domi LGMF1559 User manual

ASSEMBLY MANUAL
󾋸󾋹'×󾋹󾋷' Metal Gazebo
d mi
o u t d o o r l i v i n g
Missing part? Damaged? Contact us via email at
[email protected]
Copyright 2022-2024 domi LLC. I All Rights Reserved.
©
MODEL#: LGMF1559
www.domioutdoorliving.com

Pole Pole
Beam Beam
Beam Beam
Beam Corner Roof Support Tube
Corner Roof Support Tube Middle Roof Support Tube
Middle Roof Support Tube Roof Solidifying Bar
Roof Solidifying Bar Roof Solidifying Bar
Middle Roof Tube Middle Roof Tube
1

Middle Roof Tube Roof Support Tube
Roof Support Tube Solidifying Tube
Solidifying Tube
Solidifying Tube
Solidifying Tube Finishing Bar
Finishing Bar
Finishing Bar
Finishing Bar Finishing Bar
Finishing Bar Roof Panel
Roof PanelRoof Panel
2

Corner
Solidifying Bar
Corner
Solidifying Bar
Middle
Solidifying Bar
Middle
Solidifying Bar
Middle Beam Middle Beam
Base Joint Bracket Joint Bracket Base
Bracket Beam Union
Connector
Middle Roof
Tube Connector
Middle Beam
Union Connector
Joint Cover Corner Cover Plastic Cover Corner Roof
Tube Connector
Joint Bracket Joint Bracket Bracket Bracket
Bracket
Bracket
Bracket Joint Bracket
Fixing Bracket Fixing Bracket Fixing Bracket Hook
3

Spacer Plastic
Bracket
4

(1) Attach part #B2 to part #A
with 6 bolts #1.
(2) Attach part #B1 to part #A
with 4 bolts #1.
(3) Attach part #B to part #A
with 3 bolts #3.
(4) Repeat the above procedures to assemble the other 3 poles #A.
5

(1) Attach part #B1 to part #A1
with 4 bolts #1.
(2) Attach part #B3 to part #A1
with 4 bolts #3.
(3) Repeat the above procedures to assemble another pole #A1.
6

Back View
Front View
(1) Insert one side of part #Q into part #C1 and secure with
2 bolts #3.
(2) Insert the other side of part #Q into part #C and secure with
2 bolts #3.
(3) Place part #R to the assembled beam, secure with 4 bolts #8.
(4) Repeat the above procedures to assemble another part #C
and part #C1.
7

Back View
(1) Insert one side of part #Q into part #C3 and secure with 4 bolts #3.
(2) Insert the other side of part #Q into part #C2 and secure with 4 bolts #3.
(3) Insert one side of part #Q into part #C3 and secure with 4 bolts #3.
(4) Insert the other side of part #Q into part #C4 and secure with 4 bolts #3.
(5) Repeat the above procedures to assemble another part #C2,
#C3 and #C4.
Back View
8
32x

Back View
(1) Place 2 part #R to the assembled beam,
secure with 8 bolts #8.
(2) Use 8 bolts #3 to secure 4 part #T1 to
the assembled beam as shown.
(3) Repeat the above procedures to assemble another part #C2,
#C3 and #C4.
9
16x

(1) Connect part #C4 & #C /(#C1 & #C2) with 8 bolts #7.
(From Outside)
(2) Repeat the above procedures to assemble the other 3 corners.
Please don't fully tighten the bolts.
10

(1) Secure part #C4 & #C /(#C1 & #C2) to part #A
with 4 bolts #3 (From Inside)
(2) Repeat the above procedures to assemble the other 3 corners.
Please don't fully tighten the bolts.
11

(1) Insert part #N /#N1 to the bracket on the pole #A, secure with
2 bolts #3.
(2) Align the holes and secure
part #N to the beam #C with 2 bolts #3.
(3) Align the holes and secure
part #N1 to the beam #C4
with 2 bolts #3.
(4) Repeat the above procedures to assemble the other 3 corners.
Tighten all the bolts.
12

(1) Put the corner cover #R1 on the
corner and secure with 8 bolts #8.
(2) Repeat the above procedures to assemble the other 3 corner covers.
13

(3) Repeat the above procedures to assemble the opposite side.
(1) Insert part #N2 /#N3 to the bracket on the middle pole #A1,
secure with 2 bolts #3.
(2) Align the holes and secure part #N2 /#N3 to the beam #C3
with 2 bolts #3.
14

(1) Use 2 bolts #3 to secure part #S1 to corner roof support
tube #D, use bolts #3 to secure part #T to corner support roof
support tube #D as shown.
(2) Use 2 bolts #3 to secure part #S2 to corner roof support
tube #D1, use bolts #3 to secure part #T to corner roof
support tube #D1 as shown.
(3) Repeat the above procedures to assemble another corner
roof support tube #D & #D1.
15

(1) Insert part #S to part #D and #D1, secure with 6 bolts #3.
(2) Repeat the above procedures to assemble the opposite side.
