DSC WS4965 User manual

The WS4965 is a 3-zone device. The primary zone can be configured as a traditiona norma y c osed door/window contact with supp ied magnet. If
mounting the device/magnet combination is inconvenient, it can be configured for norma y c osed ti t switch operation for overhead doors. The WS4965 a so
has 2 norma y c osed contact inputs.
Specifications
Compatib e with PC5132-433, PC4164-433, NT9005-433, RF5501-433, RF5108-433.
Installation
1. Select Operating Mode: Remove the cover by pressing on the end notch to ift top cover. Ensure that the jumpers 1, 2 and 3 are as fo ows:
2. Install Battery: Use care when insta ing the battery and observe the correct po arity (see Figure A). Use on y the Panasonic CR123A ithium battery.
3. Position Transmitter: Se ect the ocation where the WS4965 is to be mounted.
Note: RF signals can be affected by metal objects, including metal doors or large mirrors. Ensure that these types of objects are not located between
the device and the receiver as it can interfere with the proper operation of the WS4 65.
4. Enrolling, Programming and Placement: The three zones of the WS4965 have unique seria numbers. The 6 digit seria number ocated on
the device is for the reed or ti t switch zone. The seria numbers for the second and third zone (i.e. externa contacts inputs) is the seria number ocated on
WS4965 + 1 for Zone 2 and the seria number +2 for Zone 3 as indicated be ow.
Examp e: Seria number printed on the WS4965 is 211117.
Reed or Ti t switch zone - 211117
Zone 2 - 211118
Zone 3 - 211119
If the ast digit is a etter, use the fo owing sequence: A, B, C, D, E, F (A+1=B, A+2=C etc.)
The fo owing steps out ine the basic programming and enro ment of this device when used with PowerSeries receivers. For additiona options, or for
other receivers, refer to the specific receiver Installation Manual.
Step 1: Program E ectronic Seria Number (ESN) - Section [804], subsections [01] - [32]
[01] Zone 1 ... [32] Zone 32
Enter the 6 digit ESN ocated on the back of the device into the next avai ab e zone s ot.
For Examp e ESN: 211117
Step 2: Program Zone Definition - Section [001] - [004]
Define corresponding zone with appropriate zone type [Ex. De ay (01), Instant (03), etc.]
Step 3: Enab e Wire ess Zone Attribute - Section [101] - [132]
Turn Option [8] ON (wire ess zone attribute) in the corresponding zone attribute section
A wire ess devices must be tested for good signa strength from where they are
positioned.
Note: Test wireless device signal strength from the final mounting position.
Step 4: Modu e P acement Test - Section [904], subsections [01] - [32]
Create a transmission by moving the magnet away from the WS4965, or by activating
the ti t sensor.
The pane wi sound the siren and ight LED 1 or 3 to indicate the test resu t:
1 squawk of the siren (or keypad LED 1) indicates GOOD p acement
3 squawks of the siren (or keypad LED 3) indicates BAD p acement
If the transmitter tests BAD, move the transmitter and repeat the P acement Test unti 3 GOOD resu ts in a row are indicated.
• Dimensions: 75mmx43mmx25mm (2 15/16" x 1 11/16" x 1") • Operating Frequency: 433MHz
• Operating Temperature: -10 to 49ºC (14 to 120ºF) • Battery: Panasonic CR123A Lithium
• Operating Humidity: 5-93% RH • Battery Life: 5-8 years (Not tested by UL/ULC.)
• UL/ULC Listed for residentia use on y
eed Switch mode Tilt Switch mode
JP1 - IN (JP1 must a ways be IN) JP1 - IN (JP1 must a ways be IN)
JP2 - NA (No effect in Reed Switch operating mode) JP2 - IN (No de ay)
JP2 - OUT (1 minute de ay before sending an a arm)
JP3 - IN JP3 - OUT
[01] Zone #1 211117(Reed/Tit zone)
[02] Zone #2 211118(Externa contact zone)
[03] Zone #3 211119(Externa contact zone)
WS4965
TriZone Door/Window Contact Version 1.0
Installation Instructions
Z2 COM Z3
Z1
MAGNETIC
(1.27 CM)
+
-
MAGNETMAGNET
JP3 JP2 JP1
Figure A

5. Mounting the WS4965
Mounting the WS4965 in eed Switch Mode
• P ace the mounting bracket in the position determined in the Enro ing, Pro-
gramming P acement step. Secure the bracket to the door frame using the two
screws provided. See Figure B.
• “Snap” the sensor in p ace.
• To re ease bracket: Remove the front cover. Push the tab (see Figure B) with a
sma screwdriver and s ide the WS4965 down.
• A ign one end of the magnet with the notch on the side of WS4965 housing.
See Figure A.
• Mount the magnet a maximum of 1/2" (1.27cm) from the WS4965 using
the screws provided. If necessary use the spacers provided. See Figure C.
• Mount magnet: Open and c ose the door/window to ensure that there is no
interference.
Note: Only one magnet can be used for each WS4 65. The contact shall
be installed so that a door or window cannot be opened more than 2
inches (51 mm) without causing an alarm condition.
Mounting the WS4965 in Tilt Switch Mode
Remove Jumper 3 (JP3) for “ti t switch” operation.
For the ti t switch to be in the c osed position, mount the WS4965 in the vertica position, with the battery ocated on the bottom. Once the garage
door is open, the ti t switch wi activate and generate a transmission. See Figure D.
The WS4965 can be programmed to wait 1 minute after the ti t switch activates before it transmits the a arm. This is usefu for the garage doors
which require onger entry de ay time. To program this feature, remove Jumper 2 (JP2).
Notes: The reed switch is deactivated when using the tilt function.
By carefully moving the tilt switch up or down, the degree of motion required to cause an alarm can be adjusted.
Do not permanently mount the WS4 65 until the Placement Test has been successfully passed.
Note: This mode is not to be used in UL listed installations.
6. External Contacts: The WS4965 has 2 norma y c osed contact termina s. These can be used for additiona hardwired wired contacts or other dry con-
tact switches. Connect the externa devices to the contact termina s as per the manufacturers instructions. The maximum wire run from the externa con-
tacts must not exceed 25ft (7.6m).
Note:For UL Installation, the external contacts and WS4 65 must be in the same room.
7. Testing: Verify Sensor operation, Tamper operation and Supervisory Operation. Operation of these features is exp ained be ow.
WS4965 Operation:
•Tamper Switch: The WS4965 comes equipped with case tamper detection. If the cover is removed, the WS4965 wi report a zone tamper to the
contro pane . Upon tamper, a 3 seria numbers wi report a tamper transmission.
•Supervision: The WS4965 sends a periodic supervisory transmission to the pane . If the pane fai s to receive a transmission within the prepro-
grammed period (refer to receiver manua for supervisory window), it wi indicate a fau t on the keypad. A three seria numbers wi transmit a
separate supervisory signa to the receiver.
•Low-Battery LED Indicator: There is a ow-battery LED indicator on the WS4965. It wi f ash at 10 second interva s when a ow battery con-
dition is detected and transmitted to pane . This wi provide visua identification of the unit that requires a battery change.
•Battery eplacement: The WS4965 requires one CR123A ithium battery. To rep ace the battery, remove the cover by pressing on the end and
ifting it up. Use care when insta ing the battery and observe the correct po arity. Dispose of used battery promptly. Keep away from children. Do
not disassemble and do not dispose of in fire.
Caution: The battery used in this device may present a fire or chemica burn hazard if mistreated. Do not recharge, disassemb e, heat above
100°C (212°F) or dispose of in fire. Rep ace battery with Panasonic CR123A on y. Use of another battery may present a risk of fire or exp osion.
WARNING!: Battery may explode if mistreated. Do not recharge, disassem le or dispose of in fire.
FCC ID: F5305WS4965
This device complies with Part 5 of the FCC rules. Operation is subject to the following conditions: ( ) This device must not cause harmful
interference, and (2) must accept any interference received, including interference that may cause undesired operation.
IC: 60A-WS4965 - The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.
TILT SWITCH
MAKING
CONTACT
(Normally Closed)
TILT SWITCH
NOT MAKING
CONTACT
(Open)
Alarm Restore
Sho n ith NO Spacer Sho n WITH Spacer
Figure C Figure D
©2005 Digital Security Controls
Toronto, Canada • www.dsc.com
Technical Support:
1-800-387-3630 (Canada & US), 905-760-3036 Printed in Tai an
WS4965
(1.27 CM)
Tab
Push the tab
ith scre driver
Mounting Bracket
1/2” (1.27 CM)
MAX
MAGNETMAGNET
Figure B
29007111R002
