existing roof hatch or device.
Fig. on page2
2. Take out the roof hatch or device.
3. Remove the sealant around the opening using a scraper or similar tool.
Installing optional accessories (depending on the model)
NOTICE! Damage hazard
• Observe the correct installation sequence before making the electrical connections.
• Observe the installation manuals of the accessories (optional).
1. Roof top unit
2. Solar panel (optional)
3. LED light strip (optional)
4. Air purification module (optional)
5. Heat exchanger unit
6. Performance booster (optional)
7. Interior cover
Laying the connecting cables
1. Check that the voltage specification on the data plate of the ventilation system is the same as that of the power
supply. The ventilation system must be connected to an electric circuit which is able to supply the required cur-
rent .
2. Install an all-pole switch with a contact opening width of at least 3 mm on the installation side.
3. Select the cross-section of the power supply cable corresponding to the length:
• Length < 7.5 m: 1.5 mm²
• Length > 7.5 m: 2.5 mm²
15

EN 
4. Make an opening on one side in order to feed through the power supply cable.
Fig. on page2
5. Feed the power supply cable through the opening into the vehicle interior.
Installing the roof top unit
1. Only for version 1: Remove the center ring on the roof top unit.
Fig. on page3
2. Seal around the roof frame with flexible non-hardening butyl sealing compound (e.g. SikaLastomer-710, Selleys
Butyl Mastic, Bostik ezycaulk butyl sealant, or similar products). Observe the sealant manufacturer's instructions.
3. Li the roof top unit onto the roof of the vehicle. Observe the direction of travel.
4. Position the roof top unit centrally on the roof of the vehicle.
5. Remove the cable tie on the rooop unit and lead the cables through the corresponding opening into interior of
the vehicle.
Installing the air purification module (optional)
1. Fix the air purification module to the heat exchanger unit.
Fig. on page3
2. Lead the cable through the key hole bushing to the underside of the heat exchanger unit.
3. Mount the ionization needle.
Fig. on page4
Installing the heat exchanger unit
1. Depending on the roof thickness, cut the spacers supplied with the fixing kit to the required lenght.
Fig. on page4
Roof thickness (W) Spacer length required (h)
–
2mm
4mm
23 mm… 29 mm
6mm
8mm
10 mm
12 mm
14 mm
16 mm
18 mm
20 mm
22 mm
30 mm… 48 mm
24 mm
16

EN
Roof thickness (W) Spacer length required (h)
26 mm
28 mm
30 mm
32 mm
34 mm
36 mm
49 mm… 60 mm
38 mm
2. Feed the cables through the key hole bushing of the heat exchanger unit.
Fig. on page4
3. Insert the spacers into the screw holes from the upper side of the heat exchanger unit.
Fig. on page5
4. NOTICE! Damage hazard
Ensure that no cable is pressed in or pinched.
Align the heat exchanger unit to the roof top unit.
5. Fasten the heat exchanger unit though the ceiling to the roof top unit with the 12 bolts supplied with the fixing
kit. Tighten the bolts using a torque spanner and a fastening torque of max. 1.2 Nm.
Installing the interior cover
1. Feed the cables through the key hole bushing of the interior cover.
Fig. on page5
2. NOTICE! Damage hazard
Ensure that no cable is pressed in or pinched.
Attach the interior cover to the heat exchanger unit.
3. Fasten the interior cover to the heat exchanger unit with the 4 bolts supplied with the fixing kit. Tighten the bolts
using a torque spanner and a fastening torque of max. 1.2 Nm.
Installing the LED light strip (optional)
Fix the LED light strips to the interior cover.
Fig. on page6 Fig. on page6
Electrical connection
1. Connect the plugs to the sockets.
Fig. on page6
Item Socket Description
1 C1 Input power supply from vehicle battery
2 C6 Output LED light strip (optional)
17

EN 
Item Socket Description
3 C7 Output LED light strip (optional)
4 – Secondary PCB (optional)
5 C3 Output fan 1
6 C4 Output fan 2
7 C2 Output motor
– C5 Output air purification module (optional)
– C9 Communication CAN (optional)
– C10 Communication LIN (optional)
2. Secure the cables with cable ties.
Fig. on page7
Installing the ADB center cover
1. Check that the filters are fully in.
Fig. on page7
2. Clip the ADB center cover to the interior cover.
Fig. on page8
3. Ask the vehicle manufacturer if a technical inspection is required after fitting a ventilation system and whether
the height entered in the vehicle documents needs to be altered.
The installation is now completed.
4. Connect to the power supply and test if the ventilation system works.
9 Disposal
Recycling products with batteries, rechargeable batteries and light sources: Remove any batteries,
rechargeable batteries, and light sources before recycling the product. Return defective or used batteries
to your retailer or dispose of them at collection points. Do not dispose of any batteries, rechargeable bat-
teries, and light sources with general household waste. If you wish to finally dispose of the product, ask
your local recycling center or specialist dealer for details about how to do this in accordance with the ap-
plicable disposal regulations. The product can be disposed free of charge.
Recycling packaging material: Place the packaging material in the appropriate recycling waste bins wher-
ever possible.
10 Warranty
For repair and warranty processing, please include the following documents when you send in the device:
• A copy of the receipt with purchasing date
• A reason for the claim or description of the fault
Note that self-repair or nonprofessional repair can have safety consequences and might void the warranty.
18

EN
11 Technical data
ACC3100DWH(A) ACC3100DWHWLD(A)
Input voltage 12 V
Maximum power input 7.6 W 16.5 W
Maximum power consumption 0.18 kWh/24h
15.2 Ah
0.40 kWh/24h
33 Ah
Minimum power consumption 0.06 kWh/24h
4.9 Ah/24 h
Operating temperature range – 20 °C (– 4°F)… 70 °C (158 °F)
Protection class IPX4
External fuse 3 A
Ceiling vent opening 150 cm²
Dimension roof top unit (W x L x H) 542.6× 553× 127 mm
Dimension air distribution unit (W x L x H) 517.6× 517.6× 46 mm
Roof thickness 23… 60 mm
Outside noise level 43 dB(A)
Inside noise level 52 dB(A)
Inside noise level (sleep mode) 35 dB(A)
Ventilation 30… 50 m³/h
Heat recovery efficiency 72… 87 %
Weight 7 kg 7.14 kg
Features Upgradable with:
• LED Light Strip
• Air Purification Module
• Performance Booster
• Solar Panel
Provided with:
• LED Light Strip
• Air Purification Module
• Installation kit
Upgradable with:
• Performance Booster
• Solar Panel
Certifications
19
