DSE DSE9473 User manual

NOTE: The DSE9473 & DSE9483 chargers are
designed to be mounted
the base to a vertical surface with the terminal strips at the bottom.
NOTE
: This document is intended as a ‘quick start’ guide only. For full
operating instructions and specifications, refer to DSE publication:
057-085 DSE9xxx Operator Manual.
DEEP SE A ELECTRONICS
DSE9473 & DSE9483
Installation Instructions
DANGER OF DEATH: LIVE PARTS exist within the DSE9
473 & DSE9483
enclosures. The enclosure cover must not be removed.
INSTALLATION
The DSE9473 & DSE9483 battery chargers are
designed to be mounted within a
control panel, utilising the integral
mounting holes. The DSE9473 & DSE9483
battery chargers are fit-and-forget. It may
be permanently connected to the supply
and the load, with no requirement to disable the charger during times of heavy
load (such as engine cranking) or when in parallel with a charging alternator.
BATTERY SUITABILITY
The chargers are factory set by DSE
to suit Lead Acid batteries and may be
ordered to suit other battery types. Additionally, configuration is possible using the
DSE Configuraiton Suite PC Software
to suit other battery types.
Care must
be taken to ensure the batteries connected to the charg
correct ‘technology’ to suit the setting of the charger.
INDICATIONS
The DSE9473 & DSE9483 Battery Chargers
feature LED indicato
battery charger status.
DIMENSIONS AND MOUNTING
Case Dimensions 205 mm x 135 mm x 80 mm
(8.0 ” x 5.3 ” x 3.1 ”)
Mounting Holes
Dimensions Suitable for M4 (0.2 ” diameter)
Mounting Hole Spacings 190 mm x 120 mm
(7.5 ” x 4.7 ”)
designed to be mounted
with
the base to a vertical surface with the terminal strips at the bottom.
: This document is intended as a ‘quick start’ guide only. For full
operating instructions and specifications, refer to DSE publication:
Installation Instructions
053-185
ISSUE 1
473 & DSE9483
designed to be mounted within a
mounting holes. The DSE9473 & DSE9483
be permanently connected to the supply
and the load, with no requirement to disable the charger during times of heavy
load (such as engine cranking) or when in parallel with a charging alternator.
to suit Lead Acid batteries and may be
ordered to suit other battery types. Additionally, configuration is possible using the
to suit other battery types.
be taken to ensure the batteries connected to the charg
er are of the
feature LED indicato
rs to show the

TYPICAL CONNECTION DIAGRAM
Connection Type Screw terminal, rising clamp, no internal spring
Min Cable Size (AC Supply) 2.0 mm² (AWG 15)
Min Cable Size (Charge Output) 1.0 mm² (AWG 18)
Min Cable Size (All Other Connections) 0.5 mm² (AWG 20)
Max Cable Size (AC Supply) 3.3 mm² (AWG 12)
Max Cable Size (All Other Connections) 2.5 mm² (AWG 14)
Recommended AC Fuse
230 V AC Input
110 V AC Input
DSE9473 3.5 A anti-surge 6.3 A anti-surge
Recommended AC Fuse
230 V AC Input
110 V AC Input
DSE9483 2.0 A anti-surge 3.5 A anti-surge
