Dr. Trust FR200 User manual

1
Infrared Forehead Thermometer User
Manual

2
①Measuring Sensor
②Tracking light
③START Button
④Display
⑤ON/OFF Button
⑥Mode Switch
⑦Battery Compartment Cover
⑧All Segments displayed
⑨Memory
⑩Ready for Measurement
⑪Measurement complete
⑫Body Mode
⑬Object Mode
⑭Low Battery Indication
⑮Changing between Celsius
and Fahrenheit
⑯Recall Mode
⑰Recall the last 30 Readings
⑱Measured Temperature too
high
⑲Measured Temperature too
low
⑳Ambient Temperature too
high
○
21 Ambient Temperature too low
○
22 Error Function Display
○
23 Blank display
○
24 Flat Battery
Infrared Forehead Thermometer is a high quality product incorporating the latest technology and tested
in accordance with international standards. With its unique technology, this thermometer can provide a stable,
heat-interference free reading with each measurement. The instrument performs a self-test every time it is
switched on to always guarantee the specified accuracy of measurements. This Thermometer is intended for the
periodic measurement and monitoring of human body temperature. This thermometer has been clinically tested
and proven to be safe and accurate when used in accordance with its operating instruction manual. Please read
through these instructions carefully so that you understand all functions and safety information.

3
Table of Contents
1Advantages of Infrared Forehead Thermometer
2Important Safety Instructions
3How this Thermometer measures Temperature
4Control Displays and Symbols
5Changing between Body and Object Mode
6Directions for Use
7Changing between Celsius and Fahrenheit
8How to recall 30 readings in Memory Mode
9Error Messages
10 Cleaning and Disinfecting
11 Battery Replacement
12 Technical Specifications

4
1. Advantages of Infrared Forehead Thermometer
Measurement in a matter of seconds
The innovative infrared technology allows measurement without even touching
the object. This guarantees safe and sanitary measurements within seconds.
Multiple Uses (Wide Range Measurement)
Infrared thermometer offers a wide measurement range feature from 0 °C to
100.0 °C (32.0 °F to 212.0 °F), that means the device can be used to measure
body temperature or it can be used to measure surface temperature of the
following:
Milk surface temperature in a baby's bottle
Surface temperature of a baby's bath
Ambient temperature
Accurate and reliable
The unique probe assembly construction, incorporating an advanced infrared
sensor, ensures that each measurement is accurate and reliable.
Gentle and Easy to Use
Ergonomic design enables simple and easy use of the
thermometer.
It can even be used on a sleeping child, thereby causing no
disruption.
It is quick and child-friendly.
Auto-Display Memory
The last reading is automatically displayed for 2 seconds when the unit is
switched ON.
Multiple Reading Recall
Users can recall last 30 readings when entering the recall mode, enabling
efficient tracking of temperature variations.
Safe and Hygienic
Do not require direct skin contact.
No risk of broken glass or mercury ingestion.
Completely safe for children.
Cleaning of the probe can be done with an alcohol-moistened cotton tissue,
making this thermometer completely hygienic for use by the whole family.
Fever Alarm
10 short beeps and a red LCD backlight alert indicates the patient have a

5
temperature equal to or higher than 37.5 °C
2. Important Safety Instructions
This instrument may only be used for the purposes described in this booklet.
The manufacturer cannot be held liable for damage caused by incorrect
application.
Never immerse this instrument in water or other liquids. For cleaning
please follow the instructions in the «Cleaning and Disinfecting»
section.
Do not use the instrument if you think it is damaged or notice anything unusual.
Never open the instrument.
A basic physiological effect called vasoconstriction can occur in the early stages
of fever, resulting in a cool skin effect. The recorded temperature using this
thermometer can, therefore, be unusually low.
If the measurement result is not consistent with the patient's finding or
unusually low, repeat the measurement every 15 minutes or double check the
result by another core body temperature measurement.
This instrument comprises sensitive components and must be treated with
caution. Observe the storage and operating conditions described in the
«Technical Specifications»section!
Ensure that children do not use the instrument unsupervised; some parts are
small enough to be swallowed.
Protect it from:
extreme temperatures
impact and dropping
contamination and dust
direct sunlight
heat and cold
If the instrument is not going to be used for a prolonged period the batteries
should be removed.
WARNING: Use of this instrument is not intended as a substitute for
consultation with your physician. This instrument is NOT waterproof, so
never immerse in liquids.

6
3. How this Thermometer measures Temperature
Dr. Trust Infrared Forehead Thermometer measures infrared energy radiated
from the forehead as well as objects. This energy is collected through the lens and
converted to a temperature value. Temperature readings are obtained efficiently by
scanning on the forehead area.
4. Control Displays and Symbols
All segments displayed ⑧: Press the ON/OFF button ⑤to turn on the unit; all
segments will be shown for 2 seconds.
Memory ⑨: The last reading will automatically be shown on the display for
2 seconds.
Ready for measurement ⑩: When the unit is ready for measurement, the «°C»
or «°F»icon will keep flashing while the mode icon (body or object) will be
displayed.
Measurement complete ⑪: The reading will be shown on display 4 with the «°
C»or «°F»icon and the mode icon steady. The unit is ready for the next
measurement as soon as the «°C»or «°F»icon is flashes again.
Low battery indication ⑭: When the unit is turned on, the battery icon will keep
flashing to remind the user to replace the battery.
5. Changing between Body and Object Mode
For changing from body to object mode, slide the mode switch ⑥at the side of
the thermometer downwards. For switching back to body mode, slide the switch up
again.
6. Directions for Use
Measuring in Body Mode
1. Press the ON/OFF button⑤. The display ④is activated to show all segments
for 2 seconds.
2. The last measurement readings will automatically be shown on the display for 2
seconds with the «M»icon ⑨.
3. When the «°C»or «°F»icon flashes, a beep sound is heard and the
thermometer is ready for measurement⑩.
4. Place the thermometer at the center of the forehead with a distance of no more
than 5 cm. If the forehead is covered with hair, sweat or dirt, please remove the
obstacle beforehand to get accurate reading.
5. Press the START button ③and steadily move the thermometer from the
middle of the forehead to the temple area (about 1 cm above the eyebrow). The
activated blue tracking light will indicate the measurement area. After 3 seconds
a long beep will verify the completion of measurement. If unable to reach temple
area, before the long beep is heard, repeat the measurement as described
above, but move the thermometer a little faster.

7
6. Read the recorded temperature from the LCD display.
Measuring in Object Mode
1. Follow steps 1-3 as described in Body Mode, then aim the thermometer at the
center of the object you want to measure with a distance of no more than 5 cm.
Press the START button ③. After 3 seconds a long beep will verify the
completion of measurement.
2. Read the recorded temperature from the LCD display.
NOTE:
Patients should stay in steady-state room condition for at least 30
minutes.
Do not take a measurement while or immediately after nursing a baby.
Do not use the thermometer in high humidity environments.
Avoid drinking, eating, or exercising before /while taking the measurement.
Do not move the measurement device from the measuring area before
hearing the termination beep.
Use an alcohol swab to carefully clean the probe and wait for 15 minutes
before taking a measurement on another patient.
10 short beeps and a red LCD backlight alert the patient that he/she may
have a temperature equal to or higher than 37.5 °C.
Always take the temperature in the same location, since temperature
readings may vary according to locations.
Doctors recommend rectal measurement for newborn infants within the
first 6 months, as all other measuring methods might lead to ambiguous
results. If using a non contact thermometer on those infants, we
recommend to always verify the readings with a rectal measurement.
It is recommended to take three temperatures in case of the following
conditions, out of which the highest one need to be considered:-
1. Children under three years of age with a compromised immune
system and for whom the presence or absence of fever is critical.
2. When the user is learning how to use the thermometer for the first
time until he/she has familiarized himself/herself with the instrument
and obtains consistent readings.
3. If the measurement is surprisingly low.
Readings from different measuring sites should not be compared as the
normal body temperature; it varies by measuring site and time of day, being
highest in the evening and lowest about one hour before waking up.
Normal body temperature ranges:
-Axillaries: 34.7 - 37.7 °C / 94.5 -99.1 °F
-Oral: 35.5 - 37.5 °C / 95.9 - 99.5 °F
-Rectal: 36.6 -38.0 °C / 97.9 - 100.4 °F
-COMBEIFR200: 35.4 °C - 37.4 °C / 95.7 - 99.3 °F

8
7. Changing between Celsius and Fahrenheit
This thermometer can display temperature measurements in either Fahrenheit
or Celsius. To switch the display between °C and °F, simply turn OFF the unit,
press and hold the START button ③for 5 seconds; after 5 seconds, the current
measurement scale («°C»or «°F»icon) will flash on the display⑮. Change the
measurement scale between °C and °F by pressing the START button ③. When
the measurement scale has been chosen, wait for 5 seconds and the unit will
automatically enter the «ready for measuring»mode.
8. How to recall 30 readings in Memory Mode
This thermometer can recall the last 30 readings.
Recall mode ⑯: Press the START button ③to enter Recall mode when power
is off. The memory icon «M»will flash.
Reading 1 - the last reading ⑰: Press and release the START button③to
recall the last reading. Display 1 alone with memory icon.
Reading 30 - readings in succession: Press and release the START button ③
consecutively to recall the last 30 readings in succession.
Pressing and releasing the START button 3 after the last
30 readings will resume the above sequence from reading 1.
9. Error Messages
Measured temperature too high ⑱: Displays «H»when measured
temperature is higher than 42.2 °C / 108.0 °F in body mode or 100 °C /
212 °F in object mode.
Measured temperature too low ⑲: Displays «L»when measured
temperature is lower than 34.0 °C /
93.2 °F in body mode or 0 °C / 32 °F in object mode.
Ambient temperature too high ⑳: Displays «H»in conjunction when ambient
temperature is higher than 40.0 °C / 104.0 °F.
Ambient temperature too low ○
21 : Display «L»in conjunction when ambient
temperature is lower than 16.0 °C / 60.8 °F in body mode or lower than
5.0 °C / 41.0 °F in object mode.
Error function display ○22 : The system has a malfunction.
Blank display ○23 : Check if the batteries have been loaded correctly. Also check
polarity (<+> and <->) of the batteries.
Flat battery indication ○
24 : If this icon « » is the only symbol shown on the

9
display, the batteries should be replaced immediately.
10. Cleaning and Disinfecting
Use an alcohol swab or cotton tissue moistened with alcohol (70% Isopropyl)
to clean the thermometer casing and the measuring probe. Ensure that no liquid
enters the interior of the thermometer. Never use abrasive cleaning agents, thin-
ners or benzene for cleaning and never immerse the instrument in water or other
cleaning liquids. Take care not to scratch the surface of the probe lens and the
display.
11. Battery Replacement
This instrument is supplied with 2 new, long-lives 1.5V, size AAA batteries.
Batteries need replacing when this icon « »○
24 is the only symbol shown on the
display. Use a screwdriver to open the battery cover. Replace the batteries –
ensure correct polarity as shown by the symbols in the compartment.
Batteries and electronic instruments must be disposed of in accordance
with the locally applicable regulations, not with domestic waste.
12. Technical Specifications
Type: Non-Contact Thermometer FR200
Measurement Range: Body Mode: 34.0-42.2 °C (93.2-108.0 °F)
Object Mode: 0-100.0 °C (32-212.0 °F)
Resolution: 0.1 °C / °F
Measurement Laboratory: ±0.2 °C, 36.0~39.0 °C
Accuracy:(±0.4 °F, 96.8~102.2 °F)
Display: Liquid Crystal Display, 4 digits plus special
Acoustic: The unit is turned ON and ready for the measurement: 1 short beep Complete the
measurement:1 long beep (1 sec.) if the reading is less than 37.5 °C (99.5 °F), 10 short
«beep», if the reading is equal to or greater System error or malfunction:3 short «bi»sounds
Memory: Auto-Display the last measured temperature30 readings recall in the Memory
Mode
Backlight: The display light will be GREEN for 4 seconds, when the unit is turned ON. The
display light will be GREEN for 5 seconds, when a measurement is completed with reading
equal to or lower than 37.5 °C(99.5 °F).The display light will be RED for 5 seconds, when a
measurement is completed with a reading higher than 37.5 °C(99.5 °F).
Operating: Body Mode: 16-40.0 °C (60.8-104.0 °F)
Temperature: Object Mode: 5-40.0 °C (41-104.0 °F) icons
Storage:-20 °C to +50 °C (-4 °F to 122 °F)
Temperature: 15-95 % relative
maximum humidity
Automatic:Approx. 1 minute after last measurement

10
Switch-off: has been taken.
Battery: 2 x 1.5 V Batteries; size AAA,
Dimensions: 150 x 40 x 39 mm than 37.5 °C (99.5 °F).
Weight: 81 g (with batteries), 56 g (w/o batteries)
Reference to EN12470-5:2003
Standards: IEC 60601-1; IEC 60601-1-2 (EMC)
This device complies with the requirements of the Medical Device Directive 93/42/EEC.
Technical alterations reserved. According to the Medical Product User Act a biennial
technical inspection is recommended for professional users. Please observe the applicable
disposal regulations.
Remark:
Some electrical and electrical equipments forbid to abandon
and disposal at will
Inapplicable baby
Attention consult accompanying documents
TUV NO.
Type BF equipment
For any query contact: - [email protected]
