Dräger Medical Narkomed Mobile Operating manual

Service
Manual
Technical
Date: 5 May 2004
© 2004 Draeger Medical, Inc.
Part Number: 4115138-001
Rev: R
Narkomed Mobile
Anesthesia System
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

i
Narkomed Mobile Service Manual Table of Contents
DESCRIPTION PAGE
What's New in Rev. R
Section 1: Introduction
General Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1 Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2 Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.3 General Troubleshooting Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.4 Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.5 Symbol Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Section 2: Diagnostics
2.1 Main Service Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2 Service Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.3 PMS Criteria Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.4 Oxygen Monitor Service Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.5 Pressure Monitor Service Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.6 Serial Port Configuration Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Section 3: Troubleshooting
3.1 Power Supply and Voltage Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.3 Troubleshooting Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Section 4: Replacement Procedures
4.1 Cylinder Yokes and Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2 Cylinder and Pipeline Pressure Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.3 Flowmeters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4.4 Auxiliary O2 Flowmeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
4.5 Flow Control Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
4.6 Oxygen Supply Failure Protection Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
4.7 Oxygen Supply Pressure Alarm Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
4.8 O2 - Air Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
4.9 System Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
4.10 Oxygen Ratio Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28
4.11 O2 Flush Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31
4.12 Ventilator Controller (Bezel Assembly) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
4.13 Bellows Valve Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37
4.14 Caster Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39
4.15 Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-41
4.16 Power Supply Assembly Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-43
4.17 Processor Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
4.18 Display Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-49
4.19 Breathing Pressure Hose Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-51
4.20 Manual/Automatic Selector Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-53
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

ii
CONTENTS (continued)
DESCRIPTION PAGE
NM MOBILE
4.21 Ultrasonic Flow Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-55
4.22 Oxygen Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-57
Section 5: Adjustment and Calibration Procedures
5.1 Cylinder Pressure Regulator Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.2 Oxygen Supply Pressure Alarm Switch Adjustment . . . . . . . . . . . . . . . . . . . . . 5-4
5.3 Oxygen Ratio Controller (ORC) Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
5.4 Oxygen Sensor Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
5.5 Breathing Pressure Monitor Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Section 6: PMC Procedure, Narkomed Mobile
6.1 Self-Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
6.2 Electrical Safety- One Year Service Interval; Due Date _____ . . . . . . . . . . . . . 6-12
6.3 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
6.4 Service Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
6.5 Calibrations - One Year Service Interval; Due Date ______ . . . . . . . . . . . . . . . 6-15
6.6 Absorber Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
6.7 High Pressure Leak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17
6.8 Breathing System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
6.9 Oxygen Analyzer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21
6.10 Flowmeters & Concentrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
6.11 High Pressure Regulators - Six Month Service Interval;
Due Date _____ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-24
6.12 Low O2 Supply – Six Month Service Interval; Due Date ______ . . . . . . . . . . . 6-25
6.13 Oxygen Supply Failure Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
6.14 Pressure Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
6.15 Ventilator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27
6.16 Bellows Adult . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-29
6.17 Scavenger- Six Month Service Interval; Due Date ______ . . . . . . . . . . . . . . . . 6-30
6.18 Final Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-32
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

iii
CONTENTS (continued)
DESCRIPTION PAGE
NM MOBILE
Section 7: Update Procedure
7.1 Software Transfer to PC Via Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.2 Installing Narkomed Mobile Software from a PC . . . . . . . . . . . . . . . . . . . . . . . 7-1
Section 8: Spare and Replacement Parts
Vaporizer & rel. parts, fresh gas outlet, mainswitch, flowmtr sub-asm . . . . . . 8-2, 8-3
Processor Assembly and related parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4, 8-5
Ventilator Controller (Bezel Assembly). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6, 8-7
Bellows Valve Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8, 8-9
Bellows Valve Assembly Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9A, 8-9B
Display Assembly and Monitor Support Arm . . . . . . . . . . . . . . . . . . . . . . . . . 8-10, 8-11
Pipeline Inlet (Manifold) Assemblies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12, 8-13
Failsafe (OFPD) and ORC Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14, 8-15
Main Switch Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16, 8-17
O2 Supply Pressure Switch, O2 - Air Switch . . . . . . . . . . . . . . . . . . . . . . . . . 8-18, 8-19
Flowmeter Shield, Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-20, 8-21
Flow Tubes, Restrictor Assemblies, Flow Control Valves . . . . . . . . . . . . . . . 8-22, 8-23
Auxiliary O2 Flowmeter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-24, 8-25
Cylinder Yokes, Regulators, O2 Flush Valve . . . . . . . . . . . . . . . . . . . . . . . . . 8-26, 8-27
Frame, Casters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-28, 8-29
Power Supply Assembly and related items. . . . . . . . . . . . . . . . . . . . . . . . . . . 8-30, 8-31
Absorber, Inspiratory Valve, Ultrasonic Flow Sensor . . . . . . . . . . . . . . . . . . 8-32, 8-33
Valve, Man/Auto Selector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-34, 8-35
Breathing Pressure Hose Assembly, O2 Sensor, PEEP Valve, Exp. valve . . 8-36, 8-37
Scavenger, Touch-up paint: Euro white, Euro Blue . . . . . . . . . . . . . . . . . . . . . . . 8-38, 8-39
Miscellanous Items. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-40
Section 9: Specifications
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Contents continues on next page with a List of Figures.
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

iv
CONTENTS (continued)
DESCRIPTION PAGE
NM MOBILE
List of Figures
Narkomed Mobile Anesthesia System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-0
2-1 Power-up Diagnostic Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2-2 Main Service Screen, View Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2-3 Main Service Screen, Service Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2-4 Main Service Screen, ID Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2-5 Service Log Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2-6 PMS criteria Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2-7 Oxygen Monitor Service Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2-8 Pressure Monitor Service Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2-9 Serial Port Configuration Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
3-1 Power Supply Voltage Test Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3-2 Narkomed Mobile Power Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
4-1 Cylinder Yokes and Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4-2 Cylinder and Pipeline Pressure Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4-2A Tubing Connections: Flowmeter Sub-assembly . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4-3 Flow Tube Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
4-4 Auxiliary O2 Flowmeter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
4-5 Flow Control Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
4-6 OFPD Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
4-7 Oxygen Supply Pressure Alarm Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
4-8 O2 - Air Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
4-9 System Power Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
4-10 Oxygen Ratio Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
4-11 O2 Flush Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
4-12 Ventilator Controller (Bezel Assembly) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36
4-13 Bellows Valve Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38
4-14 Caster Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-40
4-15 Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-42
4-16 Power Supply Assembly Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
4-16A Removal of Machine from Support Frame . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
4-17 Processor Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-48
4-18 Display Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-50
4-19 Breathing Pressure Hose Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-52
4-20 Manual/Automatic Selector Valve. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-54
4-21 Ultrasonic Flow Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-56
4-22 Oxygen Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-58
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

v
CONTENTS (continued)
DESCRIPTION PAGE
NM MOBILE
List of Figures (continued)
5-1 Cylinder Pressure Regulator Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5-2 Oxygen Supply Pressure Alarm Switch Adjustment . . . . . . . . . . . . . . . . . . . . . 5-5
5-3 Oxygen Ratio Controller (ORC) Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
5-4 Oxygen Sensor Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
5-5 Pressure Monitor Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
7-1 Narkomed Mobile Serial Port Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Vaporizer & rel. parts, fresh gas outlet, mainswitch, flowmtr sub-asm . . . . . . . . . 8-2
Processor Assembly and related parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Ventilator Controller (Bezel Assembly). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Bellows Valve Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Display Assembly and Monitor Support Arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
Pipeline Inlet (Manifold) Assemblies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
Failsafe (OFPD) and ORC Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
Main Switch Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16
O2Supply Pressure Switch, O2- Air Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-18
Flowmeter Shield, Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-20
Flow Tubes, Restrictor Assemblies, Flow Control Valves . . . . . . . . . . . . . . . . . . . 8-22
Auxiliary O2Flowmeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-24
Cyl. Yokes and Regulators, O2Flush Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-26
Casters, . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-28
Power Supply Assembly and related items. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-30
Absorber, Inspiratory Valve, Ultrasonic Flow Sensor . . . . . . . . . . . . . . . . . . . . . . 8-32
Valve, Man/Auto Selector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-34
Breathing Pressure Hose Assembly, O2Sensor, PEEP Valve, Expiratory valve . 8-36
Scavenger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-38
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

1-0
Narkomed Mobile Anesthesia System
DISPLAY
MONITOR
SUPPORT ARM
ABSORBER
ASSEMBLY
STORAGE
AREA FOR
ADDITIONAL
VAPORIZERS
VENTILATOR
CONTROLS
GAS
INSTRUMENTATION
AND CONTROL
VAPORIZER
SWING-OUT
TRAY
SWING-OUT
DRAWER
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

1-1
INTRODUCTION
NM MOBILE
General Safety Precautions
The following are general safety precautions that apply during servicing of the equipment
covered by this manual. These precautions are repeated elsewhere in this manual where
needed.
WARNINGS indicate conditions or practices which if not strictly observed could result in
personal injury.
CAUTIONS indicate conditions or practices which if not strictly observed or remedied could
result in damage to the equipment.
WARNING: Ensure that AC power is removed from the machine before removing the power
supply. Failure to observe this precaution may cause injury by electric shock.
WARNING: Possible explosive hazard if used in the presence of flammable anesthetics.
CAUTION: The flow tube must be properly centered over the guide rings or damage to the
flow tube may occur.
CAUTION: Do not over-tighten the retainer. Over-tightening the retainer may break the
flowmeter tube.
CAUTION: The controller circuit board contains static sensitive devices. Use ESD
protection when handling the controller assembly. Static discharge can damage
components on the circuit board.
CAUTION: The processor board contains static sensitive devices. Use ESD protection
when handling the processor assembly. Static discharge can damage
components on the circuit board.
CAUTION: Observe wiring colors and polarity markings to ensure that the battery is
connected correctly. Connecting the battery with reversed polarity may damage
the circuitry.
CAUTION: Always operate machine on level surface. Before moving the machine, remove
vaporizer, remove items from top shelf and display arm, secure absorber
against left side of machine.
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

1-2
INTRODUCTION (continued) NM MOBILE
1.0 Introduction
1.1 Purpose
This manual provides the information needed to field service and maintain the
Narkomed Mobile anesthesia system. The DIAGNOSTICS section describes self-test
and service diagnostics for checking the system functions. An understanding of the on-
board service capabilities is necessary before any attempt is made to troubleshoot the
unit. The TROUBLESHOOTING section shows the electrical distribution scheme and
provides troubleshooting guides to assist the TSR in locating the source of a problem.
The REPLACEMENT PROCEDURES section contains instructions for removal and
replacement of the assemblies that are considered field-replaceable. The
ADJUSTMENT AND CALIBRATION PROCEDURES section contains the field
procedures needed to restore original system specifications. The Periodic
Manufacturer's Certification (PMC) PROCEDURE section outlines the steps required
to verify the electrical, mechanical and pneumatic safety of the unit and also identifies
components requiring periodic replacement.
1.2 Recommendations
Because of the sophisticated nature of Draeger Medical, Inc. anesthesia equipment
and its critical importance in the operating room setting, it is highly recommended
that only appropriately trained and experienced professionals be permitted to service
and maintain this equipment. Please contact DrägerServiceSM at [phone] for
service of this equipment.
Draeger Medical, Inc. also recommends that its anesthesia equipment be serviced at
three-month intervals. Periodic Manufacturer's Service Agreements are available for
equipment manufactured by Draeger Medical, Inc.. For further information
concerning these agreements, please contact us at [phone].
Draeger Medical, Inc. products/material in need of factory repair shall be sent to:
DrägerService
3124 Commerce Drive
Telford, PA 18969
(Include RMA Number)
Rev. L
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

1-3
INTRODUCTION (continued)
NM MOBILE
1.3 General Troubleshooting Guidelines
Troubleshooting the Narkomed Mobile should always begin by communicating with
those who observed or experienced a problem with the unit. This may eliminate
unnecessary troubleshooting steps. Once a general problem is identified, refer to the
troubleshooting flow charts in Section 3 to determine the proper corrective action to be
taken.
After a component has been replaced, verify that the unit is operating properly by
running the appropriate diagnostic procedure. The PMC PROCEDURE in Section 6
must also be performed after any component has been replaced.
1.4 Related Publications
Narkomed Mobile Operator's Manual, Part Number 4115139-001
1.5 Symbol Definitions
CAUTION: Refer to accompanying documents before operating equipment.
CAUTION: Risk of electric shock. Do not remove cover. Refer servicing to a
qualified technical service representative.
Degree of protection against electric shock: Type B.
Rev. L
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

2-1
DIAGNOSTICS
NM MOBILE
2.0 Diagnostics
The Narkomed Mobile contains a diagnostic system that monitors certain system functions
and records their operational status. Following a brief System Startup display at power up,
the diagnostics screen shown in Figure 2-1 appears. This display includes one of three
messages at the completion of the diagnostics
FUNCTIONAL: This message indicates that the Narkomed Mobile has passed all power-up
tests and is fully functional. The machine will proceed to the MACHINE MONITOR screen
after a short delay.
CONDITIONALLY FUNCTIONAL: This message indicates that a minor problem has been
detected. The screen will retain this display until any key is pressed, then the MACHINE
MONITOR screen will be displayed.
NON-FUNCTIONAL: this message indicates that a serious problem has been detected. The
machine will not proceed into the MACHINE MONITOR or SYSTEM MONITOR screen.
The PREVENTIVE MAINTENANCE DUE message will appear on the screen if the current
date exceeds the Periodic Manufacturer's Service due date stored in the machine.
Further diagnostic functions are available through service screens that can be called up at
the display panel. The following paragraphs provide a description of each service screen that
can be accessed at the display. If no display is present upon system power-up, refer to
Section 3 of this manual for troubleshooting assistance.
Figure 2-1. Power-Up Diagnostics Screen
COPYRIGHT 1998 NAD INC.
SOFTWARE ID XXXX
DIAGNOSTIC TESTS
FIRMWARE PASS
RAM PASS
VIDEO PASS
A/D CONVERTER PASS
AUDIO -PRIMARY PASS
-BACKUP PASS
SERIAL I/O PASS
CLOCK PASS
NON-VOLATILE MEMORY PASS
PREVENTIVE MAINTENANCE DUE
FUNCTIONAL
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

2-2
DIAGNOSTICS (continued) NM MOBILE
2.1 Main Service Screen
2.1.1 View Mode
The Main Service Screen displays the machine serial number, the last service
date, hours run since last service and total hours run.
To access the Main Service Screen, press and hold the Oxygen High Limit and
Volume Low Limit keys, and press the key. The View Mode service screen
shown in Figure 2-2 will then appear.
Press the key to proceed to the Service Mode as shown in Figure 2-3, or press
the key next to EXIT to return to the monitoring screen.
Figure 2-2. Main Service Screen, View Mode
#
#
MAIN SERVICE SCREEN
MACHINE SERIAL NUMBER : XXXXXXXX
LAST SERVICE DATE : 8-30-1998
HOURS RUN SINCE LAST SERVICE: 263
TOTAL HOURS RUN : 624
SERVICE CODE
SRVC
LOG
PMS
SCHED
MON
CAL
PORT
SELECT
EXIT
VIEW
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

2-3
DIAGNOSTICS (continued)
NM MOBILE
2.1.2 Service Mode
In this screen, the Service Code changes to SRVC.
Press the key next to SELECT to enable the Technical Service ID entry as
described on the next page.
Figure 2-3. Main Service Screen, Service Mode
MAIN SERVICE SCREEN
MACHINE SERIAL NUMBER : XXXXXXXX
LAST SERVICE DATE : 8-30-1998
HOURS RUN SINCE LAST SERVICE: 263
TOTAL HOURS RUN : 624
SERVICE CODE
SRVC
LOG
PMS
SCHED
MON
CAL
PORT
SELECT
EXIT
SRVC
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

2-4
DIAGNOSTICS (continued) NM MOBILE
2.1.3 Service Mode: I.D. Entry
The Service Mode screen appears as shown in Figure 2-4. Press the key next to
SELECT. Enter the first digit of your service code by using the and keys to
display the desired character. Press the key next to SELECT to advance to the
next digit, and enter the next and remaining I.D. characters in the same manner.
When this screen is entered, an entry is made in the Service Log.
To access any of the other service screens described on the following pages, press
the key next to the desired function on the left side of the screen: Service Log,
PMS Schedule, Monitor Calibration, or Port communication settings.
Pressing the key next to RESET will reset the HOURS RUN SINCE LAST
SERVICE to zero, and the LAST SERVICE DATE to the current date.
If desired, press the key next to EXIT to return to the monitoring screen.
Figure 2-4. Main Service Screen, ID Entry
#$
MAIN SERVICE SCREEN
MACHINE SERIAL NUMBER : XXXXXXXX
LAST SERVICE DATE : 8-30-1998
HOURS RUN SINCE LAST SERVICE: 263
TOTAL HOURS RUN : 624
SRVC
LOG
PMS
SCHED
MON
CAL
PORT
SELECT
EXIT
TECHNICAL SERVICE
REPRESENTATIVE I.D.
0 0 0 0
RESET
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

2-5
DIAGNOSTICS (continued)
NM MOBILE
2.2 Service Log
From the Service Screen (described earlier), press the key next to SRVC LOG.
Figure 2-5 shows an example of the screen that will appear. This screen allows you to
view the events recorded in the machine's service log. Use the and keys to
scroll down or up through the log entries.
Press the key next to EXIT to return to the Main Service Screen.
Figure 2-5. Service Log Screen
$#
DATE TIME PARAMETER CODE
09-11-98 10:26 00000000 0000
SYSTEM POWERUP
09-11-98 10:30 00000000 E400
AUDIOGEN SPKR CHK
09-13-98 07:30 00000004 E100
EXIT
SERVICE LOG
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

2-6
DIAGNOSTICS (continued) NM MOBILE
2.3 PMS Criteria Screen
The PMS Criteria Screen allows you to select the month when the PREVENTIVE
MAINTENANCE DUE message appears on the power-up diagnostics screen.
From the Service Screen (described earlier), press the hidden key next to PMS
SCHED.
Figure 2-6 shows an example of the screen that will appear. Use the and keys to
set the desired month.
Press the key next to EXIT to return to the Main Service Screen.
Figure 2-6. PMS Criteria Screen
#$
SELECT CRITERIA FOR
“PREVENTIVE MAINTENANCE” MESSAGE
1998
EXIT
MONTH SEP
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

2-7
DIAGNOSTICS (continued)
NM MOBILE
2.4 Oxygen Monitor Service Screen
The Oxygen Monitor Service Screen shown in Figure 2-7 displays current readings for
the O2cells, a zero calibration procedure, and the stored calibration values.
From the Service Screen (described earlier), press the key next to MON CAL.
To perform a zero calibration, follow the calibration procedure shown on the screen.
Pressing the key next to ZERO stores the current values as the new zero calibration.
To proceed to the Pressure Monitor Service Screen, press the key next to PRES MON.
To return to the Main Service Screen, press the key next to EXIT.
Figure 2-7. Oxygen Monitor Service Screen
OXYGEN MONITOR SERVICE SCREEN
CURRENT CELL A: 238
CURRENT CELL B: 250
ZERO CALIBRATION PROCEDURE:
- REMOVE O2 CELL FROM HOUSING
- LET CURRENT CELL VALUES STABILIZE
- PRESS “ZERO” KEY TO ENTER
CALIBRATION VALUES
- REINSTALL O2 CELL IN SENSOR HOUSING
STORED ZERO CELL A: 250
STORED ZERO CELL B: 250
EXIT
ZERO
PRES
MON
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS

2-8
DIAGNOSTICS (continued) NM MOBILE
2.5 Pressure Monitor Service Screen
The Pressure Monitor Service Screen shown in Figure 2-8 displays the current
reading for airway pressure, a procedure for zero and span calibration, and the stored
calibration values.
To enter the Pressure Monitor Service Screen from the Oxygen Monitor Service
Screen (described earlier), press the key next to PRES MON (ref. Figure 2-7).
To perform a zero calibration, follow the procedure shown on the screen. Pressing the
key next to ZERO stores the current value as the new zero calibration.
To perform a span calibration, follow the procedure shown on the screen. Pressing the
key next to SPAN stores the current value as the new span calibration.
To return to the Oxygen Monitor Service Screen, press the key next to OXY MON. To
return to the Main Service Screen, press the key next to EXIT.
Figure 2-8. Pressure Monitor Service Screen
PRESSURE MONITOR SERVICE SCREEN
CURRENT PRESSURE VALUE: 250
ZERO CALIBRATION PROCEDURE:
- REMOVE PRESSURE SAMPLE LINE FROM
ABSORBER, EXPOSE TO AIR.
- LET CURRENT PRESSURE VALUE STABILIZE
- SELECT “ZERO” KEY TO
ENTER CALIBRATION VALUES.
SPAN CALIBRATION PROCEDURE:
- REMOVE PRESSURE SAMPLE LINE FROM
ABSORBER, APPLY 50 CMH2O CONSTANT
PRESSURE AT THE SAMPLE LINE, VERIFIED
BY A KNOWN, CALIBRATED METER.
- LET PRESSURE VALUE STABILIZE
- SELECT THE “SPAN” KEY TO
ENTER THE CURRENT VALUE.
EXIT
ZERO
OXY
MON
SPAN
RETURN TO CD-ROM TABLE OF CONTENTS
RETURN TO THIS MANUAL'S TABLE OF CONTENTS
