Drive 11120SV-1F User manual

www.drivemedical.com
wheeled drop arm
commode w/
4 locking casters
and footrests
item # 11120SV-1F
VER.A.6.20
SUNGO Europe B.V.
Olympisch Stadion 24
1076DE Amsterdam, Netherlands
lifetime limited warranty
maintenance
© 2020 Medical Depot, Inc. All rights reserved.
Drive is a trademark of Medical Depot, Inc.
Port Washington N.Y. 11050 USA Made in China
Your Drive branded product is warrantied to be free of
defects in materials and workmanship for the lifetime
of the product for the original consumer purchaser.
This device was built to exacting standards and carefully
inspected prior to shipment. This Lifetime Limited
Warranty is an expression of our confidence in the
materials and workmanship of our products and our
assurance to the consumer of years of dependable service.
This warranty does not cover device failure due to owner
misuse or negligence, or normal wear and tear. The
warranty does not extend to non-durable components,
such as rubber accessories, casters, and grips, which are
subject to normal wear and need periodic replacement.
If you have a question about your Drive device or this
warranty, please contact an authorized Drive dealer.
WARNING: This product can expose you to chemicals,
including bisphenol A (BPA), which is known to the State
of California to cause birth defects or other reproductive
harm. For more information go to www.P65Warnings.ca.gov.
Drive recommends periodic visual inspection of this
product by the user, to ensure that all parts and hardware
are secure, that components are in good working order
and not worn, torn, frayed, or loose, and that there are no
obstructions or impediments to normal, safe operation.
If any part or mechanism appears to be unsafe or
compromised, do not use the product. If you experience
problems, please contact the provider that sold you the
product or visit www.drivemedical.com/help for more info.

additional precautions
1. Before assembling seat, allow toilet seat to reach room
temperature if exposed to cold. This will help prevent the
seat clamps from cracking while being assembled onto
commode back cross brace.
2. Assemble the backrest by inserting the supporting poles
into the back of seat frame. Secure in place using the
lock knobs provided.
3. To drop arm, depress release buon on arm and gently
allow to drop.
4. Align the toilet seat clamps onto the back frame rail
(both clamps should sit outside the pail brackets). Push
down on seat until clamps snap firmly into place.
5. When removing the seat grasp the back of the seat and
li. Install commode bucket by placing in bucket frame.
Reverse to remove.
6. Assemble the footrests by inserting the footrests into
the top of the front legs from the outside of the frame.
Once inserted, turn the footrests inward until they lock in
position.
assembly instructionscommode assembly
instructions and precautions
• Do NOT install commode without first reading and
understanding this assembly and instruction sheet. If
you can not understand these instructions, contact a
healthcare, dealer or technical professional before
aempting to install. Otherwise, injury or damage may
occur.
• Inspect all parts for shipping damage before assembly.
If there is shipping damage - DO NOT USE. Contact
dealer/carrier for further instructions.
• Ensure ALL screws, nuts and/or bolts are tightened.
• All four legs MUST touch the floor simultaneously at all
times.
• Users with limited physical strength should be supervised
or assisted while using commode.
• Use the arm supports only for assistance. DO NOT
aempt to use the arms to support full body weight.
• Arms should be unlatched and dropped to assist in
transfer onto/off the device.
Back
Support
Arm
Bucket
Frame
Bucket
Footrests
Release
Buon
Locking
Casters
WEIGHTCAPACITYLBS/KG
