Doyon DP14 User manual

DP14
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
DANGER
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE INSTRUCTIONS
TABLE OF CONTENTS
SECTION «A»DESCRIPTION PAGE
Installation and maintenance manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A2
Shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3
Distances to respect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A6
Maintenance and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A7
For more information, please contact our office: . . . . . . . . . . . . . . . . . . . . A8
SECTION «B» DIMENSIONS
DP14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION «E» COMPONENT PARTS
Component parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B1
E1
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DP14.DOC Rev. 01.2008

A1
CAUTION
The manufacturer suggests to read this manual carefully.
INSTALLATION AND MAINTENANCE MANUAL
This proofer is manufactured with first quality material by experienced technicians. Proper
installation and maintenance will guarantee a reliable service for years to come.
A nameplate fixed to the front of the proofer specifies the serial number, model number, number of
phase, amperage, voltage and frequency.
Drawings, electrical diagram and replacement part numbers are included in this manual. The
electrical diagram is affixed in the control panel located on the top of the proofer.
ATTENTION
DOYON is not responsible for damages to the property or the equipment caused
by personnel who is not certified by known organizations. The customer is
responsible for finding qualified technicians in electricity and plumbing for the
installation of the oven.

A2
C O N S T R U C T I O N
You just bought the most advanced proofer in the world, the "DOYON" technology at its best. This
proofer is manufactured using the highest quality components and material.
The DOYON equipments are designed with parts that are easy to find.
S H I P P I N G
For your safety, this equipment is verified by qualified technicians and carefully crated before
shipment. The freight company assumes full responsibility concerning the delivery in good condition
of the equipment in accepting to transport it.
IMPORTANT
RECEPTION OF THE MERCHANDISE
Take care to verify that the received equipment is not damaged before signing the delivery receipt. If
a damage or a lost part is noticed, write it clearly on the receipt. If it is noticed after carrier left,
contact immediately the freight company in order that they do their inspection.
We do not assume the responsibility for damages or losses that may occur during transportation.

A3
W A R N I N G S
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF THIS OR ANY APPLIANCE.
IMPORTANT
INSTALLATION AND SERVICE
Installation and service must be done by specialized technicians. Contact a certified electrician and
plumber for set up.
The proofer must be connected to the utility and electrically grounded in conformity to the effective
local regulations. If these are not established, the oven must be connected according to the Canadian
Electrical Code (CSA-C22.1-XX) or National Electrical Code (NFPA 70-XX). Refer to last
edition year for XX.

A4
DISTANCES TO RESPECT
•Top of the proofer: a clearance of 12 inches to the ceiling must exist to permit maintenance.
•Back and sides: 0 inch clearance.
I N S T A L L A T I O N
IN GENERAL
Take off the packaging material with care. Take off all the material used for packing and
accessories.
Each unit is set up to be used with the electrical supply specified on the nameplate fixed on the front
of the unit.
Always LOCK the wheels after installation and use a flexible conduit.
1. To the electrician
Electrical supply installation must be in accordance with the electrical rating on the nameplate and
use flexible wire.
2. To the plumber
MANUAL WATER FILL
No water line is required. Water is filled manually in the pan inside the proofer.
This equipment is to be installed to comply with the applicable federal, state or local plumbing codes.
Connect the steam system (1/4 NPT) to the cold water distribution network. We highly
recommend a water softener to eliminate minerals in the water. We suggest to use CUNO #
CFS6135 (Doyon part number PLF240).

A5
O P E R A T I O N
1. Switch "ON".
2. Set the thermostat control at 100oF.
3. Fill water pan if not automatic and set the humidity control at 4.
If there is too much fog and water drips from the glass doors, adjust humidity control to a
lower number.
4. When the temperature is stabilized, put the products in the proofer.
(Leave them inside until they are ready to bake.)
5. When proofing cycle is completed, turn the switch "OFF".
When the proofer is not in operation, open the doors to let out the humidity and then prevent
mould.
P.S. The doors should not be opened unnecessarily to conserve the heat and humidity in the
proofer.
Every day cleaning of the water pan under the proofer's doors should be exercised.
POWER FAILURE
When the power comes back, the proofer will start automatically. Then it is recommended to turn off
the unit to avoid it starting without supervision.

A6
TROUBLESHOOTING
BEFORE CALLING FOR SERVICE
ANSWERS TO MOST FREQUENT QUESTIONS
Always cut off the main power before replacing any parts. Take care of water piping and
electric cable.
Control parts on the front. To remove parts from front panels, you have to
go on the top of the unit.
Control panel, proofer unit and refrigeration
unit.
They are located on the top.
Questions Solutions
The unit does not turn on when installed. Check if the light is on.
Check if the proofer switch is on.
Check the breaker of the building.
Check the fuses on the front and in the
electrical control panel.
The blower runs but the unit does not
produce heat.
Make sure that the thermostat is adjusted to the
desired temperature (over ambient temperature)
and the pilot light is lit.
The blower runs but the unit does not
produce steam.
Make sure that the humidity control is set at
about 4.
Check if you have water in the pan and if the
pan is sit properly on the element.

A7
MAINTENANCE AND CLEANING
Step by step Recommendations
Clean the inside of the unit with water and
soap.
We recommend and sell:
Dirt Buster III : Action foam cleaner
CHEMCO
Part number : NEB201
Clean the unit exterior with a stainless steel
polish.
We recommend and sell:
Stainless steel cleaner
SANY or CURTIS (comestible)
Part number : NES201
CAUTION
Save these instructions.

A8
FOR MORE INFORMATION,
PLEASE CONTACT OUR OFFICE :
DOYON EQUIPMENT INC.
1255, rue Principale
Linière, Qc, Canada G0M 1J0
Tel. : [phone]
Canada : 1 [phone]
U.S. : 1 [phone]
FAX : [phone]
Internet: www.doyon.qc.ca
E-Mail : [email protected]

SECTION
B
DIMENSIONS

B1

B2

SECTION
E
COMPONENT PARTS

E1

E2
Item Part Number Description Quantity
1 ELT627 THERMOSTAT 110°F 1
AND ELT628 THERMOSTAT KNOB 110°F 1
AND ELT620 THERMOSTAT BEZEL 1
2 ELL650 RED PILOT LIGHT 2
3 ELI230 INFINITY SWITCH 240V (HUMIDITY CONT.) 1
AND ELI240 INFINITY SWITCH KNOB 1
4 ELI550 MAIN SWITCH (SELECTOR) 1
AND ELI555 CONTACT BLOCK 1NO 1
AND ELI556 ON - OFF PLATE 1
5 ELB096 5A BREAKER 1
6 QUP465 DOOR HANDLE STAINLESS TUBING 2
7 VT1251 TEMPERED GLASS 5 MM 12" X 51 3/4" 2
AND MBAV1921 ALUMINIUM DOOR EXTRUSION 2
8 QUP320 DOOR HINGE 4
9 QUA200 DOOR MAGNET 2
10 STP500 STAINLESS STEEL WATER PAN FOR BOTTOM DOOR 1
11 REEF10 STAINLESS STEEL WATER PAN 1
12 ELE185 ELEMENT (CIRCULAR) 120V 1250W FOR PROOFER 1
Model : DP14 View : FRONT & SIDE

E3

E4
Item Part Number Description Quantity
1 ELM731 MOTOR BLOWER 115 CFM 1
2 ELE130 COIL ELEMENT 120V 1500W 1
3 ELB072 TERMINAL BLOCK 3P 175A 1
4 ELL050 GROUND LUG 1
5 ELC860 CONTACTOR 2P 30A 110V 1
6 ELT505 HIGH LIMIT TEMPERATURE 300° 1
Model : DP14 View:

LIMITED WARRANTY
(Continental United States Of America And Canada Only)
Doyon Equipment Inc. guarantees to the original purchaser only that its product are free of defects in
material and workmanship, under normal use.
This warranty does not cover any light bulbs, thermostat calibration or defects due to or resulting
from handling, abuse, misuse, nor shall it extend to any unit from which the serial number has been
removed or altered, or modifications made by unauthorized service personnel or damage by flood,
fire or other acts of God. Nor will this warranty apply as regards to the immersion element damaged
by hard water.
The extent of the manufacturer’s obligation under this warranty shall be limited to the replacement or
repair of defective parts within the warranty period. The decision of the acceptance of the warranty
will be made by Doyon Equipment service department, which decision will be final.
The purchaser is responsible for having the equipment properly installed, operated under normal
conditions with proper supervision and to perform periodic preventive maintenance.
If any parts are proven defective during the period of one year from date of purchase, Doyon
Equipment Inc. hereby guarantees to replace, without charge, F.O.B. Linière, Quebec, Canada, such
part or parts.
Doyon Equipment Inc will pay the reasonable labor charges in connection with the replacement
parts occurring within one year from purchase date. Travel over 50 miles, holiday or overtime
charges are not covered. After one year from purchase date, all labor and transportation charges in
connection with replacement parts will be the purchaser’s responsibility.
Doyon Equipment Inc. does hereby exclude and shall not be liable to purchaser for any consequential
or incidental damages including, but not limited to, damages to property, damages for loss of use,
loss of time, loss of profits or income, resulting from any breach or warranty.
In no case, shall this warranty apply outside Canada and continental United States unless the
purchaser has a written agreement from Doyon Equipment Inc.
