Dreamland L1647 User manual

Instructions for use
STARLIGHT
EXPRESS FLEECE
EASY FIT HEATED
UNDERBLANKET
TYPE L1647
L1648
L1649
L1650

DESCRIPTION OF THE APPLIANCE
TECHNICAL DATA
I
TYPE L1647
220-240 V 50/60 Hz 85 W
TYPE L1649
220-240 V 50/60 Hz 140 W
TYPE L1650
220-240 V 50/60 Hz 2X85 W
TYPE L1648
220-240 V 50/60 Hz 100 W
ILLUSTRATIVE GUIDE
1. Blanket connector
2. Control connector
3. Mains socket
4. Underblanket
5. Label
6. Control unit
[A] [B]
[D]
Fitting the elasticated straps
A
Elasticated
strap
Elasticated corner strap
B
B
STARLIGHT EXPRESS
[C]

1
EN
Dear Customer, thank you for choosing our product. We feel certain
you will appreciate its quality and reliability as it was designed and
manufactured with Customer satisfaction in mind. These instructions
for use are compliant with the European Standard EN 82079.
INDEX
Symbols page 1
Important instructions page 2
Use page 4
Cleaning and maintenance page 6
Storing the underblanket page 7
Trouble shooting page 8
Disposal page 8
Warranty page 8
Illustrative guide I
Description of the appliance I
Technical data I
SYMBOLS
Protection class II Prohibited actions
Carefully read the operating
instructions Important note
Warning Children under 3 years old
not allowed
Do not use folded or creased Do not insert pins or
needles
Wash at maximum 40° C on a
wool programme Do not bleach
Tumble drying possibile at low
temperature Do not dry clean
Do not iron

2
EN
IMPORTANT INSTRUCTIONS.
RETAIN FOR FUTURE USE.
WARNING! Instructions and warnings for safe use.
Before using this appliance, carefully read the
instructions for use and in particular the safety notes
and warnings, which must be complied with. Keep this
manual together with its illustrative guide for future
consultation. Should you transfer the appliance to
another user, make sure you hand over this
documentation as well.
NOTE: should any part of this manual be difficult to understand or
any doubt arise, contact the company at the address indicated on
the last page before using the appliance.
NOTE: persons with impaired vision may consult these instructions
for use in digital format at the website www.dreamlanduk.co.uk
• After unpacking, make sure the appliance is intact, complete with all
its parts as shown in the illustrative guide and with no sign of damage.
If in any doubt, do not use the appliance and contact an authorised
service centre.
WARNING! Risk of suffocation.
Children shall not play with the packaging. Keep the plastic
bag out of the reach of children.
• This appliance must be used only for the purpose for which it was
designed, namely as an underblanket to warm a bed for home use.
Any other use is considered not compliant with the intended use and
therefore dangerous.
• Before connecting the appliance to the mains supply, make sure
that the voltage and frequency indicated on the technical data of
the appliance correspond to those of the mains supply. The rating is
on the appliance or on the power supply unit, if any (see illustrative
guide).

3
EN
• This appliance can work automatically at a frequency of 50 Hz or 60 Hz.
• This appliance is only to be used with the types of detachable control
unit that are marked on the appliance.
Children under the age of three are not to use this appliance
due to their inability to react to overheating.
• This appliance can be used by children older than 3 years and
younger than 8 years under supervision and with the control always
set to minimum temperature.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
• This appliance must not be used by persons insensitive to heat and
other very vulnerable persons who are unable to react to overheating.
• The cable and control unit of the appliance can give rise to risks
of entanglement, strangulation, tripping or treading if not correctly
arranged. The user shall make sure that electric cords shall be
arranged in a safe way.
• Examine the appliance frequently for signs of wear or damage. lf there are
such signs, if the appliance has been misused or does not work, contact
an authorised technical service centre before switching it on again.
• If the supply cord is damaged, take the whole appliance to an authorised
technical service centre for the replacement of the control unit, so as
to prevent all risks.
• If the appliance is used on an adjustable bed, check that the blanket and cord do
not become trapped or rucked, for example in hinges.
• This appliance is not intended for medical use in hospitals.
• DO NOT use if wet.
DO NOT USE FOLDED OR CREASED.

4
EN
DO NOT INSERT PINS OR NEEDLES.
• When storing the appliance, allow it to cool down before folding.
WARNING! DO NOT crease the appliance by placing items
on top of it during storage.
• Follow indications in the relevant chapters of this manual on how to use,
clean, maintain or store the appliance.
WARNING! Always disconnect the appliance from the socket
when the appliance is not in use.
• DO N OT use the appliance with wet hands or damp feet.
• DO NOT pull the supply cord or the appliance itself to remove the plug
from the socket.
• DO NOT pull or lift the appliance by the supply cord.
• DO NOT expose the appliance to humidity, to the effects of weather
(rain, sun, etc.) or to extreme temperatures.
• If the appliance is faulty or malfunctions, switch it off and do not tamper
with it. Contact an authorised technical service centre for any repairs.
• DO NOT use this appliance to warm animals.
• DO NOT place the control unit under the pillow or between the sheets
or blankets.
• DO NOT tuck in.
• See the external packaging for the features of the appliance.
USE
WARNING! The electric blanket must only be placed
between the mattress and the flat sheet and not on top of
persons in bed.
POSITIONING THE UNDERBLANKET DIAGRAM (D)
• Open the folded underblanket and place on your mattress, leaving room
for pillows. Smooth out any packing folds. Lay the underblanket (4) on the

5
EN
mattress without putting it underneath the pillows.
• Make sure that it is smoothly spread out (Diagram [B]).
• Secure the underblanket to the mattress with the mains lead at the pillow end
(Diagram [D]). Secure your blanket to the mattress with the mains lead at the
pillow end. Pull the elasticated strap (A) (Diagram D) over and under the top
of the mattress, as shown in Diagram D. Attach the elasticated corner straps
(B) over the bottom corners of the mattress. Ensure that the underblanket is
smooth and secured to the mattress.
• Lay the bottom sheet (Diagram [B]) on the top of the underblanket, then finish
making the bed as normal with a sheet and duvet.
• Frequently check to see that your underblanket is properly secured to the
mattress and does not ruck up.
CONNECTING THE CONTROL TO THE UNDERBLANKET
Quick start guide to heat settings on the back of the control unit:
Express Heat Up – Fast Pre-heat
2 – All Night Use (Max)
1 – All Night Use (Min)
0 – Off
Join the connector (2) of the control unit to connector (1) on the underblanket. Ensure
the plug is pushed fully home until the locking catch engages. (Diagram [A]).
USING YOUR UNDERBLANKET
Your Dreamland Starlight Express heated underblanket is designed to fast
pre-heat your bed in 10 minutes. It also has 2 “all night use settings” which
you can choose to keep you warm whilst in bed all night long.The temperature
control has 3 heat settings (Diagram [C]).
EXPRESS HEAT UP is ONLY for preheating your underblanket.
2 ALL NIGHT USE is the maximum temperature.
1 ALL NIGHT USE is the minimum temperature.
Before getting into bed, you must either select the all night use option or switch
off your underblanket.
Plug into the main socket (3) (Diagram [B]).
Switch on the underblanket (6) selecting Express Heat Up setting.The control
unit will light up BLUE showing that the underblanket is on. In 10 minutes
your bed will be pleasantly warm. This time may vary depending on room
temperature and additional bed covers.

6
EN
When you go to bed if you wish to keep your underblanket on all night, you
must select your desired temperature from settings 1 or 2 for all night use. (6)
(Diagram [C]). Setting 2 being the warmest.
If you do not want your underblanket on all night, switch the underblanket off
by selecting ‘O’ on the control switch (6) (Diagram [C]).
For night-time or continuous use, set the control unit to
temperature levels 1 or 2 only.
DO NOT get into bed with the control unit set to a higher
temperature than recommended for continuous use. If the
appliance is slept on with the controls set to a higher
temperature the user may suffer skin burns or heat stroke.
WARNING! DO NOT place the control unit under the pillow
or under the sheets when in use.
DISCONNECT: To disconnect your underblanket from the mains, switch the
control to OFF position selecting ‘O’ on the control switch (6) (Diagram [C]) and
then safely disconnet the plug from the main socket (3) (Diagram [B]).
CLEANING AND MAINTENANCE
Your underblanket is suitable for washing. Check the washing instructions on the
label of your underblanket to wash it correctly.
WARNING! Always disconnect the appliance from the mains
and disconnect the control connector from the blanket
before cleaning or performing maintenance.
BEFORE WASHING OR STORING YOUR BLANKET:
1. Disconnect power cord from wall.
2. Disconnect the connector (2) from the blanket by pressing the push buttons at the
sides of the control connector (1).
3. Ensure that no cords are still connected and none of the wires have worn through
the fabric.
MACHINE WASHING
• The underblanket can be machine washed at 40°C on a wool programme.
• Only the gentle spin cycle is to be used. DO NOT use an extra spin cycle.

7
EN
TUMBLE DRYING
• The underblanket can be tumble dried on a wool programme, but at the end of
the drying cycle it must be laid out to let it dry completely.
• Tumble dry at a low temperature.
• Remove the underblanket from the drier at the end of the drying cycle and pull it
back into shape, and into its original size.
• Lay the underblanket flat on a clothes airer to allow it to dry completely.
HANGING THE ELECTRIC BLANKET TO DRY OUTSIDE
• The underblanket must be stretched back to approximately its original size
during the drying process. This is best done whilst damp, working from side to
side, stretching a piece at a time.This procedure may need to be repeated a few
times until fully dry.
• DO NOT use the underblanket until it is completely dry.
WARNING! Dry the appliance flat without using pegs to
avoid damaging it. Leave it to dry, laid out flat on a clothes
airer, not in direct sunlight.
• DO NOT iron the underblanket.
WARNING! Examine the appliance against the light to make
sure the cables are not bent or twisted.
WARNING! If the appliance does not resume its original size
or if problems arise with the internal cables contact an
authorised service centre for a safety check.
STORING THE UNDERBLANKET
When not in use, store as follows:
• Make sure your underblanket is dry if it has been washed.
• Fold your underblanket as a normal blanket.
• It is recommeded to store the underblanket in the bag it was purchased in.
• When storing the appliance, allow it to cool down before folding.
• Store the underblanket in a dry place.
The fabric may take on a natural yellow colour over time.This does not compromise
the safety and/or performance of the product in any way.

8
EN
TROUBLE SHOOTING
This appliance is built to the very highest of standards. Follow the trouble shooting guide if the unit fails
to operate. If you don’t find any solution, discontinue use and return it to our Service Centre for a Safety
inspection.
Problem Solution
The led on the control unit does not light up.
Make sure the control unit is fully plugged
into the mains socket (3). If the leds still do
not light on, disconnect the plug from the
mains socket (3) and return the appliance to
our Service Centre.
You feel a tingling sensation while in use.
This can be quite common and is completely
harmless. Contact the after sales service for
further information.
Damage to the control unit.
Discontinue use and return it to our Service
Centre for a safety inspection.
Fabric rucking or creasing.
Wear or tear on the fabric.
The product has been misused or accidentally
damaged.
DISPOSAL
The packaging of the appliance is made of recyclable materials. Dispose of it in accordance
with the environmental protection regulations.
Pursuant to Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the
crossed bin symbol on the appliance or its packaging indicates that the appliance must be
disposed of separately from other waste at the end of its useful life.
The user must therefore take the appliance to an appropriate recycling centre for electrical
and electronic equipment. Alternatively, instead of handling the disposal, the user can hand
over the appliance to the retailer when a new, equivalent one is purchased.The user can hand over
electronic products measuring less than 25 cm to retailers of electronic products having a sales
area of at least 400 m2free of charge and with no obligation to buy. Appropriate separate collection
for the subsequent procedure for the decommissioned appliance for recycling, which includes
treatment and environmentally friendly disposal helps prevent adverse effects on the environment
and health and promotes reusing and/or recycling materials that the appliance consists of.
WARRANTY
This product is guaranteed for a period of 3 years from the date of purchase against material, mechanical
and electrical defects. The warranty is binding if it is accompanied by a valid receipt of payment. This
guarantee is only valid if the appliance is used solely for domestic purposes in accordance with the
instructions provided that is not connected to an unsuitable electricity supply, dismantled, interfered

9
EN
with in any way damaged, through misuse, fair wear and tear. Under this guarantee we undertake to
repair or replace free of charge any parts found to be defective.
PLEASE NOTE, THE COST OF A SAFETY INSPECTION IS NOT COVERED BY THIS
GUARANTEE. A CHARGE WILL BE MADE IN RESPECT OF ANY PRODUCT RETURNED UNDER
THIS GUARANTEE, WHERE NO FAULT IS FOUND.
This guarantee is offered as an extra benefit and does not affect your statutory rights as a consumer.
This guarantee does not confer any rights other than those expressly set out above and in particular
we shall not be liable for any indirect or consequential loss or damage. Nothing in this guarantee or the
instructions relating to the product excludes, restricts or otherwise affects your statutory rights. In line
with our policy of continuous development, we reserve the right to change this product, packaging and
documentation without notice. If a defect appears and after checking that the blanket is being used
properly in accordance with the instructions, return it with a valid proof of purchase, as soon as possible
to the manufacturer’s Service Centre.This guarantee is valid in the UK only.
SERVICE CENTRE
PO Box 166 – Middlewich – Cheshire – CW 10 0ZU - Tel: [phone]
E-mail: [email protected]
www.dreamlanduk.co.uk

MI003361
070319
