Doro PhoneEasy 621 User manual

Doro PhoneEasy® 621
Quick Start Guide
English

Complete manual
For the complete user guide please visit
www.doro.co.uk/Support/ or contact our Helpline.
Overview
1
2
15
16
3
4
5
6
7
18
17
8
19
21
20
9
10
11
12
14
13

1. Earpiece
2. Display
3. Arrow buttons
4. Left selection button
5. Call button
6. Speed dial
7. Voice mail
8. Silent/Input method
9. Camera shortcut
10. Message shortcut
11. Volume control
12. End call/ Power on/
off
13. Microphone
14. Right selection
button
15. Charging socket
16. Headset socket
17. Assistance button
18. Camera lens
19. Loudspeaker
20. Green light=New
message / Missed
call
21. Red light=Battery
level low / Charging
22. Charging stand
23. Lanyard
22
23

4
Installation
Important!
Turn off the phone and disconnect the charger before
removing the battery cover.
Installing the SIM card, memory card and
the battery
The SIM and memory card holders are located
inside the battery compartment.
1 2 3 4 5
1. Remove the battery cover and the battery if it is
already installed.
2. Optional: Insert the memory card into the slot
under the SIM card holder. Make sure that the
memory card contacts are facing inwards and
push the card in, until you hear a click. Take
care not to scratch or bend the contacts on the
card. To remove or replace the card, push the
card in until you hear a click and then pull the
card out.

5
3. Insert the SIM card by gently sliding it into the
holder. Make sure that the SIM card’s contacts
are facing inwards and that the cut off corner is
pointing downwards. Take care not to scratch or
bend the contacts on the SIM card.
4. Insert the battery by sliding it into the
battery compartment with the contacts facing
downwards to the left.
5. Replace the battery cover.
Charging
CAUTION
Only use batteries, charger and accessories that have
been approved for use with this particular model.
Connecting other accessories may be dangerous
and may invalidate the phones type approval and
guarantee.
When the battery is running low, is displayed
and a warning signal is heard.
To charge the battery:
• Connect the mains adapter to the wall socket
and to the charging socket y.

6
Get to know your phone
Turn the phone on and off
Press and hold the red button on the phone to
turniton/off.Conrmwith Yes to power off.
If the SIM card is valid but protected with a PIN
code(PersonalIdenticationNumber), PIN is
displayed.
• Enter the PIN code and press OK ( upper left
cornerofthekeypad).Deletewith Clear (
upperrightcornerofthekeypad).
Note!
If PIN and PUK codes were not provided with
your SIM card, please contact your service
provider.
Attempts: # shows the number of PIN attempts
left. When no more attempts remain, PIN blocked
is displayed. The SIM card must now be unlocked
withthePUKcode(PersonalUnblockingKey).
1. EnterthePUKcodeandconrmwith OK .
2. EnteranewPINcodeandconrmwith OK .
3. Re-enterthenewPINcodeandconrmwith
OK .

7
Start-up wizard
Whenstartingthetelephoneforthersttime,
you can use the Start-up wizard to set some basic
settings.
1. Turn on the phone and Run start-up wizard? is
displayedthersttime.
2. Press Yes to change or press No if you do not
want to change.
See Settings/General/Start-up wizard in the full
manual.
Change the language, time and date
The default language is determined by the SIM
card. See Settings on how to change language,
time and date in the full manual.
Enter text
• Press a numerical key repeatedly until the
desired character is shown. Wait a few seconds
before entering the next character.
• Press *for a list of special characters. Select
the desired character with / and press OK
to enter it.
• Use the side keys + / - or / to move the
cursor within the text.
• Press #to cycle upper case, lower case and
numerals.
• Press and hold #to change input language.

8
Calls
Make a call
1. Enter the phone number including the area code.
Delete with Clear .
2. Press to dial. Press Abort to cancel
dialling.
3. Press to end the call.
Tip:
For international calls, always use +before the
country code for best operation. Press *twice
for the international prex +.
Make a call from the phonebook
1. Press Name to open the phonebook.
2. Use the arrow buttons / to scroll through
the phonebook, or quick search by pressing the
keycorrespondingtotherstletteroftheentry.
3. Press Call to dial the selected entry, or press
Back .

9
Receive a call
Toansweranincomingcallwhentheipisclosed,
opentheip.
To answer an incoming call when you have set
Open to answer to Off , see Settings/Calls/Answer
mode in the full manual.
1. Opentheipandpress to answer.
Alternatively press Silent to switch off the
ringsignal or press /closetheiptoreject
thecalldirectly(busysignal).
2. Press to end the call.
Volume control
Use the side keys + / - toadjustthesoundvolume
during a call. The volume level is indicated on the
display. See Settings/Sound/Audio setup in the full
manual.
Selection buttons
During a call the selection buttons have
multiple functions. The current key function is
shown above the selection button on the display.
Call information
During a call, the outgoing or incoming phone
number and the elapsed call time is displayed. If
the identity of the caller is withheld, Unknown is
displayed.

10
Calls
Speed dial
Use A–B, 0and 2–9 to speed dial an entry
from standby.
• Press and hold the corresponding button.
Add speed dial numbers
1. Press Menu â Settings â Calls â Speed dial .
2. Select A â Add an select an entry from the
phonebook.
3. Press OK toconrm.
4. Repeat to add speed dial entries for buttons B,
0, 2–9.
Silent
Silentisaxedprolewith Keypad tone ,
Message tone and Ringtone disabled, while
Vibration , Tasks , Daily reminder and Alarm are
unchanged.
• Press and hold shortcut button #to activate/
deactivate Silent mode.
