Dr. Trust HANDY User manual

Driven by the passion for innovation, we at Dr Trust endeavour to provide our customers
with the latest medical inventions with an objective to promote good health and wellness
all around the world. All the medical devices and health monitors provided by Dr Trust are
supported by accurate, latest and ground breaking technologies, innovated at our
headquarters in NY, USA. All our products adhere to the most stringent CE and FDA
guidelines and are strongly recommended by doctors and health practitioners. Our
products are designed in the utmost exemplary ways to ensure that their accuracy and
convenience are unrivalled. The ease of their use and operation makes them even more
suitable for users of all age groups.
Dr Trust strives to enhance the quality of lifestyle by providing with the most trusted and
innovative health care and wellness products. Being a renowned global leader in health
care products, Dr Trust ensures that our technically efficient team works dynamically and
tirelessly to provide the best of the medical devices to our clients. The products that we have
to offer are suitably designed for use at homes, laboratories and hospitals.
Our ground breaking solutions allow you to monitor your health in the easiest ways
possible. In today's era when all of our lives are too hassled to handle, it becomes a bit
difficult to pay attention to our health. But it has now become easier with the coming of the
monitoring devices which can be conveniently used at homes and even on the go.
We bring to you a variety of best self medical devices, trusted and used by Doctors,
medical professionals and home users all over the world.
17. ABOUT US
Thank you for purchasing the Dr Trust Handy Forehead and Ear Thermometer- 607. It
has been carefully developed for accurate, safe and fast temperature measurements in a
gentle way.
Please read these instructions carefully before using this product. Keep the instructions
manual in a safe place for future reference.
HANDY
Forehead and Ear Thermometer-607
Please visit /607 for further information & Updatewww.drtrustusa.com
126

32
CONTENTS
6. HOW TO USE YOUR THERMOMETER
2. Ear Temperature Measurement
7. Switching Between Mute and Un-Mute
1. Forehead Temperature Measurement
3. FEATURES
8. Recall 35 Sets of Memory Data
5. Temperature Reading
4. After a measurement
6. Intelligent Light Indicator
2. PRODUCT DESCRIPTION
4. PRODUCT STRUCTURE
10. Temperature Compensation Adjustment
12. The Battery Replacement
9. ºC/ºF Conversion
3. Room/object Temperature Measurement
11. Turn off Thermometer
1. WARNINGS AND PRECAUTIONS
5. DISPLAY DESCRIPTION
4. Indications for use
3. Operating principle
2. Structure
1. Overview
7. TIPS TO MAKE CORRECT TEMPERATURE MEASUREMENTS
8. MULTI MEASUREMENTS REQUIREMENTS
9. KEY FACTORS THAT INFLUENCE EAR TEMPERATURE READINGS
10. CARE AND MAINTENANCE
11. SPECIFICATIONS
13. SYMBOLS
14. EMC INFORMATION
15. WARRANTY AND AFTER-SALE SERVICE
12. ERROR AND TROUBLESHOOTING
16. CUSTOMER SUPPORT
17. ABOUT US
5
4
7
9
8
9
18
16
16
24
26
17
19
25
15
14
15

54
1. WARNINGS AND PRECAUTIONS
2. Never immerse the thermometer into water or other liquid (not waterproof).
1. Keep the thermometer out of reach of children under 12 years.
3. For cleaning and disinfection, please follow the instructions shared in the “Care and
Cleaning” section.
5. Please follow the general safety precautions when using on children.
6. Keep the thermometer away from direct exposure to the sun.
(50°F)-40°C (104°F).
8. Do not use the thermometer in high humidity environment. (95% RH)
9. Do not use the thermometer if there are signs of damage on the measuring sensor
or on the instrument itself.
10. Do not drop the thermometer as consists of high-quality precision parts.
11. Protect it from severe impact and shock.
7. Keep it in a dust- free, dry and a well-ventilated place at a temperature between 10°C
4. Never use the thermometer for purposes other than those it has been intended for.
12. Do not twist the instrument or the measuring sensor.
18. Do not use the thermometer on newborns.
16. Use of this thermometer is not intended as a substitute for consultation with your
20. Do not take a measurement while or immediately after nursing a baby.
21. Patients should not drink, eat, or be physically active before/while taking the
14. This thermometer is not intended for pre-term babies.
measurement.
19. Do not use it for continuous temperature monitoring purposes.
physician or pediatrician. It is for household use only.
13. If damaged, do not attempt to repair the instrument on your own.
17. Clean the thermometer probe after each use.
15. Do not allow children to take their temperature unattended.
When You Need to Receive Medical Attention
1. Please consult your doctor if you see symptoms such as unexplained irritability,
frail, have a weakened immune system, or neonates and infants.
vomiting, diarrhea, dehydration, changes in appetite or activity, seizure, muscle pain,
shivering, stiff neck, pain when urinating, etc.
2. People who are on antibiotics, analgesics, or antipyretics should not be assessed solely
on temperature readings to determine the severity of their illness. Even in the absence
of fever, you may still need to receive medical attention.
3. Temperature elevation may signal a serious illness, especially in adults who are old,
4. Please seek professional advice immediately when there is a temperature elevation
and if you are taking temperature for whom are:
ŸBedridden (e.g., nursing home patient, stroke, chronic illness)
ŸA transplant patient (e.g., liver, heart, lung, kidney)
ŸHaving diabetes mellitus or a weakened immune system (e.g., HIV positive, cancer,
chemotherapy, chronic steroid treatment, splenectomy)
ŸOver 60 years of age (Fever may be blunted or even absent in elderly patients)
2. PRODUCT DESCRIPTION
1) Overview
The Dr Trust Handy Forehead and Ear Thermometer- 607 measures the body temperature
based on the infrared energy emitted from the eardrum or the forehead. Users can quickly
get measurement results after positioning properly the temperature probe in the ear canal
or on forehead.
Normal body temperature is a range. The following tables shows that this normal range also
varies by site. Therefore, readings from different site should not be directly compared. Tell
your doctor what type of thermometer you used to take your temperature and on what part
of the body. Also bear this in mind if you are diagnosing yourself.

76
Measurements
Forehead temperature 36.1°C to 37.5°C (97°F to 99.5°F)
Ear temperature 35.8°C to 38°C (96.4°F to 100.4°F)
Oral temperature 35.5°C to 37.5°C (95.9°F to 99.5°F)
Rectal temperature 36.6°C to 38°C (97.9°F to 100.4°F)
Axillary temperature 34.7°C to 37.3°C (94.5°F to 99.1°F)
2) Structure
The thermometer consists of a shell, an LCD, an operation button, an infrared
temperature sensor, a microprocessor and a beeper.
3) Operating principle
The infrared temperature sensor collects infrared energy emitted by the eardrum or the
skin surface. The collected energy is converted into a temperature reading by the
thermopiles and measurement circuits.
4) Indications for use
The Dual-mode Infrared Thermometer is intended for the measurement of human body
temperatures. The forehead mode is indicated for people of all ages and the eardrum mode
is indicated for people above three months.
Note
Do not use the thermometer if the ear is infected with otitis or suppuration.
3. FEATURES
Ÿ1 second results: Takes less than 1 second for temperature measurement
ŸIntelligent Light Indicator: Normal body temperature shows green, low fever shows
orange and high fever shows red
ŸSound and mute function: Do not worry about the prompt beep sound that may
disturb your baby. It can be used while a child is asleep.
ŸMulti-functional: Can measure ear, forehead, room, milk, water and object
temperature.
ŸAccurate and reliable
Ÿ35 sets of memories
ŸEasy to recall historical measurements data
ŸFever alarm function displayed in orange and red light
ŸEasy switching between mute and un-mute mode
ŸEasy switching between ºC and ºF
ŸAuto shut-down after 30 seconds and power-saving
ŸCompletely safe with passive infrared receiving technology
ŸAdopt the latest algorithm, temperature compensation function
ŸZero emission of radiation during usage

98
4. PRODUCT STRUCTURE
1 Probe cover (take it off when measuring ear temperature)
2 Probe
3 Battery cover
4 LCD display screen
6 Memory/Baby button
5 Measure button (Head & ear button)
5. DISPLAY DESCRIPTION
6. Fahrenheit / Celsius degrees
2. Forehead temperature mode
3. Ear temperature mode
4. Object temperature mode
5. Baby mode
7. Ear cover
8. Memory recall
9. Mute /Un-mute icon
10. Battery level
1. Temperature value
ŸWhen low battery icon appears, please replace the battery.
Note:
6. HOW TO USE YOUR THERMOMETER
The Dr Trust Handy Forehead and Ear Thermometer- 607 is lightweight, gentle and easy
to use device. It comes with all the things needed to get a thorough reading. When using
the thermometer for the rst time, please check the batteries and press the Measure
button to check it is ready for use.
ŸRelease the buon when a beep is heard.
1. Forehead Temperature Measurement
ŸKeep in contact the thermometer probe at the middle
Ÿ of forehead.
ŸThe body temperature is shown on the LCD display.
Ÿ thermometer to the temple.
ŸPress and hold the Measure buon and slide the

1110
NOTE
ŸThe normal temperature range on the forehead is approximately between 35.4 °C
and 37.4 °C.
ŸIf the eyebrow area is covered with hair, sweat or dirt, please clean the area
beforehand to improve the reading accuracy.
ŸThe forehead measurement is an indicative reading. The measured forehead
temperature can uctuate up to 1 ºF/0.5 ºC from your actual body temperature.
Please be aware of the factors that inuence the accuracy as described in the
section “Temperature taking tips” and “WARNINGS AND PRECAUTIONS”.
ŸAlways make sure the user and the thermometer will have been in the same room
for at least 30 minutes prior to the measurement.
ŸAlways check if the lens is clean.
2. Ear Temperature Measurement
The temperature of the eardrum can be measured easily with this thermometer.
ŸTake off the probe cover
ŸInsert the probe into the ear canal to get the result in 1 second.
ŸPress the Measure button and release it in 1 second when the beep is heard.
ŸThe body temperature is shown on the LCD display.
Safety Measures
üChildren under 1 year: Pull the ear straight back.
üWhen taking the temperature on an adult, gently pull the ear up and back to make
sure the ear canal is straight, so that the temperature probe can receive an infrared
ray from the eardrum.
üBe careful when taking temperature on a child, whose ear canal is small.
üChildren aged 1 year to adult: Pull the ear up and back.
üDo not force the thermometer into the ear canal. Otherwise, the ear canal may get
injured.
Note
ŸInsert the probe straight into the ear canal.
ŸPlease make sure that the ear is clean, with no earwax or obstructions.
ŸThe normal ear temperature range is approximately between 35.5 °C and 37.7 °C.
ŸTo straighten the ear canal, gently pull on the outer ear in the direction of the rear of
the head.
ŸIt is important to point the probe lens of the ear thermometer toward the eardrum
and its periphery inside the ear.
ŸEach ear canal has a slightly different shape, be sure to check it before taking
temperature readings.
ŸThe right ear reading may differ from the reading taken at the left ear. Therefore,
always take the temperature in the same ear.
3. Room/object Temperature Measurement
When the thermometer is power off, press the Memory/baby button for 5 seconds until it
shows on display.
ŸPress and release the measure button to start the object temperature
measurements.
ŸThe LCD display shows the results for object temperature value.
ŸKeep the thermometer about 1-5cm away from the object.
ŸPress and release the Measure button in 1 second with a beep sound.

1312
Note:
ŸMeasures surface temperatures and not the internal temperature of objects or items
like food etc.
ŸNeeds adjustments depending on your requirements.
ŸMeasurements can be affected by moisture, dust, smoke or other particles in the air.
4. Switch to Baby mode
Press the Memory/baby button when power on. Then it will switch to baby mode. Baby
mode is suitable for baby aged from 0-36 month.
After A Temperature Measurement
ŸOnce the temperature measurement has been completed, remove the thermometer
away from the forehead/ear and observe temperature.
ŸAfter each measurement, you can enter the recall mode to check the earlier
temperature readings.
ŸNote
ŸPlease wait for 10 seconds between each measurement.
ŸDo not hold the thermometer for a long time, because it is sensitive to the ambient
temperature.
ŸAfter each measurement, clean the temperature probe with a soft cloth, and put the
thermometer in a dry and well-ventilated place.
IMPORTANT
It is dangerous to make a self-diagnosis or self-treatment based on the obtained
measurement results. For such purposes, please consult a doctor.
Temperature Reading
In forehead or ear mode T indicates a temperature reading.
Intelligent Light Indicator
one long beep.
1. If 32°C≦T≦37.3°C(89.6°F≦T≦99.2°F), the green light will last for 3 seconds, with
fever.
3 short beeps, and the value in LCD flickers, which is a warning that you may have a light
2. If 37.4°C≦T≦37.9°C(99.3°F≦T≦100.3°F), the orange light will last for 3 seconds, with
short beeps, and the value in LCD flickers, which is a warning that you may have a high
3. If 38°C≦T≦42.9°C(100.4°F≦T≦109.2°F), the red light will last for 3 seconds, with 5
fever.
Switching Between Mute and Un-Mute
When the thermometer is turned on, by keep pressing the
ºC/ºF button for 4 seconds, to switch from un-mute to mute.
Recall 35 Sets of Memory Data
If there is no value saved, it will display “---M”.
Press this button again to check the 35 sets of memories one by one.
Press the Memory/Baby button to go to the memory mode.
ºC/ºF Conversion
When the thermometer is turned on, short pressing the ºC/ºF button for
to change the ºC/ºF.

1514
Temperature Compensaon Adjustment
ŸPress the Memory/baby button to adjust the temperature from ±0.0 to ±2.0.
ŸWhen the thermometer is turn on, press both the Memory/Baby button and
Measure button for 5 seconds to go to the temperature compensation mode.
Note
All the future temperature you are taking will be automatically added the value you are
adjusted.
Turn off Thermometer
The unit will shut down automatically after 10 seconds of no use. Or you can keep
pressing the Measure button for 6 seconds.
Cautions
ŸAll memory records will loss when uninstall or reinstall the battery.
ŸAll settings will come to default when uninstall the battery. If need adjust the
settings, please power on and make the new settings.
The Battery Replacement
Slide down the battery cover along the marked direction. Put two AAA batteries correctly
into the compartment.
Remove the batteries if the thermometer will not be used for more than two months.
Cautions
7. TIPS TO MAKE CORRECT TEMPERATURE MEASUREMENTS
ŸIt is important to know everyone’s normal temperature when they are well. This is
the only way to accurately diagnose a fever.
ŸRecord readings twice a day (early morning and late afternoon). Take the average of
the two temperatures to calculate normal oral equivalent temperature.
ŸAlways take the temperature in the same location, since the temperature readings
may vary from different locations on the forehead.
ŸHolding the thermometer for too long in the hand before taking a measurement can
cause the device to warm up. This means the measurement could be incorrect.
ŸPatients and the thermometer should stay in steady-state room condition for at least
30 minutes.
ŸA child’s normal temperature can be as high as 99.9°F (37.7) or as low as 97.0°F
(36.11). Please note that this unit reads 0.5ºC (0.9°F) lower than a rectal digital
thermometer.
ŸBefore placing the thermometer sensor onto the forehead, remove dirt, hair, or
sweat from the forehead area.
ŸWiping the forehead with a warm or cool cloth may impact your reading. It is advised
to wait 10 minutes before taking a reading.
ŸUse an alcohol swab to carefully clean the sensor and wait for 5 minutes before
taking a measurement on another patient.
8. MULTI MEASUREMENTS REQUIREMENTS
ŸNewborn infants in the rst 100 days.
ŸWhen the user is learning how to use the thermometer for the rst time until he/she
has familiarized himself/herself with the instrument and obtains consistent readings.
ŸChildren under three years of age with a compromised immune system and for
whom the presence or absence of fever is critical.
In the following situations 3-5 measurements recommended to be taken in the same
location. The highest one is the standard reading.
9. KEY FACTORS THAT INFLUENCE EAR TEMPERATURE READINGS
Some external factors that may inuence ear temperature, include:
Ÿbeen exposed to very hot or very cold temperatures, or
Ÿbeen recently swimming or bathing
Ÿbeen lying on one ear or the other
Ÿhad their ears covered

1716
Cautions
ŸUse the untreated ear if prescription ear drops or other ear medications have been
placed in the ear canal.
ŸIn these cases, remove the individual from the situation and wait 20 minutes prior to
taking a temperature reading.
10. CARE AND MAINTENANCE
ŸUse an alcohol swab or cotton swab moistened with 70% alcohol to clean the
thermometer casing and the measuring probe. After the alcohol has completely
dried out, you can take a new measurement.
11. SPECIFICATIONS
Product name Dr Trust Handy Forehead and Ear Thermometer- 607
Power supply DC1.5V×2
Measurement range Ear & Forehead : 32.0°C–42.9°C (89.6°F–109.2°F)
Object: 0°C–100°C (32°F–212°F)
Accuracy
(Laboratory)
Ear & Forehead mode ±0.2°C /±0.4°F
Object mode ±1.0°C/1.8°F
Display resolution 0.1°C/°F
Automatic shutdown 10s±1s
Memory 35 groups of measured temperature.
Operational
conditions
Temperature: 10°C-40°C (50°F-104°F) / Humidity: 15-95%RH, non-condensing
Atmospheric pressure: 86-106 kPa
Battery 2*AAA, can be used for more than 3000 times
Weight & Dimension 60.8g (without battery), 120×53×43mm
ŸNever use abrasive cleaning agents, thinners or benzene for
cleaning and never immerse the instrument in water or other
cleaning liquids.
ŸTake care not to scratch the surface of the LCD screen.
ŸEnsure that no liquid enters the interior of the thermometer.
12. ERROR AND TROUBLESHOOTING
Symptom Possible Cause Description & Solution
Failed to
power on.
The battery level is too
low.
Replace with a new battery
Polarities of the batteries
are reversed.
Ensure the batteries are in the
right position
The thermometer is
damaged
Contact dealer
The reading
is too low
The lens of the probe is
dirty.
Clean the lens with a cotton
swab.
The distance of the item
and target is too far
Keep the thermometer in
contact with forehead, or put
the probe into the Ear Canal.
You have just come from
a cold environment
Stay in a warmer room for at
least 30 minutes before taking
a reading
The reading
is too high
You have just come from
a hot environment.
Stay in an adequately cool
room for at least 30 minutes
before taking a reading
The ambient temperature
is not in range.
3 short beeps and red backlit
for 3 seconds. Take a
measurement under an
ambient temperature between
10°C (50.0°F) and 40°C (104°F).
Memory Error 3 short beeps and red backlit
for 3 seconds. Contact dealer.

1918
Symptom Possible Cause Description & Solution
In ear or forehead mode,
T > 42.9°C (109.2°F)
3 short beeps and red backlit
for 3 seconds.
In ear or forehead mode,
T < 32ºC (89.6ºF)
3 short beeps and red backlit
for 3 seconds.
2.5V ± 3% ≦power voltage
≦2.6V±3%
The battery level is low, it
suggests you to replace the
battery, but you can continue
to use it.
The power voltage is
lower than 2.5V± 3%.
It will turn off automatically
after 30 seconds. Please
replace with a new battery
13. SYMBOLS
Symbol Description
Type BF applied part.
Information about a manufacturer
Please read the instructions carefully.
Waste electrical materials should be sent to a
dedicated collection point for recycling.
SN Serial number
LOT Batch number
IMPORTANT
Inaccurate reading or thermometer damage may
occur if the thermometer is not correctly used.
IP22 2 Protected against solid foreign objects of 12,5
mm Ø and greater ；
2 If keep the thermometer in 15 degree angle, it
still can prevent the water drop.
14. EMC INFORMATION
Guidance and manufacturer ’s declaration-electromagnetic emissions
The infrared thermometer is intended for using in the electromagnetic
environment specified below. The customer or the user
of the infrared thermometer should assure that it is used in such an
environment.
Emissions test Compliance Electromagnetic
environment-guidance
RF emissions
CISPR 11
Group 1 The infrared thermometer uses RF
energy only for its internal function.
Therefore, its RF emissions are very
low and are not likely to cause and
interference in nearby electronic
equipment.
RF emissions
CISPR 11
Class B The infrared thermometer is suitable
for use in all establishments other
than domestic and those directly
connected to the public low-voltage
power supply network that supplies
buildings used for domestic
purposes.
Harmonic emissions
IEC 61000-3-2
N/A
Voltage fluctuations
/flicker emissions
IEC 61000-3-3
N/A

2120
Guidance and manufacturer ’s declaration-electromagnetic immunity
The infrared thermometer is intended for use in the electromagnetic
environment specified below. The customer or the user of the infrared
thermometer should assure that it is used in such an environment.
Immunity test IEC60601 test
level
Compliance
level
Electromagnetic
environment -guidance
Electrostatic
discharge
(ESD)
IEC 61000-4-2
±2, ±4, ±6kV for
Contact
discharge
±2,±4,±8kV
air discharge
±2, ±4, ±6kV for
Contact
discharge
±2,±4,±8kV
air discharge
Floors should be
wood, concrete or
ceramic tile.
If floors are covered
with synthetic material,
the relative humidity
should be at least 30%
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for a.c.
power lines
±1 kV for d.c.
power lines
N/A Mains power quality
should be that of a
typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1 kV line(s)
to line(s)
±2 kV line(s)
to earth
N/A Mains power quality
should be that of a
typical commercial or
hospital environment.
Voltage dips,
short
interruptions
and voltage
variations in
power supply
input lines
IEC 61000-4-11
<5%UT
(>95 dip inUT)
for 0.5 cycle
40%UT
(60% dip in UT)
for 5 cycles
70% UT
N/A Mains power quality
should be that of a
typical commercial or
hospital environment.
If the user of the
infrared thermometer
requires continued
operation during
power mains
Guidance and manufacturer ’s declaration-electromagnetic immunity
The infrared thermometer is intended for use in the electromagnetic
environment specified below. The customer or the user of the infrared
thermometer should assure that it is used in such an environment.
Immunity
test
IEC 60601
test level
Compliance
level
Electromagnetic
environment-guidance
(30% dip in UT)
for 25 cycles
<5%UT(>95%
dip inUTfor 5 s
interruptions, it is
recommended
that the infrared
thermometer be
powered from an
uninterrupted power
supply or a battery
Power
frequency
(50/60Hz)
magnetic field
IEC 61000-4-8
3 A/m 3 A/m Power frequency
magnetic fields should
be at levels
characteristic of a
typical location in a
typical commercial or
hospital environment
NOTEUTis the a.c. mains voltage prior to application of the test level.
Conducted
RF
IEC
61000-4-6
3Vrms
150kHz to
80MHz
N/A Portable and mobile RF communications
equipment should be used no closer to any
part of the infrared thermometer including
cables, than the recommended separation
distance calculated from the equation
applicable to the frequency of the transmitter.
Recommended separation distance
d=1.2 P

2322
Radiated RF
IEC
61000-4-3
3V/m
80kHz to
2.5GHz
3V/m d=1.2 P80MHz to 800MHz d=2.3 P800MHz
to 2.5MHz
Here Pis the maximum output power rating
of the transmitter in watts (W) according to
the transmitter manufacturer and dis the
recommended separation distance in meters
(m). Field strengths form fixed RF transmitters,
as determined by an electromagnetic site
survey, should be less than the compliance
b level in each frequency range. Interference
may occur in the vicinity of equipment
marked with the following symbol:
NOTE 1 At 90MHz and 800MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations.
Electromagnetic propagation is affected by absorption and reflection
from structures, objects and people.
a
Field strengths from fixed transmitters, such as base stations for radio
(cellular/cordless) telephones and land mobile radios, amateur radio,
AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site
survey should be considered. If the measured field strength in the
location in which the thermometer is used exceeds the applicable RF
compliance level above, the thermometer should be observed to verify
normal operation. If abnormal performance is observed, additional
measures may be necessary, such as reorienting or relocating the
thermometer.
b
Over the frequency range 150kHz to 80MHz, field strengths should be
less than 3V/m.
Recommended separation distances between portable and mobile RF
communications equipment and the infrared thermometer
The infrared thermometer is intended for use in an electromagnetic
environment in which radiated RF disturbances are controlled.
The customer or the user of the infrared thermometer can help prevent
electromagnetic interference by maintaining a minimum
distance between portable and mobile RF communications equipment
(transmitters) and the infrared thermometer as recommended below,
according to the maximum output power of the communications
equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to frequency of
transmitter
m
Rated
maximum
output power
of transmitter
W
150kHz to
80MHz
d=1.2 P
80MHz to
800MHz
d=1.2 P
800MHz to
2.5GHz
d=2.3 P
0.01 0.01 0.12 0.23
0.1 0.1 0.38 0.73
1 1 1.2 2.3
10 10 3.8 7.3
100 100 12 23
For transmitters rated at a maximum output power not listed above, the recommended
separation distance d in meters (m) can be estimated using the equation applicable to
the frequency of the transmitter, where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter manufacturer.

2524
NOTE 2 These guidelines may not apply in all situations.
NOTE 1 At 80MHz and 800MHz, the separation distance for the higher frequency range
applies.
Electromagnetic propagation is affected by absorption and reection from structures,
objects and people.
15. WARRANTY AND AFTER-SALE SERVICE
2. Failure resulting from an unexpected dropping during application or transportation.
The batteries, the packaging, and any damage caused by improper use are not covered
by the warranty.
Excluding the following user-caused failures:
1. Failure resulting from unauthorized disassembly and modication.
3. Failure resulting from not following the instructions in the operating manual.
13. CUSTOMER SUPPORT
