How to assemble a Cirrus Plus EC
Last Updated: Feb 25, 2015 10:09AM EST
Assembly of Cirrus Plus EC
Remove all items from the shipping carton and unfold the chair. Verify that all parts are
present.

Click here to view detailed product information and pricing. Call 800-397-5899 to order today!


The back upholstery outer cover is installed over the inner back upholstery which is
already mounted on the Cirrus Plus power chair.Wrap the outer cover around the
inner upholstery with the Drive logo facing reward.



Align the Velcro strips on the outer upholstery cover and press together.



The amount of tension in the back upholstery can be adjusted.Remove the outer cover
from the back.Release one Velcro strap and pull tighter to increase tension.Loosen
up to decrease tension.



When the desired tension is achieved reattach the strap.Repeat this procedure for the
three other straps. Install the outer back cover.



Install the seat cushion on the seat upholstery with the pouch in the front.





Wrap one end of one of the battery straps under either side of the rear of the battery
tray.The Velcro should be facing up.Place the hook section of the Velcro over the
smooth section of the Velcro and press together.

Repeat for the other strap.



Verify that the batteries are connected in the battery boxes.



Place the battery box with only one connector on the battery tray and slide to the front
of the battery tray.The connector should be facing towards the rear of the chair.



Place the remaining battery box on the tray with the red connector facing forward.



Connect the two red connectors.



Secure the battery boxes with the two battery box straps.





Insert the joystick and arm into the joystick bracket on the arm of the Cirrus Plus power
chair.

Route the wire from the joystick behind the rear upright of the side frame.



Connect the large black two prongs to the black connector from the battery box. The
connector will only t in one way.



Connect the connector marked right motor to the right motor. The connector will only
t in one way.



Repeat for the left side.



Install one footrest by aligning the hole on the footrest hanger with the pins on the
footrest mounting plate on the chair



Slide the footrest onto the pins. Swing the footrest inward until it looks into
place.Repeat for the other side.

