DSE DSE9462 User manual

TYPICAL WIRING DIAGRAM
WARNING!: Ensure the Remote Sensing Wires are connect to the
correct battery to prevent damage caused by overcharging.
DEEP SEA ELECTRONICS
DSE9462 Installation Instructions
053-189
ISSUE 1
DANGER OF DEATH: LIVE PARTS exist within the DSE9462 enclo
sure.
The enclosure cover must not be removed.
INSTALLATION
The battery charger is designed to be mounted within a control panel, utilising the
integral mounting holes. The battery charger is fit-and-forget. It may be
permanently connected to the supply and the load, with no requirement to disable
the charger during times of heavy load (such as engine cranking) or when in
parallel with a charging alternator.
BATTERY SUITABILITY
The charger is factory set by DSE to suit Lead Acid batteries and may be ordered
to suit other battery types. Additionally, configuration is possible using the DSE
Configuration Suite PC Software to suit other battery types.
Care must be taken to ensure the batteries connected to the charger are of the
correct ‘technology’ to suit the setting of the charger.
INDICATIONS
The DSE9462 Battery Charger features LED indicators to show the battery charger
Status.
Deep Sea Electronics Plc.
Tel:[phone]
Fax: [phone]
Email: [e-mail]
Web: www.deepseaplc.com
Deep Sea Electronics Inc.
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.deepseausa.com

SPECIFICATIONS
NOTE: This document is intended as a ‘quick start’ guide only. For full
operating instructions and specifications, refer to DSE publication:
057-255 DSE9462 Operator Manual.
Description
Specification
Connection Type Cage clamp terminals
Min Cable Size Accepted in Terminal
(Battery Connection) 0.08 mm² (AWG 28)
Max Cable Size Accepted in Terminal
(Battery Connection) 4.0 mm² (AWG 12)
Strip Length (Battery Connection) 8 mm to 9 mm
(0.31 “ to 0.35 “)
Min Cable Size Accepted in Terminal
(Other Connections) 0.08 mm² (AWG 28)
Max Cable Size Accepted in Terminal
(Other Connections) 2.0 mm² (AWG 14)
Strip Length (Other Connections) 7 mm to 8 mm
(0.28 “ to 0.31 “)
Recommended AC Fuse
230 V AC Input
110 V AC Input
10 A anti-surge 10 A anti-surge
MAINS SUPPLY CABLE
Connection
Cable Colour
L1 Brown
Neutral Blue
Earth Green and Yellow
STATUS LEDS
Each output has its own dedicated LED to show charge status.
Status 1: Charge status of Output 1.
Status 2: Charge status of Output 2.
Condition
Status LED
Output Not Charging (Due to Fault or Charger Off) Off
Battery Detection Mode Green Constant
Bulk (Boost) Charge in Progress Yellow Constant
Absorption Charge in Progress Yellow Flashing
Float Charge in Progress Green Constant
Storage Charge in Progress Green Flashing
FAULT LEDS
Two Fault LEDs, Fault 1 and Fault 2 are used to indicate faults. Output 1 and
Output 2 share these indications. Where two alarms are present at the same time,
the most critical is displayed.
Condition
LED
Fault 1
Fault 2
DC Over Volts Warning and Trip
DC Under Volts Warning
Battery Detection Warning
DC Over Current
Battery Reverse Polarity
Short Circuit Protection
Battery Detection Warning
Red Constant Off
Input Fuse Failure
AC Under Voltage Warning and Trip
AC Over Volts Warning and Trip
DC Over Current Warning
Cable Voltage Drop Alarm
Red Flashing Off
Battery Over Temperature Warning and Trip
Battery Temperature Sensor (PT1000) Fail
Ambient Over Temperature Off Red Constant
Battery Charger Failure Red Constant Red Constant
Battery Detection Mode - Battery Not Detected Red Flashing Red Flashing
DIMENSIONS AND MOUNTING
NOTE: The DSE battery charger is designed to be mounted with the
base to a vertical surface with the connection terminals at the bottom.
Description
Dimension
Case Dimensions 162 mm x 291 mm x 74 mm
(6.4 ” x 11.5 ” x 2.9”)
Mounting Holes Dimensions Suitable for M5
(0.2 ” diameter)
Mounting Hole Spacing 95 mm x 279 mm
(3.7 ” x 11.0 ”)
Required Ventilation Spacing 100 mm (3.9 ”) air space around the battery charger.
