Dräger Alcotest 5820 User manual

i
Dräger Alcotest 5820
WARNING
Strictly follow the Instructions for Use.
The user must fully understand and strictly observe the instructions.
Use the product only for the purposes specified in the Intended use
section of this document.
!
enUS Instructions for use
3
fr Notice d’utilisation
18
es Instrucciones de uso
33

2
OK
1
9
2
3
4
7
8
6
14
5
00133580.eps
11
13
10
12
For description of device parts, please
voir « Description », page 4
Pour obtenir une description des pièces,
voir « Description », page 19
Para la descripción de las piezas del
aparato, consulte voir « Descripción »,
page 34
en
fr
es

For your safety
3
en
1 For your safety
1.1 General safety notes
Before using this product, carefully read the Instructions for Use.
Strictly follow the Instructions for Use. The user must fully understand
and strictly observe the instructions. Use the product only for the
purposes specified in the Intended use section of this document.
Do not dispose of the Instructions for Use. Ensure that it is retained
and appropriately used by the product user.
Comply with all local and national rules and regulations associated
with this product.
Only trained and competent personnel are permitted to inspect,
repair and service the product. Dräger recommend a Dräger
service contract for all maintenance activities and that all repairs
are carried out by Dräger.
Do not use a faulty or incomplete product. Do not modify the product.
Notify Dräger in the event of any component fault or failure.
2 Conventions used in this document
2.1 Definitions of alert icons
The following alert icons are used in this document to provide and
highlight areas of the associated text that require a greater awareness
by the user. A definition of the meaning of each icon is as follows:
WARNING
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.

Description
4
en
2.2 Typographical conventions
This symbol indicates information which facilitates the use of the
product.
3 Description
3.1 Product overview
1 Breath-alcohol-analyzer
2 button (switch instrument on/off; confirm inputs)
3 button (open menu; set value)
4 LEDs
5 Mouthpiece receptacle (configurable: right or left)
6 Display
7 button (set value)
8 USB connection (Important: Not for charging the device, for
Service only)
9 Wrist strap
10 Battery compartment cover
11 Battery
12 Pull strap for battery replacement
13 Loudspeaker (Important: Not reset button)
14 Mouthpiece
3.2 Intended use
The Dräger Alcotest® 58201) is used for measuring the alcohol
concentration in the breath of a human. The measurement is used as
an indication for alcohol intoxication. Based on the measurement
results no therapeutic measures should be initiated.
1) Alcotest is a registered trademark of Dräger.

Use
5
en
4 Use
WARNING
Small parts of the device can come loose and be swallowed.
► Keep the device out of reach of children under the age of 3.
4.1 Prerequisites
The instrument is factory-calibrated when delivered. If the calibration
date has exceeded12 months, the instrument should be adjusted, e.g.
by DrägerService. It is still possible to use the device, even if the
calibration period is exceeded. After the last alcohol intake, wait
approx. 15 minutes before a measurement is carried out. Residual
mouth-alcohol may cause incorrect measuring results. This may also
occur by aromatic drinks (e.g. fruit juices), alcoholic mouth sprays,
medicines and drops, as well as by burping and vomiting. Rinsing the
mouth with water or non-alcoholic drinks does not replace the wait
time!
4.2 Initial start-up
A quick setup process (“wizard”) starts when the instrument is
switched on for the first time. This step is not required for
pre-configured instruments.
The following settings are accessible using the wizard:
Language
Date format
Date
Time format
Time
Measuring unit
All settings can be changed later on via the menu.

Use
6
en
4.3 Carrying out an automatic breath test
A new mouthpiece must be inserted for each new person who
provides a breath test.
Do not allow any high alcohol concentrations on the sensor, e.g.
by rinsing the mouth with a high proof alcohol shortly before the
measurement, as this will shorten the service life of the sensor.
1. Remove mouthpiece (order no. 68 10 690 “Standard”, 68 11 055
“with back valve”)
2. For reasons of hygiene, leave the protective wrapping around the
mouth contact area. Open the packaging at the perforation and
take off the protective wrapping only around the attachment area
of the mouthpiece.
3. Attach the mouthpiece at an angle to the mouthpiece receptacle.
4. Press it into the receptacle. The fluted markings (press-on surface)
on the mouthpiece faces upwards while this is done. The
mouthpiece audibly snaps into place (see page 2).
5. Remove all packaging.
6. Keep the button pressed for approx.1 second until the startup
screen is displayed. An optional self-test is carried out.
7. After approx. 4 seconds the display shows READY and the
instrument is now ready to test. Take a deep breath and blow
evenly and without interruptions into the mouthpiece as long as
possible. A progress bar is displayed. An adequate breath flow is
confirmed by a continuous tone.
8. Without any further action from user side, the device takes
automatically a test sample at the end of the breath of the test
subject.
9. The continuous tone is muted directly afterwards which gives the
signal that the test subject can stop with blowing. The test result is
displayed with date and time after 5 to 25 seconds (depending on
the instrument temperature and the measured concentration).
In case of a negative alcohol test, 0,00 will be displayed.

Use
7
en
In case of a positive alcohol test, the measured alcohol level will be
displayed.
To perform a new measurement, press the button.
After the sensor‘s short recovery time, (see "Technical data" on
page 15) READY will be displayed and the device is ready to use
again.
4.4 Performing a manual breath test (optional)
If the test subject cannot provide the required minimum volume, the
sampling of breath can be triggered manually.
1. Preparation as for the automatic breath test (see chapter 4.3 on
page 6).
2. If the progress bar is displayed after breath flow is detected, tap
the button.
In the results display, MANUAL is also displayed.
4.5 Performing a passive breath test (optional)
With passive sampling, the sampling is initiated manually by the
instrument user. The passive test must be done without an attached
mouthpiece. Possible applications include the testing of ambient air or
the breath of persons for the presence of alcohol. To perform a passive
test:
1. Keep the button pressed for approx.1 second until the startup
screen appears.
2. Hold the instrument into the air to be analyzed without a
mouthpiece.
3. Briefly press the button to initiate the measurement.
The device will take a test sample at that very moment and will
start analyzing.
In the results display, PASSIVE is also displayed. If no alcohol is
detected, the No Alcohol will be displayed and the LED will be green.
In case alcohol is detected, Alcohol will be displayed and the LED will
be red.

Use
8
en
4.6 Switching off the Instrument
The instrument will switch off after pressing the button for approx. 3
seconds. A switch-off count down will be shown as well. If the display
is off, stop pressing the button. Otherwise the device will be switched
on again.
The instrument will switch off automatically after approx. 4 minutes
without any activity.
Switching off the instrument does not reduce the post-test
waiting period before you can perform another test.
4.7 Removing the mouthpiece
1. Push the mouthpiece upwards out of the mouthpiece receptacle.
2. Dispose of the mouthpiece in accordance with local regulations.
Do not reuse a mouthpiece.
4.8 Settings/information
Start the device pressing until READY is displayed.
To enter the device menu, press the button.
In the main menu all menu options are listed one below the other.
To navigate within the options list and select a menu option:
1. Press or button to mark the respective menu option with the
cursor.
2. Confirm the selected menu option with the button.

Use
9
en
The following table provides an overview of the menu options and how
to use them:
Menu option Description Interaction
instruction
Measuring Option to leave the
menu and to go back to
the READY screen to
perform a test.
press to leave
the menu and
prepare for
measuring
Results Overview of the last
tests performed on the
device (incl. result,
date, time, test ID).
There is one test dis-
played per screen.
press to enter
the menu
press or to
navigate through
the list
Date/Time Date: to set the date
Time: to set the time
Date format: to choose
a format (yyyy/mm/dd,
yyyy-mm-dd, mm/dd/
yyyy, dd.mm.yyyy)
Time format: to choose
a format (12 or 24)
press to enter
the menu
press or to
navigate through
the list
press to select
the option
change a setting or
number by
pressing or
press to
confirm, the
submenu will be
displayed again
select Back to
leave the submenu

Use
10
en
Contrast The display contrast
can be adjusted within
5 levels.
press to enter
the menu
change the setting
by pressing or
press to
confirm
Speaker Any acoustic signals of
the device can be
turned off or to a
volume of 50% or
100%.
press to enter
the menu
change the setting
by pressing or
Language The language of the
display can be
adjusted.
press to enter
the menu
choose the
language by
pressing or
press to
confirm
Meas. unit The measurement
results can be
displayed in the
following units: %, ‰,
g/L, mg/100 mL, mg%,
mg/mL, mg/L, μg/100
mL, μg%, μg/L, g/210
L.
press to enter
the menu
choose the unit by
pressing or
press to
confirm
Software Version Software version and
part number are
displayed.
press to enter
or leave the menu
Menu option Description Interaction
instruction

Use
11
en
An error message is displayed in the event of an instrument fault.
The number that appears below the message is used for service
functions. If the fault remains after switching the instrument on and off
several times, contact DrägerService.
Login Option for service
technicians only. Do
not enter this
submenu.
Switch off Device can be
switched off.
Hold the button for
4 seconds to
switch off the
device.
Menu option Description Interaction
instruction

Troubleshooting
12
en
5 Troubleshooting
Fault / message Cause Remedy
Instrument cannot
be switched on.
Battery empty. Replace the battery.
Volume too low /
sample invalid.
Test subject is blowing
intermittently or not
hard enough.
Blow more strongly and
without interruptions
into the mouthpiece.
Volume too large Measuring range
exceeded.
Repeat breath test.
Instrument outside
temperature range
Instrument too hot or
too cold.
Allow the instrument to
cool down or become
warmer.
Measuring range
exceeded
Measuring range
exceeded. Residual
mouth alcohol may
cause incorrect
measuring values.
There must be an
interval of at least
15 minutes after alcohol
has been taken into the
mouth (see page 6).
To repeat, press the
button.
Sample interruption Abrupt breath
interruption or
inhalation detected
Repeat breath test.
Fault number Instrument fault Switch the instrument
off and on again. If the
fault remains, contact
DrägerService.

Maintenance
13
en
6 Maintenance
Dräger recommends a device calibration every 12 month, because of
the sensor drift the uncertainty of measurement increases over time.
Instrument calibration and maintenance should only be carried out by
authorized persons, e.g. DrägerService.
The last 30 days before next adjustment / service is needed, a day
count down will be shown as information in the display after switching
on the device. You have to confirm this information with the button.
After the adjustment / service date the device starts to count up how
many days it is over requested adjustment / service. This information
has to be confirmed by pressing the button as well. It shall
remember you that the device needs to be adjusted / serviced.
Have the instrument re-calibrated, if an accuracy check does not
produce a result per NHTSA‘s EBT Model Specifications. Calibrations
should only be carried out by authorized persons, e.g. DrägerService.
6.1 Replacing the battery
1. If necessary, switch off the device.
2. Slide the battery cover off.
3. Replace the battery (battery type: 3 V CR123A; order no.
83 21 390), by observing the correct polarity.
4. Replace the battery cover.
5. Verify that the time is set correctly.
If the battery replacement process takes longer than 5 minutes,
the time must be reset. A measurement is only possible with the
time set.

Maintenance
14
en
6.2 Cleaning
Do not immerse in fluids and avoid contact of fluids with the electrical
receptacles. Do not use any cleaning agents containing alcohol,
solvents or substances containing citrus. Wipe down the instrument
with a disposable cloth.

Technical data
15
en
7 Technical data
Measuring principle
Electrochemical sensor
Measuring range
Breath alcohol concentration 0.000 to 0.500 g/210L
Blood alcohol concentration 0.000 to 0.500% BAC
Small values will be shown as
0.000
0.000 to 0.0063 g/210L
Ethanol mass per blood volume or mass at 20°C/ 68 °F and 1013 hPa.
For the above data, a conversion factor of 2100 is used for breath
and blood alcohol concentration data.
Units of measure
%, ‰, g/L, mg/100 mL, mg%, mg/mL, mg/L, μg/100 mL, μg%, μg/L, g/210 L
Ambient conditions
During operation -5°C to +50°C / +23°F to +122°F
10 to 100% rel. hum.
(non-condensing)
600 to 1300hPa
During storage -20°C to +70°C / -4 to +158°F
Taking Samples
Respiratory volume >1.3 L (default)
Minimum flow rate >10 L/min (default)
Minimum blow time >1.6 s (default)

Technical data
16
en
Measurement accuracy
Standard deviation of the repeatability with ethyl alcohol standard
Up to 0.50 mg/L 0.008 mg/L
≥0.50 mg/L 1.7% of the measured value
up to 0.100 % BAC 0.0017 % BAC or
≥ 0.100 % BAC 1.7% of the measured value
whichever value is higher
Sensitivity drift
Typically 0.4 % of the measured value per month
Wait time for measurement readiness following a previous
measurement with:
0.25 mg/L 20 s 0.050 % BAC 20 s
0.50 mg/L 40 s 0.100 % BAC 40 s
1.00 mg/L 80 s 0.200 % BAC 80 s
>1.50 mg/L 120 s >0.300 % BAC 120 s
Calibration
every 12 months
Dimensions
1.96/2.36 “ x 5.55“ x 1.22“ (W x H x D)
Weight
approx. 144 g/ 5.1 oz
Power supply
1 x 3 V CR123A

Technical data
17
en
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Interface
USB, 2.0 fullspeed (for service only)
Protection class
IP 54
CE markings
Electromagnetic compatibility (Directive 2014/30/EU).
Configuration possible, see name plate

Pour votre sécurité
18
fr
1 Pour votre sécurité
1.1 Consignes générales de sécurité
Veuillez lire attentivement la notice d'utilisation du produit avant
de l'utiliser.
Veuillez respecter exactement les instructions de la notice
d'utilisation. L'utilisateur devra parfaitement comprendre ces
instructions et les exécuter très précisément. Le produit ne peut
être utilisé que conformément à son domaine d'application.
Veuillez ne pas jeter la notice d'utilisation. Veuillez vérifier qu'elle est
conservée et utilisée correctement par l'utilisateur de ce produit.
Veuillez respecter les réglementations locales et nationales
applicables à ce produit.
Seul le personnel compétent et muni de la formation adéquate est
autorisé à contrôler, réparer et entretenir le produit. Dräger
recommande de souscrire un contrat de maintenance pour toutes
les interventions de maintenance et de laisser le personnel de la
société prendre en charge les réparations.
Veuillez ne pas utiliser de produits défectueux ou incomplets. Veuillez
ne pas modifier le produit.
Veuillez informer Dräger en cas de défaut ou de panne de
quelconque composant.
2 Conventions utilisées dans ce document
2.1 Signification des symboles d'avertissement
Les symboles d'avertissement suivants sont utilisés dans ce
document pour signaler et mettre en avant les textes d'avertissement
associés auxquels l'utilisateur doit prêter une attention particulière.
Les icônes sont définies comme suit :
AVERTISSEMENT
Signale une situation potentiellement dangereuse qui, si elle n'est pas
évitée, pourrait entraîner des blessures graves ou mortelles.

Description
19
fr
2.2 Conventions typographiques
Ce symbole précède une information destinée à faciliter
l'utilisation de l'appareil.
3 Description
3.1 Aperçu du produit
1 Éthylotest respiratoire
2 Bouton (marche / arrêt, confirmation de saisie)
3 Bouton (ouverture de menu, définition de valeur)
4 DEL
5 Emplacement pour embout buccal (configurable : à droite ou
à gauche)
6 Écran
7 Bouton (définition de valeur)
8 Port USB (importan t: réservé au service, ne sert pas à recharger
l'appareil)
9 Dragonne
10 Couvercle du logement de la pile
11 Pile
12 Tirer sur la languette pour remplacer la pile
13 Haut-parleur (important : pas un bouton de réinitialisation)
14 Embout buccal
3.2 Domaine d'application
L'alcootest Dräger Alcotest® 58201) sert à mesurer la concentration
d'alcool dans l'haleine humaine. Cette mesure est destinée à
déterminer le taux d'alcoolisation des personnes testées. Elle ne
devrait en aucun cas servir de base à des mesures thérapeutiques ni
à des mesures juridiques.
1) Alcotest est une marque déposée de Dräger.

Utilisation
20
fr
4 Utilisation
AVERTISSEMENT
Les petits composants de l'appareil peuvent se détacher et être avalés.
►Tenez l’appareil hors de la portée des enfants de moins de 3 ans.
4.1 Conditions d'utilisation
L'appareil est livré calibré en usine. Si le dernier calibrage remonte à plus
de 12 mois, l'appareil devrait être recalibré, par ex. par DrägerService.
L'appareil peut cependant être quand même utilisé si la période de
calibrage est dépassée. Veuillez attendre env. 15 min entre deux tests.
La présence d'alcool résiduel dans la bouche peut fausser la mesure.
Certaines boissons aromatisées (par exemple jus de fruit), les liquides
de rinçage ou sprays buccaux, les sirops et les gouttes, un renvoi ou
vomissement peuvent influencer les résultats. Un rinçage de la bouche
avec de l’eau ou une boisson non alcoolisée ne remplace pas le temps
d’attente.
4.2 Première mise en service
Un programme de configuration rapide (Assistant) s'affiche à la
première mise en service de l'appareil. Cette étape n'est pas requise
pour les appareils préconfigurés.
L'assistant de configuration vous aide à effectuer les réglages
suivants :
Langue
Format de la date
Date
Format de l'heure
Heure
Unité de mesure
Tous les réglages peuvent être modifiés dans le menu.
